Studiomaster Professional 10 SUB User manual

- Thank you for purchasing the SMProfessional 10 Sub Active Speaker.
- To ensure optimum performance and safety, please follow this instruction manual carefully.
- Please retain this manual for future reference.
- For any complaint, feedback or testimonials please contact our distributor / dealer.
1. Warranty Information
2. Introduction
3. Features
4. Panel Description
5. Block Diagram
6. Linking Multiple A Series
7. Cable Connections
8. Suspended Mouting
9. Connector Details
10. Technical Specifications
10 SUB
Professional Speaker Active
Index

In case an abnormality occurs during operation
contact your dealer. If you continue using the unit without heed-
ing this instruction, fire or electrical shock may result.
Should this unit be dropped or the cabinet be damaged, turn the
power switch off, remove the power plug from the AC outlet, &
If you notice any abnormality, such as smoke, odor, or noise, or
if a foreign object or liquid gets inside the unit, turn it off imme-
diately. Remove the power cord from the AC outlet. Consult your
dealer for repair. Using the unit in this condition is a fire and
electrical shock hazard.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
Explanation of Graphical Symbols
The lightning flash with arrowhead symbol within
an equilateral triangle is intended to alert the
user to the presence of uninsulated “dangerous
voltage” within the product’s enclosure that may
be of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the pre-
sence of important operating and maintenance
(servicing) instructions in the literature
accompanying the product.
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT NOTICE
Connecting the Plug and Cord
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE.
WARNING: THIS APPARATUS MUST BE EARTHED
IMPORTANT. The wires in this mains lead are coloured in accordance
with the following code:
GREEN: EARTH
BLUE: NEUTRAL
BROWN: LIVE
As the colours of the wires in the mains lead of this apparatus may not
correspond with the coloured markings identifying the terminals in your
plug proceed as follows:
The wire which is coloured GREEN must be connected to
the terminal in the plug which is marked by the letter E or by the safety
earth symbol or colored GREEN.
The wire which is coloured BLUE must be connected to the terminal which
is marked with the letter N or coloured BLACK.
The wire which is coloured BROWN must be connected to the terminal
which is marked with the letter L or coloured RED.
1 Read the instructions carefully.
2 Keep this instructions manual handy for reference.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with dry cloth.
7 Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8 Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9 Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
10 Only use attachments/accessories specified by the
manufacturer.
11 Use only with the cart, stand, tripod, bracket,
or table specified by the manufacturer, or
sold with the apparatus. When a cart is
used, use caution when moving the cart/
apparatus combination to avoid injury
from tip-over.
12 Unplug this apparatus during lightning storms or when unused
for long periods of time.
13 Refer all servicing to qualified service personnel. Servicing in
any way, such as power supply cord or plug is damaged,
liquid has been spilled or objects have fallen into the appara-
tus, the apparatus has been exposed to rain or moisture. does
not operate normally, or has been dropped.
WARNING
Operation
Do not scratch, bend, twist, pull, or heat the power cord. A
damaged power cord is a fire and electrical shock hazard.
Do not remove the unit’s cover. You could receive an electrical
shock. If you think internal inspection, maintenance, or repair
is necessary, contact your dealer.
If lightning begins to occur, turn off the unit as soon as possible,
and unplug the power cable from the electrical outlet.
If there is a possibility of lightning, do not touch the power cable
plug if it is still connected. Doing so may be an electrical shock
hazard.
Installation
Connect this unit’s power cord only to an AC outlet of the type
stated in this Owner’s Manual or as marked on the unit. Failure
to do so is a fire and electrical shock hazard.
Do not allow water to enter this unit or allow the unit to become
wet. Fire or electrical shock may result.
Do not place a container with liquid or small metal objects on
top of this unit. Liquid or metal objects inside this unit are a fire
and electrical shock hazard.
Do not place heavy objects, including this unit, on top of the
power cord. A damaged power cord is a fire and electrical
shock hazard. In particular, be careful not to place heavy
objects on a power cord covered by a carpet.
PRECAUTIONS FOR SAFE OPERATION
Do not modify the unit. Doing so is a fire and electrical shock
hazard.

• 1 Line Inputs, 1 Aux input.
• Built-in soft clip limiter.
• Link out to link to other speaker.
• Parameter selection switch (flat - boost).
• Sub phase switching between . - 0°& 180°
1. Warranty Information
Unpacking
As part of our system of quality control, every SMProfessional product is carefully inspected before leaving the
factory to ensure flawless Product quality. After unpacking, please inspect for any physical damage. In the event that
damage has occurred, immediately notify your SMProfessional dealer.
Retain the cartons for future use should the product require servicing / maintenance.
2. Introduction
The Sub Woofer 10 SUB from SMProfessional is compact Loudspeaker designed to deliver excellent sound even
at extreme sound pressure levels.
3. Features
4. Panel Description
1) POWER SWITCH: Used for switching the unit on and off.
2) FUSE CARRIER “FUSE”: Mains fuse housing.
3) POWER AC INLET SOCKET : Used for connecting the power cable supplied with the speaker.
4) Line input: This combo LXR- Jack input accept line-Level signals from various sources.
5) Aux input: This is a stereo RCA line input to connect devises such as CD / media player, pads, Mps player &
DJ Mixer etc.
6) Output: This Balanced XLR (M) output to connecte/link this speaker to an added thermal speakers.
7) Sub Level: This battery knob to control the volume level of the line in / Aux in.
8) Phase switch: Use this switch for selecting of eighter flat or boost the signal.
9) Status led: The power led indicates the On and OFF status of the speaker the signal led indicate the presences
of audio signal at any of the connected input. the clip led indicate clipping or
distortion at any of the connected input.
3

Panel 10 SUB
POWER SIG CLIP
AUX IN
RL
LINE IN
240V~ 50Hz, 350W,
FUSE T 3.15A, 250V~
POWER
OUT PUT
EQ
LINK
FLAT BOOST
PHASE
0°
*[e-mail]
91-8879028079
[phone] / 001
ACTIVE SUB-WOOFER SYSTEM
10 SUB
MIN MAX
SUB LEVEL
1
3
2
6
47
8
9
10
5
180°

5
Block Diagram
10 SUB
0° 180°
LIM
Low Pass
AMP
Line Out
Volume LIM
Aux I/P
Line I/P
Power Clip
Sig
Woofer 10”, 2” VC 400Z magnet net
Phase
Flat Boost
EQ
6. Linking Multiple 10 SUB
10 SUB can be connected in daisy chain as shown above.
• Connect the link output of first 10 SUB amplifier to the input of other 10 SUB amplifier & again the Line-out
can be connected to the input of further amplifiers.
• Keep the volume control of cascaded amplifiers at maximum position.
• You can connect same models (10 SUB) in a daisy chain or in combination as per availability & requirement.
10 SUB
OUT PUT
LINK
OUT PUT
LINK
OUT PUT
LINK
MASTER SLAVESLAVE
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
OUT PUT
LINK
POWE R SIG CLIP
RL
OUT P UT
EQ
LIN K
FLAT BO OST
PHAS E
0°
[e-mail]
91-8879028079
[phone] / 001
ACTIVE SUB-WOOFER SYSTEM
10 SUB
MIN MAX
7. Cable Connections
POWER S IG CLIP
RL
240V~ 50Hz, 350W,
FUSE T 3.15A, 250V~
POWE R
OUT PU T
EQ
LINK
FLAT BOO ST
PHASE
0°
[e-mail]
91-8879028079
[phone] / 001
ACTIVE SUB-WOOFER SYSTEM
10 SUB
MIN MAX
180°
180°

6
8. Connector Details
Balanced use of stereo 1/4” jack plug
Unbalanced use of stereo 1/4” jack plug
Tip = Positive/Hot/+VE Phase Ring = Negative/Cold/-VE Phase
Sleeve = Screen/Ground/Earth
Sleeve
RingTip
Sleeve
Tip
Sleeve = Screen/Ground/Earth
Tip = Signal
Balanced use with XLR connectors
Unbalanced use with XLR connectors
Pin 2 = Positive/Hot/+VE Phase
Pin 1 = Screen/Ground/Earth
Pin 3 = Negative/Cold/-VE Phase
Pin 2 = Positive/Hot/+VE Phase
Pin 1 = Screen/Ground/Earth
Input
Input
XLR - male
XLR - male
Pin 3 = Link to Pin 1

9. Technical Specifications
240V/50Hz
System
Amplifier Type
RMS Power
Frequency Response
Max SPL
Phase switch
EQ
Transducer
Input sensitivity
Output Connector (Line output)
Fuse
Power Supply
Dimension (W x D x H)mm
Net Weight
Balanced XLR
SUB
Class D
250W LF
50Hz - 200Hz
123 dB
0°& 180°
Flat, Boost
10” WOOFER, 2" VC 400Z MAGNET
T 3.15A/250V
345 x 405 x 360
14.2 Kg
0dBu/±1dB (774mV±50mV)
Peak Power 500W LF
7
Models 10 SUB

10 SUB REV. 1 JUNE 2023
A1/A2, Giriraj Industrial Estate, Mahakali Caves Road, Andheri (East), Mumbai - 400 093 India.
Tel.: [phone] / 001 WhatsApp.: [phone] E [e-mail]
W www.audioplus-india.com / www.studiomasterprofessional.com
* Design and specification are subject to change without notice.
are registered trademarks of Audioplus in India. © Copyright Audioplus.
All rights reserved. Any unauthorised reproduction or use of logos, images or design elements is strictly prohibited
by law. No part of thecompilation may be reproduced in any manner or translated without written permission.
