SUMERAIN S1247CM User manual

MODEL: S1247CM
Version: 2.0
WIDESPREAD LED WATERFALL BASIN FAUCET

Dear Valued Customer,
SUMERAIN would like to take this opportunity to thank you for
purchasing SUMERAIN products. It is our sincere hope that you are
completely satisfied with your new purchase. We welcome any
questions or comments you may have and look forward to assisting you
in the future.
Sincerely,
SUMERAIN customer service department
1. Unpack your new product and ensure that all the parts are contained
in the packaging. Keep the product in its original box until you ready
to install it.
2. Shut off the water supply if replacing a previously-installed faucet.
3. Observe all plumbing and building codes in your area.
4. It is recommended that installation of the product be done by a
professional plumber.
5. SUMERAIN reserves the right to make revisions in the design of
faucets without notice, as specified with the price book.
Tools you may need when installing the faucet

Specification
Function Bathroom Sink Faucets
Feature LED, Waterfall, Widespread
Style Contemporary
Finish Chrome
Installation Holes Three Holes
Number of Handles Two knobs
Faucet Total Height 90mm [3.54 Inch]
Spout Spread 85mm [3.35 Inch]
Spout Width 81mm [3.19 Inch]
Spout Height 86mm [3.39 Inch]
Valve Type Ceramic Valve
Faucet Body Material Brass
Faucet Spout Material Stainless steel
SPOUT Net Weight 0.6 KG
Gross Weight 2.2 KG
Working water press 0.2 ~0.8 Mpa
LED power supply Water flow generator
LED Color changing
Water temperature < 28 ℃Blue color
Water temperature 28 ℃~ 38 ℃Green color
Water temperature > 38 ℃Red color

Dimension

CODE ITEM NAME QTY CODE ITEM NAME QTY
A Faucet Body 1PCS Q Valve body (Cold) 1PCS
C Foam gasket 2PCS D Knob 2PCS
E Escutcheon 2PCS F Rubber gasket 1PCS
G Nut 1PCS H Shank 1PCS
I Rubber gasket 1PCS J Rubber gasket 2PCS
K Nut 2PCS L Valve body(Hot) 1PCS
M T-pipe 1PCS N G1/2” Hoses 2PCS
O Hex wrenches 1PCS
P Hot/cold sign 2PCS

Step 1:
Screw the Shank ”H” with the faucet body “A” on the table ,screw
nut ”K” and Rubber gasket “F”.
Step 2:
Screw nut ”K” and put Rubber gasket “J” on Valve body “L”, fixing the
Escutcheon “E” with Foam gasket “C” and knob “D” on the table
use the hex wrench “O” screw the knob “D” and then put the hot sign
“P” on.
Install another cold valve body with the same way.
Step 3:
Connecting the flexible hoses “N” to the cold and hot water inlet (“L”
and “Q”), the other end of the hoses connect to the cold and hot water
supply system
Step 4:
Connecting the other connection pipes according to above diagram

Clean the faucets and showers as and when required. Regular■
cleaning can prevent calcification.
Never use cleaning materials contain hydrochloric■, formic,
phosphoric or acetic acid, which may cause considerable damage.
Never use cleaning materials or appliances with an abrasive effect,■
such as unsuitable cleaning powders, sponge pads, or micro fiber
cloths.
After cleaning, rinse thoroughly■the faucet with clean water to
remove any cleaner residue.
■Unscrew and clean the aerator regularly.
TROUBLESHOOTING
Symptom Solution
Faucet leaks from
the handle
A. Tighten the packing nut
B. Replace the "O" ring or packing
The water
pressure is too
low
A. Make sure the water supply valves under the sink are
turned on all the way
B. Clean or replace the aerator
C. Check plumbing system for water pressure problems
The spout sprays
water all over A. Clean or replace the aerator
B. Replace the aerator washer
Water is leaking
from the faucet
under the sink
A. Check the water supply connections to the faucet
B. Inspect the water supply lines or hoses for leaks
Handle is loose
A. Remove the cap and tighten the screw
B. Locate and tighten the hex set screw
C. Remove the handle and check for stripped teeth on the
stem.
LED does not
illuminate A. Increase the water press
B. Clean the strainer of hot and cold water inlet
