Sub-Zero BI-36U User manual

Over-an -un er mo el BI-36U offers large
refrigerate storage, plus a convenient roll-
out freezer rawer. Sub-Zero ual refrigera-
tion along with new air purification an
water filtration systems guar the freshness
of your foo an water like nothing before.
Frame , overlay, flush inset an stainless
steel esign options are available. The flush
inset installation allows the unit to sit flush
with surroun ing cabinetry. Mo el BI-36U
is ENERGY STAR®qualifie .
36" Built-In Over-an -Un er
INTERIOR FEATURES
•Refrigerator
16.2 cu ft Capacity
Air Purification System
3 Adjustable Glass Shelves
1 Stationary Glass Shelf
1 High-Humidity Drawer with Dividers
1 Storage Drawer with Dividers
2 Adjustable Door Shelves
Adjustable Dairy Compartment
•Freezer
5.2 cu ft Capacity
Water Filtration System
Full-Extension oll-Out Freezer Drawer
Two-Tier Wire Storage Baskets
Automatic Ice Maker
Model BI-36U shown with st inless steel flush inset p nels nd tubul r h ndles.
ACCESSORIES
•Grilles for 83" or 88" finished height
(84" is standard).
•Framed front panels in white or stainless
steel.
•Flush inset and dual flush inset panels in
stainless steel with tubular or pro handles.
•Dual installation kit with or without dual
wide grille, 84" finished height.
•Custom front panel mounting kit.
•Side panel in white or stainless steel.
•Stainless steel kickplate.
•Framed grille insert and full-length handles.
•Stainless steel tubular and pro handles.
•Dozen egg container.
•eplacement air purification cartridge and
water filter.
•90° door stop.
Accessories re v il ble through your Sub-Zero
de ler. For loc l de ler inform tion, visit the find
showroom section of our website, subzero.com.
Flip-up grille. Air purification system.
MODEL OPTIONS BI-36U/O BI-36U/S/TH BI-36U/S/PH
Design Overlay/Framed/Flush Inset Stainless Stainless
Grille Panel Stainless Stainless
Han le * Tubular Pro
*H ndle not included to llow for design flexibility.
FEATURES
•Dual refrigeration system ensures the
freshest food and energy efficiency.
•Electronic microprocessor constantly
monitors entire unit to ensure proper food
storage environment.
•Air purification system reduces odors,
bacteria, viruses and ethylene gas.
•Advanced water filtration system.
•Illuminated touch control panel.
•Bright interior lighting throughout, includ-
ing storage drawer area.
•Adjustable spill-proof glass shelves, door
shelves and dairy compartment.
•Soft-close crisper and deli drawers form a
lower temperature zone ideal for produce
and meats.
•Easy-access flip-up grille.
•Informational freshness cards.
•Full-extension, roll-out freezer drawer.
•Max ice feature increases production for a
24-hour period.

INSTALLATION NOTES
Built-In models may be used in a standard
installation or in a flush inset installation
which allows the unit to be flush with
surrounding cabinetry.
Complete installation specifications, including
panel sizes, can be found on our website,
subzero.com/specs.
SPECIFICATIONS
Overall Dimensions 36"W x 84"H x 24"D
Door Clearance Standard 371/4"
Flush Inset 373/4"
Opening Width 351/2"
Flush Inset Width 38"
Opening Height 833/4"
Flush Inset Height 84"
Opening Depth 24"
Flush Inset Depth 263/16"
Electrical equirements 115 V AC, 60 Hz
15 amp circuit
Plumbing equirements 1/4" OD copper,
braided stainless steel or PEX tubing
35–120 psi
Shipping Weight 515 lbs
36" Built-In Over-an -Un er
OVERALL DIMENSIONS
©Sub-Zero, Inc. ll rights reserved. Fe tures nd specific tions re subject to ch nge t ny time without notice. 9/11
36" (914)
84"
(2134)
24" (610)
4" (102)
503/4"
(1289)
23"
(584)
237/8"
(606)
235/8"
(600) 371/4"
(946)
17"
(432)
237/8"(606)
23/8" (60)
HEIGHT DIMENSIONS ±
1/2" (13)
Unit dimensions
m y v ry by
±1/8" (3).
Dimensions in
p rentheses re
in millimeters
unless otherwise
specified.
24" (610)
OPENING
DEPTH
FRONT VIEWSIDE VIEW
TOP VIEW
351/2" (902)
OPENING WIDTH
24" (610)
OPENING DEPTH
833/4"
(2127)
OPENING
HEIGHT
Flush Inset Installation
INSTALLATION SPECIFICATIONS
Standard Installation
IMPORTANT NOTE:
Dimensions ssume
3/4" (19) p nel
thickness.
UNIT WITH
3/4"(19) P
ANEL
DETAIL A
DETAIL B
FRONT VIEW
351/2" (902)
WIDTH TO CLEAT
38" (965)
FLUSH INSET WIDTH
11/4"
(32)
11/4"
(32)
SIDE VIEW
84"
(2134)
FLUSH
INSET
HEIGHT
1/4"
(6)
24" (610)
DEPTH TO CLEAT
263/16" (665)
FLUSH INSET DEPTH
23/16"
(56)
833/4"
(2127)
HEIGHT
TO CLEAT
24" (610)
DEPTH
TO CLEAT
263/16"
(665)
FLUSH
INSET
DEPTH
TOP VIEW
23/16"
(56)
11/4"
(32) CLEAT
CLEAT
Detail A
Detail B
11/4"
(32)
24" (610)
OPENING
DEPTH
TO CLEAT CLEAT
TOP VIEW
263/16"
(665)
FLUSH
INSET
DEPTH
23/16" (56)
3" t
4"
3" (76)
typical
24" (610)
OPENING
DEPTH TO
CLEAT
11/4"
(32)
23/16" (56)
CLEAT
SHADED
AREA
MUST BE
FINISHED
3" typical
(76)
4" (1 02 )
3
Location of
Electrical Supply
FRONT VIEW
751/2"
(1918)
FROM
FLOOR
7"
(178)
E
6"
(152)
Location of Water
Supply— ear
3" (76)
18" (457)
FRONT VIEW
FLOOR
6"
(152)
Location of Water
Supply—Bottom
TOP VIEW
BACK WALL
1/2"
(13)
18" (457) 6"
(152)
