STORAGEGEAR STFS12 User manual

Model: STFS12
Floating Shelf Instruction Manual V2.0
Thank you for choosing this STORAGEGEAR product! At STORAGEGEAR we
strive to provide you with the best quality products and services in the
industry. Should you have any issues, please don't hesitate to contact us at
[email protected].

• Check package contents against supplied parts and hardware list to assure that all
components were received undamaged. Do not use damaged or defective parts. lf you
require replacement parts, please contact amada customer service at
[email protected].
• Carefully read all instructions before attempting installation. If you do not understand the
instructions or have any concerns or questions, please contact customer service at
[email protected].
• Not all parts and hardware included will be used.
• Do not use this product for any purpose that is not explicitly specified in this manual. Do
not exceed weight capacity. We cannot be liable for damage or injury caused by improper
mounting, incorrect assembly or inappropriate use. Thank you for your understanding.
IMPORTANT SAFETY INFORMATION
Tools Needed (Not lncluded)
Stud Finder Pencil Screwdriver
Level Drill 5/64 in.(2mm)
Wood Drill
15/64 in.(6mm)
Concrete Drill
Supplied Parts and Hardware
Wall Anchor
M13x42mm
x12
F
CAUTION!
These wall anchors [F]
are for drywall ONLY.
DO NOT use them in
concrete / brick / wood
studs wall.
CAUTION!
These anchors are for
concrete or brick
walls ONLY. DO NOT
use them in drywall
or wood studs.
x12
G
Wall Anchor
M6x30mm
Hammer
Long Lag Screw
M4x50mm
(C) x12
Short Lag Screw
M4x30mm
(D) x12
Screw
M4x15mm
(E) x18
(A) x3
(B) x6
01 02 03 04 05 06

Before installation, please identify your wall type.
For wood stud installation, follow the step 1A.
For drywall installation, follow the step 1B.
For solid concrete and concrete block walls installation, follow the step 1C
Step 1 Secure Metal Brackets to Wall
Step 1A For Wood Stud
For wood stud mounting, wall
anchors [F] and [G] are not
necessary.
WARNING:
XX
F G
01 02 03 04 05 06

C
D
[Not Included] (For wood stud only!)
[Optional]
2 in.(50mm)
For Lag Screw [C]
ø5/64 in.(ø2mm)
Step 1B For Drywall
01 02 03 04 05 06
F

Step 1C For Solid Concrete and Concrete Block Walls
F
D
01 02 03 04 05 06

G
15/64 in.(ø6mm)
2 11/64 in.(55mm)
01 02 03 04 05 06

C
Step 2 Secure the Floating Shelf to Wall
G
E
01 02 03 04 05 06

Thank you again for
choosing this STORAGEGEAR product!
All of us at STORAGEGEAR do appreciate your product purchase. We hope that
you are as happy with your product as we are designing and manufacturing it
for you. We strive to provide you with the best quality products and services in
the industry. Should you have any issues, please don't hesitate to contact us at
[email protected] (US/CA)
