STRUC MUTA Maestral User manual

-20-
STRUC MUTA, Kmetijska mehanizacija d.o.o.
Koroška cesta 51
MUTA 2366
Tel.: 00386 (0)2 87 70-112/113
Fax.: 00386 (0)2 87 70-104
MOTOCULTIVATOR
MAESTRAL
OPERATING MANUALS
CATALOGUE OF SPARE PARTS
ENG
STRUC MUTA, kmetijska mehanizacija d.o.o.
KOROŠKA CESTA 51
2 66 MUTA
SLOVENIJA

1. TECHNICAL SPECIFICATIONS
Engine (detailed information are enclosed
in engine manuals)
4-stroke gasoline or diesel, single cylinder,
air cooled
max power 6,5 kW, max turns 3600 RPM
Clutch dry multidisks (optionally conical)
Speeds (by engine 3600 RPM) 4/3(wheels 4.00x12)
4/3 (wheels 5.00x12)
-I forward and backward
-II forward and backward
-III forward and backward
-IV forward
1,6 km/h
2,4 km/h
5,3 km/h
14,4 km/h
1,8 km/h
3,5 km/h
5,9 km/h
16,1 km/h
Turns of output shaft independent 943 RPM – max
Steering handlebar rotateable for 180°, handles height
adjustable
Wheels 4.00x12 (optionally 5.00x12)
Clutch safety switch engine stop by loosing of steering lever
Blockade of activating rotary tiller by
backward gear
prevents activating backward gear and rotor
simultaneously
Brakes drum brakes (for left and right wheel
separated –parking position)
Weight cca 95 kg gasoline, 115 kg diesel
2. DESCRIPTION OF FUNCTIONS
1. gas lever
2. brake lever (right and left wheel)
3. clutch lever
4. safety switch lever
5. lever for activating the PTO
6. lever for activating forward
or backward gear
7. lever for handlebar adjustment
8. gear lever
9. differential lock lever
-19-
1
2
3
4
5
6
7
8
9
-
2
-

-18-
3. LABELS ON THE MACHINE
4. OPERATING MANUALS
Before use you must read the operating manuals precisely!
The operating manuals will introduce the MAESTRAL and also warn you on
particularity to which you should pay special attention. Because the MAESTRAL is a
working machine what requires also suitable knowledge, qualification to handle with
motor machines. Consideration of the manuals assures safety and faultless operation
of the machine. You will also avoid possible costs because of mishandling or wrong
maintenance of the machine. In that case the machine will be useful help by various
works. In case of buying of spare parts, please see the
-3-

catalogue of spare parts with marked spare parts. In case of machine trouble
please go to nearest authorised service of Tovarna Muta.
WARNING!
When buying the machine please demand confirmed
indemnity bond from the dealer. With confirmed indemnity
bond you carry guarantee intervention into force. When
ordering spare parts please state the machine type, year of
production and code of spare part you are ordering.
5. USE OF MAESTRAL
Motocultivator MAESTRAL is multipurpose machine, in combination with
various attachments is performing particular works like cultivating of land on the
field or in the garden with attached rotary tiller, mowing – haymaking with
attached mowing system and cutter bar, ploughing, transport …
Superiority of the machine is multifunctional, it can perform various works, it
is easy to handle with, light machine regarding to it’s functionality.
Motocultivator MAESTRAL we can use together with attachments, made by
Štruc Management, adapted for use on this machine.
Regarding to the work we adjust also the speed of work. MAESTRAL has a
lot of possibilities in both directions. For harder work conditions we can choose
lower gear, for easy work we can choose higher gear. The work can be done more
efficiently and safe.
6. DESCRIPTION OF INDIVIDUAL FUNCTIONS OF THE
MACHINE
The handle levers on the machine we will describe in position of machine,
when the machine is ready for mowing, that means that in front of you is first the
engine thereafter is gearbox (Pic. 1). For proper functioning of the machine all the
levers should be adjusted properly, only in that case the work with machine is
easy and correct.
Handle bar with steering functions
-adjustment of working height of handle bar you achieve with pushing of lever
No.7 till first position, then raise or lower the handle bar regarding your body
height and attachment you are using (Pic.2)
adjustment of side deviation of the handle bar you achieve also with pushing
of lever No. 7 but till second position then you turn the handle bar to right or left
side (Pic. 11). After releasing the lever the cork should stuck into the
-4-
739492
FLANCHE 779349
ENTRYSHAFT
741127
WASHER A 12X16 CU 779352
MOVINGGEARWHEEL
743209
PLACINGSCREWM8 779353
GEARWHEELIGEAR
743291
GEARBOXCOVERFRONTCPL.II 779354
CONNECTINGRING
743766
SANPRINGINN. 18 779356
GEARWHEELWORKINGSHAFT
743810
CLUTCHWIREROPECPL. 779357
WORKINGSHAFTCPL.
743811
BRAKWIREROPECPL. 779364
SNAILWHEEL
743812
DIFFERENTIALWIREROPE 779365
PINION
743982
SCREW M 8X80 779366
GUIDANCE
744483
ARM17/28 779368
DIFFERENTIALBLOCKADE
746235
CLUTCHFORK 779370
CROSS-SHAPEDSHAFT
751027
LINER 32X25,5X0,2 779373
DIFFERENTIALNBLOCKADELEVER
751440
LINER A 6 779374
DIFFERENTIALNBLOCKADESPRING
753122
BRAKELEVER 779375
DIFFERENTIALNEBLOCKADETAP
753124
DISTANCER 779376
HANDLE
753125
SPRING 779377
LEVER
753126
BLOCKINGELEMENT 779378
LEVERTAP
753569
SPRING 779379
SPRING
754296
HANDCORK2,8X60-SMALL 779380
CONNECTINGRINGLEVER
755743
NUTM 16X1,5 779381
FLANCHEDIF.BLOCKADE
756001
HUB-DRUMCPL. 779386
GEARWHEELBACKWARDGEARCPL.
756142
BEARING 6205 779388
SNAILRING
756145
BEARING 7205B 779389
BRAKEPLATELEFT
756146
BEARING 6204 779575
FASTENERMUTA
756155
BEARING 6202 779576
UPPERCOVER
756441
NUTM 6 779668
SPRINGFORDIF.BLOCKADEHANDLE
756846
WIREROPEHOLDERM6 779669
COVERWASHER
756914
GASLEVERPLATE 779670
CASINGWASHER
756915
HEIGHTREGULATION 779674
OILDIPSTICK
756932
HANDLEDIF.BLOCKADE 779675
ADJUSTABLEFELLYCPL.
757027
ENGINESHIELD-ACME330 779682
HANDLE
757110
ROTATINGPOLEMAESTRAL 779684
WIREROPEHOLDER
757113
HEIGHTREGULATIONLEVER 779688
DIF.BLOCKADEHANDLE
757682
DISTANCELINER47/37/0.25 779691
OILWASHER 16X24X7
757736
SAFETYSWITCH 779692
CORK 5 X20
757737
CLUTCHARM 779696
SPRING
757738
CLUTCHLEVER 779702
PLATEBRAKERIGHT
773127
BALL 6,35 779873
SPRINGP2
773157
LINER B 6 779874
WASHER O 14 X3,2
774086
SCREW M 6X45 779879
SPRINGP1
779346
GEARBOXCASING 779881
ARRESTINGSCREW M12x20,5
779347
BRAKEJAW 779882
HANDLE
-17-

710448
LINER A10 718621
ATTACHMENTCOVER
710479
CORK 4 X20 719198
WHEELCPL.4,00X12-L
710511
SNAPRING INN.52 719293
SAFETYBLOCKADEB4
710525
NUTM6 719294
CORK 5 X30
710526
NUT M8 719769
SUPPORTINGPLATECPL.
710529
NUTM10 719781
HANDLECPL.
710543
LINER A12 719801
SCREW
710567
SCREW M5X15 719803
GEARCHANGEHANDLELEFT
710581
SCREW M8X16 719805
GEARCHANGEHANDLERIGHT
710607
SCREW M10X25 719807
HANDLEFORACTIVATINGP.T.O.
710619
SCREW M10X50 720310
TYRE 4.00-12TP
710695
SCREW M18X1,5 720312
INNERTUBE 4.00-12
710712
SHAFTLEFTCPL. 720629
SNAILSHAFTII.
711106
JOINT 722341
WASHER O 9 X2
711155
AXLESAFETY-DEVICE 8 722647
WIREROPE
711165
RUBBERRING 722652
COVERCASINGCPL.
711189
WIREROPEACCESSORY 722700
COVERMAESTRAL-LAC.
711475
LINER 52/42x0,2 722703
COVERCARRIERMAESTRAL-LAC.
711476
LINER 52/42x0,3 722849
RUBBERBULBA6H
711520
LINER A 8 722928
COVERGEARBOXFRONTII.
711521
LINER A10 724507
ARRESTINGPIN
711687
SCREW M 8X50 724815
STALLSCREWM12X1,5/M12
711688
SCREW M 8X25 725827
GASLEVERPLASTIC
711691
SCREW M 8X35 726149
SPRING
711692
SCREW M 8X22 726152
CARRINGTHORNCPL.
711794
CORK 6m6X16 726278
GEARCHANGEHANDLECPL.
712613
NUTM 12X1,5 726315
ENDARM
713343
CLUTCHCPL. 726329
HANDLEN-NWITHBLOCKADE
713611
P.T.O.SHAFT 726331
LIMITERCPL.
713648
WHEELCPL.4,00X12-D 726333
SCREW M6/8
713649
DIFFERENTIAL-CPL. 726334
SPRING
714076
OILWASHER12X22X7 727268
SCREW M 10X75
714080
OILWASHER15X35X10 727521
SCREW M 6X15
714094
OILWASHER25X52X10 727568
LINER A16
714177
SANPRINGEXT. 14 728465
SANPRINGEXT. 12
715079
LINER B 8 728543
AXLESAFETYDEVICE12
715367
OILWASHER 20X35X7 733869
ENGINEACMEALN330
717131
SHAFTRIGHTCPL. 734760
LINER 24X8,5X6
717306
TRENAILB 6X6X22 738061
SCREW M 8X30
717785
HANDLERED 739011
GASWIREROPE2100/1950
717786
HANDLEBLACK 739446
CLIP210.207
717822
SPRING 739490
CONICGEARWHEEL
717823
FORCESPRING 739491
SHAFTLEFT
groove of dividing part and hole of the thorn, so that the handle bar remains in this
position. For height regulation there are 7 positions available, side deviation has one
position on the left and one on the right side.
-for some works like tillage, transport with trailer, cultivating and ploughing the
machine has to be adjusted properly. That means you must turn the handle bar for
180 degrees. In that case you must dismount all three steering levers. To do that you
must pull out with hand all the corks (Pic. 16). You dismount the levers, rotate the
handle bar and mount the levers back into place (put back the corks!). Check if the
handle bar is locked! For side deviation the procedure is the same like for mowing
position (Pic. 11).
Clutch lever with safety switch
-clutch lever is mounted together with safety switch which prevents running of the
machine when the clutch lever is not pressed. This prevents eventual accidents by
unintentional release of clutch lever (the engine stops). Mechanical principle of
safety switch is blocking the clutch lever when the safety switch is not pressed. By
starting of the motor you must press the clutch lever first and then block the clutch
lever with the button inside the clutch lever holder. Starting of motor is possible
only when the clutch lever is pressed! Start the motor according to enclosed
manuals and pictures for motor.
-when the motor is running you can begin with work. The clutch lever should be used
together with lever of safety switch. When both levers are pressed (Pic. 3) you can
change the gears, drive direction or activate driven attachments (Pic. 8). When all
the levers are in correct position you begin with releasing of the clutch lever slowly
but you are still pressing the lever of the safety switch, which must be pressed all the
working time.
-the clutch is dry conical (optionally is multidisks). The clutch is adjusted correct,
when the clutch lever has 2 – 5mm of free movement.
WARNING!
M OTOR IS NOT RUNNING WHEN THE CLUTCH LEVER AND THE
LEVER OF SAFETY SWITCH ARE NOT PRESSED (P IC . 3)
Brakes
-the brakes are by machines with differential made separately for left and right wheel
and are a support by steering – rotating the machine. Both brakes (left and right)
must be adjusted equal. Locking of brakes – parking position we achieve with
pushing of locking tonguelet into the groove, than remains the brake lever in pressed
position. You unlock the brake with pressing the brake lever again (Pic. 4a and 4b)
-5-
-16-
PARTS OF
MAESTRAL

WARNING!
W HEN THE DIFFERENTIAL LOCK IS ACTIVATED (P IC . 5 B ) BRAKES
ARE NOT WORKING SEPARATELY FOR LEFT AND RIGHT WHEEL – THERE
IS NO STEERING FUNCTION !
Gear changing
-there are 7 gears available on MAESTRAL – 3 forward and 3 backward. Fourth
gear is possible only when the motor is in front and serves only for transport with
trailer or moving the machine to the working place. When we rotate the handle
bar the fourth gear is blocked! We choose the desired gear with lever on the left
side – No.8, the moving direction we choose with lever forward – backward on
the right side of the machine – No.5.
When changing gears you must use the clutch! Reduce the gas and
choose the desired gear with the lever (Pic. 8).
Mounting the attachments
-you mount the attachments on the basic machine with two (2) nuts (Pic. 13, 20)
-when mounting the machine must not run (safety switch released)
-when activating the attachments with lever 5 you must use the clutch (Pic. 8)
-by attachments with quick connection you change the attachments with pulling
out the cork and than change the attachment
Correct False
Pic. 20
-6-
7 1 0 5 2 6
7 4 3 2 0 9
7 4 4 4 8 3
7 1 7 8 2 2
7 1 9 8 0 1
7 2 4 5 0 7
7 2 2 6 4 7
7 4 3 7 6 6
7 5 7 1 1 0
7 2 7 5 2 1
7 1 0 5 2 9
7 1 0 6 1 9
7 1 0 6 0 7
7 1 0 4 4 8
7 1 1 1 6 5
7 7 9 6 9 6
7 5 7 1 1 3
7 5 6 9 1 5
7 1 1 1 5 5
75 6 91 4
72 5 82 7 -(7 11 15 4)
75 6 94 8
77 9 6 82
71 0 4 79
75 3 1 24
75 3 1 26
75 3 1 25
72 2 8 49
75 3 1 22
711 155
75 6 4 41
75 1 4 40
73 9 0 11
71 7 7 86
76 1 2 71
75 6 9 27
77 9 6 84
74 3 8 10
71 0 5 26
74 3 2 09
757 027
711 6 9 2
715 079
719 198 -L
713 648 -D
720 310-tyre
720 312-tube
722 908 -felly
779 777
710 529
710 448
710 607
7 2 7 2 6 8
7 5 7 6 3 5
7 1 8 4 8 4
7 11 5 2 1
7 1 0 5 2 9
7 1 7 7 8 5
7 1 7 7 8 6
7 1 9 8 0 5
7 1 9 8 0 3
7 1 9 8 0 7
7 2 2 7 0 0
722 703
711 1 6 5
711 6 9 1
711 6 9 2
7 11 1 5 5
7 11 1 0 6
7 5 4 2 9 6
(756 053-extension)
726152
743 982
715 079
779 575
757 736 -gasoline
757 324 -diesel
HANDLEBAR,WHEEL,..
743 811
710 567
-15-

-14-
SPECIAL WARNING!
BECAUSE OF MOST FREQUENT USE FUNCTION OF
CHANGING THE MOVING DIRECTION FORWARD –
BACKWARD, YOU MUST HANDLE WITH THIS LEVER
CORRECTLY. WE DO THE CHANGING AS FOLLOWS (SHOWN
ON PICTURES 7,8,9 AND 10): YOU MUST REDUCE THE GAS,
PRESS THE CLUTCH LEVER AND MOVE THE LEVER FORWARD –
BACKWARD GENTLY. WHEN YOU ARE SURE, THE LEVER IS IN CORRECT
POSITION, SLOWLY RELEASE THE CLUTCH LEVER AND ADD THE GAS
WHEN NECESSARY. WHEN CHANGING THE MOVEMENT DIRECTION THE
SPEED OF THE MACHINE IS NOT CHANGED.
The correct adjustment you can check on the gearbox, where the limiter is
mounted. The limiter is adjusted correct when the gear change lever leans onto
limiter just before end position (app. 1mm). In that case we avoid burdening and
wearing out in the gearbox.
Differential lock
-it activates with pulling of the lever backwards, it should remain in this position.
You use the differential by hard work, when both wheels traction is required or
when one wheel slips (on slopes for example) (Pic. 5a, 5b)
WARNING!
A CTIVATING OF DIFFERENTIAL LOCK WITHOUT CLUTCH IS NOT
ALLOWED WHEN THE MACHINE IS OPERATING OR WHEN FULL GAS . B Y
REDUCING THE GAS YOU CAN ACTIVATE IT WITHOUT USE OF THE
CLUTCH .
DIFFERENTIAL, BRAKES
-
7
-

Pic. 1 Pic. 2
Pic. 3 Pic. 3b
Pic. 4a Pic. 4b
Pic. 5 -8- Pic. 5b
WORKING SHAFT
-
13
-

Pic. 7 Pic. 9
Pic. 8 Pic. 13
Pic. 11 Pic. 12
Pic. 14
-9-
Pic. 16
ENTRY SHAFT
-
12
-

7. MAINTENANCE
Maintenance manuals for the motor are in the motor Operating manuals. We
recommend you to check the oil level regularly every 20 hours (oil gauge) (Pic.
14). Change oil every 100 working hours or once in a season!
When changing oil the machine must be warmed up. Pour the oil out through the
hole on the bottom of the gearbox by unscrewing the oil screw. Pour in the oil
quality SAE 90 1,7l.
After the work clean the machine of earth, grass or similar dirt. When storing the
machine for longer time, grease metal parts with oiled mop.
We wish you successful work with machine MAESTRAL!
-10-
8. CATALOGUE OF SPARE PARTS
CASING
-
11
-
