Summit FS-56L User manual

FELIX STORCH, INC.
SUMMIT APPLIANCE DIVISION®
INSTRUCTION MANUAL FOR MODELS:
FS-60
FS-56L
Thank you for putting your trust in our company and for purchasing this appliance. We
hope it will successfully serve its purpose for many years.
A Freezer is used for freezing fresh foods at a temperature of -25°C.
The FS-60 is a front opening freezer. This freezer contains open shelves and in-door
storage. It offers a full 5.0 cubic feet of capacity.
The FS-56L is the same as the FS-60 but with a side mounted lock.
All-Freezer

Before Putting Into Use
Before connecting the appliance to the power supply, leave it standing for about 2
hours, which will reduce a possibility of malfunctions in the cooling system due
to transport handling.
Clean the appliance thoroughly; especially in the interior (See Cleaning and
Maintenance).
Instructions for Use
These instructions for use are intended for the user. They describe the appliance and
the correct and safe way to use it. The instructions were prepared for various
types/models of refrigerators therefore you may find in it descriptions of some
accessories and functions that your appliance may not have.
We Care for the Environment
Our appliances are distributed in packaging made of environmental friendly
material which could safely be recycled, disposed of or destroyed without any
effects on the environment whatsoever.
Our instruction manuals are printed either on recycled paper or chlorine free
bleached paper.
Tips for Energy Savings
Try not to open the door too often, especially when the weather is hot and
humid. Once you open the door try to close it as soon as possible.
Every now and then check if the appliance is sufficiently ventilated
(adequate air circulation behind the appliance).
Set thermostat from higher to lower settings as soon as possible
(depending on how loaded the appliance is, the ambient temperature
etc...).
The coils on the rear of the refrigerator should be cleaned and free of dust
or any other impurities.
Ice and frost layer increase energy consumption, so do clean the appliance
as soon as the layer is 1/8” thick.
Always consider instructions stated in sections Positioning and Energy
Saving Tips, otherwise the energy consumption is substantially higher.
Instructions for Use

Important
To reduce the risk of fire, electrical shock,
Warning! or in
j
ur
y
when usin
g
y
our appliance,
follow these basic precautions.
Read all instructions before using the appliance
If you bought this appliance to replace an old one equipped with a lock
that cannot be opened from inside (lock, bolt), make sure that the lock is
broken. This will make it impossible for children to lock themselves
inside the appliance and suffocate.
The appliance must be correctly connected to the power supply.
If the food has a strange smell or color throw it away because it is very
likely that it is spoiled and therefore dangerous to eat.
Disconnect the appliance from the power supply before repairing and
cleaning it (only a qualified technician should repair it).
Use only enclosed tools or tools recommended by the manufacturer.
For the sake of environmental protection be careful not to damage the rear
wall of the appliance (the condenser unit or the tubes when moving the
refrigerator) or any part of the freezing system inside the appliance. Use
only enclosed tools or tools recommended by the manufacturer.
DANGER: Risk of child entrapment.
Before throwing away your old freezer please remove the doors and leave
the shelves in place so that children may not easily climb inside.
The rating plate is inside the appliance or outside on the rear wall.
Disposing of the Worn Out Appliance
When your appliance finally wears out, dispose of it. If the appliance has
a lock, break it to prevent eventual accidents (danger of children getting
locked inside the appliance).
Instructions for Use

Placing and Installation
Choosing the Right Place
Place the appliance in a strong dry and regularly ventilated room. Allowed
ambient Temperature depends on the model (class) of the appliance and is stated
on the rating plate of the appliance.
Class Ambient Temperature
SN (sub-normal) from + 56°F to + 90°F
N (normal) from + 62°F to + 90°F
ST (sub-tropical) from + 64°F to +100°F
T (tropical) from + 64°F to +120°F
The appliance may be exposed to lower or higher temperatures but only for
shorter period of time and the temperature should never be lower than 41°F.
Never place the appliance near heat emitting devices (e.g. cooker, radiator, water
heater or similar devices) and do not expose it to direct sunlight.
The appliance should be positioned at least 3 cm away from the electric or gas
cooker and at least 30 cm away from the oil or coal stove. If this isn’t possible use
an appropriate insulation. Behind the appliance there should be free space at least
200 cm² wide. And above the appliance the high kitchen units should be at least
five cm above the appliance in order to assure adequate ventilation of the
condenser unit.
Placing the Self-Standing Appliance
It is important to make sure the appliance is leveled evenly to prevent falling.
Two spacers attached to the appliance must be fitted onto the upper edge of the
condenser, thus preventing the appliance from being installed too close to the
wall. Spacers are manufactured for all-purpose functions depending on the
distance of the condenser from the wall. Therefore turn spacers correspondingly
and adjust them accordingly to the appliance.
Connection to Power Supply
Connect the appliance with the cable and plug to the power supply socket outlet
with a ground terminal (safety socket).
“DO NOT USE AN EXTENSION CORD.”
Required nominal voltage and frequency are indicated on the rating plate.
The connection to the power supply and grounding has to be made according to
current standards and regulations. The appliance resists temporary voltage
tolerance up to -15 to 10%.
Instructions for Use

Description of the Appliance
Shelves
If you want to remove the shelf slightly lift up the back part and pull it out.
Quickly perishable foods should be stored on the back of the shelf which is the
coldest part.
Lock (optional)
The side mounted lock with a spring can be locked or unlocked by slightly
pressing the key turning it to the left or right at the same time.
NOTE:
•The appliance can be equipped with various accessories, depending on the model
of the appliance.
•Door handles are in various shapes, depending on the model.
•Various accessories (spice container, tube holder or additional shelves) can be
bought in authorized centers.
Instructions for Use

Operation Control
The appliance is controlled with the thermostat knob, placed in the right upper
part inside the appliance.
Turn the knob clockwise from STOP (0) position towards 7 and backwards.
Temperature Selection
•When the freezer operates automatically, the interior temperature is
controlled by the thermostat. Higher settings on the knob mean colder
temperatures in all compartments of the appliance. The temperature in the
interior of the appliance may even drop below 32°F. Only use higher
thermostat settings when required or recommended. The most suitable
thermostat position is in the middle, between max and min.
•Changes of the ambient temperature affects the temperature in the interior
of the appliance (choose the correct setting on the thermostat knob).
•When the knob is on the STOP (0) position the appliance does not operate
(the cooling system is switched off), yet the power supply is not
interrupted (the light will still come on if you open the door).
•Temperature in the refrigerator and in low temperature compartments also
depend on how often you open and close the door.
Instructions for Use

Use
Storing Fresh Foods
•Foods to be stored in the freezer should be properly packed as to prevent
mixing various moisture degrees and odors (in polyethylene bags or sheet,
aluminum foil and covered containers).
•Never store any inflammable, volatile or explosive substances.
•Food should not touch the rear wall of the freezer.
•Some organic solutions like volatile oils in lemon and orange peel, acid in
butter etc. can cause damages when in contact with plastic surfaces or
gaskets for a long period of time.
•An unpleasant odor inside the freezer is a sign that something is wrong
with the food or that your freezer needs cleaning. Odors may be
eliminated or reduced by washing the interior of the freezer with a mild
solution of water and vinegar. We also recommend using activated carbon
filters to clean the air or to neutralize odors.
Commercially Frozen Foods
Storage time (months)
Article of Food
1 2 3 4 5 6 7 8 9 10 11 12
Vegetable + + + + + + + + + +
Fruit + + + + + + + + + + + +
Bread, Pastries + + +
Milk + + +
Ready-Made Meals + + +
Beef + + + + + + + + + + + +
Veal + + + + + + + + + +
Pork + + + + + +
Poultry + + + + + + + + + +
Game + + + + + + + +
Minced Meat + + = = = = = = = =
Smoked Sausages + + + +
Lean Fish + + +
FatFish +
Offal ++
Legend: + means recommended storage time
Instructions for Use

Changing the Direction of Opening the Door
If the door opening direction does not suit you, it may be changed to the opposite
side of the cabinet were holes are already made.
•Before changing the door the front side of the appliance must be slightly
raised.
•If the screws are covered with caps take them off before undoing the
screws.
•The lower hinge (2) can be removed by unscrewing the hinge and
removing the nuts (8) from the appliance.
•Then remove the door.
•Push the kick plate into its new position.
•Unscrew the upper hinge pin (1)
•Change the positions of the pins (5) and the door bearings, (7) at the top
and the bottom.
•Slip the door on the upper hinge pin (1).
•With the screws and nuts fix the lower hinge.
•Make sure the refrigerator is leveled so that it doesn’t fall.
•Unscrew the handle and place it on the opposite side of the appliance (it
cannot be done with handles mounted horizontally).
•At last check the resting of the magnetic seals (the seal must not be
creased and should seal well).
Instructions for Use

Maintenance and Cleaning
Manual Defrosting of the All-Freezer
When the frost and ice layer in the freezer is 1/8” thick you should clean the
freezer.
•First turn the thermostat knob to the STOP (0) position and disconnect the
power supply. Empty the compartment and make sure that the packages
remain frozen.
•Place a suitable vessel under freezer to collect the defrost water. Leave the
freezer door open to accelerate defrosting.
Cleaning the Appliance
Disconnect the power supply before cleaning the appliance. Do not use coarse or
Aggressive cleaning agents as you can damage the surface.
•Clean the exterior with water and detergent. Varnished surfaces are
cleaned with soft cloth and an alcohol based cleaning agent (for example
glass cleaners). You may also use alcohol (ethanol or isopropyl alcohol).
The application of abrasive and especially aggressive cleaners, such as
stainless steel cleaners, is not appropriate for the cleaning of plastic and
coated parts.
•Remove the detachable accessories in the interior of the appliance and
clean it with water and liquid detergent. Plastic parts cannot be washed in
a washing machine.
•Wash the interior of the appliance with lukewarm water, in which you add
one or two spoonfuls of vinegar.
•Every now and then wipe the condenser on the rear wall. Use a soft non-
metal brush or vacuum cleaner.
•Do not forget to clean the defrost water receptacle above the refrigerators
compressor (do not remove the receptacle). After cleaning, connect the
appliance to the power supply and reload the packages.
•Clean the drain pan on the refrigerators compressor, but do not remove the
drain pan.
After Cleaning, connect the appliance into the power supply and reload the
packages.
Instructions for Use

Switch Off the Appliance When Not in Use
If you do not intend to use the appliance for a long period of time set the
thermostat knob to the STOP (0) position and disconnect the power supply. Then
take out the foods and defrost and clean the appliance. Leave the door slightly
open.
Trouble-Shooting Guide
During the service of your appliance, you can come across some troubles that in
most cases result from improper handling of the appliance that can easily be
eliminated.
The Appliance Fails to Operate After Connecting to the Power Supply
•Check the supply in the outlet socket and make sure the appliance is
switched on (thermostat in the operating position).
Continuous Operation of the Refrigerating System
•The door was frequently opened or it was left open too long.
•The door is not properly closed (the door may sag; the gasket may be
polluted or damaged).
•Perhaps you have overloaded the appliance with fresh foods.
•The reason may be inadequate ventilation of the compressor and
condenser (assures adequate air circulation and wipe off the condenser).
Ice Formation on the Inner Rear Wall
As long as the defrost water runs to the channel and through the opening to the
drain pan on the compressor, automatic defrosting of the appliance is assured. In
case the ice formation on the inner back wall is increased (1/8”), ice should be
manually defrosted.
Set the thermostat knob to STOP (0) position and leave the door open. Never use
electric devices for defrosting and do not scrape the ice or frost layer with sharp
objects. After completed defrosting, turn the knob to desired position and close
the refrigerator door.
The cause of increased ice formation may be one of the following reasons:
-The door does not seal well (clean the gasket if it is contaminated,
or replace it if it is damaged).
-The door was frequently opened or it was left opened for too long.
-The food stored in the refrigerator was warm.
-The food or dish is touching the inner back wall.
Water is Leaking from the Refrigerator
In case the discharged water outlet is clogged, or the defrost water drips over the
channel, or water leaks from the refrigerator just clean the clogged opening with a
plastic straw. Manually defrost the increased ice layer. See “Ice Formation on the
Inner Back Wall”.
Instructions for Use

Noise
Cooling in the freezing appliances is enabled by the compressor, this produces
noise. How noisy the appliance is depends on where it is placed, how it’s used
and how old the appliance is.
•After starting the appliance, the operation of the compressor may be
louder and this does not mean something is wrong with the appliance. The
noise will reduce gradually, this will not affect the lifetime of the
appliance.
•Sometimes unusual and strong noises occur which is rather unusual for the
appliance. This noise is often a consequence of inadequate placing. To
avoid the noise make sure the appliance is placed and leveled firmly on a
solid base. Make sure the appliance is not touching the wall or kitchen
units standing next to it. And always make sure you check the accessories
in the interior of the appliance; they should be placed correctly in their
positions.
BEFORE CALLING FOR SERVICE
Check the plug and fuse.
Test the outlet with a lamp
Be sure the control is not set to OFF
Read the manual, especially the items under the Use and Care sections.
You may find the answer to your questions.
If you don’t find the answer to your questions in this manual, find the
unit model number (on the upper back of the refrigerator) and contact
your Summit Appliance Dealer.
Specifications are Subject to Change Without
Notice.
Instructions for Use
