ObjetDesktopWaterJet
SitePreparationGuide
DOC‐01207Rev.A
Sept.2012
StratasysLtd.

DOC-01207 Rev. A Page 3
Copyright
Copyright © 2012 Stratasys Ltd. All rights reserved.
This documentation contains proprietary information of Stratasys Ltd. This information is
supplied solely to assist authorized users of this Stratasys 3D printing system. No part of
this document may be used for other purposes, and it may not be disclosed to other parties.
The specifications on which this document is based are subject to change without notice.
No part of this book may be reproduced in any form or by any means, nor stored in a
database or retrieval system, without prior permission in writing from Stratasys Ltd.
If this document is distributed as a PDF file, you may print it for internal use.
DOC-01207
Revision A
Sept. 2012
Trademarks
The following are registered trademarks of Stratasys Ltd.: Stratasys®, Objet®, FullCure®.
Microsoft and Windows are trademarks of Microsoft Corporation.
All names of products and services cited in this book are trademarks or registered
trademarks of their respective companies.

DOC-01207 Rev. A Page 5
Contents
1 Introduction
1.1 For More Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.2 Terms Used in This Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2 Shipment and Delivery
2.1 Shipping Information and Responsibility. . . . . . . . . . . . . . . . . . . . . . . 9
2.2 Shipping Pallets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3 Physical Description
3.1 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.2 Size and Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.3 WaterJet Unit Model Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4 Site Requirements
4.1 WaterJet Support Table/Counter Specifications . . . . . . . . . . . . . . . . 15
4.2 Water Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.3 Drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.4 Floor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4.5 Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5 Technical Specifications
6 Site Preparation Checklist

DOC-01207 Rev. A Page 7
For More Information
1Introduction
Thisdocumentprovidessite‐preparationinformationandrequirementsforthe
WaterJetsystem,toensureproperinstallationandoperation.Thecustomeris
responsibleforpreparingtheinstallationsiteaccordingtotheinstructionsand
guidelinesdescribedinthisdocument.
Thefollowingtopicsarecoveredinthisguide:
•Physicaldescription
•Siterequirements
1.1 For More Information
Forspecialoperatingconditions,orifyouhaveanyquestionsaboutthesite
preparationprocedure,contactyourStratasysrepresentative.
Visithttp://www.stratasys.comformoredetailsaboutStratasys,itstechnology,
productsandconsumables,andforapplicationinformation.
Ifyouhaveanyquestionsabouttheinformationpresentedinthisdocument,or
ifyouhaveanycommentsorsuggestionsforfutureeditions,pleasesenda
messagetoc‐[email protected].
1.2 Terms Used in This Guide
Important:
Since preparation of the site must be completed before the installation date, you must fax
the checklist at the end of this document to your local Stratasys representative after
carrying out the tasks described in this guide. After the checklist is reviewed, a date will
be set for installation.
Resin Thebasesubstancefromwhichphotopolymermaterials
aremadeforuseinStratasyspolyjetprinters.
Modelmaterial Materialusedforbuildingmodels.
Supportmaterial Materialusedforsupportingthestructureofmodels
duringproduction.

DOC-01207 Rev. A Page 9
Shipping Information and Responsibility
2 Shipment and Delivery
2.1 Shipping Information and Responsibility
StratasysLtd.willarrangeshipmenttothecustomer’sfacility,asindicatedinthe
“shipto”sectionoftheinvoice.Itisthecustomer’sresponsibilitytoprovide
Stratasyswithdetaileddeliveryinstructions.Thecustomerisalsoresponsible
fortransportingthesystemtoasuitablypreparedinstallationsite.
2.2 Shipping Pallets
TheWaterJetsystemisdeliveredtothesiteonawoodenpallet.The
approximatesizeandweightofthepalletareshowninTable 1.
* Weight—grossweightofthepackedcrate
Important:
Equipment should be unpacked and installed by authorized Stratasys representatives
only.
Table 1: Shipping pallet size and weight
W × H × D (cm) W × H × D (in.) Weight*
105 × 85 × 68 41.3 × 33.5 × 26.5 60 kg/132 lb.

DOC-01207 Rev. A Page 11
Configuration
3 Physical Description
3.1 Configuration
TheWaterJetsystemconsistsoffollowingmaincomponents:
a. WaterJetunit(cabinetandstand)
b. waterpressurepump
c. metalbase
d. standextensions
Figure 3–1 WaterJet components
The water pressure pump supplied with the WaterJet may differ from the water
pressure pump shown above.
b
cd
a

Page 12 DOC-01207 Rev. A
Objet WaterJet Site Preparation Guide
Physical Description
3.2 Size and Weight
ThefollowingtableshowsthesizeandweightoftheWaterJetunitandwater
pressurepumps.
Note: Whenthecoverisopen,theeffectiveheightoftheWaterJetunitincreasesby25
centimeters(9.8inches).
ThefollowingfigureshowstheWaterJetunitinstalledonatable.
Figure 3–2 WaterJet unit installed on a table
Table 2: WaterJet and water pressure pump dimensions and weights
Unit W × H × D (cm) W × H × D (in.) Weight
WaterJet with table stand 58 × 75× 70 22.8 × 29.5 ×
27.5 25.6 kg / 56.3 lb
WaterJet with floor stand 58 × 155 × 70 22.8 × 61 × 27.5 30 kg / 66 lb
Water
Pressure
Pump
220-240 V 29.5 × 55.6 × 24 11.6 × 21.9 × 9.4 9 kg / 19.8 lb
110-120 V 31.8 × 57.2 × 22.912.5 × 22.5 × 9 7 kg / 15.4 lb
100 V 22.9 × 58.4 × 35.69 × 23 × 14 7.3 kg / 16 lb

DOC-01207 Rev. A Page 13
WaterJet Unit Model Capacity
ThefollowingfigureshowstheWaterJetunitinstalledonthefloor.
Figure 3–3 WaterJet unit installed with stand extensions
3.3 WaterJet Unit Model Capacity
WaterJetcancleanmodelsthathavethefollowingmaximumdimensions:
TheWaterJetisadequateforcleaningprintedmodelsoftypicalsize.Some
Stratasysprintersarecapableofprintingmodelswhosedimensionsaregreater
thanthosespecifiedinTable 3.TheWaterJetisnotsuitableforcleaningvery
largemodels.
Table 3: Maximum model dimensions
W × H × D (cm) W × H × D (in.)
Maximum model size 30 × 25 × 20 11.8 × 9.8 × 7.9

DOC-01207 Rev. A Page 15
WaterJet Support Table/Counter Specifications
4 Site Requirements
Thefollowingfactorsshouldbeconsideredwhenchoosingasuitablelocation
fortheWaterJetunit:
•Typeofconfiguration:countertoporfloor
•ProximitytotheStratasys3Dprinter.
Toavoidwaterdamagetotheprinter,installtheWaterJetinanotherroomor
atleast5meters(16.5feet)awayfromtheprinter.
•Proximitytoanareawheremodelscanbesoakedincausticsoda(sodium
hydroxide),andwheretheycandryafterWaterJettreatment.
4.1 WaterJet Support Table/Counter Specifications
Therecommendedheightofthetable/counteris80cm(31inches).This
establishesaheightof120cm(47.2inches)atarmlevelfortheaverageperson.
Thesupporttableorcountermustbesturdycapableofcarryingaloadofatleast
30kg(66lb).Thetablemustbelevel.
4.2 Water Supply
TheWaterJetsystemrequiresaconnectiontotheregularwatersupply.
Thecustomermustsupplyasuitablewatertap.Thewatertapshouldbelocated
nextto,orinbackofthewaterpump.
Warning:
Two people are required to lift the WaterJet unit onto the table.

Page 16 DOC-01207 Rev. A
Objet WaterJet Site Preparation Guide
Site Requirements
Awaterfilterisalsorecommendedtoprotectthewaterpressurepump.For
waterfilteringrecommendations,see“WaterFilter”onpage 17.
Figure 4–4 Water tap (an example)
TheWaterJetunitconnectstoaseparatewaterpressurepump.Stratasys
suppliesa3 meter (10 foot) garden hose, necessary clamps and adaptors to
connect the WaterJetunittothewaterpressurepump.
Figure 4–5 Garden hose, hose adapters and hose clamps
Thewaterpressurepumpcanbeplacedupto3meters(10feet)fromthewater
tap.Ifyouneedtoplacethewaterpressurepumpfartherawayfromthewater
tap,installalongergardenhose(notsupplied).
Usingthepressurehoseandelectricalcablesuppliedwiththepump,youcan
placethewaterpressurepumpupto3meters(10feet)fromtheWaterJetunit.
USA
Europe & Japan
Important:
The pressure of the water supplied to the water pressure pump after the filter must never
drop below 1 atm.
Lower water pressure may cause the pump to overheat and fail.

DOC-01207 Rev. A Page 17
Drain
Water Filter
Thefollowingillustrationshowsasuggestedinstallationarrangement.
Figure 4–6 Suggested room layout
4.2.1 Water Filter
Itisrecommendedthatyouinstalla100‐micronfilterbetweenthewatertapand
thegardenhose.Wheninstalled,thewaterfiltershouldbeaccessiblefor
maintenance.
4.3 Drain
ThewastewaterfromtheWaterJetunittypicallyemptiesintothebuilding’s
drainagesystem.Therefore,youmustprepareasuitabledrainneartheunit.Itis
recommendedthatyoulocatethedrainpipebehindtheWaterJetunitandbelow
thedrainoutletontheWaterJet.
TheWaterJetunitcomesequippedwithadrainhose,approximately3meters
(10feet)inlength.Youcanconnectthehosetoastandarddrainpipewitha
diameterof3.9centimeters(1.5inches).
Power to
Pump
Water In
Pressurized Water to WaterJet
WaterJet
11'9"
300 cm
3'9"
90 cm
Power
Drain
79"
200cm
Water Filter
Non-slip surface
Drying
Surface
The filter element should be replaced regularly, as required, to ensure sufficient water
pressure to the pump.

Page 18 DOC-01207 Rev. A
Objet WaterJet Site Preparation Guide
Site Requirements
Alternatively,youcanconnectanextensiontotheWaterJetdrainhoseandrunit
toanearbydrain,asshowninFigure4–7.
Figure 4–7 Drain configurations (examples)
4.4 Floor
ItisrecommendedthattheflooraroundtheWaterJetunithaveanon‐slip
surfacebecausewatermaydripfromcleanedmodels.
4.5 Power
•Walloutlet
AnelectricaloutletmustbeavailableneartheWaterJetunit,preferablyin
backoftheunit,toreducethechancesofwatersprayingontheoutlet.
Thewalloutletmusthave(orbeconnectedto)aresidualcurrentdevice
(RCD)—groundcurrent‐leakagedetector—thatprotectsfromaleakageof
morethan30mA.
•Circuitbreaker
Theelectricalcircuitmustbeprotectedbyacircuitbreakerwiththe
specificationsshowninthefollowingtable.
Table 4: Circuit breaker specifications
Voltage Circuit Breaker
100 VAC 15 Amps
110–120 VAC 15 Amps
220–240 VAC 10 Amps

DOC-01207 Rev. A Page 19
Power
Grounding
•Powercable
•ForEurope,thedistributororcustomermustsupplyan
IEC320(C13)10A/100–230Vpowercable.
•ForNorthAmericaandJapan,anIEC320(C13to5–15P)15A/120V
powercableissupplied.
Figure 4–8 Power cable for North America and Japan (example)
4.5.1 Grounding
TheWaterJetunitisgroundedthroughtheACplug.Makesurethattheground
connectorinthegroundfaultprotectionwalloutletoronthecircuitisproperly
grounded,inaccordancewithyourlocalelectricalcodes.
