Summit Cold Cavern ALFZ37BFROST User manual

COLD CAVERN®BEER FROSTER
Models:
ALFZ37BFROST
ALFZ37BSSTBFROST
User Manual
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING
INSTRUCTIONS
FELIX STORCH, INC.
An ISO 9001:2015 registered company
770 Garrison Avenue
Bronx, NY 10474
www.summitappliance.com

2
TABLE OF CONTENTS
Appliance Safety 3
Important Safeguards 3-4
Installation Instructions 5-8
Before Using your Appliance 5
Installing your Appliance 5
Electrical Connection 5-6
Extension Cord 6
Reversing the Door Swing 6
Installing the Handle 7
Operating your Beer Froster 7-9
Control Panel 7-8
Defrosting 9
Shelves 9
Care and Maintenance 10
Cleaning your Appliance 9
Power Failure 9
Vacations 9
Moving your Appliance 9
Energy-Saving Tips 9
Troubleshooting 10
Limited Warranty 12

3
APPLIANCE SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read
and obey all safety messages.
This is the Safety Alert Symbol. The symbol alerts you to potential hazards that can kill or
injure you and others. All safety messages will follow the Safety Alert Symbol and either the
word DANGER or WARNING.
DANGER means that failure to heed this safety
statement may result in severe personal injury or
death.
WARNING means that failure to heed this safety
statement may result in extensive product
damage, serious personal injury, or death.
All safety messages will alert you about the potential hazard, tell you how to reduce the chance of injury,
and let you know what can happen if the instructions are not followed.
IMPORTANT SAFEGUARDS
Before the appliance is used, it must be properly positioned and installed as
described in this manual, so read the manual carefully. To reduce the risk of fire,
electrical shock or injury when using the appliance, follow basic precautions,
including the following:
•Plug into a grounded 3-prong outlet, do not remove grounding prong, do not use an adapter, and do
not use an extension cord.
•Replace all panels before operating.
•It is recommended that a separate circuit serving only your appliance be provided. Use receptacles
that cannot be turned off by a switch or pull chain.
•Never clean appliance parts with flammable fluids. These fumes can create a fire hazard or
explosion. And do not store or use gasoline or other flammable vapors and liquids in the vicinity of
this or any other appliance. The fumes can create a fire hazard or explosion.
•Do not connect or disconnect the electric plug when your hands are wet.
•Unplug the appliance or disconnect power before cleaning or servicing. Failure to do so can result in
electrical shock or death.
•Do not attempt to repair or replace any part of your appliance unless it is specifically recommended in
this manual. All other servicing should be referred to a qualified technician.
•This appliance is CFC- and HFC-free and contains small quantities of Isobutane (R600a) which is
environmentally friendly, but flammable. It does not damage the ozone layer, nor does it increase the
greenhouse effect. Care must be taken during transportation and setting up of the appliance that no
parts of the cooling system are damaged. Leaking coolant can ignite and may damage the eyes.

4
•In the event of any damage:
oAvoid open flames and anything that creates a spark,
oDisconnect from the power supply,
oAir the room in which the appliance is located for several minutes, and
oContact the Service Department for advice.
•The more coolant there is in an appliance, the larger the room it should be installed in. In the event of
a leakage, if the appliance is in a small room, there is the danger of combustible gases building up. For
every ounce of coolant at least 325 cubic feet of room space is required. The amount of coolant in the
appliance is stated on the data plate inside the appliance. It is hazardous for anyone other than an
Authorized Service Person to carry out servicing or repairs to this appliance.
•Take serious care when handling, moving and using the appliance to avoid either damaging the
refrigerant tubing or increasing the risk of a leak.
•Replacing component parts and servicing shall be done by factory authorized service personnel, so as
to minimize the risk of possible ignition due to incorrect parts or improper service.
FOLLOW WARNING CALLOUTS BELOW ONLY WHEN APPLICABLE TO YOUR MODEL
•Use two or more people to move and install appliance. Failure to do so can result in back or other
injury.
•To ensure proper ventilation for your appliance, the front of the unit must be completely unobstructed.
Choose a well-ventilated area with temperatures above 60°F (16°C) and below 90°F (32°C).
•The appliance should not be located next to ovens, grills or other sources of high heat.
•The appliance must be installed with all electrical, water and drain connections in accordance with
state and local codes. A standard electrical supply (115 V AC only, 60 Hz), properly grounded in
accordance with the National Electrical Code and local codes and ordinances, is required.
•Do not kink or pinch the power supply cord of the appliance.
•The size of the fuse (or circuit breaker) should be 15 amperes.
•It is important that the appliance be leveled in order to work properly. You may need to make several
adjustments to level it.
•All installations must be in accordance with local plumbing code requirements.
•Make certain that the pipes are not pinched, kinked or damaged during installation.
•Check for leaks after connection.
•Never allow children to operate, play with or crawl inside the appliance.
•Do not use solvent-based cleaning agents or abrasives on the interior. These cleaners may damage
or discolor the interior.
•Use this appliance only for its intended purpose as described in this Instruction Manual.
•Keep fingers out of the “pinch point” areas. Clearances between the door and cabinet are necessarily
small. Be careful closing the door when children are in the area.
Risk of child entrapment!
Child entrapment and suffocation are not problems of the past. Junked or abandoned appliances are
still dangerous, even if they will “just sit for a few days”.
Before discarding your old refrigerator:
Take off the doors
Leave the shelves in place so that children may not easily climb inside.
- SAVE THESE INSTRUCTIONS -

5
INSTALLATION INSTRUCTIONS
Before Using your Appliance
•Remove the exterior and interior packing.
•Before connecting the appliance to the power source, let it stand upright for approximately 2
hours. This will reduce the possibility of a malfunction in the cooling system from handling during
transportation.
•Clean the interior surface with lukewarm water using a soft cloth.
•Install the handle on the door, if it is not already attached. (See page 8.)
Installation of your Appliance
•The appliance is designed for built-in or recessed or free standing installation for indoor use.
CAUTION: This appliance is not designed for the storage of medicine or other medical products.
•Place your appliance on a floor that is strong enough to support it when it is fully loaded. To level
the unit, adjust the front leveling legs.
•For free standing installation, 5” (127mm) of space between the back and sides of the unit, and
4” (102mm) at the top, are suggested, which allows the proper air circulation to cool the
compressor and condenser. Even for built-in installation, it is a must to keep ¼” (6.35mm) space
on each side and at the top and 2” (51mm) at the rear. Take care that the air vent at the front of
the appliance is never covered or blocked in any way.
NOTE: It is recommended that you do not install the appliance near an oven, radiator or other
heating source. Direct sunlight may affect the acrylic coating and heat sources may increase
electrical consumption. Don’t install in a location where the temperature will fall below 44°F
(7°C). For best performance, do not install the appliance behind a cabinet door or block the
base grille.
•Avoid locating the unit in moist areas.
•Plug the appliance into an exclusive, properly grounded wall outlet.
Electrical Connection
This appliance should be properly grounded for your safety. The power cord of this appliance is
equipped with a three-prong plug which mates with standard three-prong wall outlets to minimize the
possibility of electrical shock.
Do not under any circumstances cut or remove the third (ground) prong from the power cord
supplied. For personal safety, this appliance must be properly grounded. Any questions concerning
power and/or grounding should be directed toward a certified electrician or an authorized service
center.
WARNING
Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is
damaged, have it replaced by a qualified electrician or an authorized service center.

6
This appliance requires a standard 115/120 Volt AC ~60Hz three-prong grounded electrical outlet.
Have the wall outlet and circuit checked by a qualified electrician to make sure the outlet is properly
grounded. When a standard 2-prong wall outlet is encountered, it is your responsibility and obligation
to have it replaced with a properly grounded 3-prong wall outlet.
To prevent accidental injury, the cord should be secured behind the appliance and not left exposed
or dangling.
The appliance should always be plugged into its own individual electrical outlet which has a voltage
rating that matches the rating label on the appliance. This provides the best performance and also
prevents overloading house wiring circuits that could cause a fire hazard from overheating. Never
unplug the appliance by pulling on the power cord. Always grip the plug firmly and pull straight out
from the receptacle. Repair or replace immediately all power cords that have become frayed or
otherwise damaged. Do not use a cord that shows cracks or abrasion damage along its length or at
either end. When moving the appliance, be careful not to damage the power cord.
Extension Cord
Because of potential safety hazards under certain conditions, it is strongly recommended that you do
not use an extension cord with this appliance. However, if you must use an extension cord, it is
absolutely necessary that it be a UL/CUL-Listed, 3-wire grounding type appliance extension cord
having a grounding type plug and outlet and that the electrical rating of the cord be 115 volts and at
least 10 amperes.
Reversing the Door Swing
If you find the direction of opening the door of the appliance inconvenient, you can change it. Holes
on the opposite side have already been prepared at the factory. To reverse your door, follow these
instructions:
1. Take the upper hinge cover from the door and remove the
screws that hold the top hinge
2. Lift the hinge straight up to free the hinge pin from the
socket in the top of the door
3. Lift the door up and away to free its bottom socket from the
hinge pin
4. Remove the screws to the bottom hinge
5. Remove the decorative caps from the opposite side and
plug the holes from the original side with the decorative
caps
6. Move the bottom hinge to the opposite side and tighten the
screws. Use any lock washers or nuts if they were used in
the original installation.
7. Replace door onto the hinge pin on the bottom hinge. Place top hinge pin into door. Insert
screws into the top hinge.
NOTE: Some door styles may not be reversible. Consult our website for details

7
Installing the Handle
Some units include a handle, which you may want to install. The handle is not required to operate
the unit. To install the handle, follow the instructions below:
1. Use a screwdriver to remove the screws on the side of door where the handle is to be installed.
2. Align the handle with the screws removed in step # 1. Tighten the screws using a Phillips head
screwdriver until the handle is both flush and secured tightly against the door side. (DO NOT
over-tighten as this will cause damage to the door surface.)
OPERATING YOUR BEER FROSTER
It is recommended you install the appliance in a place where the ambient temperature is between
44° and 90°F (7° to 32°C). If the ambient temperature is above or below the recommended
temperatures, the performance of the unit may be affected.
NOTE: If the door of the unit is left open for more than 60 seconds, an alarm will sound. The alarm
will stop once the door is closed.
Your Cold Cavern Beer Froster is designed to keep your beer so cold that the bottle literally frosts
over when removed! The Cold Cavern stores your beer at a frigid 24°F in order to give you the
coldest, crispest beer possible.
This freezer is designed for storing lighter domestic beer, preferable in aluminum cans or bottles
(approximately 50 aluminum bottles or 80 aluminum cans). It is NOT recommended for the storage
of heavier or craft beers, or any beer stored in glass bottles.
Control Panel
A digital thermostat (DT) is located in the kick plate of your unit. The DT is set to 24°F for ideal
frosting, but you may see other symbols displayed, which you may not be familiar with. Refer to the
table below to find the meaning of each indicator symbol:
Indicator
Symbol
Status
Meaning
Setting
Set
ON
Set parameters
OFF
Temperature measuring and
controlling
Cooling
ON
Cooling active
OFF
Cooling inactive
Flash
Cooling delays
Defrost
ON
Defrost active
OFF
Defrost inactive
Dripping
drip
ON
Dripping active
OFF
Dripping inactive
Measurement
unit indicator
light
°C
ON
Unit of measurement display
Measurement
unit indicator
light
°F
ON
Unit of measurement display

8
•Press and hold the SET and the LIGHT keys for three seconds to turn the unit on/off/
•Press the key to view the temperature
•To adjust the temperature, press and hold the SET key for 3 seconds. When the display shows
St, you can raise the temperature by pressing the LIGHT key or lower it by pressing the MENU
ADJUST key, shown below. Press the key, or press no key for 30 seconds, to exit. The
temperature set-point will be saved automatically.
Door Open Alarm:
Your unit will sound an alarm when the door is open for longer than 60 seconds. To disable this:
1. Follow the Setting Parameters instructions on page 8.
2. Find parameter do2.
3. The default for the unit is set at 1(Enabled).
4. To disable the alarm, set the parameter to 0(Disabled).
5. Press the key, or press no key for 30 seconds, to exit. The temperature set-point will be
saved automatically.
Low Temperature Alarm:
To set a low temperature alarm:
1. Follow the Setting Parameters instructions on page 8.
2. Find parameter A5.
3. Use the Use the and keys to adjust the temperature.
4. Press the key, or press no key for 30 seconds, to exit. The temperature set-point will be
saved automatically.
High Temperature Alarm:
To set a high temperature alarm:
5. Follow the Setting Parameters instructions on page 8.
6. Find parameter A6.
7. Use the Use the and keys to adjust the temperature.
8. Press the key, or press no key for 30 seconds, to exit. The temperature set-point will be
saved automatically.

9
Alarms
Various alarms will sound under certain conditions if the unit’s buzzer is enabled. Below is a table
listing the unit’s alarm codes and causes:
Alarm Code
Causes
E1
Cabinet temperature sensor fails.
E2
Evaporator sensor fails.
E3
Condenser sensor fails.
cH
High condenser temperature alarm
rH
High cabinet temperature alarm
rL
Low cabinet temperature alarm
Defrosting
Freezer models and the freezer compartment of refrigerator-freezers require manual defrosting. For
the most efficient operation and minimum energy consumption, defrost the freezer when the frost on
the freezer walls is excessive or ¼ to ½” thick.
CAUTION: Never use boiling water to defrost because it may damage the plastic parts. In addition,
never use a sharp or metallic instrument to remove frost, as it may damage the cooling
coils and will void your warranty. We recommend using a plastic scraper.
To Defrost:
1. Remove any stored items from the unit and place it in another cooling device
2. Turn the thermostat off and unplug your freezer, leaving the door open to help speed up the
defrosting process
3. Use a sponge or toweling to remove water and melting ice from the freezer floor. Pouring warm
(not boiling) water on the ice/frost may also help speed the defrosting process.
4. Clean and thoroughly dry the freezer interior
5. Close the door and plug the freezer in, resetting the thermostat to the desired setting
6. Allow several hours for the cabinet to reach the proper storage temperature
Shelves
To prevent damaging the door gasket, make sure to have the door all the way open when pulling the
shelves out of the rail compartment.
Any of the shelves can be removed to store larger items.
•When removing the shelf from the rail compartment, make sure to remove all items first. Then
move the shelf to the position where the notch of the shelf is exactly under the plastic post and
lift the shelf. In order to replace the shelf, repeat steps described above in reverse.

10
CARE AND MAINTENANCE
Cleaning your Appliance
•Turn off the power, unplug the appliance, and remove all items, including shelves.
•Wash the inside surfaces with a solution of warm water and baking soda (about 2 tablespoons of
baking soda to a quart of water).
•Wash the shelves with a mild detergent solution.
•Wring excess water out of the sponge or cloth when cleaning the area where the controls are
located, or any electrical parts.
•Wash the outside cabinet with warm water and mild liquid detergent. Rinse well and wipe dry
with a clean soft cloth.
CAUTION: Failure to unplug the appliance during cleaning could result in electrical shock or other
personal injury.
Power Failure
Most power failures are corrected within a few hours and should not affect the temperature of your
appliance if you minimize the number of times the door is opened. If the power is going to be off for a
longer period of time, you need to take the proper steps to protect the contents.
Vacations
•Short vacations: Leave the appliance operating during vacations of less than three weeks.
•Long vacations: If the appliance will not be used for several months, remove all items and turn
off the appliance. Clean and dry the interior thoroughly. To prevent odor and mold growth, leave
the door open slightly, blocking it open if necessary.
Moving your Appliance
1. Remove all items.
2. Securely tape down all loose items (shelves) inside your appliance, and tape the door shut.
3. Turn the adjustable legs up to the base to avoid damage.
4. Be sure the appliance stays secure in the upright position during transportation. Also, protect the
outside of the appliance with a blanket or similar item.
Energy-Saving Tips
•The appliance should be located in the coolest area of the room or outdoor location, away from
heat-producing appliances and out of direct sunlight.
•Ensure that the unit is adequately ventilated. Never cover air vents.
•Do not keep the door open any longer than necessary.
•Let warm items cool before placing in the unit. Overloading the unit forces the compressor to run
longer.
•Unit shelves and storage bins should not be lined with aluminum foil, wax paper, or paper
toweling. Liners interfere with cold air circulation, making the unit less efficient.

11
TROUBLESHOOTING
You can solve many common problems easily, saving you the cost of a possible service call. Try the
suggestions below to see if you can solve the problem before calling the servicer.
PROBLEM
POSSIBLE CAUSE
REMEDY
Appliance
does not
operate.
Appliance is not connected to a power
supply.
The appliance is turned off.
Tripped circuit breaker or a blown fuse.
Connect the appliance.
Switch on the appliance.
Switch on circuit breaker or replace
fuse.
Appliance is
not cold
enough.
The temperature is not set correctly.
The ambient temperature could require a
lower temperature setting.
The door was opened too often.
The door was not closed completely.
Door is not hermetically sealed.
The condenser is too dirty.
The ventilation opening is blocked or too
dusty.
Check the set temperature.
Set a lower temperature.
Do not open the door more often than
necessary.
Close door properly.
Check the door seal and clean or
replace.
Clean the condenser when necessary.
Clear the obstructions and clean off
the dust.
Appliance
turns itself
on and off
frequently.
The room temperature is higher than
average.
A large number of bottles or cans has
been added to the unit.
The door is open too often.
The door is not closed completely.
The door gasket does not seal properly.
Put the appliance in a cooler place.
Leave the appliance to work for a
while until the set temperature has
been reached.
Do not open the door more often than
necessary.
Close door properly.
Check the door seal and clean or
replace.
Vibrations
The appliance is not properly leveled.
Level the appliance with the adjustable
feet.
The
appliance
seems to
make too
much noise.
The rattling noise may come from the flow of the refrigerant, which is normal. As
each cycle ends, you may hear gurgling sounds caused by the flow of refrigerant
in your appliance.
If temperature fluctuations occur, the contraction and expansion of the inner walls
may cause popping and crackling noises.
The appliance is not properly level.
Level the appliance with the adjustable
feet.
The door will
not close
properly.
The appliance is not properly level.
The door was reversed and not properly
installed.
The gasket is dirty.
The shelves are out of position.
Level the appliance with the adjustable
feet.
Check the door hinge and reassemble
correctly.
Clean the door gasket.
Check the shelves and refit correctly.

12
LIMITED WARRANTY
ONE-YEAR LIMITED WARRANTY
Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is
operated and maintained according to instructions attached to or furnished with the product, warrantor
will pay for factory-specified parts and repair labor to correct defects in materials or workmanship. Service
must be provided by a designated service company. Outside the 48 states, all parts are warranted for
one year from manufacturing defects. Plastic parts, shelves and cabinets are warranted to be
manufactured to commercially acceptable standards, and are not covered from damage during handling
or breakage. 5-YEAR COMPRESSOR WARRANTY
1. The compressor is covered for 5 years.
2. Replacement does not include labor.
ITEMS WARRANTOR WILL NOT PAY FOR:
1. Service calls to correct the installation of your appliance, to instruct you how to use your appliance,
to replace or repair fuses or to correct wiring or plumbing.
2. Service calls to repair or replace appliance light bulbs or broken shelves. Consumable parts (such
as filters) are excluded from warranty coverage.
3. Damage resulting from accident, alteration, misuse, abuse, fire, flood, acts of God, improper
installation, installation not in accordance with electrical or plumbing codes, or use of products
not approved by warrantor.
4. Replacement parts or repair labor costs for units operated outside the United States.
5. Repairs to parts or systems resulting from unauthorized modifications made to the appliance.
6. The removal and reinstallation of your appliance if it is installed in an inaccessible location or is
not installed in accordance with published installation instructions.
7. DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
CUSTOMER'S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE
PRODUCT REPAIRAS PROVIDED HEREIN. IMPLIED WARRANTIES, INCLUDING WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR.
WARRANTOR SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. SOME
STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES, OR LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS, SO THESE EXCLUSIONS OR LIMITATIONS MAY NOT APPLY
TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO HAVE
OTHER RIGHTS, WHICH VARY FROM STATE TO STATE.
FELIX STORCH, INC.
An ISO 9001:2015 registered company
770 Garrison Avenue
Bronx, NY 10474
www.summitappliance.com
FELIX STORCH, INC.
An ISO 9001:2015 registered company
770 Garrison Avenue
Bronx, NY 10474
www.summitappliance.com
