Si e-by-si e mo el BI-48S provi es the
highest refrigerator an freezer capacity in
a single built-in unit. Sub-Zero ual refriger-
ation along with new air purification an
water filtration systems guar the freshness
of your foo an water like nothing before.
Frame , overlay, flush inset an stainless
steel esign options are available. The flush
inset installation option allows the unit to
sit flush with surroun ing cabinetry. Mo el
BI-48S/S is ENERGY STAR®qualifie .
48" Built-In Si e-by-Si e
INTERIOR FEATURES
•Refrigerator
18.8 cu ft Capacity
Air Purification System
4 Adjustable Glass Shelves
1 Stationary Glass Shelf
1 High-Humidity Drawer with Divider
2 Storage Drawers with Divider
3 Adjustable Door Shelves
2 Stationary Door Shelves
Adjustable Dairy Compartment
•Freezer
9.5 cu ft Capacity
Water Filtration System
Automatic Ice Maker
3 Adjustable Wire Shelves
1 Stationary Solid Shelf
3 Storage Drawers
5 Adjustable Door Shelves
Stainless steel model BI-48S shown with tu ular handles.
ACCESSORIES
•Grilles for 83" or 88" finished height
(84" is standard).
•Framed front panels in white or stainless
steel.
•Flush inset panels in stainless steel with
tubular or pro handles.
•Custom front panel mounting kit.
•Side panel in white or stainless steel.
•Stainless steel kickplate.
•Framed grille insert and full-length handles.
•Stainless steel tubular and pro handles.
•Dozen egg container.
•eplacement air purification cartridge and
water filter.
•etrofit kit for 600 series panels.
•90° door stop.
Accessories are availa le through your Su -Zero
dealer. For local dealer information, visit the find a
showroom section of our we site, su zero.com.
Flip-up grille. Air purification system.
MODEL OPTIONS BI-48S/O BI-48S/S/TH BI-48S/S/PH
Design Overlay/Framed/Flush Inset Stainless Stainless
Grille Panel Stainless Stainless
Han le * Tubular Pro
*Handle not included to allow for design flexi ility.
FEATURES
•Dual refrigeration system ensures the
freshest food and energy efficiency.
•Electronic microprocessor constantly
monitors entire unit to ensure proper food
storage environment.
•Air purification system reduces odors,
bacteria, viruses and ethylene gas.
•Advanced water filtration system.
•Illuminated touch control panel.
•Bright interior lighting throughout, includ-
ing storage drawer area.
•Adjustable door shelves, spill-proof glass
refrigerator shelves, dairy compartment
and wire freezer shelves.
•Soft-close crisper and deli drawers form a
lower temperature zone ideal for produce
and meats.
•Easy-access flip-up grille.
•Informational freshness cards.
•Max ice feature increases production for a
24-hour period.
Excludes
BI-48S/O.

INSTALLATION NOTES
Built-In models may be used in a standard
installation or in a flush inset installation
which allows the unit to be flush with
surrounding cabinetry.
Complete installation specifications, including
panel sizes, can be found on our website,
subzero.com/specs.
SPECIFICATIONS
Overall Dimensions 48"W x 84"H x 24"D
Door Clearance Standard 30"
Flush Inset 301/2"
Opening Width 471/2"
Flush Inset Width 50"
Opening Height 833/4"
Flush Inset Height 84"
Opening Depth 24"
Flush Inset Depth 263/16"
Electrical equirements 115 V AC, 60 Hz
15 amp circuit
Plumbing equirements 1/4" OD copper,
braided stainless steel or PEX tubing
35–120 psi
Shipping Weight 630 lbs
48" Built-In Si e-by-Si e
OVERALL DIMENSIONS
©Su -Zero, Inc. all rights reserved. Features and specifications are su ject to change at any time without notice. 9/11
48" (1219)
84"
(2134)
24" (610)
4" (102)
733/4"
(1873)
237/8" (606)
237/8"
(606)
30"
(762)
14"
(356)
93/4"
(248)
23/8" (60)
HEIGHT DIMENSIONS ±
1/2" (13)
Unit dimensions may vary y ±1/8" (3).
Dimensions in parentheses are in millimeters unless
otherwise specified.
24" (610)
OPENING
DEPTH
FRONT VIEWSIDE VIEW
TOP VIEW
471/2" (1206)
OPENING WIDTH
24" (610)
OPENING DEPTH
833/4"
(2127)
OPENING
HEIGHT
Flush Inset Installation
INSTALLATION SPECIFICATIONS
Standard Installation
IMPORTANT NOTE:
Dimensions assume
a 3/4" (19) panel
thickness.
UNIT WITH
3/4"(19) P
ANEL
DETAIL A
DETAIL B
FRONT VIEW
471/2" (1206)
WIDTH TO CLEAT
50" (1270)
FLUSH INSET WIDTH
11/4"
(32)
11/4"
(32)
SIDE VIEW
84"
(2134)
FLUSH
INSET
HEIGHT
1/4"
(6)
24" (610)
DEPTH TO CLEAT
263/16" (665)
FLUSH INSET DEPTH
23/16"
(56)
833/4"
(2127)
HEIGHT
TO CLEAT
24" (610)
DEPTH
TO CLEAT
263/16"
(665)
FLUSH
INSET
DEPTH
TOP VIEW
23/16"
(56)
11/4"
(32) CLEAT
CLEAT
Detail A
Detail B
11/4"
(32)
24" (610)
OPENING
DEPTH
TO CLEAT CLEAT
TOP VIEW
263/16"
(665)
FLUSH
INSET
DEPTH
23/16" (56)
3" t
4"
3" (76)
typical
24" (610)
OPENING
DEPTH TO
CLEAT
11/4"
(32)
23/16" (56)
CLEAT
SHADED
AREA
MUST BE
FINISHED
3" typical
(76)
4" (1 02 )
3
Location of
Electrical Supply
FRONT VIEW
751/2"
(1918)
FROM
FLOOR
7"
(178)
E
6"
(152)
Location of Water
Supply— ear
3" (76)
18" (457)
FRONT VIEW
FLOOR
6"
(152)
Location of Water
Supply—Bottom
TOP VIEW
BACK WALL
1/2"
(13)
18" (457) 6"
(152)
