Stronghold SH5436 User manual

Assembly & Fitting Instructions
Scope of use:
This product can be used on alloy wheels only with a tyre width
capacity of 165-205mm. It is only suitable for use with M12 x 1.5 pitch
wheel bolts. It is recommended that you use this product in
conjunction with a suitable Stronghold hitchlock
when tted to a caravan or trailer.
Maintenance:
• Lubricate lock regularly with a light oil spray.
• When cleaning this product use a cloth and mild
detergent.
• Lightly grease M12 x 30mm socket headed screw
when in regular use.
This box contains:
1 x ‘U’ shaped wheel clamp
1 x Lockholder and pin
3 x Keys
1 x 10mm allen key
1 x M12 x 30mm socket headed
screw
2 x M12 x 1.5 x 24.5mm pitch
wheelbolts
1 x Fitting instructions and
warranty card
Stronghold Security Products
Wheel Clamps & Hitchlocks
www.stronghold-security.com
Maypole Stronghold 162 Clapgate Lane Woodgate Business Park Birmingham B32 3DE United Kingdom
Ax
Stamp
Here
For more information on our range
of Stronghold Security Products
visit our website:
SH5436 Alloy Wheel
Clamp
Caravan Leg Lock
Suitable for all corner steadies
tted with an exposed 19mm
hexangonal drive
Winterho
Sold Secure Gold Approved.
Fits Winterho WS3000 hitches.
ALKO
Sold Secure Gold Approved.
Fits a wide range of ALKO
hitches including AK130,
AK160, AKS1300, AKS2004,
AKS3004.
5436 insert.indd 1 26/04/2019 09:55:25

Name:
Address:
Postcode:
Email:
Please note:
• Familiarise yourself with all parts prior to assembly & tting
• This product is supplied with three keys. Separate and keep a key
in a designated place of safety
• Record your key number here
You will need this in order to obtain replacements
• Keep this instruction card and your proof of purchase
(receipt or invoice) for future reference
Fitting Instructions
Fig 1
Remove two existing wheel bolts, which
are diagonally opposed on the wheel. After
checking that they have the same thread
length, size and type as the special wheel
bolts (M12 x 1.5mm pitch) provided, replace
and tighten to the manufacturers
recommended torque setting.
Please note if tting to a 5-bolt wheel, remove
one bolt, moving around the wheel leave the
next one in position and then remove the
next bolt.
Fig 4
Take ‘U’shaped wheel clamp and using the
approach angle shown, oer it to the locking
pin.
Fig 5
Now pass ‘U’ shaped wheel clamp arm over
the locking pin.
Warranty
Please see warranty card for details. Full warranty terms can be
viewed on our website www.stronghold-security.com
Replacement Keys
The design of Stronghold keys means that genuine replacements
are only available by special order through the place of purchase,
for which you will require your key number. Please note, the use of
unapproved copy keys will void your warranty.
