Summer IN VIEW 2.0 PLUS User manual

QUICK START GUIDE
Charge the Handheld
Charge for 7 hours before first use.
Install the Camera
Plug in camera. Place camera on a
flat surface, such as a tabletop, or
shelf or mount the camera on a
wall using the screw and wall
anchor provided.
tabletop wall mount
Congratulation You are now ready to use your Panorama™ Digital Color
Video Monitor!
SET-UP 1
or
3 sec.
Power on the Camera and
Handheld
Press the ON/OFF/Nightlight button
on the camera and hold for 3
seconds. A green light will appear
near the lens.
Press and hold the power button on
the handheld unit for 3 seconds.
The handheld will automatically
sync with the camera. (The handheld
unit and the camera are paired at the
factory for privacy reasons. If the handheld
and camera are not paired with each other
for any reason, see pairing section in the
user guide.)
Secure the Camera Cord
NEVER place the camera or cords
within 3-feet of the crib. Secure
the cord to your wall using the 6
security clips included to keep the
cord away from baby’s reach.
3ft.
STRANGULATION HAZARD:
Children have strangled
in cords. Keep this cord
out of the reach of
children (more than 3 ft.
(0.9m) away).
WARNING
Read all warnings prior to using this product.
Screen Icons
Function Buttons
Nightlight On (Red/Blue)
Image Zoom
Temperature
Reception
Current Viewing Camera (1-4)
Battery Life/ Plugged In
Power
Video On/Off
Volume Control
Talkback/Navigate Right
Zoom/Navigate Left
Camera Control/Enter
Menu/Navigate Up
Nightlight/Navigate Down
SCREEN ICONS & FUNCTION BUTTONS 2
Flip out the
kick-stand and
place the
monitor on a
stable, level
surface.
7hr.
Thank you for purchasing the In View™2.0 Plus Digital Color
Video Monitor by Summer Infant. This quick start guide will
illustrate the few simple steps to get your device up and
running.
zoom
in & out
2-color
nightlight
secure
signal recharge
battery
remote
pan/tilt
temp
display
800 ft.
range talk
back
with remote pan/tilt camera
IN VIEW 2.0 PLUS
QUICK START GUIDE
29740

Adjusting Brightness
Adjust the handheld screen
brightness by pressing the menu
button. Select brightness from the
menu. Use the left and right
arrow buttons to adjust the
brightness.
Nightlight
Press the nightlight button on the
handheld to activate the soft glow
nightlight on the camera. The light
will glow blue. Blue light acts as a
soothing soft glow nightlight.
Nightlights are comforting to little
ones, especially toddlers who
become scared in a pitch black
room.
Pan/Tilt Camera
Press the camera control button
on the handheld to activate the
camera’s remote pan and tilt. An
icon will appear on screen
indicating Pan/Tilt mode. Use the
arrow buttons to pan left/right and
tilt up/down. Press the camera
button agin to exit Pan/Tilt mode.
Press the nightlight button again to
change the nightlight color to red.
Red light helps soothe infants to
sleep. This color is prominent in the
sunset, natures very own way of
telling your little one it’s time to go
to sleep. An added bonus: young
baby’s find red light soothing as it
is a familiar color to them– it’s the
only color light your baby was able
to see in the womb.
The nightlight can be turned
on or off from the camera
by pressing the
ON/OFF/Nightlight button.
Zoom
Press the zoom button to magnify
the image. Press the button again
to zoom out.
For understanding additional Menu features including: scan, view camera, delete camera,
and add camera, please refer to the user’s guide.
Talk-back
Press and hold the talk-back button
to activate the talk-back feature.
Release the button to end
talk-back mode.
QUICK START GUIDE
USING THE HANDHELD
Sound Activated Lights
The LED light bar on the top of the
handheld will light up as it picks up
noises. Softer sounds will light up
the amber LEDs. Louder noises will
light up the red LEDs.
3
Video On/Off
Turn off the handheld’s video by
pressing the VIDEO button. The
screen will go dark. This feature
allows you to preserve battery life
when not plugged into A/C
adapter. The audio feature will
remain activated allowing you to
monitor sounds. Press the button
again to resume video monitoring.
Summer Infant, Inc. 1275 Park East Drive Woonsocket, RI 02895 1 800 268-6237
VIEW CAM
SCAN
BRIGHTNESS
DELETE CAM
ADD CAM
VIEW CAM
SCAN
BRIGHTNESS
DELETE CAM
ADD CAM
734-2974000-0400
11/16
