1
Theselectablefeaturescanbesetmanuallyasexplainedbelow,orwiththeRFfeatureprogrammer.
TosetfeaturesusingtheRFprogrammer,followtheinstructionspackagedwiththeprogrammer.
Factory default settings are indicated by bold text.
Note : The method of manual override can either be selected to operate from the valet switch or operate as custom code.
Be certain to place a check mark indicating the method used in the box located on the last page of the owner's manual.
NOTE: Keyless Entry Models with no horn output will Flash the Parking Lights instead of chirp where chirp is indicated.
Also, No data will be indicated if a feature is not available for a particular model. The unit will enter the feature but no selection will be available.
RF Programmable Feature Bank 1 Is For Transmitter Programming See Transmitter Programming Guide.
RF Programmable Features Bank 2 Is Alarm Selectable Features:
Feature Selection 1 Chirp 2 Chirps 3 Chirps 4 Chirps 5 Chirps 6 Chirps
1st DoorL/UL 1 Sec. 3.5 Sec. 1 Sec L, Dbl. U/L Dbl L, 1 Sec UL DblL,DblUL 1 Sl/350mS ul
2nd Accy Lock Auto Lock On Auto Lock Off
3rd Accy. UL Auto UL Dr. Auto UL All Auto UL Off `
4th Headlights Not Available
5th Passive Locks Not Available
6th Pass/Act Arm Not Available
7th Siren/Horn Not Available
8th Horn Chirp 10mS 16mS 30mS 40mS 50mS
9th O/R Method Not Available
10th 2 Step U/L On Off
11th Chp Del Tx On Off
12th Vlot Sense/Hd Wire NotAvailable
13th Trigger Circuits NotAvailable
14thL/ULPoll NotAvailable
15th Aux Ch 5 Sel Pulse Push & Hold 10 Sec 20 Sec Latch On/Off Hold3/S For O/P
16th Aux Ch 6 Sel Pulse Push & Hold 10 Sec 20 Sec Latch On/Off Hold3/S For O/P
17th Aux Ch 7 Sel Pulse Push & Hold 10 Sec 20 Sec Latch On/Off Hold3/S For O/P
18th Trigger Delay Not Available
When using the RF programmer, enter the program mode as follows:
Turn the ignition on.
Press and release valet switch 3 times;
turn ignition off then on.
Press and hold valet switch for 5 seconds.
Siren and or lights chirp/flash 2 times indicating access to RF feature program mode.
Model PRO-9276
Installation Manual

128-7855
2 of 20
2
To program these selectable features;
Action System Response
Turn ignition on No response
Press and release the valet switch 3 times 1 Chirp - LED 1 flash
Within 3 seconds, turn ignition Off Then On Short chirp, then long chirp
This Action Accesses Feature Bank 2 Alarm Selectable Features
First Press and release the valet switch 1 time 1 chirp = 1 second door lock & unlock
Press transmitter Lock button to change 2 chirps = 3.5 second door lock & Unlock
Press transmitter Lock button to change 3 chirps = 1 sec. lock, dbl 1 sec. unlock
Press transmitter Lock button to change 4 chirps = dbl 1 sec lock, 1 sec unlock
Press transmitter Lock button to change 5 chirps = dbl 1 sec lock, dbl 1 sec unlock
Press transmitter Lock button to change 6 chirps = 350mS unlock. 1 sec lock
or
Second Press and release the valet switch 2 chirps = auto locks off
Press transmitter Lock button to change 1 chirp = auto locks on
or
Third Press and release the valet switch 3 chirps = auto unlock off
Press transmitter Lock button to change 1 chirp = auto unlock drivers door only
Press transmitter Lock button to change 2 chirps = auto unlock all doors
or
Fourth Press and release the valet switch Non Functional On This Unit
or
Fifth Press and release the valet switch Non Functional On This Unit
or
Sixth Press and release the valet switch Non Functional On This Unit
or
Seventh Press and release the valet switch Non Functional On This Unit
or
Eighth Press and release the valet switch 2 chirps = horn chirp output 16mS
Press transmitter Lock button to change 3 chirps = horn chirp output 30mS
Press transmitter Lock button to change 4 chirps = horn chirp output 40mS
Press transmitter Lock button to change 5 chirps = horn chirp output 50mS
Press transmitter Lock button to change 1 chirp = horn chirp output 10 mS
or
Ninth Press and release the valet switch Non Functional On This Unit
or
Tenth Press and release the valet switch 2 chirps = 2 step unlock off
Press transmitter Lock button to change 1 chirp = 2 step unlock on
or
Eleventh Press and release the valet switch 2 chirps = chirp delete from transmitter
inactive Press transmitter Lock button to change 1 chirp = chirp delete from transmitter active
or
Twelfth Press and release the valet switch Non Functional On This Unit
or
Thirteenth Press and release the valet switch Non Functional On This Unit
or
Fourteenth Press and release the valet switch Non Functional On This Unit
or
Fifteenth Press and release the valet switch 1 chirp = ch 5 pulsed output
Press transmitter Lock button to change 2 chirps = ch 5 output as long as button held
Press transmitter Lock button to change 3 chirps = ch 5-10 second output
Press transmitter Lock button to change 4 chirps = ch 5-20 second output
Press transmitter Lock button to change 5 chirps =ch 5 latch on/latch off output
Press transmitter Lock button to change 5 chirps = ch 6 hold 3 sec for pulsed output
or
Sixteenth Press and release the valet switch 1 chirp = ch 6 pulsed output
Press transmitter Lock button to change 2 chirps = ch 6 output as long as button held
Press transmitter Lock button to change 3 chirps = ch 6-10 second output
Press transmitter Lock button to change 4 chirps = ch 6-20 second output
Press transmitter Lock button to change 5 chirps =ch 6 latch on/latch off output
Press transmitter Lock button to change 5 chirps = ch 6 hold 3 sec for pulsed output
or
Seventeenth Press and release the valet switch 1 chirp = ch 7 pulsed output
Press transmitter Lock button to change 2 chirps = ch 7 output as long as button held
Press transmitter Lock button to change 3 chirps = ch 7-10 second output
Press transmitter Lock button to change 4 chirps = ch 7-20 second output
Press transmitter Lock button to change 5 chirps =ch 7 latch on/latch off output
Press transmitter Lock button to change 5 chirps = ch 7 hold 3 sec for pulsed output
or
Eighteenth Press and release the valet switch Non Functional On This Unit
or
Press and release the valet switch or turn the ignition off to: ExitProgrammingMode
or
Turn ignition switch off then on to advance to feature Bank 3:

128-7855
3 of 20
3
To exit program mode, turn ignition off, or press and release valet switch.
RF Programmable Features Bank 3 Is Remote Start Selectable Features:
Feature Selection 1 Chirp 2 Chirps 3 Chirps 4 Chirps 5 Chirps 6 Chirps
1st Defrost Output Pulsed 10 Mins
2nd RF Start Chirp Off On On & Car Finder
3rd RunTime 5 Mins 10 Mins 15 Mins 20 Mins
4th Parking Lights On Steady Flashing
5th Input Check Voltage Tach DBITach
6th Voltage Level >0.5V B4 Start < 0.5V B4 Start
7th Ign. 2 Select Off During Crank On During Crank Same As Accy.
8th Ign. 3 Select Off During Crank On During Crank Same As Accy Same As Starter
9th Diagnostics Off On
10thCrankTime 0.8 Sec 1.0 Sec 1.5 Sec 2.0 Sec
11th Gas/Diesel Gas Diesel 10 Diesel 15 Diesel 20
12th Transponder O/P While R/S On During Start Until Ign. Off
13th Temp Start Not Available
14th Crank Averaging Averaging PresetTime
Note: When averaging, the engine must be started 4 times with the key to be effective.
15th R/S Shock Not Available
16th Turbo Select Off 3 Mins 5 Mins 10 Mins
17th Black/Blue (Aux O/P) Single Pulse As Feat #1 Bank 2
When using the RF programmer, enter the program mode as follows:
Turn the ignition on.
Press and release valet switch 3 times;
turn ignition off then on.
Press and hold valet switch for 5 seconds.
Siren chirps 2 times indicating access to RF feature program mode.
To exit program mode, turn ignition off, or press and release valet switch.

128-7855
4 of 20
4
Action System Response
Turn ignition on No response
Press and release the valet switch 3 times 1 Chirp - LED 1 flash
Within 3 seconds, turn ignition Off, On, Off, On Short chirp, then 2 long chirps
This Action Accesses Feature Bank 3 Remote Start Selectable Features
First Press the valet switch one time 1 chirp = defrost output pulsed
Press transmitter Lock button to change 2 chirps = defrost output 10 Mins
or
Second Press and release the valet switch 2 chirps = RF start chirp on
Press transmitter Lock button to change 1 chirp = RF start chirp off
or
Third Press and release the valet switch 2 chirps = run time set for 10 mins
Press transmitter Lock button to change 3 chirps = run time set fro 15 mins
Press transmitter Lock button to change 4 chirps = run time set for 20 mins
Press transmitter Lock button to change 1 chirp = run time set for 5 mins
or
Fourth Press and release the valet switch 1 chirp = parking lights on steady w/RS active
Press transmitter Lock button to change 2 chirps = parking lights flashing w/RS active
or
Fifth Press and release the valet switch 2 chirps = tachometer input checking
Press transmitter Lock button to change 1 chirp = voltage sense input checking
or
Sixth Press and release the valet switch 1 chirp = greater than 0.5 V check before start
Press transmitter Lock button to change 2 chirps = less than 0.5 V check before start
or
Seventh Press and release the valet switch 2 chirps = ign 2 on during crank
Press transmitter Lock button to change 3 chirps = ign 2 same as accessory
Press transmitter Lock button to change 1 chirp = ign 2 off during crank
or
Eighth Press and release the valet switch 2 chirps = ign 3 on during crank
Press transmitter Lock button to change 3 chirps = ign 3 same as accessory
Press transmitter Lock button to change 4 chirps = ign 3 same as starter
Press transmitter Lock button to change 1 chirp = ign 3 off during crank
or
Ninth Press and release the valet switch 1 chirp = diagnostics off
Press transmitter Lock button to change 2 chirps = diagnostics on
or
Tenth Press and release the valet switch 2 chirps = crank time 1.0 sec
Press transmitter Lock button to change 3 chirps = crank time 1.5 sec
Press transmitter Lock button to change 4 chirps = crank time 2.0 sec
Press transmitter Lock button to change 1 chirp = crank time 0.8 sec
or
Eleventh Press and release the valet switch 1 chirp = unit set for gasoline engine
Press transmitter Lock button to change 2 chirps = unit set for diesel engine 10 sec delay
Press transmitter Lock button to change 3 chirps = unit set for diesel engine 15 sec delay
Press transmitter Lock button to change 4 chirps = unit set for diesel engine 20 sec delay
or
Twelfth Press and release the valet switch 1 chirp = transponder output while R/S active
Press transmitter Lock button to change 2 chirps = transponder output during start only
Press transmitter Lock button to change 3 chirps = transponder output until ignition turned off
or
Thirteenth Press and release the valet switch Non Functional On This Unit
or
Fourteenth Press and release the valet switch 1 chirp = crank averaging w/voltage input checking
Press transmitter Lock button to change 2 chirps = preset crank time w/voltage input check
Fifteenth Non Functional On This Unit
or
Sixteenth Press and release the valet switch 1 chirp = turbo timer off
Press transmitter Lock button to change 2 chirps = turbo timer 3 mins
Press transmitter Lock button to change 3 chirps = turbo timer 5 mins
Press transmitter Lock button to change 4 chirps = turbo timer 10 mins
or
Seventeenth Press and release the valet switch 1 chirp = aux o/p Black/Blue single pulse
Press transmitter Lock button to change 2 chirps = aux o/p Black/Blue as alarm feature #1
Press and release the valet switch
or
turn the ignition off to: ExitProgrammingMode
Note : Once you enter the feature programming mode, do not allow more than 15 seconds to pass between steps or the
programming will be terminated.

128-7855
5 of 20
5
This Remote Start System is designed for use with Automatic Transmission Vehicles Only! The unit
provideswait tostart inputforglow plugpre-heat whichwill beusedfor alldiesel applications. Ifthis wire
isnot connected,thenthe unitwill remaininthe Gasolinemode setting, whichwill crankthecar whenthe
RFsignal isreceived withno delay. Regardlessof thevehicle, Gasoline orDiesel, forevery installation,
thevehicle
MUST HAVE a Tach Signal Input, and an Automatic Transmission.
INSTALLATIONOFTHEMAJORCOMPONENTS:
CONTROLMODULE:
Select a mounting location inside the passenger compartment (up behind the dashboard). The mounting
location selected must be within 24" of the ignition switch wiring harness to allow connection of the 6 pin
mainwiring harness.
Becertainthat thechosenlocation willnotinterferewith properoperationof thevehicle. Avoidmounting the
moduleto orroutingthe wiringaround thesteeringshaft/column, asthe moduleorwiring maywrap around
or block the steering wheel preventing proper control of the vehicle. Secure the module in the chosen
location using cable ties or screws as necessary.
NOTE: DoNot MountThe ModuleIn TheEngine Compartment,as itis notwaterproof.
HOOD PIN SWITCH:
Thehood pinswitch includedinthis packageis requiredfor thesafetyshut downof theremote startunit. If
the vehicle is being worked on, this hood switch prevents the remote start activation even if the RF com-
mand to start is issued. This hood pin switch MUST be installed in all applications. Failure to install the
hood pin switch may result in personal injury or property damage. Mount the hood pin switch in an area
under the hood that is away from water drain paths. If necessary, the included brackets may be used to
movethe hoodpin switchaway fromrain guttersor allowmounting tothe firewallbehind thehood seal. In
either case the hood pin switch must be set up to allow the hood to depress the switch at least 1/4" when
the hood is closed and fully extended when the hood is opened. For direct mounting, a 1/4" hole must be
drilled. Carefullycheck behindthe chosenlocation toinsure thedrill willnot penetrateany existingfactory
wiringor fluid lines. Drilla 1/4" holein the desiredlocation andthread the hoodpin switch intoit using a7/
16" nut driver or deep well socket. If using the mounting bracket, first secure the bracket to the desired
locationand securethe hoodpin switch inthe pre-threadedmounting brackethole.
PUSHBUTTONLED SWITCH
Select a mounting location known and accessible to the operator of the vehicle. A dash knockout plug or
front dash panel is desirable as the now Pushbutton LED assembly needs the LED to be visible from the
outsideof thevehicle andwill beused forvalet modes, programming features, programming transmitters,
and for overriding the remote start unit when the vehicle is being serviced. Inspect behind the chosen
locationto insure thatadequateclearance isallowedfor thebodyof theswitch,and alsothatthe drillwillnot
penetrate any existing factory wiring or fluid lines. Drill a 5/16" or 8mm hole in the desired location and
mount the switch by passing the connectors, one at a time, through the panel from the front side and
pressing on the bezel until the switch is fully seated.
This system is to be used in vehicles with AUTOMATIC TRANSMISSIONS only! Although this combina-
tion Keyless Entry/Remote Start unit is a sophisticated system with many advanced features, IT MUST
NOT be installed into a vehicle with a manually operated transmission. Doing so may result in serious
personalinjuryandpropertydamage.
THERECEIVER/ANTENNAASSEMBLY:
TheReceiverAntennaAssemblyprovided withthis unitallows routingfrombelow thedashboard formaxi-
mumoperating range. Choosea locationabove thebelt line(dashboard) ofthe vehiclefor bestreception.
Specialconsiderationsmustbemade forwindshield glassassomenewer vehicles utilizeametallicshielded
window glass that will inhibit or restrict RF reception. In these vehicles, route the antenna toward a rear
windowlocation forbestreception. Securethe antenna withdouble sticktapeprovided. Aftersecuringthe
antenna with tape, we advise also securing a section of the antenna cable to a fixed support. This will
prevent the antenna from dropping down in case the double stick tape is exposed to extreme heat, which
mayloosen itsgummedsurface. Route theconnectortoward thecontrolmodule usingcautionnot topinch
the cable as this will cause poor or no RF reception to the control module.

128-7855
6 of 20
6
IMPORTANT!
DONOTPLUGTHESIX PINMAINPOWER HARNESSORTHEMULTI PININPUT/OUTPUTHARNESS
INTOTHECONTROLMODULEUNTILALLCONNECTIONSTOTHE VEHICLEHAVE BEENMADE. AF-
TER SELECTING YOUR TARGET WIRESAS DEFINED BELOW, DISCONNECT THE NEGATIVE BAT-
TERYCABLEFROMTHEVEHICLE BATTERYPRIORTOMAKINGANYCONNECTIONS.
WIRING THE 6 PIN MAIN POWER HARNESS:
Note: Do not remove the fuse holders from this wire harness. Fuses must be used and located
as close as possible to the power source for adequate protection of the vehicle.
Fused RED w/ WHITE TRACE WIRE: + 12 volt Battery 1 Source
Locate the vehicle battery wire(s) at the ignition switch. Verification: These wires will register voltage in all
positions of the ignition switch. Connect the Red w/White wire to the vehicle's battery wire. This wire
provides power for the control circuit as well as the ignition 1 and ignition 2 relays.
Fused RED WIRE: + 12 Volt Battery 2 Source
Locate the vehicle battery wire(s) at the ignition switch. Verification: These wires will register voltage in all
positionsofthe ignitionswitch. Connectthe Red wiretothevehicle's batterywire. Thiswire providespower
for the start relay and the accessory relay. IMPORTANT!
ITISTHERESPONSIBILITYOFTHEINSTALLINGTECHNICIANTODETERMINETHELOADFACTOROF
THEVEHICLESELECTRICALCIRCUITSWHENTHEVEHICLEISRUNNINGANDTOADEQUATELYFUSE
THETWO POWER WIRESBASED ONTHATLOAD. IFTHEVEHICLE, RUNNINGUNDER LOAD WITH
THEAIRCONDITIONER, HEATERBLOWER MOTOR,ANDACCESSORIES EXCEEDS24AMPSCON-
TINUOUS,WE RECOMMENDTHATTWO FUSES BEUSEDINCOMBINATIONONEACHPOWERWIRE
ASSHOWNBELOW. FORADDITIONALINFORMATIONSEETECHUPDATEISSUED9/30/96.
YELLOW WIRE: StarterOutput
Careful consideration for the connection of this wire must be made to prevent the vehicle from
starting while in gear. Understanding the difference between a mechanical and an electrical
Neutral Start Switch will allow you to properly identify the circuit and select the correct installa-
tion method. In addition you will realize why the connection of the safety wire is required for all
mechanical switch configurations.
Failure to make this connection properly can result in personal injury and property damage. In all installa-
tions it is the responsibility of the installing technician to test the remote start unit and assure that the
vehicle cannot start via RF control in any gear selection other than park or neutral.
Inbothmechanical andelectricalneutral startswitch configurations,theconnection oftheYellowwire will be
madeto thelowcurrent startsolenoidwire ofthe ignition switchharness. This wirewillhave +12voltswhen
the ignition switch is turned to the start (crank) position only. This wire will have 0 volts in all other ignition
switch positions.
NOTE: This wire must be connected to the vehicle side of the starter cut relay (when used). For the
electrical neutral switch configuration, this connection must be made between the starter inhibit
relay, (when used)and theneutral safety switch as shownin thefollowing diagram.
Failure to connect this wire to the ignition switch side of the neutral safety switch can result in personal
injuryand propertydamage.

128-7855
7 of 20
7
SEENEUTRALSTARTSAFETYTESTFOR FURTHER DETAILS.
BLUE WIRE: Ignition1 Output
Connect this wire to the ignition 1 wire from the ignition switch. This wire will show +12 volts when the
ignitionkeyis turnedtothe tothe"ON"or "RUN"andthe"START"or CRANK"positionsand willhave0volts
when the key is turned to the "OFF" and "ACCESSORY" positions.
ForDieselApplications, thiswire must be connected tothe ignitioncircuit thatpowers theglow plugsif the
vehiclerequiresglow plugpre-heating.
GREEN WIRE: Ignition2Output
Connect this wire to the ignition 2 wire from the ignition switch. This wire will show + 12 volts when the
ignition key is turned to the "ON" or "RUN" position and is some cases the "START" or CRANK" position.
This wire will show 0 volts when the key is turned to the "OFF" and "ACCESSORY" positions.
NOTE: Seeprogramming informationconcerning thiswireto allowoutput duringthe "START" mode.
VIOLET WIRE: AccessoryOutput
Connect this wire to theAccessory wire from the ignition switch. This wire will show + 12 volts when the
ignitionswitch isturnedto the "ACCESSORY"or "ON"and"RUN" positionsand willshow0 voltswhen the
key is turned to the "OFF" and "START" or "CRANK" positions.

128-7855
8 of 20
8
WIRING THE 4 PINALTERNATE IGNITION HARNESS
ORANGE/BLACK Wire: ParkingBrake Input
This wire is used only when the turbo timer mode, Bank 3, feature # 16 is selected ON. This input insures
thatthevehicleparkingbrakeisappliedwheneverthevehicleissetupforandtheturbotimercircuitisused.
Thisinputmustswitchtogroundwhenthevehicle'sparkingbrakeisapplied.ConnecttheOrange/Blackwire
tothenegative outputofthevehicle's parkingbrakeswitch.
RED/BLACK Wire: + 12 Volts Input
Note: The Red/Black and Pink are dry contacts and may be used for negative switching when necessary.
Connecting the Red/Black to chassis ground will result in Pink being ground when the R/S is activated.
Thisinputistobeconnectedtoaseparate,(OtherthanthewireRedorRed/Whiteisconnectedto),constant
on+ 12 voltsource which willsupply +12 volt powerto the additional ignition output,(Pink), wire. Connect
this wire to a separate + 12 Volt source.
PINK Wire: Additional Ignition Output
Thiswirecan be usedasanadditional +12Voltignitionoutput suppliedbytheRed/Black wire. Thisoutput
can be selected to be on or off during the start cycle. (See feature bank 3 selection # 8) Connect this wire
to the third ignition circuit in the vehicle and set the selectable feature # 8 of Bank 3 according to the way in
whichthevehicle'signition switchoperates.
Note: Do not remove the fuse holders from this wire harness. Fuses must be
used and located as close as possible to the power source for adequate protec-
tion of the vehicle.

128-7855
9 of 20
9
WIRINGCONNECTIONS: 12 Pin Input/OutputHarness
Black Wire: Chassis Ground Source. Connect the Black wire to a known vehicle ground source or to a
solidclean metal partof the chassis. Be certain toremove any paintor greaseand secure thiswire witha
self-tappingscrew andringterminal.
GRAYWIRE:NegativeInhibitInput1
ConnecttheGRAYwiretothepreviouslymountedhoodpinswitchprovided. Thiswirewillberoutedthrough
the firewall into the engine compartment. It is necessary to use an existing grommet when passing wires
throughthe firewall toprevent short circuiting.This isan important safetyfeature of theSystem, failure to
use this feature can result in serious injury. Route the wire to the pin switch and connect it using the bullet
connectorprovided.
GRAYw/BLACKTRACERWIRE:NegativeInhibitInput2
Anytimethegrayw/blacktracerwireisgrounded,theRemoteStarterwillstopoperating,evenifthesignal
isreceivedfromthetransmitter.
If the brake light switch in the vehicle switches ground to the brake light circuit, connect the Gray w/ Black
tracewire tothe outputof thebrake lightswitch. If thebrake lightswitch inthe vehicleswitches +12Volts,
do not use the Gray w/ Black wire; see Brown w/ Black tracer wire.
BROWNWIRE:PositiveInhibitInput1
Any time + 12 Volts is applied to the Brown wire, the Remote Starter will stop operating, even if the signal
isreceivedfromthetransmitter.
Ifthevehiclehasafactoryinstalledhoodpinswitchandthatswitchprovides+12Voltstoanunderhoodlight,
the Brown wire can be connected to the existing pin switch.
BROWN w/ BLACK Tracer Wire: Positive Inhibit Input 2
Anytime+12VoltsisappliedtotheBrownw/Blacktracerwire,theRemoteStarterwillstopoperating,even
ifthesignalisreceivedfromthetransmitter.Ifthebrakelightswitchinthevehicleswitches+12Voltstothe
brakelightcircuit,connectthe Brown w/Blacktracewiretotheoutput ofthe brakelight switch.Ifthebrake
light switch in the vehicle switches ground, do not use the Brown w/ Black wire; see Gray w/ Black tracer
wire. Brake Switch Positive Shutdown Detail

128-7855
10 of 20
10
YELLOW w/ BLACK Tracer Wire: + 12 Volt Alarm By - Pass Output
NOTE: You must disconnect the ignition input of the alarm from any other wire that it is presently connected
to in the vehicle.
Thiswire providesa+ 12Voltoutput whentheignition key isturned to the“ON” position, and0 Volts whentheignition
key is “OFF” and when the vehicle is running under the control of the remote starter.
This wire should be connected to the ignition input of the alarm system.
The Yellow w/ Black wire output will allow you to remote start the vehicle while leaving the alarm armed, and to lock/
unlock the doors while running under control of the remote start unit.
(2) WHITE Wires: Parking Light Flasher
These wires are the COMMON and NORMALLY OPEN contacts of the on-board parking lamp relay.
If the vehicle's parking lights are a +12 volt switched system, connect (1) of the White wires to a fused (15A max.)
+12 volt battery source, and connect the second White wire to the vehicle's parking light wire.
If the vehicle's parking lights are a chassis ground switched system, connect (1) of the White wires to a chassis
ground source, and connect the second White wire to the vehicle's parking light wire.
LIGHT BLUE Wire: Ignition 3 / Shock Disable Output
This wire provides a 300mA ground output that becomes active 3 seconds before the Remote Start Unit initializes,
and remains grounded while running plus an additional 4 seconds after the Remote Start Unit turns off. In all of
the applications described below, a relay will be required. The Light Blue wire can be used to accommodate the
following situations:
A. Shock Sensor By Pass:
If there is Shock Sensor used with an alarm system and it is not shunted during the Remote Start activation
period, then vibration from the running vehicle can cause the alarm to trigger. In this case, connect the Light
Blue Wire to terminal #86 of a external relay. Connect terminal #85 of the relay to a fused + 12 volt battery
source. Cut the shock sensor trigger wire and connect one end of the cut wire to terminal #30 and the other end
of the cut wire to terminal #87a. Just before the Remote Start unit is activated, the relay contacts will open,
preventing the shock sensor's operation until the Remote Start unit shuts off.
B.Ignition 3Output:
Some newer vehicles use a third ignition wire, which is required to start and keep the vehicle's engine running.
If this is the case, connect the Light Blue wire to terminal #86 of an external relay. Connect terminal #30 & #85
to a fused + 12 volt battery source rated for a minimum of 25Amp. Connect terminal #87 to the third ignition wire
in the vehicle.
Switch

128-7855
11 of 20
11
C.GM VATSKey Override:
If the vehicle has the General Motors VATS system installed, you will need to bypass the system while the vehicle
is operating under the control of the Remote Start Unit. To Do This;
1. Measure the resistance of the resistor pellet on the ignition key then select a resistor within 5% of the key's
value from the resistor pack supplied.
2. Locate the pair of VATS wires in the vehicle, usually a pair of thin gauge wires running from the ignition switch
to the VATS control module.
NOTE: These wires are typically White w/ Black trace and Violet w/ Yellow trace, however in later model Cadillacs,
they are run through an orange sleeve, and are either both Black, both Yellow, or both White wires. Consult
the factory service manual for additional information.
3. Connect the Light Blue Wire from the Remote Start Unit to terminal #86 of an external relay. Connect terminal
#85 of the relay to a fused + 12 volt battery source.
4. Cut (#1) wire (as shown), and connect the ignition switch side of the cut wire to terminal #87a of the relay.
Connect the other side of the (#1) wire to terminal #30.
5. Connect the previously selected resistor from terminal #87 to the second (#2) wire (as shown).
NOTE: The above information and following diagram is for the GM VATS system only. For GM PASS LOCK System
you will require theAudiovox AS-PASS II Module.
General Motors VATS By-Pass Diagram
Tachometer Input Wiring Detail
GREEN/ORANGE Wire:TachSensor Input
This wire will continually monitor the engine tach rate while the unit is under power of the Remote Start module.
This wire will be routed to the vehicle ECM tach input or through the firewall into the engine compartment and
connect to the negative side of the ignition coil. This Remote Start unit learns the tach rate of the vehicle and in most
cases will operate properly from one multi coil pack regardless of the number of cylinders. If the vehicle has a
single coil unit for each cylinder, it may be necessary to connect this wire to more than one cylinder for proper tach
reference. See multi coil wiring detail shown later in this manual for additional information.

128-7855
12 of 20
12
WIRING THE 4 PIN AUXILIARY OUTPUT HARNESS
Theauxiliary 4pin connectorprovides lowcurrent outputs to control variousfunctions inthe vehicleduring
different stages of the Remote Start unit's operation. Understanding these outputs and the time in which
theyoccur willallowyou todetermineif theyare neededforthe particularvehicleyou areworking onaswell
as how to use them.
Black w Blue Trace Wire: Pulsed Ground Output Before Start
The Black w/ Blue Trace wire will provide a 1 second 300 mA pulsed ground output 1.5 second before the
remotestartunit activatesas wellaswhen thetransmitter isused todisarm thesystem. Typicaluse forthis
output would be to disarm a factory theft deterrent system to prevent false triggering of the factory alarm
when the remote start unit engages or when the transmitter is used to unlock the doors.
Black w/ Light Green Trace Wire: Pulsed Ground Output After Start
TheBlackw/ LightGreenTrace wirewillprovidea 1second300mA pulsedgroundoutput after thevehicleis
started under control of the remote start unit. Typically this wire will be used to re-lock the vehicle doors if
the doors unlock automatically when the factory anti-theft system is disarmed.
Black w/ Red Trace Wire: Pulsed Ground OutputAfter Shutdown
TheBlackw/ RedTracewire willprovidea 1second300 mApulsedground output aftertheremote startunit
shuts down. This output will occur regardless of whether the circuit times out or is manually terminated.
Typically this output will be used to re-lock the vehicle doors if the doors unlock automatically when the
ignition circuit transitions to off.
Black w/ Yellow Trace Wire: Ground Output During Start (Crank)
The Black w/ Yellow Trace wire will provide a 300 mAground output while the starter output of the remote
start unit is active. This output can be used to activate the Crank Low/Bulb Test wire found in some GM
vehicles. This wire is also referred to as the ECM wake up wire in some Chrysler vehicles.
NOTE: Theoutputs abovearelow currentoutputsand mustbe used witha relayifthe circuit'srequirement
is more than 300 mA.
Push-Button LED Programming Switch Assembly: (2 Pin Blue & 2 Pin White Connectors)
Routethe grayand blackwiresin the2 pinconnectorand theredand bluein thetwopin connectorfrom thepreviously
installed push-button LED programming switch assembly to the control module and plug these into the mating blue
and white connectors on the side of the module.
2 Pin Transponder Control Output: (YellowConnector)
Thisoutput isintended toallow thecontrol ofa transponderbypass interfacemodule ortransponder
bypass relay. The system also allows software selections to control the way in which this output oper-
ates, see remote start feature # 10 for setting this output.
When the unit is selected for output during the start sequence, this output will be active at the same time
Ign. 3 becomes active, and will remain active until the vehicle has started. This will be used for one time
readtransponder circuits.
When the unit is selected for transponder on, this output will become active at the same time ign. 3
becomes active, and will remain active all the time the unit is operational under the control of the remote
start. When the unit is selected for continuous and the vehicle is started via the Remote Start, this
output will become active at the same time ign. 3 becomes active and will remain active until the ignition
in the vehicle goes low. This will allow the unit to be used for continuous read transponders circuits.
Green/Yellow Wire: Diesel Wait To Start Input
The Green/Yellow wire will connect to a diesel vehicles glow plug wire. When the unit receives a start command,
this wire must go to + 12 then to ground to allow the crank sequence to begin. When ignition #1 is activated by the
remote start unit, the glow plug circuit gets energized, (+ 12 volts), when the glow plug circuit of the vehicle drops
the + 12 volts, which effectively grounds the wait to start input, then 500mS later the starter will engage. This wire
can also be connected to the Glow Plug Bulb wire in the vehicle if this bulb wire gets + 12 volts when the ignition
comes on and drops low when the glow plug circuits temperature is reached. Be sure to fuse the wire with a 1 Amp
Fuse when connecting to a high current circuit such as a factory glow plug wire. The fuse should be installed as
close to the high current wire as possible. If you are installing this unit in a Gasoline vehicle, this wire is not used.
NOTE: If the Glow Plug sense wire, Green/Yellow is connected, this wire will have priority over the setting of feature
Bank 3 Feature #11.

128-7855
13 of 20
13
5PinAccessoryOutputHarness
Dark Blue Wire : Delayed 300 mA Pulsed Output/Channel 3
Thedarkbluewirepulses toground viaan independentRF channelfrom thekeychaintransmitter. Thisis
a transistorized, low current output, and should only be used to drive an external relay coil.
Thisoutputisactivatedbythesametransmitterbuttonthatisusedtoactivatetheremotestartfunction. Press
andholdthetrunk/keybuttontoactivatethistrunkreleaseoutput,orpressandreleasethetrunk/keybutton
two times within 2 seconds to activate the remote starter.
WARNING:Connectingthedarkbluewiretothehighcurrentswitchedoutputofthetrunkreleasecircuitsand
some remote start trigger inputs, will damage the control module.
Connectthedarkbluewiretoterminal86oftheAS-9256relay(orequivalent30Aautomotiverelay),connect
terminal85toafused+12voltsourceandwiretheremainingrelaycontactstoperformtheselectedfunction
desired. Channel 3 Relay Wiring Detail
Green w/ Black Trace Wire: 300mA Latched Channel 4 Output
TheGreenw/ BlackTracewire suppliesa 300mA switchedoutputwhenever channelfourof thereceiveris
accessed. Pressing the pre-programmed transmitter button(s) will access channel four and will remain
active, for up to 20 seconds, as long as the transmitter button(s) is held. This is a low current output and
mustbe connectedto a relay to supplypower tothe deviceyou intendto control. ConnectGreen w/Black
Trace wire to terminal #86 of a VF45F11 P&B relay or equivalent. Connect terminal #85 of the relay to a
fused+ 12 voltsource. Connect thecommon, normally open,and normallyclosed contacts ofthe relayto
performthe selectedfunction ofthe channel4 output.
NOTE: Thiswire alsocan be usedfor defrostactivation asdictated bythe settingof feature# 1 ofBank 3.
Anytimethevehicle isrunningundercontrol oftheRemoteStartandChannel 4isactivated,then dependent
on the selection of this feature, Green/Black will be activated as a pulse for 1 second, or for 10 minutes.
Note this wire will not operate when the vehicle is running under the power of the ignition key, only while
under the control of the remote start or if not used for defrost then an output will occur as indicated above.
WARNING ! Connecting the Dark Green w/Black trace wire to any high current switched out-
put (300mA max.) will damage the control module.
Lt Blue/Green Wire : DELAYED 300 mAPULSED OUTPUT / CHANNEL5
The light blue/green wire pulses to ground via an independent RF channel from the keychain transmitter.
This is a transistorized, low current output, and should only be used to drive an external relay coil.
WARNING: Connecting the light blue/green to the high current switched output of trunk release circuits,
some remote start trigger inputs, will damage the control module.
Connectthe lightblue/green toterminal 86of theAS -9256 relay(orequivalent 30Aautomotiverelay) and
wire the remaining relay contacts to perform the selected function of channel 5.
Lt Blue/Black Wire : DELAYED 300 mAPULSED OUTPUT / CHANNEL6
The light blue/green wire pulses to ground via an independent RF channel from the keychain transmitter.
This is a transistorized, low current output, and should only be used to drive an external relay coil.
From2Pin

128-7855
14 of 20
14
WARNING: Connecting the light blue/black to the high current circuits, will damage the control module.
Connect the light blue/black to terminal 86 of theAS - 9256 relay (or equivalent 30Aautomotive relay) and
wire the remaining relay contacts to perform the selected function of channel 6.
Blue/Red Wire : DELAYED 300 mAPULSED OUTPUT / CHANNEL7
Thelightblue/red wirepulsestoground viaanindependent RF channelfromthe keychaintransmitter.This is
a transistorized, low current output, and should only be used to drive an external relay coil.
WARNING: Connecting the light blue/redto the highcurrent circuits,will damage thecontrol module.
Connectthe light blue/redtoterminal 86oftheAS- 9256relay(or equivalent30Aautomotiverelay) andwire
the remaining relay contacts to perform the selected function of channel 7.
3PinInput/OutputHarness:
Dark Blue/Black Trace Wire: External Trigger Input
The Dark Blue/Black trace wire allows the remote start unit to be activated from an external source. The
intent of this wire is to allow the unit to be controlled from a "POSSE/CAR-LINK" paging system or similar
device. Whenthis wirereceives aground pulse,the unitwill startthe vehicle.Connect thiswire toa ground
pulsed output from the controlling circuit.
Green w/ White Trace Wire: Entry Illumination Ground Output
This wire provides a 30 second ground output (300 mA Max.) whenever the remote is used to unlock the
doors . This wire should be connected to an external relay, and wired to the vehicles interior entry lighting
wheneverthe optionalInterior Illuminationcircuit isdesired. See belowfor relaywiring details.
Black w/ White Trace Wire: 300 mAHorn Output
The black w/ white trace wire is provided to beep the vehicle’s horn. This is a transistorized low current
output, and should only be connected to the low current ground output from the vehicle’s horn switch.
If the vehicle uses a + 12 VDC horn switch, then connect the black w/ white trace wire to terminal 86 of the
AS 9256 relay ( or an equivalent 30 Amp automotive relay ), and connect relay terminal 85 to a fused
+12 VDC battery source. Connect relay terminal 87 to the vehicle’s horn switch output, and connect relay
terminal 30 to a fused + 12 VDC battery source.
Entry Illumination Detail
3 Pin Antenna/Receiver Connector: (White Connector)
Plugthepreviously routedantennaconnector fromtheantennareceiver assembleintothe matingconnector
ofthecontrol module. Thisconnectorsupplies12 volts,groundand RFdatafromthe antennareceivertothe
remote start module. Be certain this connector is firmly seated making good contact to the control unit.
TIMEDSTARTPROGRAM:
TheRemoteStartunithastheabilitytostartthevehicleautomaticallyattimedintervals. Thisfeatureisuseful
inextremelycoldclimateswherestartingtheengineistheonlymeanstokeepthebatterychargedandfluids
warm. Theoperatorhastheoptiontohavetheunitstartevery2or4hoursforamaximumof48hours. Factory
preset is to start at 4 hour intervals. To select 2 or 4 hour automatic start timer:
1. Start By Holding the Push Button Switch On.
2.While Holdingthe Push ButtonSwitch TurnThe IgnitionSwitch OnThen Off
3a) Within 10 seconds of turning the ignition switch off, Release and then Push On and release the Push
Button Switch 2 times holding it on the second time until the siren and or lights flash and chirp 2 times
indicating that the 2 Hour Start Interval has successfully been set. or
3b) Within 10 seconds of turning the ignition switch off, (Step 2) Release
and then Push On and release the Push Button Switch 4 times holding it on the fourth time until the siren
and or lights flash and chirp 4 times indicating that the 4 Hour Start Interval has successfully been set.

128-7855
15 of 20
15
NOTE: Once selected, 2 or 4, this timer interval will remain in memory until it is manually changed. To
change,theabovesequencewillhavetobefollowed.
TIMEDSTARTOPERATION:
Tobeginthestarttimer,within10secondsofturningofftheignitionswitch,activatetheRFcommandtostart
2times.(Pressthetrunk/keybuttonfourtimes). Thelightswillflashandthesirenwillchirp4times.Indicating
timedintervalmodehasbeeninitiated.Thevehiclewillautomaticallystartevery2or4hoursasprogrammed.
To cancel the timed start mode start the vehicle either by RF or by the ignition key.
Programming Tach Rate:
NOTE: Allapplicationsrequire thattachbe programmed.
Theunitwillnotoperateunlesstachisprogrammed. Ifanattemptismadetostartthevehicleviatheremote
startwithoutfirstprogrammingtach,theunitwillflashtheparkinglights7timesindicatingtachhasnotbeen
learnedandstored. Ifthetachrateisnotproperlyprogrammedtothespecificvehicle,theunitmaynotrealize
that the vehicle is running in certain instances and could re-engage the starter motor.
TheRemoteCarStarterwilllearnthetachrateofmostvehiclessingleignitioncoils,multiplecoilpacks,and
or single injector. To learn tach;
1. Turn the ignition key to the ON position.
3. Press and release the program push-button switch 3 times.
4. Immediately turn the ignition key OFF.
5. Hold the program push-button switch ON, then start the vehicle using the ignition key.
6. When the unit senses the tach signal, the parking lights will begin to flash.
7. Releasetheprogrampush-buttonswitch. Theparkinglightswillturnonfor3secondstoindicatethatthe
tach signal is stored and the unit is now out of the program mode.
3.Diagnostics:
1. Be sure that programmable feature number #9 is set to the "Diagnostics On" mode.
2. Press and hold the program push-button switch on, then turn the ignition key to the "ON" position.
3. Thelightswillflashandthenumberofflasheswillindicatethereasonforshutdownonthelastremotestart
attempt. The indications are as follows.
1 Flash 5, 10, 15, or 20, minute run timer expired.
2Flashes LoworNotachsignalreceived.
3Flashes Positive input shutdown.
4Flashes Control switchwas movedto"Off" position.
5Flashes RFShutdowncommandreceived.
6Flashes HighRPM signal overspeedshutdown.
7Flashes TachhasNOTlearned.
8 Flashes Negativeinputshutdown
Multi Coil Pack Adapter: (Optional)
Themulti coilpackadapter,(P/N 136B1400), isdesigned forusewith vehiclesthat donotrespond tosingle
coil tach programming. Although the tach resolution of this circuit is designed to interface direct with most
vehicles,there maybe an occasion where thefollowing circuitmay berequired.
To use the adapter, the Green/Black wires must connect to the negative side of the ignition coil(s).
1. For vehicles utilizing independent coils per cylinder, connect the three Green/Black leads to alternate
coils.To achieveoptimumperformance thecoil signalsmustbe evenlydistributed. Thisis accomplished
by first mapping out the firing order of the engine in groups of as indicated below. Draw a circle around
any of the columns. The Green/Black wires should be connected to the negative (-) terminal of the
respectivecylinder numberwhich appearsin any ofthe circles.
2. For vehicles utilizing 2 cylinder firing per coil pack, connect Green/Black to the tach side of each coil
pack. For 8 cylinder, four coil systems, connect to any of the three coils.
3. Connect theYellowwire toa+12 voltignition1 source. This wirewillhave +12voltswiththe ignitioninthe
on and start position and have 0 volts with the ignition in the off position.
4. Connectthe Green wireto the(Green) or (Orange/Green)tach inputof theAudiovox remote startunit.

128-7855
16 of 20
16
TESTINGYOUR INSTALLATION:
WARNING!! Thefollowing proceduremust beperformed after theinstallation of anAudiovoxRemote
StartDevice. Itis theresponsibility oftheinstallingtechnician tocomplete thesetests. Failuretotest theunit
inthe followingmanner mayresult in personal injury, propertydamage, orboth.
HOOD PIN SAFETY SHUT DOWN:
Theintention ofthehood pinsafetyshut downisto preventtheRemote Start unitfrombeing activatedwhilea
mechanicor vehicleowneris performingnormalroutine vehiclemaintenance.
To test the integrity of this circuit:
1. With the driver's window in the down position, start the vehicle using the RF transmitter.
2. Reach inside the car and pull the hood release.
3. Raise the hood and confirm that the remote start unit shuts down.
If the unit fails this test, recheck your pin switch connection to the Gray/Black wire of theAudiovox Remote
Start Unit. WARNING!!
DONOT RELEASE THISVEHICLE TO THE CONSUMERUNTIL YOU CONFIRM THE
OPERATION OF THE HOOD PIN SAFETY SHUT DOWN FEATURE.
MANUALSHUTDOWN / ENABLECIRCUIT:
Theintent ofthe manualshut down/ enablecircuit is toallow thevehicle operatorto preventoperation ofthe
RemoteStartUnit regardlessof theRF transmitteroperation.
1) With the system disarmed/unlocked, and the ignition switch off Press and Hold the PRLED on.
2) Turn the ignition switch on, off, on, off, on, off.
3) The LED begins to flash two short flashes followed by one long flashes and continues this pattern until
returnedto normalmodeof operation.
This puts the unit into the R/S Override mode indicating that the remote start is in the service mode and will
not start from RF or any other input Posse or otherwise.
ToExit R/SOverrideMode
1) With the system disarmed, Press and Hold the PRLED on.
2) Turn the ignition switch on, off, on, off, on, off.
3) The LED turns off indicating that the R/S unit is fully functional one again.
WARNING!!
DONOT RELEASE THISVEHICLE TO THE CONSUMERUNTIL YOU CONFIRM THE
OPERATION OF THEMANUALSHUT DOWN /ENABLE FEATURE.
NEUTRALSTART SAFETYTEST:
The intent of the neutral start switch is to prevent the vehicle from starting while the gear selector is in any
position other than Park, or Neutral. When installing a Remote Start Device, it is imperative that theYellow
Starter wire be connected to the ignition switch side of the Neutral Start Switch. Consideration for the
placementof astarter inhibitrelay isimportantas well,and shouldbe connectedto theignition switchsideof
the Yellow Start Wire.
To test the integrity of the Neutral Start Safety Circuit:
1. Set the vehicle parking brake.
2. Blockthe drivewheels topreventvehicle movement.
3.Temporarilydisconnect theBrown/Black positiveshut downwire fromthe vehicle'sbrake switch.
4. Sitting in the vehicle, start the engine using the vehicle's ignition key.
5. Step on the brake pedal and shift the gear selector into reverse.
6. Allowthe transmission toshift. When you feelthe enginepull, do notmove the gearselector just turnthe
ignition switch off. DO NOT attempt to remove the key.
7. Keepingthe brakepedal depressed,activatethe RFtransmitter inan attemptto startthevehicle. The car
should not start.
8. Repeat the above test this time move the gear selector to the drive position. If the unit attempts to start,
failingthis test,recheck yourYellow Wire'sconnection.This wire mustbe connectedto theignition switch
side of the Neutral Start Switch. If the vehicle you are working on does not have an Electrical Neutral
Safety Switch, it will be necessary to reconfigure the Remote Starts Wiring to accommodate this vehicle.

128-7855
17 of 20
17
The information concerning the Mechanical Neutral Safety Switch provided below will help you to deter-
mine if the vehicle you are working on has this type of safety switch and will provide alternate wiring
methods to accommodate this situation. WARNING!!
REMEMBERTORECONNECT THE BROWN/BLACK WIRE TEMPORARILY
DISCONNECTEDIN STEP 3.
DO NOT RELEASE THIS VEHICLE TO THE CONSUMER UNTILYOU CONFIRM THE OPERATION OF
THENEUTRALSAFETYSTARTFEATURE.
MECHANICALNEUTRALSAFETYSWITCHCONSIDERATIONS:
Mechanicalneutral safetyswitchconfigurations differslightlyin thatthey do notoffer thesamelevel ofsafety
when installing a remote start device. Often when the ignition switch is turned off while the gear selector is
in any position other than park or neutral, the mechanical function will not allow the key to be turned to the
startposition orberemovedfrom theignitioncylinder.Thisconfigurationpreventsmechanicaloperationwhile
the vehicle is in gear but offers no consideration for electrical operation. Because of this potential problem,
thisinstallation requiresthe additionalconnection ofasafety wirefrom theremote startdevice tothevehicle
Park/NeutralECMInput orthevehiclekey insensor. Thisconnectionwillprevent remotestartoperationifthe
key is left in the ignition switch regardless of the gear selector position.
PARK / NEUTRAL ECM INPUT:
ThePark / NeutralECM inputis the preferredmethod ofinstallation. This notonly maintains theintegrity of
thefactory circuit,itis alsothe easiesttoinstall, providingthe vehicleyouare workingon hasthisECM input.
Theinstallation requiredfor thisapplication (shownbelow),indicates theslight reconfigurationof thecontrol
switchwiring andthe additionofa 4000series diode. Shownis atypical GM Park/NeutralECM inputcircuit.
To connect theAudiovox remote start unit to the GM Park / Neutral ECM input:
1. Locatethe Orange/ Blackreference wire inthe "C2"connector foundat theECM inGM BBody vehicles
or,locatetheequivalent referencewirein thevehicle youareinstalling theAudiovox RemoteStartUnitin.
2. Connectthe Cathode, (Striped) end, ofa 4000 series diode tothis reference wire.
3. Connect theAnode, (Non Striped) end, of the diode to one side of the Remote Start enable switch.
4. Connect the other side of the enable switch to the Black/White enable input wire of the Remote Start unit.
Thereference diagrambelow showsa typical GMB BodyECM referencewire andhow it isto beconnected
to the Remote Start Unit.
KEYIN SENSOR CIRCUITS:
If the vehicle you are working on does not have or you cannot locate the ECM reference wire, there are two
alternatives available. Although not preferred, the vehicle Key In Sensor may be reconfigured to allow a
marginof safetyand will preventthe vehiclewith aMechanical NeutralStartSwitch fromstartingin gear.
AUDIOVOXADVISESTHATYOUMAINTAINTHEFACTORYCIRCUITWHENEVERPOSSIBLE. Thefollow-
ing two circuits may be used only if the above circuit is not available.
NOTE: When completing an installation using either of the following key in sensor circuits, if the operator
insertsthe ignitionkey while thevehicle is runningunder thecontrol of theRemote Start,the vehicle
will shut down. This must be explained to the operator as it is in contrast to the normal operation of
a vehicle utilizing an electrical neutral start switch and is inconsistent with the operator's manual.
Additional information concerning Key In Sensor methods 1 & 2 are listed below and should be reviewed
beforeconsidering eitheralternative.

128-7855
18 of 20
18
Method 1 willallow thesafety requiredfor theremote startunit andprevent thevehicle fromstarting while
in any gear other than Park or Neutral while the key is in the ignition cylinder. However, if the key is left in
theignition switchand thedoor is leftopened, theadded relaywill beenergized causing a150mA drainon
the battery.
Method 2 willallow thesafety requiredfor theremote startunit andprevent thevehicle fromstarting while
inany gearother thanPark orNeutral whilethe key isin theignition cylinder. However, theoriginal factory
keyin chimemodulewill notalert theownerthat thekeyhas beenleft intheignition switch. Inaddition,this
may also effect other warning tones such as the light on reminder.
These situations should be carefully considered before altering the vehicle's wiring and must be fully ex-
plainedto theconsumer.
Circuits may be used only if the above circuit is not available.
METHOD1
To connect to the key in sensor as shown in method 1:
A. Locate the control wire that connects the drivers door pin switch to the key in sensor switch.
B. Cut this wire and connect the ignition cylinder side to chassis ground.
C. Locate the key in sensor switch wire that connects the chime module to the ignition cylinder .
D.Cut this wireand connect theignition cylinder sidetoterminal #30ofa P&BVF45F11 orequivalentrelay.
E. Connect the cathode (striped) side of a 4002 series diode to this same wire, and connect the (non
striped) side to the negative shut down safety wire (Gray / Black) of theAudiovox Remote Start Unit.
F. Connect terminal #86 of the relay to a fused +12 volt constant battery source.
G. Connect terminal #87 of the relay to the Chime Module side of the previously cut wire in step D.
H.Connect terminal#85 ofthe relayto the DriversDoor sideof thepin switchwire previouslycut instepB.
NOTE: Asecond 4002series diodemay berequired tomaintain theintegrity ofthe hoodopen, shutdown
circuit. If this is the case, it must be installed as shown in the diagram above. The anode (Non
Striped) side must be connected to the Gray/Black wire of the Remote Start Unit. The cathode
(Striped) side must be connected to the hood pin switch. If the hood pin switch is also used for an
alarmtrigger input,be certainto usethe dualdiode assemblypackagedwiththeAudiovoxRemote
StartUnit as shownfollowing.
METHOD2
To connect to the key in sensor circuit as shown for method 2:
A. Locate the control wire that connects the drivers door pin switch to the key in sensor switch.
B. Cut this wire and connect the ignition cylinder side to chassis ground.
C. Locate the key in sensor switch wire that connects the chime module to the ignition cylinder .
D.Cut thiswire andconnect the ignitioncylinder sideto theRemote StartNegative SafetyShut downWire
Gray/Black,using a 4002series diodeas shown above.

128-7855
19 of 20
19
NOTE: A second 4002 series diode may be required to maintain the integrity of the hood open, shut down
circuit. If this is the case, it must be installed as shown in the diagram above. The anode (Non
Striped) side must be connected to the Gray/Black wire of the Remote Start Unit. The cathode
(Striped) side must be connected to the hood pin switch. If the hood pin switch is also used for an
alarmtrigger input,be certainto usethe dualdiode assembly packagedwiththeAudiovox Remote
Start Unit as shown in this installation guide.
AFTERTHECONNECTION OFTHENEUTRALSTARTSAFETYWIREAS INDICATEDINANYOFTHE
PREVIOUSALTERNATECONFIGURATIONS,THISCIRCUITMUSTBETESTEDFOR OPERATION.
Retest by following the steps outlined in the NEUTRALSTARTSAFETYTEST shown in this manual.
4 Pin Upgrade Telematic Module:
Red = + 5 Volts
Black = Ground
White = Data TX
Yellow = Data RX
If used, connect the 4 pin harness from the Telematic one way module kit to the mating port on the
controllingcircuit. NOTE: If usingtheTWO WAYTelematicmodule, onlyGround,TX, andRX are usedon
this port, the + 12 volt supply for the two way module must be sourced separately or the unit will not
operate.
4 Pin Upgrade Data Bus/Flash Logic Module:
Ifyou are usinganAudiovox FlashLogic module,it can beconnected directlyto theAlarm/Remote Start's
controlmodule. Using theBlue4 pinblue,red, black,&white harnessandconnect tothemating connector
on the Alarm/Remote Start control module. Wire the Flash Logic/Data Bus module to the vehicle as
prescribed in it's installation guide.
COMPLETINGTHE INSTALLATION:
Afteryou haveconfirmed theoperation oftheAudiovoxRemote Start unitand testedallthe safetyfeatures
of the system:
1. Ifyou havenot doneso already, placethe redrubber handlecover overthe handleof thecontrol switch
for ease of identification. This will allow your customer to distinguish the Remote Start control switch
fromthe programswitch.
2. Mount the control module up and behind the dash securing it in place with cable ties or screws. Be
certain that the chosen mounting location will not inhibit any of the controls of the vehicle.
3. Securely harness and tie all wiring up and away from all hot and moving parts that they may come in
contact with
underthe dashboard orin theengine compartmentareas.
CAUTION:Particularly avoid the area around the steering shaft and column, as wires can wrap around
these mechanisms and impair thesafe operationof the vehicle.
4. Applythe CautionLabels suppliedwith thiskit toaconspicuous areain theengine compartment. Make
sureto cleanthe surfacebefore affixingthe label.
5. Check the vehicle's wipers, lights, horn, etc.... to insure proper operation.
6. Replace all panels that were removed during installation, and retest the system.
7. Explain all activated features and safety systems associated with Remote Start Unit installed to the
customer.

128-7855
20 of 20
20
© 2006 Audiovox Electronics Corp., Hauppauge, NY 11788 128-7855
