STRIDE SE-SW8U User manual

Desc iption:
TRIDE limLine Industrial Unmanaged Ethernet witch with eight
10/100BaseT RJ45 Ethernet ports. Redundant power inputs with surge
and spike protection. Auto-crossover. DIN rail mounting. upports
store & forward wire speed switching and full-duplex with flow control.
UL, C A (CUL), & CE. The -WT models have a metal case and are
rated for a wider temperature range, from -40 ° to 85 °C.
1
w w w . A u t o m a t i o n D i r e c t . c o m
1 - 8 0 0 - 6 3 3 - 0 4 0 5
STRIDE™ INDUSTRIAL UNMANAGED ETHERNET SWITCH
8-PORT – DATA SHEET
3505 HUTCHINSON ROAD
CUMMING, GA 30040-5860, USA
NNOOTTEE::DIMENSIONS, INSTALLATION AND WIRING INFORMATION IS
SHOWN ON THE BACK OF THIS DATA SHEET.
SE-SW8U
Copper RJ45 Ports: (10/100BaseT)
10/100BaseT ports Shielded RJ45
Protocols supported All standard IEEE 802.3
Ethernet compliancy IEEE 802.3, 802.3u, 802.3x
Auto-crossover Yes, allows you to use straight-through or crossover wired cables
Auto-sensing operation Yes, Full and half duplex
Auto-negotiating Yes, 10BaseT and 100BaseT
Auto-polarity Yes, on the TD and RD pair
Flow control Automatic
Ethernet isolation 1500 VR S 1 minute
Plug and play Yes
Cable requirements Twisted pair (Cat. 5 or better) (shielded recommended)
Max. cable distance 100 meters
General Specifications
Ethernet switch type 8 ports
Operating mode Store and forward wire speed switching, non-blocking
Devices supported All IEEE 802.3 compliant devices are supported
Standards IEEE 802.3, 802.3u, 802.3x
MAC addresses 1024 addresses
Memory bandwidth 3.2 Gbps
Latency or
10 Mbps ports 16 us + frame time (typical)
Latency or
100 Mbps ports 5 us + frame time (typical)
Power input Redundant Input Terminals
Input power
(typical with all ports
active at 100 Mbps)
4.0 W
Input voltage 10-30 VDC (continuous) - Class 2 Power Supply
Reverse power protection Yes
Transient protection 15,000 watts peak
Spike protection 5,000 watts (10x for 10 uS)
Ethernet isolation 1500 VR S 1 minute
Operating temperature
range
SE-SW8U -10 to +60 °C (+14 to +140 °F),
cold startup at -10 °C (+14 °F)
SE-SW8U-WT -40 to +85 °C (-40 to +185 °F),
cold startup at -40 °C (-40 °F)
Storage temperature
range -40 to +85 °C (-40 to +185 °F)
Humidity
(non-condensing) 5 to 95% RH
Environmental Air No corrosive gasses permitted
Vibration, shock & ree all IEC68-2-6, -27, -32
Agency Approvals
UL/cUL 508, CSA C22 per EN61010-1,
UL/cUL 1604 (Class 1, Div. 2, Groups A, B, C, D),
CSA C 22.2/213 9 per EN50021/EN60079-15
(Zone 2, Category 3), CE (ATEX)
EMI emissions FCC part 15, ICES-003, EN55022
EMC immunity IEC61326-1
Hazardous locations UL1604, CSA C22.2/213 (Class I, Div.2) (file #E200031);
EN50021/EN60079-15 (Zone2)
RoHS and WEEE RoHS (Pb free) and WEEE compliant
Packaging and protection SE-SW8U UL94VO Lexan, IP30
SE-SW8U-WT Aluminum IP30
Dimensions (L x W x H) See mechanical diagrams for details
Weight SE-SW8U 6 oz (0.17 kg)
SE-SW8U-WT 8 oz (0.23 kg)
Safety Standa ds:
UL
CUS
R
Electrical Safety European
Directives US Emissions
WEEE Compliant RoHS Compliant
RoHS
NNOOTTEE::FOR ADDITONAL PRODUCT DETAILS, A USER MANUAL,
SE-USER-M, IS AVAILABLE AS A DOWNLAODABLE PDF FILE FROM THE
ONLINE DOCUMENTATION AREA OF THE AAUUTTOOMMAATTIIOONNDDIIRREECCTTWEBSITE.
SE-SW8U-WT
Metal case designed
for -40 ° to 85 °C.

2
w w w . A u t o m a t i o n D i r e c t . c o m
1 - 8 0 0 - 6 3 3 - 0 4 0 5
Copyright 2014, AutomationDirect.com Incorporated/All Rights Reserved Worldwide
3.96
[100.6]
1.50
[38.1]
Dia. 0.15 [3.8]
Use for direct
panel mounting
to a flat surface.
1.98
[50.3]
3.26
[82.8] 0.06
[1.5]
Units: inches [mm]
1.98
[50.3]
Snaps to standard
35 mm x 7.5 mm height
DIN rail (EN50022)
Removable
Screw Block,
Phoenix
p/n 1757035
1.01
[25.7]
1.01
[25.7]
8 Port – SE-SW8U
4.35
[110.5]
Dimensions:
Snaps to standard
35 mm x 7.5 mm height
DIN rail (EN50022)
Removable
Screw Block,
Phoenix
p/n 1757035
C
2.25
[57.1]
2.25
[57.1]
Dia. 0.175 [4.4]
Use for direct
panel mounting to
a flat surface with
up to #8 screw.
4.00
[101.6]
0.30
[7.6]
4.35
[110.5]
Removable
for direct panel
mounting
1.50
[3.81]
1.60
[40.6] Units: inches [mm]
0.80
[20.3] 3.00
[76.2] 0.39 [9.9]
8 Port – SE-SW8U-WT
4.50
[114.3]
0.175
[4.4]
Additional Help and Suppo t
• For additiona product support, specifications, and
insta ation, a User Manua , SE-USER-M, is avai ab e
as a down oadab e PDF fi e from the On ine
Documentation area of www.AutomationDirect.com
• For additiona technica support and questions, ca our Technica
Support team @ 770-844-4200.
P2 P1
One DC Supply
+–
Single DC Power Redundant DC Power
Chassis
GND
(panel)
P2 P1
+–+–Chassis
GND
(panel)
Dual DC Supplies
Powe Wi ing:
The switch can be powered from the same DC source that is used to
power your other devices. To maintain the UL508 listing, this must be
a Class 2 power supply. A DC voltage in the range of 10 to 30 VDC
needs to be applied between the P1 (plus) terminal and the Minus
terminal as shown below. The chassis screw terminal should be tied to
panel or chassis ground. To reduce down time resulting from power
loss, the switch can be powered redundantly with a second power
supply as shown below.
A recommended DC power supply is AutomationDirect.com Part
number P C-24-015.
Communication Po ts Wi ing:
The switch provides connections to standard Ethernet devices such as
PLCs, Ethernet I/O, industrial computers and much more. Use data-
quality (not voice-quality) twisted pair cable rated category 5 (or better)
with standard RJ45 connectors. traight-through or crossover RJ45
cable can be used for all devices the switch is connected to as all the
ports are capable of auto-mdi/mdix-crossover detection.
The RJ45 Ethernet port connector bodies on the switch are metallic
and connected to the Chassis GND terminal. Therefore, shielded cables
may be used to provide further protection. To prevent ground loops,
the cable shield should be tied to the metal connector body at one end
of the cable only. Electrical isolation is also provided on the Ethernet
ports for increased reliability.
DIN rail mounting steps, plastic and metal case:
1. Hook top back of unit over the DIN rai .
2. Push bottom back onto the DIN rai unti it snaps into p ace.
DIN rail removal steps, plastic case:
A. Insert screwdriver into DIN c ip and pry unti it re eases from the rai .
B. Unhook top of unit from DIN rai .
DIN rail removal steps, metal case:
A. Push the unit down to free the bottom of the DIN rai .
B. Rotate the bottom of the unit away from the DIN rai .
C. Unhook top of unit from DIN rai .
Installation – DIN Rail Mounting:
The switch can be snapped onto a standard 35 mm x 7.5 mm height
DIN rail ( tandard: CENELEC EN50022) and can be mounted either
vertically or horizontally.
10-30 VDC, 4.0W
1
2
A
B
A
B
C
Maximum power
terminal screw
torque is
5.0 lb-in (0.57Nm).
Mounting Removal, plastic case Removal, metal case
Wire Size Range
24 – 12 AWG
All power, input and output (I/ ) wiring must be in accordance with Class I, Division 2 wiring methods and in
accordance with the authority having jurisdiction.
“This Equipment is Suitable for Use in Class I, Division 2, Groups A, B, C, D or Non-Hazardous Locations nly”.
WARNING – EXPL SI N HAZARD – SUBSTITUTI N F C MP NENTS MAY IMPAIR SUITABILITY F R CLASS I, DIVISI N 2.
WARNING – EXPL SI N HAZARD – WHEN IN HAZARD US L CATI NS, DISC NNECT P WER BEF RE REPLACING R WIRING UNITS.
WARNING – EXPL SI N HAZARD – D N T DISC NNECT EQUIPMENT UNLESS P WER HAS BEEN SWITCHED FF R THE AREA IS
KN WN T BE N NHAZARD US.
WARNING – EXPL SI N HAZARD – IN HAZARD US R P TENTIALLY HAZARD US L CATI NS, D N T SEPARATE ANY
PART F THE UNIT WHEN ENERGIZED. USE THE UNIT F R INTERNAL C NNECTI NS NLY.
Tout pouvoir, le câblage d’entrée et de sortie (I/ ) doivent être conformes aux méthodes de câblage de Classe
I, Division 2 et conformément à l’autorité compétente.
“Cet équipement est adapté pour une utilisation en Classe1, Division 2, Groupes A, B, C et D ou endroits
non-dangereux seulement ”.
AVERTISSEMENT – RISQUE D’EXPL SI N – LA SUBSTITUTI N DE T UT C MP SANT PEUT NUIRE À LA C NF RMITÉ DE CLASSE I,
DIVISI N 2.
AVERTISSEMENT – RISQUE D’EXPL SI N – L RSQUE DANS DES ENDR ITS DANGEREUX, DÉBRANCHEZ LE C RD N
D'ALIMENTATI N AVANT DE REMPLACER U DE BRANCHER LES M DULES.
AVERTISSEMENT – RISQUE D’AVERTISSEMENT – NE DÉBRANCHEZ PAS L’ÉQUIPEMENT PENDANT QUE LE CIRCUIT EST DIRECT U À
M INS QUE L’ENVIR NNEMENT S IT C NNU P UR ÊTRE LIBRE DE C NCENTRATI NS INFLAMMABLES.
AVERTISSEMENT – RISQUE D’EXPL SI N – DANS LES ENDR ITS DANGEREUX U P TENTIELLEMENT DANGEREUX, NE PAS
SEPARER UNE PARTIE DE L'UNITE S US TENSI N. SEULEMENT UTILISEZ L'APPAREIL P UR LES C NNEXI NS INTERNES.
