Subaru 2004 LEGACY User manual

2004 Model Year
PDF S ervic e M a n u a l
GENERAL INFORMATION SECTION (Pub.No.G2320GE1)
ENGINE SECTION 1 (Pub.No.G2320GE2)
ENGINE SECTION 2 (Pub.No.G2320GE3)
ENGINE SECTION 3 (Pub.No.G2320GE4)
TRANSMISSION SECTION (Pub.No.G2320GE5)
CHASSIS SECTION (Pub.No.G2320GE6)
BODY SECTION (Pub.No.G2320GE7)
WIRING SYSTEM SECTION (Pub.No.G2320GE8)

FUJI HEAVY INDUSTRIES LTD. G2320GE1
2004 LEGACY SERVICE MANUAL QUICK REFERENCE INDEX
GENERAL INFORMATION
SECTION
This service manual has been prepared
to provide SUBARU service personnel
with the necessary information and data
for the correct maintenance and repair
of SUBARU vehicles.
This manual includes the procedures
for maintenance, disassembling, reas-
sembling, inspection and adjustment of
components and diagnostics for guid-
ance of experienced mechanics.
Please peruse and utilize this manual
fully to ensure complete repair work for
satisfying our customers by keeping
their vehicle in optimum condition.
When replacement of parts during
repair work is needed, be sure to use
SUBARU genuine parts.
All information, illustration and specifi-
cations contained in this manual are
based on the latest product information
available at the time of publication
approval.
FOREWORD FW
HOW TO USE THIS MANUALS HU
SPECIFICATIONS SPC
PRECAUTION PC
NOTE NT
IDENTIFICATION ID
RECOMMENDED MATERIALS RM
PRE-DELIVERY INSPECTION PI
PERIODIC MAINTENANCE SERVICES PM

FOREWORD
FW
Page
1. Foreword....................................................................................................2

FW-2
FOREWORD
Foreword
1. Foreword
A: FOREWORD
These manuals are used when performing mainte-
nance, repair, or diagnosis of Subaru LEGACY.
Applied model:
BL*****, BP***** from 2004MY
The manuals contain the latest information at the
time of publication. Changes in specifications,
methods, etc. may be made without notice.

HOW TO USE THIS MANUALS
HU
Page
1. How to Use This Manuals ...........................................................................2

HU-2
HOW TO USE THIS MANUALS
How to Use This Manuals
1. How to Use This Manuals
A: HOW TO USE THIS MANUALS
1. STRUCTURE
Each section consists of SCT that are broken down
into SC that are divided into sections for each com-
ponent. The specification, maintenance and other
information for the components are included, and
the diagnostic information has also been added
where necessary.
2. CONTENTS
The first page has an index with tabs.

HU-3
HOW TO USE THIS MANUALS
How to Use This Manuals
3. COMPONENT
Illustrations are provided for each component. The information necessary for repair work (tightening torque,
grease up points, etc.) is described on these illustrations. Information is described using symbol.
To order parts, refer to parts catalogue.
Example:
HU-00017
(14)
(9)
(8)
(7)
(6)
(10)
(4) (10)
(22)
(11)
(19)
(17)
(15)
(13)
(12)
(18)
(16)
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(11)
(10)
(9)
(12)
(13)
(19)
(18)
(20)
(17)
(16)
(24)
(10)
(25)
(5)
(4)
(4)
(4)
(3)
(3)
(3)
(2)
(1)
(21)
(15)
(23)
T7
T2
T2
T2
T2
T2
T2
T4
T5
T5
T8
T6
T6
T6
T11
T10
T1
T1
T3
T3
T3
T1
T9
T4
T5
T5 T3
T4
T3
T2
T4
T2
T1
T3
(20)
(21)
(23)
(22)
(10)
(24)
(25)
(26)
(35)
(34)
(27)
(14)
(28)
(29)
(31)
(32)
(37)
(30)
(33)
(36)
T3
T2
T1
:Selective part
:Replacement part
:Should be lubricated with grease.
:Should be lubricated with oil.
:Sealing point
:Tightening torque
....
,

HU-4
HOW TO USE THIS MANUALS
How to Use This Manuals
4. SPECIFICATION
If necessary, specifications are also included.
5. INSPECTION
Inspections to be carried out before and after maintenance are included.
6. MAINTENANCE
• Maintenance instructions for serviceable parts describe work area and detailed step with illustration. It also
describes the use of special tool, tightening torque, caution for each procedure.
• If many serviceable parts are included in one service procedure, appropriate reference is provided for each
parts.
Example:
(A) Component (D) Cautions (G) Tightening torque
(B) Process (E) Tool number of special tool (H) Illustration
(C) Reference (F) Name of special tool
HU-00020
1) Remove the manual transmission assembly
from vehicie. <Ref. to MT-33, REMOVAL, Manual
Transmission Assembly.>
15.Main Shaft Assembly for Sin-
gle-Range
A: REMOVAL
11) Tighten the lock nuts to the specified torque us-
ing ST1 and ST2.
NOTE:
Secure the lock nuts in two Places affer tightening.
ST2 499987003 SOCKET WRENCH
ST1 498937000 TRANSMISSION HOLDER
(A)
(B)
(C)
(D)
(G)
(E) (F)
(H)
Tightening torque:
118 N m (12.0 kgf-m, 86.8 ft-lb)
ST1
ST2

HU-5
HOW TO USE THIS MANUALS
How to Use This Manuals
7. DIAGNOSIS
Tables showing a step-by-step process make it
easy to conduct diagnosis.
8. SI UNITS
Measurements in these manuals are according to
the SI units. Metric and yard/pound measurements
are also included.
Example:
Tightening torque:
44 N
! m (4.5 kgf-m, 33 ft-lb)
The figure used in these manuals are described in the SI units and conventional units are described in ( ).
Item SI units Conventional unit Remarks
Force N (Newton) kgf 1 kgf = 9.80655 N
Mass (Weight) kg, g kg, g
Capacity 2, m2or cm32or cc 1 cc = 1 cm3= 1 m2
Torque N!m kgf-m, kgf-cm 1 kgf-m = 9.80655 N!m
Rotating speed rpm rpm
Pressure kPa (kilopascal) kgf/cm21 kgf/cm2= 98.0655 kPa
mmHg 1 mmHg = 0.133322 kPa
Power W PS 1 PS = 0.735499 kW
Calorie W!h cal 1 kcal = 1.16279 W!h
Fuel consumption rate g/kw!h g/PS!h 1 g/PS!h=1.3596 g/kW!h
