STOVES ST INTDW45 User manual

Instruction ManualInstruction Manual
DishwasherDishwasher
10 place settings
Alt function
Auto program
ST INTDW45

To review the sect ion on troubleshooting Tips
will help you to solve some common problems
by yourself .
Dear Customer,
Please carefully read this manual before using the
dishwasher, it will help you to use and maintain the
dishwasher properly.
Pass it on to any subsequent owner of the appliance.
This manual contains sections on safety Instructions,
Operating Instructions, Installation Instructions and
Troubleshooting Tips, etc.
The manufacturer, following a policy of constant
development and updating of the product, may
make modifications without giving prior notice.
This user manual shall also be got from the
manufacturer or responsible vendor.
Keep it as a refer in the later days.
If you can not solve the problems by yourself ,
please ask for the help of professional technicians.
Dishwasher Feat ures. ... ...... ...... ...... .............. ...6
A Water S often er.. ........ ... ......... ... ...... ..... ....... 7、
Attention b efore or after loading the Di shwasher
Basket s... ...... ............... ...... ... ... ........ ............ 12
Filtering System.............................................16
Caring for the Dishwasher..................... .........17.
B Loading the Salt into the Softener.................8、
C Fill the Rinse A id Dispenser................. ........8、
D Function of Detergent ............... ..................9、
Lo ading t he uppe r ........ ... ...... ..... .... .....1 3Ba sket
Lo ading the Low er .............. .................13Ba sket
Wash Cycle Table................................... ........14
Turning on th e Ap pliance ...... . .. ... ............ ... ..... 1 4
Change the Programme.............. ................15....
At the end of the Wash Cycle...........................15
Befor e calling for service.......................... . .....25.
Erro r cod es....... ... ... ...... .. .... ... ...... . . ... ...... ... ..26.
Techn ica l in formation............. ...... ...... ... .. .....2 7..
Co ntrol Panel. ...... ... ...... ... ......... ... ... ......... ...... ..6
.................................. 18Installation preparation
...19Aesthetic panel's dimensions and install ation
.... ..........21Tension adjustm ent of the door spring
.............................. 21Connection of drain hoses
......................... 22Dishwasher installation steps
Abo ut Electrici ty Connecting................. ...... ....23
Co ld Wate r Connection..... .............. ...... ......... 24

1
This appliance is intended to be used in household
and similar applications such as:
-staff kitchen areas in shops, offices and other
working environments;
-farm houses;
-by clients in hotels, motels and other residential type
environments;
-bed and breakfast type environments.
This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision
or instruction concerning use of the appliance in a
safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children
without supervision. For EN60335-1
This appliance is not intended for use by persons
(including children )with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge ,unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety. For IEC60335-1
This appliance is for indoor use only, for household
use only.
To protect against the risk of electrical shock, do not
immerse the unit, cord or plug in water or other liquid.
Please unplug before cleaning and maintenance the
appliance .
Use a soft cloth moisten with mild soap, and then use
a dry cloth to wipe it again.
（ ）
（ ）
When using your dishwasher,
follow the precautions listed below:

2
This appliance must be earthed. In the event of a
malfunction or breakdown, earthing will reduce the risk
of anelectric shock by providing a path of least
resistance of electric current. This appliance is equipped
with a cord having an equipment-earthing conductor
and a grounding plug.
The plug must be plugged into an appropriate outlet that
is installed and earthed in accordance with all local
codes and ordinances.
Improper connection of the equipment-earthing
conductor can result in the risk of an electric shock.
Check with a qualified electrician or service
representative if you are in doubt whether the appliance
is properly grounded.
Do not modify the plug provided with the appliance;
If it does not fit the outlet.
Have a proper outlet installed by a qualified electrician.
Do not abuse, sit on, or stand on the door or dish rack of
the dishwasher.
Do not operate your dishwasher unless all enclosure
panels are properly in place.
Open the door very carefully if the dishwasher is
operating, there is a risk of water squirting out.
Do not place any heavy objects on or stand on the door
when it is open. The appliance could tip forward.
When loading items to be washed:
1) Locate sharp items so that they are not likely to
damage the door seal;

3
2) Warning: Knives and other utensils with sharp points
must be loaded in the basket with their points down or
placed in a horizontal position.
Check that the detergent powder is empty after
completion of the wash cycle.
Do not wash plastic items unless they are marked
dishwasher safe or the equivalent.
For plastic items not so marked, check the manufacturer's
recommendations.
Use only detergent and rinse additives designed for
an automatic dishwasher.
Never use soap, laundry detergent, or hand washing
detergent in your dishwasher.
Children should be supervised to ensure that they do not
play with the appliance.
The door should not be left open, since this could increase
the risk of tripping.
If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified
person in order to avoid a hazard.
During installation, the power supply must not be
excessively or dangerously bent or flattened.
Do not tamper with controls.
The appliance is to be connected to the water mains using
new hose sets and that old hose-sets should not be reused.
The maximum number of place settings to be washed
is 10.
The maximum permissible inlet water pressure is 1MPa.
The minimum permissible inlet water pressure is 0.04MPa.

Dispose of the dishwasher packaging material
correctly.
All packaging materials can be recycled.
Plastic parts are marked with the standard
international abbreviations:
PE for polyethylene, e.g. sheet wrapping material
PS for polystyrene, e.g. padding material
POM polyoxymethylene, e.g. plastic clips
PP polypropylene, e.g. Salt filler
ABS Acrylonitrile Butadiene Styrene, e.g. Control
Panel .
Packaging material could be dangerous for children!
For disposing of package and the appliance please
go to a recycling centre. Therefore cut off the power
supply cable and make the door closing device
unusable.
Cardboard packaging is manufactured from recycled
paper and should be disposed in the waste paper
collection for recycling.
By ensuring this product is disposed of correctly, you
will help prevent potential negative consequences
for the environment and human health, which could
otherwise be caused by inappropriate waste handling
of this product.
For more detailed information about recycling of this
product, please contact your local city office and your
household waste disposal service.
DISPOSAL: Do not dispose this product as unsorted
municipal waste. Collection of such waste separately
for special treatment is necessary.
4

With each wash cycle.
Compartment
For programmes with pre-wash only.
(Follow the user instructions!)
Electric indicator on control panel (if provided).
Check the rinse aid level
(On models with water softener system only.)
Electric indicator on control panel (if provided).
If there is no salt warning light in the control panel
(for some models), you can estimate when to fill the salt into
the softener by the number of cycles the dishwasher has run.
Check the regeneration
salt level
Load the baskets
Select a programme
Turn on the water tap ,close the door . The machine will start working after about 10 seconds.Running the dishwasher
Switch off the appliance
Turn off the water tap,
unload the baskets
Fill the detergent dispenser
Warning: wait a few minutes ( about 15 minutes) before unloading the d ishwasher to avoid handling
the dishes and utensils while they are still hot and more susceptible to break.
They will also dry better.Unload the appliance, starting from the lower b asket.
Changing the programme
Add forgotten dishe s in the
dishwasher.
Scrape off any large amount of leftover food. Soften remnants of burnt food in pans,
then load the baskets. Refer to the dishwasher loading instructions.
Press the Programme Button until the selected programme lights up.
( See the section entitled Operation instruction )“ ”
When the working cycle has finished, the buzzer of the
dishwasher will soun d 8 times, then stop .
Turn off the appliance using the On/Off Button.
If the app liance is sw itched
off during a wash cycle.
Open the door care f ully.
Hot steam may esc ap e
when the doo r is op ened!
If the app liance is sw itched off during a w ash cycle, when switched
on again, please re-select the washing cycle and o perate the dishwasher
according to the original Power-on state ).
Switch on the appliance Open the door,press the On/Off button to switch on the appliance .
1.Open the door a little to stop the dishwasher.
2.After the spray arms stop working, you can open the door completely.
3.Add the forgotten dishes.
4.Close the door, the dishwasher will start running again after 10 seconds.
For detailed operating method read the corresponding content on the instruction manual.
1. A running cycle can only be modified if it has been running for a shor t time. Otherwise the detergent
may have already been released and the water already drained. If this is the case, the detergent
dispenser must be refilled.
2. Open the door.
3. Press the for mo re than 3 seconds to cancel the running programme.
4. Select a new programme.
5. Restart the dishwasher.
Programme Button
5

6
before usin g it for the first time.
To get the best performance from your dishwashe r, read all operatin g instructions
11 12
Back View
1
2
3
4
5
7
8
910
Front view
Lower basket
Salt container
Dispenser
Cup shelf
Spray arms
Filter assembly
Inlet pipe connector
Drain pip e
Upper basket
Cutlery rack
Top spray arm
1Inner pipe
5
6
7
8
9
10
12
11
3
2
4
6
1.On/Off Button: To turn on/off the power supply.
2.Delay Button : To Press the button to delay.
6. Program Button : To Press the button to select a
wash Program.
3.Option Button: to press this button to select a express
or extra drying
Alt Button: Dual zone wash function, press the
button to se lect either upper basket or lower basket
loaded.
4. Display screen: to show t he error code,delay time etc.
Program indicators:
Rinse Aid indicator,Add salt indicator:
Indicates when the dispenser needs to be refilled.
Option Indicator:
Delay time or error codes indicator:
Alt functions indicator:
In fall Warning L ig ht :
Being on When faucets is not opened.
5.
(Express) (Extra drying)
Express ca n be use when choose All in 1 Intensive
Normal Eco Glass 90 Min.
Extra drying can be use when choose All in 1 Intensive
Normal ECO Glass 90 Min.
S alt
Rin se
Aid
Aid

The water softener must be set manually, using the water hardness dial.
The water softener is designed to remove minerals and salts from the water, which would have
a detrimental or adverse effect on the operation of the appliance.
The higher the content of these minerals and salts, the harder your water is.
The softener should be adjusted according to the hardness of the water in your area. Your local Water Authority
can advise you on the hardness of the water in your area.
Adjusting Salt Consumption
The dishwasher is designed to allow for adjustment in the amount of salt consumed based on the hardness of
the water used. This is intended to optimise and customise the level o f salt consumption.
1. Open the door ,Switch on the appliance;
2. Press the Program button for more than 5 seconds to start the water softener
set model within 60seconds after the appliance was switched on( The Salt and
Rinse aid warninglights will be on periodically when it get in the set model );
3. Press the Program button to select the proper set according to your local environment,
the sets will change in the following sequence: H4 H5 H6 H1 H2 H3;
4. Press the Power button to end the set up model.
→ → → → →
WATER SOFTENER
The hardness of the water varies from place to place. If hard water is used in the dishwasher, deposits will
form on the dishes and utensils.
The appliance is equipped with a special softener that uses a salt container specifically designed to eliminate
lime and minerals from the water.
Contact your local water board for information on the hardness of your water supply.
Please follow the steps below for adjustment in salt consumption.
7
If your model do es not hav e any wa ter s oftener, y ou m ay sk ip this se ction.
C lar k: British de gr ee
fH : Fr ench degree
D H: G er man degree
dH=1.25 Cla rk e=1. 78 fH=0.1 78mm ol/l
1
Th e ma nuf acto ry se tt ing: H3 (EN 50 242)
Before using your dishwasher for the first time:
A. Set the water softener
B. Add 1.5Kg dishwasher salt and then full fill the salt container with water
C. Fill the rinse aid dispenser
D. Fill in detergent
dH mmol /l
0~90~5 0~0.94 H1 0
10-20 6-11 1.0- 2.0 H2 9
21-30
12-17 2.1-3. 0 H3 12
H4 20
fH
0~6
7-14
15-21
Clarke
WATE R HARDNES S
Selec tor Po si ti on Salt con sumption
(gram/cycle)
18-22 31-40 22-28 3. 1-4.0
41-6023-34 4.1- 6.0 H5 30
H6 60
29-42
35-55 61-98 43-69 6. 1-9.8

1. The salt container must only be refilled when the salt warning light in the control panel comes on.
Depending on how well the salt dissolves, the salt warning light may still be on even though the
salt container is filled.
If there is no salt warning light in the control panel (for some Models),you can estimate when to fill
the salt into the softener by the cycles that the dishwasher has run.
2. If there are spills of the salt, a soak or a rapid program should be run to remove the excessive salt.
Always use th e salt intended f or use with dis hwash er.
The salt con tai ner is loca ted be neath the low er baske t an d sho uld be fil led as explaine d
in the fo llowin g:
Attention!
Only u se sa lt spe cific ally design ed for the u se in dishw ashe rs! Ev ery oth er t ype o f
salt n ot sp ecifically desi gne d for th e use in a dishwasher, es pecia lly ta ble salt, will
damage the water so ftener. In c ase o f dama ges ca used by the u se of unsu itable
salt the m anu factur er doe s no t give any wa rran ty nor is lia ble f or a ny d ama ges caus ed.
Only f ill with s alt just befor e start ing o ne o f th e com plete wa shin g program s.
This will pr eve nt any gr ains of salt or salt y water, wh ich may ha ve been spilled,
rem ain ing on th e bo tto m of the m achine for any p eriod o f tim e, which may cause
cor rosion.
8
Ful l fill t he s alt c onta iner wit h wa ter,I t i s normal fo r a s mall amou nt o f water to come out o f t he
salt con ta iner.
AAfte r the low er basket ha s be en r emo ved , u nscrew an d re move the cap from the salt co nt ainer.
BP lace the end of the fu nnel (su pplied) into the h ole an d int ro duc e ab out 1.5k g of dishwas her sa lt.
C
DA fter filling the container , sc re w th e ca p tight ly bac k clockw is e.
EThe salt w arni ng li ght will stop being a fter the sal t cont aine r h as b een filled with salt.
FImmediately a fter fill in g the sal t i nt o t he s alt c ont ainer, a wash in g pr ogram sho ul d be star te d
program Otherwise the fi lter sy stem, pump or o ther imp or tant parts of th e machine may b e da mage d
by s al ty w ater. Thi s is out of w arrant y.
(We suggest t o u se a sho rt
) .

9
To open the dispenser, turn the cap t o t he "op en" (left) arrow and li ft it out.
Pour the rinse aid into the dispenser, being careful not to over fi ll .
Replace the cap by inser ting i t ali gned w it h "open" arrow and t urning it t o t he clo sed (ri ght) a rrow.
Adjusting Rinse Aid Dispenser
The rinse ai d dispenser has s ix or four settings. Alway s start with the dispenser
set on "4". If s pots and poor dryi ng are a problem , incre ase the amount of rinse
aid dispensed by r emoving th e d ispenser lid and ro tat in g the di al t o "5". If the
dis hes stil l are not d ryi ng properly or are show s pots, adjust the di al to the next
hig her le ver un ti l y our di she s a re spo t- fr ee. Th e r eco mme nd ed set ting is " 4".
(Fac tor y value is " 4".)
In cre a se the do se if the re ar e d rops o f wate r or l ime sp ots on t he dishes af te r washi ng.
Reduce i t i f there are stic ky whitish stains on your dish es or a bluish film on gl asswa re or
kni fe bl ade s.
1
2
3
As the rinse aid diminishes, the size of the black dot
on the rinse aid level indicator changes, as illustrated below.
Full
3 / 4 full
1 / 2 full
1 / 4 full - Should refill to eliminate spotting
Empty
When to Refill the Rinse Aid Dispenser
If there is no rinse-aid warning light in the control panel, you can estim ate the amount from the colour
of the optica l level indica tor C located next to the cap. When the rinse-aid container is full, the whole
indicator will be dark .As the rinse-aid diminishes, the size of the dark dot decreases. You should never let
the rinse aid level fall 1 / 4 full.
during the next wash. Don't forget to replace the cap before you close dishwasher door.
Clean up any rinse aid spilled while during filling with an absorbent cloth to avoid excessive foaming
" "
The ri ns e ai d i s r elea sed during th e fi nal ri nse t o pr ev ent water f rom f ormi ng dr ople ts o n yo ur dish es, w hich ca n
lea ve spo t s and str eaks. It al so i mpr ov es dryin g by al lo wing wat er to rol l o ff t he di shes . Your di sh washer is
de sig ned t o u se liq uid ri n se ai ds. The r inse aid dispenser is l ocated in side the do or next to the d ete rgent di spenser.
To fill the dispenser, open the cap and pour the r inse a id int o t he dispenser until the level indicat or turns compl etely
bl a ck. Th e vo l ume of the ri nse a i d cont ainer is abo ut 110ml.
Rinse Aid Dispenser
Function of Rinse Aid
Ri nse aid is aut omati cally added duri ng the last r inse, ensuring thor ough rins ing, and spot and streak f ree drying.
Attention!
Onl y u se br ande d ri n se aid for d ish washer. N ever fi ll the rinse aid d i spenser with any o the r subs tances
(e.g. Dis hwasher cleaning agent, liquid detergent). Thi s would damage t he appli ance.

10
Based on their chemical composition, detergents can be split in two basic types:
Detergent tablets of different brands dissolve at different speeds. For this reason some Detergent tablets cannot
dissolve and develop their full cleaning power during short programs. Therefore please use lo ng programs when using
detergent tablets, to ensure the complete removal of detergent residuals.
The dispenser must be refilled before the start of each wash cycle following the instructions
provided in the wash cycle table . Your dishwasher uses less detergent and rinse aid than
Conventional dishwasher. Generally, only one tablespoon of detergent is needed for
a normal wash load. More heavily soiled items need more detergent. Always add the
detergent just before starting the dishwasher, otherwise it could get damp and will not
dissolve properly.
Concentrated Detergent
Detergent Tablets
Detergent Dispenser
conventional, alkaline detergents with caustic components
low alkaline concentrated detergents with natural enzymes
Normally new pulverised detergent is without phosphate. Thus the water softener function of
phosphate is not given. In this case we recommend to fill salt in the salt container even when
the hardness of water is only 6 dH. If detergents without phosphate are used in the case of hard water
often white spots appear on dishes and glasses. In this case please add more detergent to reach
better results. Detergents without chlorine do only bleach a little. Strong and coloured spots will not
be removed completely. In this case please choose a program with a higher temperature.
°
Detergents
There are 3 sorts of detergents
1.With phosphate and with chlorine
2.Wi th phosp hate and without chlorine
3.Without phosphate and without chlorine
Proper Use of Detergent
Use only detergent specifically made for the use in dishwashers. Keep your detergent fresh and dry.
Don't put powdered detergent into the dispenser until you're ready to wash dishes.
Detergents wi th its c hemical ingredients are nec essary to remove dirt, cr ush dirt and tr ans port it out of the dishwas her.
Mo st o f th e c ommerci al q ualit y det erg ents a re sui ta ble f or this p urp ose.
Attention!

11
You find information about the amount of detergent for the single programme on the last page.
Please aware, that according to the level soiling and the specif ic hardness of water differences are possible.
Please observe the manufacturer's recommendations on the detergent packaging.
Always add the detergent just before starting each wash cycle.
Only use branded detergent aid for dishwasher.
If the lid is closed: press release button. The lid will spring open.
Amount of Detergent to Use
Fill the detergent dispenser with detergent.
The marking indicates the dosing levels , as
illustrated on the right:
Please observe the manufacturers dosing and storage
Recommendations as stated on the detergent packaging.
Close the lid and press until it locks in place.
If the dishes are heavily soiled, place an additional
detergent dose in the pre-wash detergent chamber. This detergent will take effect during the pre-wash phase.
For main wash detergent
For pre-wash detergent
A
B
Fill in Detergent
Dishwasher detergent is corrosive!
Take care to keep it out of reach of children.

Cutlery with wooden, horn china or
mother-of-pearl handles
Plastic items that are not heat resistant
Older cutlery with glued parts that are not
temperature resistant
Bonded cutlery items or dishes
Pewter or cooper items
Crystal glass
Steel items subject to rusting
Wooden platters
Items made from synthetic fibres
Some types of glasses can become
dull after a large number of washes
Silver and aluminum parts have a
tendency to discolour during washing
Glazed patterns may fade if machine
washed frequently
Are not suitable Are of limited suitability
Dishes and items of cutlery must not lie inside one another, or cover each other.
To avoid damage to glasses, they must not touch.
Load la rge items which are most difficult to clean into the lower basket.
The upper basket is designed to hold more delicate and lig hter dishware such as glasses, coffee
and tea cups
Long bladed knive s stored in an upright position are a potential hazard!
Long and/or sharp items of cutlery such as carving knives must be positioned
horizontally in the upper basket.
Please do not overload your dishwasher. This is important for good results and for
reasonable consumption of energy.
Load hollow items such as cups, glasses, pans etc. With the opening facing downwards so that
water cannot collect in the container or a deep base.
Consider buying utensils which are identified as dishwasher-proof.
Use a mild detergent that is described as 'kind to dish es'. If necessary, seek further
information from the detergent manufacturers.
For particular items, select a program with as low a temperature as possible.
To prevent damage, do not take glass and cutlery out of the dishwasher immediately
after the programme has ended.
(For best performance of the dishwasher, follow these loading guidelines.
Features and appearance of baskets and cutlery baskets may va ry from your model.)
Scrape off any large amounts of leftover food. Soften remnants of burnt food in pans.
It is not necessary to rinse the dishes under running water.
Place objects in the dishwasher in following way:
1.Items such as cups, glasses, pots/pans, etc. are faced downwards.
2.Curved items, or ones with recesses, should be loaded aslant so that water can run off.
3.All utensils are stacked securely and can not tip over.
4.All utensils are placed in the way that the spray arms can rotate freely during washing.
Very small items should not be washed in the dishwasher as they could easily fall out of the basket.
To prevent water dripping from the upper basket into the lower basket, we recommend that you
empty the lower basket first and then the upper basket.
12

13
The upper basket is designed to hold more delicate
and lighter dishware such as glasse s, coffee and
tea cups and saucers, as well as plates, sm all bowls
and shallow pans (as long as they are not too dirty).
Position the dishes and cookware so that they will
not get moved by the spray of water.
We suggest that you place large items and the most
difficult to clean items are to be placed into the lower
basket: such as pots, pans, lids, serving dishes and
bowls, as shown in the figure belo w. It is preferable to
place serving dishes and lids on the side of the racks
in order to avoid blocking the rotation of the top spray
arm.
Pots, serving bowls, etc, must always be placed top down.
Deep pots should be slanted to allow water to flow out.
Please be reminded that:
The Bottom Basket features folding spikes so that larger or more pots and pans can be loaded.
Fo lding Sp ikes of Lower Basket
For better stacking of pots and pans,
the spike s can be folded down as
show in the picture right.
Adjusting the Upper Basket
The height of the upper basket can be adjusted in order to
create more space for large utensils both for the upper
/lower basket. The height of the upper basket can be
adjusted by placing the wheels on different height of the
rails. Long items, serving cutlery, salad servers and knives
should be placed on the shelf so that they do not obstruct
the rotation of the spray arms..
Fo lding back the cup shelives
For better stacking of pots and pans,
the spikes can be folded down as
show in the picture right.
Cutlery should be placed in the cutlery rack separately from each other in the appropriate positions, and do
make sure the utensils do not nest together, this may cause bad performance.
Do not let any item extend through the bottom.
Always load sharp utensils with the sharp
point down!

*EN 50242 : This programme is the test cycle. The information for comparability test
in accordance with EN 50242, as follows:
Capacity: 10 setting
Position Upper basket: upper wheels on rails
Rinse aid setting: 6
Pl:0.49w; Po:0.45w.
Starting a cycle wash
Draw out the lower and upper basket, load the dishes and push them back.
It is commended to load the lower basket first, then the upper one (see the section entitled
Loading the Dishwasher ).
Pour in the detergent (see the section entitled Salt, Detergent and Rinse Aid ).
Insert the plug into the socket. The power supply is 220-240 VAC /50 HZ, the specification
of the socket is 10A 250VAC. Make sure that the water supply is turned on to full pressure.
Open the door, press the ON/OFF Button, and the ON/OFF light will turn on.
Press the program Button , the wash program will be changed as follows direction:
All in 1 Auto ;
If a program is selected, the response lig ht will light. Then close the door, the dishwasher begins to start.
“ ”
“ ”
-> ->Intensive->Normal->ECO->Glass->90Min->Rapid->Soak
1
2
3
4
5
Means: need to fill rinse into the Rinse-Aid Dispense r.
( )
14
W (65 )
Rinse
Rinse (65 )
Drying
ash ℃
℃
ECO
Intensi ve
N orma l
(*EN 50242)
Rapid
Gl ass
For lightly soile d crockery
and glass
For normally soiled loads,
such as , plates,glasses
and ligh tl y soiled pans.
pot s
For heaviest soile d croc kery,
and normal ly soile d po ts
pans dishes etc with drie d
on soiling.
、
、
A shorter wash for lightly
so iled l oads that do not
need drying.
To r inse di shes that you plan
t o wa sh later that da y.
So ak
Auto
Au to s ensi ng wa sh , l ig htl y,
no rma lly o r he av ily s oi le d
cr oc kery, with or with o ut
dr ied-on foo d
Pre-wash
Autowash
Ri nse
Ri nse
Dr ying
(45 )
(45-55 )
(65 )
℃
℃
℃
150
0. 9~1.3 9.5~ 13
210
For normally soiled loads,
such as , plates,glasses
and ligh tl y soiled pans.
pot s
Wash (50 )
Rin s e
Rin s e (65 )
Drying
℃
℃
10
All in 1
0.92
Th is is s tand ard p r ogra mme, it is s ui tab le
to cle an n orma ll y soi led ta bl e ware an d
it i s t he mo st effic ien t pr og ramm e i n
te rms o f it s c om bi ned e ne rgy an d wa t er
co ns ump tio n fo r tha t ty pe of ta ble wa re .
Pre-wa sh(50 )
Wash (60 )
Rins e
Rins e
Rins e(70 )
Drying
℃
℃
℃
P re -wa sh (4 5 )
Wa sh (55 )
Rin se
Rin se ( 65 )
Dry in g
℃
℃
℃
Pre-wash
Wash (45 )
Rinse (6 5 )
Dry ing
℃
℃
Wash (45 )
Rins e
Rins e (55 )
℃
℃
(50 )℃
180
19 5
17 0
30
1.1
0.74
1 .4
0 .7
15.5
12
8
10
20g
Pr e- wa sh
1 5 0.02 3. 5
12 5 0. 75 12
P re -wash
Wash (40 )
R in se
R in se (6 0 )
D ry in g
℃
℃
90 11.51.15
90 Min
For no rmally soiled loads
that ne ed qui ck was h.
25g
(or )3in1
3/ 22g
(or )3i n1
3/ 22g
(or )3i n1
3/ 22g
(or )3i n1
3/ 22g
(or )3i n1
3/ 22g
(or )3i n1
2 5g
(or )3in1

When the working cycle has finished, the buzzer of the dishwasher will sound for 8 seconds, then stop. Turn off
the appliance using the ON/OFF button, shut off the water supply and open the door of the dishwasher.
Wait for a few minutes before unloading the dishwasher to avoid handling the dishes and utensils while they
are still hot and more susceptible to breakage. They will also dry better.
Sw itch Off the D ishwasher
The program light is off, only in this case the programme has ended.
Open the door.1. Switch off the dishwasher by pressing the ON/OFF button.
2.Turn off the water tap!
Op en the door carefu lly.
Hot dishes are sensitive to knocks. The dishes should therefore be allowed to cool down around 15 minutes
before removing from the appliance.
Open the dishwasher's door, leave it ajar and wait a few minutes before removing the dishes. In this way they
will be cooler and the drying will be improved.
Unloading the d ishwasher
It is normal that the dishwasher is wet inside.
Empty the lower basket first and then the upper one. This will avoid water dripping from the upper Basket onto
the dishes in the lower one.
If you open the door , the machine will pause. The program light will
stop blinking and the buzzer will mooing every minute unless you close the door . After
you close the door ,the machine will keep on working after 10 seconds.
during a wash cycle
Premise:
A cycle that is underway can only be m odified if it has only been running for a short time. Otherwise, the
detergent may have already been re leased, and the appliance may have already drain ed the wash water.
If this is the case, the detergent disp enser must be refilled (see the section entitled " L oading the
Detergent " ).
Open the door ,press the Program bu tton , the machine will be in standby state,
then you can change the program to t he desired cycle setting (see the section entitled " Starting a
wash cycle. . ." ).
more than 3 seconds
1
2
A forgotten dish can be added any time before the detergent cup opens.
Add forgotten dishes.
Close the door
After the spray arms stop working, you can open the door
completely.
2
3
Open the door a little .
14
5The dishwasher will run after 10 seconds.
15
It is dangerous to open the door when washing,
because the hot water may scald you.

The filter prevents larger remnants of food or other objects from getting inside the pump.
The residues may block the filt er, in this case they must be removed.
The filter system consists of a coarse filter,a flat (Main filter)
And a microfilter(Fine filter).
Food and soil particle s trapped in this filter are pulve rized by a
special jet on the lower spray arm and washed down to drain.
Larger items, such as pieces of bones or glass, that could block
the drain are trapped in the coarse filter. To remove the items
caught by the filter, gently squeeze the tap on the top of this
filter and lift out.
This filter holds soil and food residues in the sump area and
prevents it from being redeposit on the dishes during wash cycle.
Main filt er
1
Coarse filter
2
Fine filter
3
2
3
1
Filter assembly
The filter efficiently
For best performance and results, the filter must be cleaned regularly. this reason, it is a good idea to
remove the larger food particles trapped in the filter after each wash cycle by rinsing the semicircular filter and
cup under running water. To remove the filter device, pull the cup handle in the upward direction.
removes food particles from the wash water, allowing it to be recycled during the cycle.
For
The dishwasher must never be used without the filters.
Improper replacement of the filter may reduce the performance level of the appliance
and damage dishes and utensils.
Step 1 Turn the filter in anti-clockwise direction,：
Step 2 lift the filter assy up：
When following this procedure from step1 to step 2, the filter system will be removed;
when following it from Step 2 to Step 1, the filter system will be installed.
16
1
2

The control panel can be cleaned by using a lightly dampened cloth.
After cleaning, make sure to dry it thoroughly.
For the exterior, use a good appliance polish wax.
Never use sharp objects, scouring pads or harsh cleaners on any part of the dishwasher.
Protect Against Freezing
1.Cut off the electrical power to the dishwasher.
2.Turn off the water supply and disconnect the water inlet pipe from the water valve.
3.Drain the water from the inlet pipe and water valve. (Use a pan to gather the water)
4.Reconnect the water inlet pipe to the water valve.
5.Remove the filter at the bottom of the tub and use a sponge to soak up water in the sump.
please take frost protection measures on the dishwasher in winter. Every fter washing cycles,
please operate as follows
time a
：
Cleaning the Filter
Cleaning The Door
To clean the coarse filter and the fine filter, use a cleaning brush. Reassemble the filter parts as shown in the figures
on the last page and reinsert the entire assembly in the dish washer, positioning it in its seat and pressing downwards.
When cleaning the filters, don't knock on them. Otherwise, the filters could be
contorted and the p er formanc e of the d ishwash er could be decreased.
To clean the edge around the door, you should use only a soft warm, damp cloth.
To avoid penetration of water into the door lock and electrical components, do not
use a spray cleaner of any kind.
Never use a spray cleaner to clean the door panel as it may damage the door lock
and electrical components.
Abrasive agents or some paper towels should not be used because of the risk of
scratching or leaving spots on the stainless steel surface.
Cleaning the Spray Arms
If your dishwasher ca nn ot work beca us e of the ice,
p lea se co ntac t p rof essio na l s er vic e p er sons .
It is necessary to clean the spray arms regularly for hard
water chemicals will clo g the spray arm jets and bearings.
- Inspect the filters for blocking after every time the dishwasher has been used.
- By unscrewing the coarse filter, you can remove the filter system. Remove any food remnants and
clean the filters under running water.
Remarks:
The entire filter assembly should be cle aned once a week.
To remove the lower spray arm, pull out the spray arm upward.
To remove the upper spray arm, hold the nut, rotate the arm
clockwise to remove it.
Wash the arms in soapy and warm water and use a soft brush to
clean the jets. Replace them after rinsing them thoroughly.
17

It is recommend that you run a wash cycle with the
dishwasher empty and then remove the plug from the
socket, turn off the water supply and leave the door of
the appliance slightly open. This will help the door
seals to last longer and prevent odours from forming
within the appliance.
If the appliance must be moved, try to keep it in the
vertical position. If absolutely necessary, it can be
positioned on its back.
One of the factors that cause odours to form in the
dishwasher is food that remains trapped in the seals.
Periodic cleaning with a damp sponge will prevent this
from occurring.
Before cleaning or performing maintenance, always
remove the plug from the socket.
To clean the exterior and rubber parts of the dishwasher,
do not use solvents or abrasive cleaning products.
Only use a cloth with warm soapy water.
To remove spots or stains from the surface of the
interior, use a cloth dampened with water an a little
vinegar, or a cleaning product made specifically for
dishwashers.
Remove the Plu g
No Solvents or Abrasive Cleaning
Moving the Appliance
Seal s
After every wash, turn off the water supply to the
appliance and leave the door slightly open so that
moisture and odours are not trapped inside.
Af ter Eve ry Wash When not in U se for a LongTim e
18
The installation of the pipes
and electrical equipments
should be done by professionals.
The installation position of dishwasher should be near the exist ing inlet and drain hoses and
power cord.
One side of the cabinet sink should be chosen to facilitate the connection of drain hoses of
the dishwasher.
Installation preparation
Note: please check the accompanying installation accessories(hook for aesthetic panel,screw)
●
Electrical Shock Hazard Disconnect electrical power before
installing dishwasher.
Failure to do so can result in death or electrical shock.
