NURSING BEDSPFLEGEBETTEN
STRIDER
MX 3 and MX 4
3-wheel and 4-wheel version
Order number: E1-04-031-001
OPERATING MANUAL

3
Issued:24.02.2005
STRIDER MX Introduction
If you have any other questions about this scooter please contact
yourretailerorsupplier.
With the Strider MX, you have now purchased a product which has
been manufactured in accordance with the newest technical
capabilities and based on the highest operating comfort.
We have placed great value on the simplest possible operation and
long service life in both construction and material selection.
A large variety of useful accessories rounds off our range in addition
to the Strider.
This Operating Manual assumes that the suitability of the user for
Strider usage has been discussed with a doctor, therapist and/or
dealerbeforeoperation.
The operating manual will help you get to know the function of our
Strider and, in addition, describes:
•operation
•careandmaintenance
•repair
The manual has been drawn up using information available at the time
of printing with regard toconstruction andoperation ofthe Strider.
We reserve the right to make changes due to technical improvements.

4
Issued:24.02.2005
STRIDER MX Contents
1.0Safetyinstructions .................................................................................8
1.1 Symbols used..............................................................................8
1.2 Intendeduse................................................................................8
1.3 GeneralInformation .....................................................................9
1.4 Safetywhendriving ...................................................................10
1.5 Safetyduringtransport,assemblyand maintenance..................11
1.6 Safetywhenhandlingbatteries .................................................. 12
1.7 Safety - information about electronics........................................ 12
2.0 Versions............................................................................................ 13
3.0 Extentof delivery ............................................................................. 13
4.0 Components ..................................................................................... 14
4.1 TheStrider.................................................................................14
4.2 Thedashboard- displays and controls.......................................14
5.0 Briefinstructions ............................................................................. 15
5.1 DrivingtheStrider ...................................................................... 15
5.2 Transporting theStrider.............................................................. 19
6.0 Setting up the Strider ...................................................................... 21
6.1 Adjusting the seat height ...........................................................21
6.2 Adjusting the seat position......................................................... 25
6.2.1 Adjusting the distance between seat and tiller ................ 25
6.2.2 Adjustingthearmrest width ............................................ 25
6.2.3 Adjustingthe armrest height ...........................................26
6.2.4 Adjusting the backrest inclination ...................................27
6.3 Adjustingtheheadrest hight.......................................................27
6.4 Adjusting the tiller angle............................................................. 28
7.0 Information about safe Strider driving ........................................... 29
7.1 Drivingup inclines and down slopes ..........................................29
7.2 Overcomingobstacles ...............................................................30
7.2.1 DrivingInformation – Overcoming kerbs .........................32
7.3 Overloadprotection-motor protection ....................................... 33
7.4 Battery charging state = driving range........................................ 34
7.4.1 Battery charging state .................................................... 34
7.4.2 Drivingrange ..................................................................35
7.4.3 Overdischargeprotection - batteryprotection..................36
8.0 Driving the Strider ........................................................................... 37
8.1 Getting on and off ......................................................................37
8.2 Seat belt - adjusting for length and putting on ............................38
8.3 Turningtheseat .........................................................................39
8.4 Switching the strider on .............................................................39
8.4.1 Operationindicator and fault display ...............................39

5
Issued:24.02.2005
STRIDER MX Contents
8.5 Adjustingthespeed ................................................................... 40
8.5.1 Preselecting the drive level.............................................40
8.5.2 Adjustingthespeed ........................................................ 40
8.6 Beforedriving ............................................................................ 41
8.7 Driving .......................................................................................41
8.8 Brakes .......................................................................................42
8.8.1 Using the motor brake .................................................... 42
8.8.2 Usingthe handbrake .......................................................42
8.9 Indicating ...................................................................................42
8.10 Switchingon the headlights .......................................................43
8.11 Using thehorn ...........................................................................43
8.12 Switching off / parking the Strider ..............................................43
8.12.1 Thewheel lock (4-wheelversiononly).............................44
9.0 Hazard lamps ................................................................................... 44
10.0 Pushing the Strider.......................................................................... 45
11.0 Attaching the shopping basket ....................................................... 45
12.0 Charging the batteries ..................................................................... 46
12.1 Preparingthe batterycharger .....................................................46
12.2 Chargingthe batteries ................................................................47
12.3 Aftercharging ............................................................................ 48
13.0 Things to know ................................................................................ 49
13.1 Thebattery charger - functioningprinciple..................................49
13.2 The batteries.............................................................................. 49
13.2.1 What are batteries for cyclic use?...................................49
13.2.2 When do the batteries achieve their maximum
performance?.................................................................. 49
13.2.3 How do I make sure the batteries achieve their
best service life? ............................................................ 49
13.3 The auto switch-off ....................................................................50
13.4 The drive unit............................................................................. 50
13.5 Thedrive ...................................................................................50
13.6 Thecontrol unit.......................................................................... 50
13.7 Lighting ......................................................................................51
13.8 Antitipping wheels..................................................................... 51
13.9 Wheelsand tyres .......................................................................52
13.10 Brakes on the strider ...............................................................52
13.10.1Themotor brake ..........................................................52
13.10.2Thehandbrake.............................................................52
13.11 Driver´slicence........................................................................ 53
13.12 Insurance.................................................................................53

6
Issued:24.02.2005
STRIDER MX Contents
14.0 Transporting the strider ................................................................... 54
14.1 Transportinformation .................................................................54
14.2 Transportingthe completestrider(3wheel version)....................54
14.3 Preparationfortransport -separatingcomponent
(4wheel version)........................................................................54
14.3.1 Working stepsummary ...................................................55
14.3.2 Removingthe seat..........................................................55
14.3.3 Removingtherearpanelling............................................56
14.3.4 Removing thebatteries ...................................................56
14.3.5 Removingthe handbrakecable .......................................57
14.3.6 Foldingthe tiller down .....................................................57
14.3.7 Disengaging the drive unit from the chassis....................57
14.4 AfterTransport-Reassembly.....................................................59
14.4.1 Engaging the drive unit to the chassis ............................ 59
14.4.2 Folding the tiller up .........................................................60
14.4.3 Inserting the brake cable ................................................61
14.4.4 Reinserting the batteries.................................................62
14.4.5 Fixingthe rearpanelling.................................................. 63
14.4.6 Fitting the seat ...............................................................64
15.0 Cleaning ........................................................................................... 64
16.0 Maintenance and Inspection ........................................................... 65
16.1 Daily maintenance before start of journey .................................. 65
16.2 Weekly inspections / tyre pressure ............................................ 65
16.3 Annualinspection - inspection timetable ....................................66
17.0 Troubleshooting............................................................................... 70
17.1 Beforetroubleshooting ...............................................................70
17.2 Troubleshooting..........................................................................70
18.0 Repairs ............................................................................................. 74
18.1 Information about safety at work................................................ 74
18.2 Tools ..........................................................................................74
18.3 Mechanics .................................................................................75
18.3.1 Adjusting the drive lock clamping bolts........................... 75
18.3.2 Wheels -removaland replacement -3-wheelversion...... 77
18.3.3 Wheels -removaland replacement -4-wheelversion...... 78
18.3.4 Replacing the inner tube / tyre ........................................ 81
18.3.5 Adjustingthe handbrake .................................................82
18.4 Lighting- 3 wheel version...........................................................84
18.4.1 Replacingbulb inheadlight ............................................. 84
18.4.2 Replacingbulbsin front indicators .................................. 85
18.4.3 Replacingbulbs in rear lights and rearindicators ............85

7
Issued:24.02.2005
STRIDER MX Contents
18.5 Lighting- 4 wheel version...........................................................86
18.5.1 Replacingbulbs in headlight andfrontindicators............. 86
18.5.2 Replacingbulbs in rear light ............................................ 87
18.5.3 Replacing bulbsinfront/rear indicators ........................... 88
18.6 Fuses ........................................................................................ 89
18.7 Batteries ....................................................................................92
18.7.1 Disposal of used or damagedbatteries ...........................92
18.7.2 Refitting battery cables ...................................................93
19.0 Temporary storage ........................................................................... 94
20.0 Appendix .......................................................................................... 94
20.1 Nameplate .................................................................................94
20.2 Specifications ............................................................................95
20.2.1 Generaldata ...................................................................95
20.2.2 Dimensions3-wheel version ...........................................96
20.2.3 Dimensions4-wheel version ...........................................97
20.3 Torque for fixing screws ............................................................. 98
20.4 Disposing of the scooter ............................................................ 98
21.0 Warranty information ....................................................................... 99
22.0 Annual inspections carried out ..................................................... 100

8
Issued:24.02.2005
STRIDER MX Safety information
This instruction manual contains the following symbols which are used
to highlight special hazards in dealing with the product or information for
simplifying the handling.
Caution!
This symbol identifies safety information which notifies you of
hazardswhen dealing withtheproduct.
NOTE
You will also find information about dealing with the product
under this symbol.
The Days Healthcare scooter is constructed for use both indoors and
outdoors(Class C, European standard EN 12 184).
It is intended to increase the mobility of persons who are both
physically and mentally capable of assessing any driving situations
correctly and reacting correspondingly to them at any time.
The scooter is a class 3 invalid carriage and must be used by a person
over 14 years of age. It has a maximum speed of less than 8 mph
(13 kph) so it can be used on roads without a driving license, tax disk,
ot MOT certificate.The scooter can also be used on pavemants when
switched down to 4 mph (6.5 kph) but can not be used on motorways,
cycle tracks or bus lanes.(RoadTraffic Act 1988)
1.0 Safety instructions
1.1 Symbols used
1.2 Intended use

9
Issued:24.02.2005
STRIDER MX Safety information
Read the entire operating manual thoroughly before using the
Strider!
Ensure that:
• the operating manual is read by all people who drive, care for and
service the scooter.
• all persons who drive, care for, service or repair the scooter have
access to the operating manual at any time.
Anydamagesresulting from nonobservance of this operating manual
areexcludedfromthe guarantee.
Risk of accidents!
• Do NOT use the scooter if your driving capability is impaired
throughconsumptionofmedicineoralcohol.
• Only use the scooter for its correct intended use.
• Only use the scooter when it is in perfect working order.
• If any breakdowns occur, stop using the scooter immediately
andsecureit against unauthorized use.
• It is imperative that you always rectify any faults which
could influence the function and safety of the scooter
immediately.
• Observe maximum loading = see Specifications
• Only use accessories and spare parts authorized by
DaysHealthcare.
• The scooter is only authorized for transport of one person.
• Do not carry out any seat adjustments while driving.
Tipping hazard!
• Do not adjust the seat if the scooter is standing on an incline.
• Do not lean out over the armrest to the sides or over the
backrest to the rear.
1.3 General Information

10
Issued:24.02.2005
STRIDER MX Safety information
1.4 Safety when driving
Tipping hazard!
•Do not carry out any seat adjustments while driving.
• Only drive over obstacles and up kerbstones at the lowest
point and at right angles.
• Avoidsudden changes of direction and speed.
• Avoid steep gradients where there is a danger of skidding
(ice, snow, wet surfaces etc.).
• Avoid loose surfaces whose characteristics you are not able
to assess (woodlands, turf, beaches, gravel etc.)
• Always drive straight up and down gradients - do not drive in
zigzags.
• Donotturnaroundoninclines.
• Do not drive down steps.
• Do not drive backwards down gradients, stairs or kerbstones,
or over obstacles.
Risk of accidents!
• Check correct functioning of the brakes and lighting unit
(indicators,headlights) beforeeveryjourney.
• Always use lights when visibility is restricted, either by day
or by night.
• Check the tyre air pressure regularly.
• Always use the seat belts when driving.
• Do not switch the scooter off while driving.
• Do not drive up or down gradients which are too steep, over
obstaclesongradientsorupanddownramps.
Observe maximum climb angle = see Specifications
• Onlydrivethrough restricted widths, around bends, inclines
andrampswithreducedsuitablespeed.
• Only drive up or down inclines when the backrest has been
adjusted to vertical.
• Don´t drive too close to open waters.

11
Issued:24.02.2005
STRIDER MX Safety information
Danger due to unintentional movement!
• Always turn the scooter off using the keyswitch if you:
- want to get on or off
- intend to stop for long periods
- are putting the scooter away.
1.5 Safety during transport, assembly and maintenance
Injury hazard due to improper assembly!
• Ensure that all components in the Scooter have been
correctlyassembled.
• After assembly, check that all locking devices are holding
correctly.
Clamping and crushing hazard!
Increased hazards due to clamping or crushing result due to the
highcomponent weight(suchas batteries) duringpreparation
for transportandmaintenancework.
• Always carry out any work to be done with great care.
• Always try to get help from a second person, especially when
stowing parts for transport.
• Only carry out any work described if you are used to working
withthetoolsrequired.
• Only carry out work using suitable tools.
If the scooter is transported in the vehicle when fully
assembled:
- no persons may sit on the scooter during loading!
- no persons may sit on the scooter during transport!
Accidenthazardduetoincorrectlyboltedconnections!
• If bolted connections have self-locking nuts, ensure that
theseare replacedwhenreassembling.
• Do not replace self-locking nuts with normal nuts.
• If bolted connections have lock washers, check lock washers
whenreassembling and replace if necessary.

12
Issued:24.02.2005
STRIDER MX Safety information
Risk of accidents!
• Onlyusethe original battery charger (included in delivery).
• Letyourdealerreplace yourbattery.
• Only use batteries as detailed in the chapter entitled
“Specifications”.
• Observewarninginformationgivenbythebatterymanufacturer.
• Batteries are extremely heavy.
Burn hazard due to damaged batteries!
Batteries discharging acid can lead to serious burns.
• Donottouchdamagedbatterieswith your bare hands. Use
rubbergloves!
• If acid should contact your skin, wash the affected area
immediately with plenty of water and contact a doctor.
• If acid should come in contact with your eyes, rinse them out
immediately with lots of water and visit a doctor.
• Always change any clothing soiled with battery acid immediately.
1.7 Safety - information about electronics
Accident hazard due to failures!
Radio, television, radio transmission devices and mobile phones
produceelectromagneticfields.Thesecannegativelyinfluence
the scooter electronics functions.
• Do not drive close to strong radio or television transmitters
(transmittermasts).
• Switch the scooter off if you are using your mobile phone.
Failure in outside devices!
TheScooterproduces an electromagnetic field which can have
a negative influence on the function of any other electrical
devices in the immediate surroundings (such as medical
devices, radio receivers, cellular phones).
1.6 Safety when handling batteries
Fire hazard!
• Do not cover the battery charger and ventilation slot while
chargingbatteries.
• Onlyuse the battery chargerin well-ventilated areas.

13
Issued:24.02.2005
STRIDER MX Versions
2.0 Versions
The following items are included in
delivery in addition to the Strider:
1. Shoppingbasket
2. Two vehicle keys for switching
the Strider on
3. BatteryCharger
4.OperatingManual
3.0 Extent of delivery
3-wheelversion
4-wheelversion
After receiving your Strider, please
check the following:
• that the delivery is complete in
accordance with the list below
• the delivery condition using the
inspectionplan(chapter 15.3)
If any faults are apparent or
components are missing, please
contact Days Healthcare or your
medicalsupplier.

14
Issued:24.02.2005
STRIDER MX
Rearview
mirror
Operationindicator
(faultdisplay)
Components
4.0 Components
4.2 The dashboard - displays and controls Speed
contoller
Batterycharge
display
Drivelever
(reverse) Drivelever (forwards)
Horn
button Hazard indicatorswitch Headlight switch
Indicator
switch
Shopping
basket
Tiller
Indicators
andrear
light
Driveunit
covers
Handle Handle
4.1 The Strider
Brake lever for
handbrake
Steering
wheel
Dashboard
withcontrols Seat unit
withhead-
and
armrests
Speedswitch

15
Issued:24.02.2005
STRIDER MX Brief instructions
5.0 Brief instructions
The following brief instructions should enable people to quickly get used
to operating the scooter after a long period of non-use and to refresh
existingknowledgeofoperation.
It is imperative that you follow the instructions given in the main
manual!
1.)Turn the seat to the outside
NOTE
Before starting driving, adjust the seat height, the
backrest and the armrests to a comfortable position.
Your specialist dealer would be very glad to help.
5.1 Driving the Strider
2.) Get in - turn the seat in the
direction of travel

16
Issued:24.02.2005
STRIDER MX
ON
5.) Check the battery charging
state
4.) Switch on the Strider
3.) Fasten the seat belt
Brief instructions

17
Issued:24.02.2005
STRIDER MX
1
7.) Set the maximum speed
Brief instructions
8.) Driving
Operate the drive lever slowly until the required speed has been
reached.
6.) Adjusting the drive level
Drive levels:
H= 12 kph (8 mph) maximum
drivingspeed
L= 6 kph (4 mph) maximum
drivingspeed
The drive lever position controls the
speed variably right up to maximum
drivingspeed.
Reverse Forwards
Max. driving speed
Max. driving speed
Standstill
(brakeengaged) Standstill
(brakeengaged)
= highest possible driving
speedfor the required
drive level
= lowest possible driving
speedfor the required
drive level

18
Issued:24.02.2005
STRIDER MX
9.) Braking = release drive lever (1)
10.) Direction indicators (1)
Horn(2)
Hazard lamps (3)
Lights (4)
Brief instructions

19
Issued:24.02.2005
STRIDER MX
5.2 Transporting the Strider
1.) Remove the seat 2.) Remove the rear panelling
3.) Remove the lighting cable
Dismantling the Strider (stages 1 to 11)
5.) Remove the battery plug
4.) Separate the front connector
Brief instructions

20
Issued:24.02.2005
STRIDER MX
9.) Unlockthedriveunit
10.)Tilt the drive unit away 11.) Remove the chassis
6.) Remove the battery belts and
batteries
8.) Fold the tiller down
Brief instructions
Reassembling the Strider
(Stages 11 to 1)
7.) Removing the handbrake
cable
