StormPro SP50 User manual

NOTE! To the installer: Please make sure you
provide this manual to the owner of the pumping
equip ment or to the responsible party who
maintains the system.
General Information
Thank you for purchasing your StormPro™ pump.
To help ensure years of trouble-free op er a tion,
please read the fol low ing manual carefully.
Before Operation:
Read the following in struc tions care ful ly.
Reasonable care and safe meth ods should be
practiced. Check local codes and requirements
before installation. Only qualied electricians
should make the installations.
Attention:
This manual contains important information for
the safe use of this product. Read this manual
completely before using this product and refer to
it often for con tin ued safe product use. DO NOT
THROW AWAY OR LOSE THIS MAN U AL. Keep it
in a safe place so that you may refer to it often.
Servicing should be performed only by a
knowledgeable pump service contractor or
authorized service stations.
WARNING: Before handling these pumps and
controls, always disconnect the power rst. Do
not smoke or use sparkable electrical devices
or ames in a septic (gaseous) or possible
septic sump.
Pump Warning
To reduce risk of electrical shock:
1. Risk of Electrical Shock: This pump has not
been in ves ti gat ed for use in swimming pool &
marine areas.
2. Risk of Electrical Shock: Connect only to a
properly ground ed receptacle.
Septic tank is to be vented in ac cor dance with local
plumbing codes.
Do not smoke or use sparkable electrical devices
or ame in a septic (gaseous) or possible septic
sump.
If it is necessary to enter sump, then (1) provide
proper safety precautions per OSHA re quire ments
and (2) do not enter sump until these precautions
are strictly adhered to.
Do not install pump in location clas si ed as
hazardous per NEC, ANSI/NFPA 70-2001.
Failure to heed above cautions could result in
injury or death.
Installation Instructions
These important instructions must be followed for
satisfactory performance of your pump:
1. Provide proper sump (recommended minimum
sump diameter is 18").
2. Do not set pump directly on the bottom of
the sump if it is not solid. Raise the pump by
placing bricks or concrete blocks underneath it.
,RQ_6WRUP3UR

SP50OS50
Submersible Efuent Pump

OPERATION MANUAL
Dated: 08/04/10
Supersedes: None
Document No.: 23833A669 Page 1 of 4

3. Make sure sump is free of string, cloth, nails,
gravel, etc. before installing pump.
4. Pump is to be connected to a properly
grounded, grounding type receptacle only.
5. Do not remove ground pin from electrical plug.
6. Do not use an extension cord.
7. Connect to separate electrical circuit taken
directly from main switch.
8. Use steel or plastic pipe for all connecting lines
between pump and sewer outlet.
Note: Some city regulations do not allow
installing a pump with plastic pipe. Check local
regulations.
9. In applications where the pump may sit idle
for months at a time, it is recommended that
the pump(s) be cycled every month to ensure
the pumping system is working properly when
needed.
10. A check valve should be installed in discharge
pipe at least 12" above the discharge outlet of
the pump.
11. For greater protection, an audible alarm should
be used with all pump installations to indicate a
high water condition exists.
,RQ_6WRUP3UR

SP50OS50
Submersible Efuent Pump

OPERATION MANUAL
Dated: 08/04/10
Supersedes: None
Document No.: 23833A669 Page 2 of 4

Performance
Pump Notes
TOTAL DYNAMIC HEAD-FEET
0
16
8
24
32
010 20 30 40 50 60
CAPACITY–U.S. G.P.M.
1/2 HP
,RQ_6WRUP3UR

SP50OS50
Submersible Efuent Pump

OPERATION MANUAL
Dated: 08/04/10
Supersedes: None
Document No.: 23833A669 Page 3 of 4

Limited Warranty
StormPro™ warrants to the original consumer purchaser (“Purchaser” or “You”) of StormPro products
that they will be free from defects in material and workmanship for the Warranty Period of 36 months from date
of manufacture.
Our warranty will not apply to any product, that, in our sole judgment, has been subject to negligence,
misapplication, improper installation, or improper maintenance. Without limiting the foregoing, operating a three
phase motor with single phase power through a phase converter will void the warranty. Note also that three
phase motors must be protected by three-leg, ambient compensated, extra-quick trip overload relays of the
recommended size or the warranty is void.
Your only remedy, and StormPro's only duty, is that StormPro repair or replace defective products (at StormPro
choice). You must pay all labor and shipping charges associated with this warranty and must request warranty
service through the installing dealer as soon as a problem is discovered. No request for service will be accepted
if received after the Warranty Period has expired. This warranty is non-transferable.
STORMPRO SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL, INCIDENTAL, OR CONTINGENT
DAMAGES WHATSOEVER.
THE FOREGOING WARRANTIES ARE EXCLUSIVE AND IN LIEU OF ALL OTHER EXPRESS AND IMPLIED
WARRANTIES, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE. THE FOREGOING WARRANTIES SHALL NOT EXTEND
BEYOND THE DURATION EXPRESSLY PROVIDED HEREIN.
Some states do not allow the exclusion or limitation of incidental or consequential damages or limitations on the
duration of an implied warranty, so the above limitations or exclusions may not apply to You. This warranty gives
you specic legal rights and You may also have other rights which may vary from state to state.
This warranty supersedes and replaces all previous warranty publications.
StormPro™
37 Forestwood Drive
Romeoville, IL 60446-1343
1-815-886-9200
stormpropumps.com
,RQ_6WRUP3UR

SP50OS50
Submersible Efuent Pump

OPERATION MANUAL
Dated: 08/04/10
Supersedes: None
Document No.: 23833A669 Page 4 of 4
