Structural Concepts G Series User manual

READ AND SAVE THESE INSTRUCTIONS
SERVICE UPPER COLD / SELF-SERVICE LOWER COLD COMBINATION DELI MERCHANDISERS:
>> VERTICAL UV-BONDED GLASS UPPER (RAISABLE/HINGED AT CENTER)
>> UPPER SECTION BLOWER COIL SYSTEM (CERTAIN MODELS ONLY)
>> REAR SLIDING/REMOVABLE DOORS
>> REMOTE UNITS
Rev A Date: 5.7.2019
Oper Manual\G-Series\GCDTV856RLB 6724A GCDV652RLB GCDV452RLB-S GCDV652RLB-S 7540 21-08630.pub
Structural Concepts Corporation ∙ 888 E. Porter Road ∙ Muskegon, MI 49441 Phone: [phone] Fax: [phone] ∙ www.structuralconcepts.com
Models Represented By This Operating Manual*:
GCDV452RLB-S.7540 GCDV652RLB-S.7540
GCDTV856RLB GCDTV856RLB.6724A
INSTALLATION AND
OPERATING MANUAL
G-SERIES PART NO.
21-08630
* This manual may be applicable to additional models not listed herein.
MODEL GCDV452RLB-S.7540
(LOWER BASE UNIT WITH VERTICAL
GLASS / UPPER METAL SHELVES)
MODEL GCDTV856RLB.6724A
(LOWER BASE UNIT WITH VERTICAL
GLASS / UPPER GLASS SHELVES /
UPPER SECTION BLOWER COIL SYSTEM)
MODEL GCDTV856RLB
(LOWER BASE UNIT WITH VERTICAL
GLASS / UPPER METAL SHELVES)
MODEL GCDV652RLB-S.7540
(LOWER BASE UNIT WITH VERTICAL
GLASS / UPPER GLASS SHELVES)

2
TABLE OF CONTENTS / MODEL LENGTH, DEPTH & HEIGHT
TABLE OF CONTENTS ……………………………………………………………………………………….......
OVERVIEW / TYPE / COMPLIANCE / WARNINGS / PRECAUTIONS / WIRING DIAGRAM / PLUGS …..
INSTALLATION: REMOVAL FROM SKID, REMOVING LOWER TOE-KICKS ………………….….……..
INSTALLATION: POSITIONING & ALIGNING CASE / BOLTING & CAULKING UNITS TOGETHER …...
INSTALLATION, CONT.: LIFT-UP FRONT GLASS …………………………………………………………….
INSTALLATION: FRAME SUPPORT RAIL SHIMMING ………………………………………………………..
INSTALLATION, CONT.: FRONT GLASS ALIGNMENT VIA FRAME SUPPORT RAILS …………….…....
INSTALLATION, CONT’D: TEMPERATURE CONTROL / THERMOMETERS / TEMPERATURE
PROBES …………....………………………………………………………………………………...…....
STORE PERSONNEL SECTION ONLY ..……………………………………………………….……….……...
STOCKING / MAINTAINING PROPER PRODUCT CONDITION ……………………………………………..
MAINTENANCE: LED DRIVERS / TERMINAL BLOCK / FIELD ACCESS BOX ………………………….
MAINTENANCE, CONT’D: BLOWER COIL SYSTEM (CERTAIN MODELS ONLY) ……………………..
MAINTENANCE, CONT’D: REAR SLIDING DOORS ………………………………………………………..
MAINTENANCE, CONT’D.: BRACKET RETAINERS / ADJUSTING SHELVES / LOAD LIMITS ……….
MAINTENANCE, CONT’D.: POWER CORD & PLUG / LED LIGHT FIXTURES ………………………….
CLEANING SCHEDULE (EXTERIOR) - TO BE PERFORMED BY STORE PERSONNEL …………….…
TROUBLESHOOTING - TO BE PERFORMED BY STORE PERSONNEL ……………...…...……….…….
TRAINED SERVICE PROVIDERS SECTION ONLY ………………………………………………….……….
CLEANING SCHEDULE - TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ………………….
PREVENTIVE MAINTENANCE - TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY ….
TROUBLESHOOTING - TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY ……………
GENERAL TECHNICAL INFORMATION (PARTS LIST / SERIAL LABEL INFO / TEMPERATURE
CONTROLLER INFORMATION / TECHNICAL SERVICE CONTACT INFO, ETC.) ….…………..
SERIAL LABEL INFORMATION & LOCATION ..……………………………………...…....……………..…….
TECHNICAL SERVICE CONTACT INFORMATION & WARRANTY INFORMATION ...……….……..........
2
3-4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21-22
23
24-25
26
27
28

3
OVERVIEW
 Upper Service Section: This merchandiser is designed
to merchandise packaged or unpackaged product at
41 °F (5 °C) or less product temperatures.
 Lower Self-Service Section: This merchandiser is
designed to merchandise packaged product at
41 °F (5 °C) or less product temperatures.
 Product Pre-Chill Requirement: Product must be
pre-chilled to above listed temperatures prior to being
placed in merchandiser.
 These cases should be installed and operated
according to this operating manual’s instructions to
ensure proper performance. Improper use will void
warranty. Improper use will void warranty.
TYPE 1 vs. TYPE 2 CONDITIONS
This unit is designed for the display of products in ambient
store conditions where temperatures and humidity are
maintained within a specific range.
 For Type 1 Conditions (most cases): ambient
conditions are to be at 55% maximum humidity and
maximum temperatures of 75 °F (24 °C).
 For Type 2 Conditions: ambient conditions are to be
at 55% maximum humidity and max. temperatures of
80 °F (27 °C).
 If unsure if unit is designed for Type 1 or 2, see tag
next to serial label. See SERIAL LABEL LOCATION &
INFORMATION LISTED / TECH INFO & SERVICE
section in this manual for sample serial labels.
REFRIGERANT DISCLOSURE STATEMENT
 This equipment is prohibited from use in California
with any refrigerants on the “List of Prohibited
Substances” for that specific end-use, in accordance
with California Code of Regulations, title 17, section
95374.
 This disclosure statement has been reviewed by
Structural Concepts and Structural Concepts attests,
under penalty of perjury, that these statements are
true and accurate.
COMPLIANCE
 Performance issues when in violation of applicable
NEC, federal, state and local electrical and plumbing
codes are not covered by warranty.
WARNING
Hazardous moving parts. Do not operate unit with covers removed.
Fan blades may be exposed when deck panel is removed.
Disconnect power before removing deck panel.
WARNING
Risk of electric shock. Disconnect power before servicing unit.
CAUTION! More than one source of electrical supply is employed
with units that have separate circuits.
Disconnect ALL ELECTRICAL SOURCES before servicing.
WARNING
ELECTRICAL
HAZARD
WARNING
KEEP
HANDS
CLEAR
COMPLIANCE
This equipment MUST be installed in compliance with all
applicable NEC, federal, state and local electrical and plumbing codes.
OVERVIEW / TYPE / COMPLIANCE / WARNINGS / PRECAUTIONS / WIRING / PLUGS - PAGE 1 of 2
WARNING: This product can expose you to chemicals, including
Urethane (Ethyl Carbamate), which are known to the state of
California to cause cancer and birth defects or other reproductive
harm. For more information go to P65Warnings.ca.gov.

4
OVERVIEW / TYPE / COMPLIANCE / WARNINGS / PRECAUTIONS / WIRING / PLUGS - PAGE 2 of 2
CAUTION! ADVERSE CONDITIONS / SPACING ISSUES
 Performance issues caused by adverse conditions are NOT warranted.
 End panels must be tightly joined or kept at least 6-inches away from
any structure to prevent condensation.
 Unit must be kept at least 15-feet from exterior doors, overhead HVAC
vents or any air curtain disruption to maintain proper temperatures.
 Unit must not be exposed to direct sunlight or any heat source
(ovens, fryers, etc.).
CAUTION
CAUTION
PRECAUTIONS
 This sheet contains important precautions to prevent
damage to unit or merchandise.
 Please read carefully!
 See previous page for specifics on OVERVIEW,
CONDITION TYPE, COMPLIANCE and WARNINGS.
WIRING DIAGRAM
 Wiring diagram is in its own packet near ballast box,
field wiring box, raceway cover or related location.
POWER CORD AND PLUG MAINTENANCE
 Caution! Risk of electric shock.
 If cord or plug becomes damaged, replace only with
cord and plug of same type.
CAUTION! POWER CORD AND PLUG MAINTENANCE
Risk of electric shock. If cord or plug becomes damaged,
replace only with cord and plug of same type.
CAUTION! GFCI BREAKER USE REQUIREMENT
If N.E.C. (National Electric Code) or your local code
requires GFCI (Ground Fault Circuit Interrupter) protection,
you MUST use a GFCI breaker in lieu of a GFCI receptacle.
CAUTION! LAMP REPLACEMENT GUIDELINES
If using LED lamps, they must reflect specific size, shape and overall design.
Any replacements must meet factory specifications.
WIRING DIAGRAM FORMAT & LOCATION
 Each case has its own wiring diagram folded & in its own packet.
 Wiring diagram placement may vary; it may be placed near field
wiring box, raceway, or other related location.

5
INSTALLATION: REMOVAL FROM SKID, REMOVING LOWER TOE-KICKS
1. Remove Case From Skid (Rails)
 Remove shipping brace that may be securing
case to skid.
 Support case to prevent tipping.
 Caution! Levelers can be damaged if case hits
floor with heavy force!
 Carefully slide unit to rear of skid and tip backward
off skid.
 Illustration may not reflect every feature or option
of your particular case.
 Case can be repositioned with pallet truck when
front lower panel is removed. Blocking may be
necessary to obtain adequate height.
Slide Skid Out
Hook (Typ.)
2. Removing Lower Toe-Kicks
 No screw removal is required to
remove lower front toe-kicks.
 Front and rear toe-kicks are
removable in same manner.
 Simply lift lower toe-kick up and
off case hooks and free from
magnets.
 Replace in same manner it was
removed.
 See illustrations at right and
Magnet (Typ.)
Front Panel
(Shown Reversed)
Slot (Typ.)

Model GCDV452RLB-S.7540
Is Shown. It May Not Reflect
Every Feature Or Option Of
Your Particular Merchandiser.
6
INSTALLATION, CONT’D: CASE ADJOINMENT INSTRUCTIONS
3. Case Adjoinment Instructions
>> Warranty is void if improper caulk/sealant is used.
>> Lay generous beads of caulk/sealant as specified.
A. Prior To Adjoinment - Apply Industrial Butyl
Caulk at Center of Uprights
 Lay a generous bead of industrial grade butyl caulk
at center of uprights (in non-visible areas).
 This butyl caulk prevents refrigerated air from
escaping between cases (causing condensation and
reducing refrigeration efficiency) as well as
preventing ants or other insects from entering case.
 See illustration below.
B. Adjoining Cases - Using Bolts and Nuts
 Use appropriately sized nuts and bolts for each hole.
#1 - Hole is accessible through upper front section or
rear sliding door (if able to avoid gas cylinder,
attach bolt); otherwise start at #2 in process.
#2 - Holes are accessible after rear plenum removal.
#3 - Holes are accessible at underside of decking.
Decking must be removed to attach bolts/nuts.
#4 - Holes are accessible at base frame (through front or rear
of case after front toe-kick has been removed).
 Tighten nuts securely (but do not over-tighten).
 See illustration below.
C. After Adjoinment - Apply Food Grade Silicone Sealant
To Inner And Outer Seams
 After all nuts/bolts are securely attached to case, apply a
generous bead of food grade silicone sealant at both
inner and outer seams.
 When properly applied, this food grade silicone sealant
will prevent water from seeping between cases (into the
case or to the floor) as well as crumbs or other residue
from entering between case seams.
 See illustrations below.
>> You must reattach toe-kick(s) and decking after case
adjoinment process is complete.
Industrial Grade
Butyl Calk (For
Refrigeration Bead
Applications)
Food Grade Silicone
Sealant (For Sanitation
Bead Applications)
1
2
3
3
4
Refrigeration
Bead
Inner
Sanitation
Bead
Inner Sanitation
Bead
Refrigeration
Bead
Outer Sanitation Bead To Be
Applied At Rear Adjoinment
Seams (Shown Above)
Outer
Sanitation
Bead
1
Outer
Sanitation Bead
Outer
Sanitation
Bead
Inner Sanitation
Bead

7
INSTALLATION, CONT.: LIFT-UP FRONT GLASS
 Gas cylinders will retain glass in raised position.
 Raised glass allows front access for product
re-stocking and/or cleaning purposes.
 Lower front glass slowly to prevent damage to unit.
Front Glass (Shown In
Raised Position)
Lift Handle
4. Lift-Up Front Glass
 Check that front glass lifts up properly.
 Front glass may be raised 90° via hinge that is
located mid-case (as shown below)
 Carefully grasp lift handle and raise upward.
Hinge
90° Angle
Model GCDV452RLB-S.7540
Is Shown. It May Not Reflect
Every Feature Or Option Of
Your Particular Merchandiser.

8
INSTALLATION, CONT.: FRAME SUPPORT RAIL SHIMMING
Note: Above Illustration May Not Depict An Exact
Representation Of Your Particular Unit Being Installed.
 Note: After case is in position, it must be
sealed to floor to prevent entry or leakage of
liquid or moisture.
 Caution: If glass scrapes against edges of case or
against each other, see INSTALLATION, CONT.:
FRONT GLASS ALIGNMENT section in this
manual.
5. Frame Support Rails Must Be Shimmed
 Illustration below shows case with frame
support rails.
 Shims will be provided with all cases that have
frame support rails.
 Use shims to level case.
Frame Support
Rails

9
INSTALLATION, CONT.: FRONT GLASS ALIGNMENT VIA FRAME SUPPORT RAILS
6. Front Glass Alignment & Adjustment via Frame Support Rails
 Proper alignment of the front glass is important to maintain a seal inside case.
 Improper alignment can cause air leaks compromising the environment inside
the case and create condensation.
 Follow the five steps listed below to assure proper front glass alignment.
 Illustrations shown may not exactly reflect every feature or option of your
case.
2. Front-to-Back Leveling:
 Place a level on top of case,
perpendicular to the front glass.
 Raise or lower either side of case by
shimming under the rails (following
steps 3 & 4 below).
 Double-check the side-to-side level.
1. Side-to-Side Leveling: Place a level on top of display case
(parallel to front glass). Level the case by inserting shims
under the rails. Follow steps 3 and 4 below for specifics.
5. Verification:
 After inserting shims, open and shut the front glass.
 Verify (again) that the front glass is properly aligned at both left-hand and right-hand side of the case.
 If not, repeat shimming procedure until the front glass is properly aligned along both sides of the case.
CURVED
FRONT
GLASS
END
PANEL
LIFT
4. If FRONT-RIGHT CORNER is too
close to end panel (or hitting it), insert
shims under rail at the BACK RIGHT
CORNER of case.
LIFT
END
PANEL
CURVED
FRONT
GLASS
3. If FRONT-LEFT CORNER
is too close to end panel (or
hitting it), insert shims under
rail at the BACK LEFT
CORNER of case.
END PANEL
END PANEL
Rails
Note: Illustrations
Shown May Not Depict
An Exact
Representation Of Your
Particular Unit
Case with Flat
Front Glass

INSTALLATION, CONT’D: TEMPERATURE CONTROL / THERMOMETERS / TEMPERATURE PROBES
10
7. Temperature Control
 Temperature is remotely controlled.
 Consult store management for guidance and
instructions.
8. Thermometer Placement & Purpose
 Lower section thermometer (self-service section)
is located against rear plenum.
 Upper section thermometer (service section) may
be located in rear storage bins above shelves (at
angled positions), however location may vary.
 Rear thermometers are in upper section just inside
rear doors (as shown below).
 Thermometers may be either spirit-filled or
digital. They reflect internal air temperature only
(not actual food temperature).
 Use probe thermometers to determine actual
product temperatures.
9. Temperature Probes
 Thermometer/thermostat probes are positioned
horizontally (behind probe plate) in lower, self-
service section rear plenum (shown below-left).
 Probes are suspended by spacer/screw
assembly, allowing probes to garner accurate
temperature readings and transmit readings as
required.
Probe
Plate
Thermometer /
Thermostat
Temperature
Probes
Thermometer
For Lower
Self-Service
Section
Thermometer
For Upper
Service Sec-
tion

11
STORE PERSONNEL’S SECTION ONLY
STORE PERSONNEL
SECTION ONLY

12
STOCKING / MAINTAINING PROPER PRODUCT CONDITION
A. Stocking
1. Product must always be maintained at a
constant and proper temperature. Thus,
from the time product is received, through
storage, preparation and display, product
temperature must be controlled to maximize
life of the product.
2. These units are not “rapid cool-down
cases”; they are “holding cases.” Thus,
product must be in its fully-refrigerated state
(at 41 °F or less) PRIOR to being placed in
cases to help maintain maximum shelf life of
product.
3. When stocking, never allow the product to
extend beyond the recommended load limit.
4. Air discharge and return air flow must be
unobstructed at all times to provide proper
refrigeration.
5. Product must be consistently rotated (older
product rotated to front of display) per your
store’s stocking protocol.
B. Maintaining Proper Product Condition
1. Improper temperature and lighting will
cause serious product loss. Discoloration,
dehydration and spoilage can be controlled
with proper use of the equipment and
handling of product.
2. To prevent product dehydration, do not
allow temperature to drop below range
specified in OVERVIEW section of this
manual.
3. Minimize processing time to avoid
damaging temperature rise to the product.
Product should be kept at proper
temperature.
4. Keep the air in and around the case area
free of foreign gasses and fumes or food
will rapidly deteriorate.
5. Do not place any product into these
refrigerators until all controls have been
adjusted and they are operating at the
proper temperature. Allow merchandiser to
operate at a minimum of 6 hours before
stocking with any product.
6. There are vents located at the base of the
front of the glass, just above the front rail.
These vents supply a continuous, gentle flow
of air across the front glass which inhibits
condensation. Do not place any signs, product
or other restrictive objects on the front of the
refrigerator that will block these vents.
7. Keep the service doors closed (when
applicable). Refrigeration performance will be
seriously affected if left open for a prolonged
period of time.
8. Avoid the use of supplemental flood or spot
lighting. Display light intensity has been
designed for maximum visibility and product
life at the factory. The use of higher output
fluorescent lamps (H.O. and V.H.O.), will
shorten the shelf life of the product.
9. Turn off case lights at night.
10.In the deli, meat and fish cases, completely
cover the product each night with a clean
damp cloth or butcher paper (never use
plastic, as it does not allow for proper
circulation). Make sure the cloth or paper is in
direct contact with the product.
11.Turn and rotate the meat fairly often. The
blood (which gives the pink color) works its
way downward with time.
12.Cold coils remove heat and moisture from the
case and deposit this as frost onto the coil.
Thus, you must thoroughly clean and defrost
the upper refrigeration system/gravity coil drip
tray assembly at least weekly. See
CLEANING SCHEDULE (INTERIOR) - TO
BE PERFORMED BY STORE PERSONNEL
section in this manual for cleaning and
defrosting specifics.
13.Understand product quantity and how it
effects dehydration. The only other moisture
within the case is that of the product itself.
Thus, a single level of meat will dry out faster
than a fully loaded case of 3-4 levels of meat.

MAINTENANCE: LED DRIVERS / TERMINAL BLOCK / FIELD ACCESS BOX
13
1. LED Driver(s) and Field Access Box
 Electrical raceways contain various electrical components.
 Access to these components can be made simply by removing raceway cover.
 See illustrations below for general layouts.
 Caution! Only certified electricians are to access electrical components!
LED
Drivers
Model GCDV652RLB-S.7540 is Shown Below
(Your Component Layout May Vary)
Terminal
Block

MAINTENANCE, CONT’D: UPPER SECTION BLOWER COIL SYSTEM (CERTAIN MODELS ONLY)
14
2. Upper Section Blower Coil System - General Layout
 Illustration on this sheet is applicable to model GCDTV856RLB.6724 only.
 Two (2) trough drains are in each case. One (1) is at each upper section / one is at lower section.
 See illustration below for locations of components under upper and lower section decks.
TXV
Fan Shroud DrainFan
Assembly
Fan
Assembly
Note: Model GCDTV856RLB.6724A (Shown Above) May Not
Depict An Exact Representation Your Unit Being Installed.
Fan
Shroud Drain
Fan Assembly
(Typical)
Fan
Shroud
TXV
Fan
Assembly
(Typical)
Solenoid
Valve
Assembly
(Optional)
Solenoid Valve
Assembly (Optional)
Filter
Dryer TXV
Filter
Dryer
Shutoff
Valve
Shutoff
Valve

15
Warning! Disconnect power before providing maintenance and service to unit.
Caution: Lamps are treated to resist breakage and must be replaced with similarly treated lamps.
Note: Warranty will be void if claims arise from negligence, misuse of goods, extreme
environmental conditions or improper maintenance. See OVERVIEW / TYPE / COMPLIANCE /
WARNINGS / PRECAUTIONS / WIRING / PLUGS section in this operating manual.
3. Rear Sliding Doors
Note: Doors are not interchangeable. There is an inner and outer door. Outer door must be removed first
and replaced last.
 The outer door is the right hand door (from the service side or rear of case).
 Move doors toward the center of the case.
 Individually lift each door up toward the top of the case; pivot the bottom of the door out.
 Replace rear sliding doors in reverse order they were removed.
MAINTENANCE, CONT’D: REAR SLIDING DOORS
Model GCDT1256RLB With End Panel Removed
For Illustrative Purposes Only

16
MAINTENANCE, CONT’D.: BRACKET RETAINERS / ADJUSTING SHELVES / LOAD LIMITS
4. Bracket Retainer Removal
 To remove brackets, it may be necessary to remove the
nylon shipping bracket retainers.
 Pliers will be required to accomplish this task.
 See illustration at top-right for location of bracket
retainers.
5. Shelf Assembly Adjustment or Removal
 Shelf can be set at 0°, 5° or 10°.
 To adjust shelving lift upward and rotate to desired
angle.
 To remove, unplug the light cord and lift up and out.
 See illustrations at right and below.
6. Load Limits
 See labels along sides of case stating load limits.
 Do not allow product to exceed these limits.
 Doing so will prevent proper airflow, causing product
temperature to warm.
Bracket
Retainer
Locations
Note: Illustration Shown May Not
Depict An Exact Representation
Your Particular Case.
Load
Limits
(Lower)
Upright Shown
Transparent
Load
Limits
(Upper)

17
MAINTENANCE, CONT’D.: POWER CORD & PLUG / LED LIGHT FIXTURES
7. Power Cord and Plug
 Power cord and plug (for LED lights) locations
vary depending upon model.
 Caution! You must plugged in an approved
outlet!
8. LED Style Light Fixtures
Removal of Faulty LED Lights:
 LED lights rarely require change-out.
 Contact Structural Concepts’ Technical Service
Department for replacement LED lights.
 Turn off LED light switch.
 To remove faulty LED light, follow these steps:
A. Disconnect plug from LED light.
B. Using both hands, grasp LED light
assembly (with its magnetic mounting
clips). Pull downward and off its shelf (or
header).
C. Remove magnetic mounting clips from LED
light by pressing against flange part of clip
with thumb.
A
Plug
Barrel
Shaped
Insert
LED
Light
Magnetic
Mounting Clip View #2
LED
Lights
B
C
Magnetic
Mounting Clip View #2 No Gap
Gap
>> Note: Mounting clips MAY be riveted to shelf or
header. In such instances, simply remove LED light
from mounting clips by pressing against flange part of
clips with thumb.
Replacement of LED lights:
 Attach magnetic mounting clips onto LED light.
 Adjust magnetic mounting clips so they are equally
spaced on LED light.
 Reattach LED light assembly to its shelf/header.
 Position properly in shelf/header.
>> Note: If mounting clips are riveted to shelf (or
header), attach by placing LED in base of clip and then
snapping into clip at FLANGE SIDE.
 Press plug’s barrel-shaped insert all the way into
LED light.
 Important: If plug is not inserted ALL THE WAY IN
the LED light’s orifice, the light may not energize.
See “BAD” vs. “GOOD” insertions below-right.
 Turn LED light switch back on.
Light
Fixtures
Light
Fixtures

18
CLEANING SCHEDULE - TO BE PERFORMED BY STORE PERSONNEL
FREQ. CASE EXTERIOR CLEANING INSTRUCTIONS
Daily All Glass: Clean side glass, front glass and/or shelves with household or commercial glass
cleaner. Clean out door track with moist cloth.
Daily Rear Sliding Door Exterior Glass: Clean with household or commercial glass cleaner.
Daily End Panels, Front Panel, Toe-Kick, Rear Ledge Cutting Board, etc.: Wipe off all surfaces
with warm water and mild soap solution and non-abrasive cloth. Dry thoroughly.
Daily Stainless Steel Surfaces:
 Wash with a solution of hand dishwashing liquid detergent and water; or a solution of baking
soda and water. Rinse and polish dry with paper towel or soft cloth.
 Never use scouring powders or steel wool as they will scratch stainless steel.
 Brighten by polishing with a cloth dipped in vinegar or in ammonia; sprinkle baking soda on
sponge and rub gently; rinse. Polish dry with paper towel.
 Remove streaks or heat stains from stainless steel by rubbing with club soda.
Weekly Wood, Laminate and Painted Surfaces (Including Rear Storage Area): Clean with mild
soap and water solution and a soft cloth .
Weekly Acrylic (Sneeze Guard): Clean with warm water, mild soap solution and soft cloth; acrylic
cleaning solutions are also available.
 Caution! Never use ammonia-based cleaners on acrylic.
 Incorrect cleaning agents or abrasive cleaning cloths cause surface to ‘cloud’ over
time.
Monthly Under Case Cleaning: Remove front toe-kick (or rear grille). Vacuum under case to remove
all dust and dirt. Replace front toe-kick (or rear grille) when complete.

19
TROUBLESHOOTING - TO BE PERFORMED BY STORE PERSONNEL
CONDITION TROUBLESHOOTING
Case Not Lining Up See Installation Section for instructions on properly aligning case (alongside
other cases) and adjusting levelers.
Case Lights Are Not
Working
Check that light switch (if any) is in the ON position.
Check for burned out bulbs. If so, turn lights off & replace.
Clean dirt and dust from the bulbs to prevent flickering.
Check that ALL lights are plugged in and receptacles capped.
Water Is On The Floor Caution! Water on flooring can cause much damage! Until cause is
determined (and repaired), following these procedures:
 Use wet-dry vacuum (or mop & bucket) to remove standing water.
 Use ‘catch pans’ for water to drain into. Swap out regularly until case has
completely drained.
Check that the drain trap is free of debris.
Check that the drain hose is correctly positioned over floor drain.
If unable to stop water from draining on floor, contact Structural Concepts
Technical Service. See telephone number on final page in this manual.
Fan Emits Excessive
Noise
Check that the case is aligned, level and plumb.
Fans Are Not
Working
Check that the MAIN power switch (if present) is on.
System Is Not
Operating
Check that the MAIN power switch (if present) is on.
Case Is Not Holding
Temperature
If a large amount of warm product was added to the case, it will take time for the
temperature to adjust. Product should be pre-chilled before placing in case.
Check that the case is not in the sun or near a heat or air conditioning vent.
Check that case is not located near outside doors: ambient temperature
fluctuation can hinder unit’s ability to maintain proper case temperature.

20
TRAINED SERVICE PROVIDERS SECTION ONLY
TRAINED SERVICE
PROVIDERS
SECTION ONLY
