Summit FS627SSHH User manual

FS627 Series 33.5" x 23.63" x 23.5" (H x W x D)
Freestanding counter height all-freezers with
commercial approval, capable of -25º C operation
Highlights:
-25º C operation for safe storage of temperature sensitive materials
3 convenient slide-out baskets to keep the cold inside
Available in white or stainless steel
ETL-S listed for commercial use
Fully finished white
cabinet Allows the unit to be used freestanding
-25º C capable Low temperature operation is ideal for vaccine, pharmaceuticals, and other temperature sensitive
materials
Slim counter height
dimensions Less than 24 inches wide to fit tight spaces
Commercially approved ETL-S Approved to ANSI-NSF Standard 7
Manual defrost No temperature fluctuations with a static manual defrost system that keeps the cold inside
Adjustable thermostat Manage the interior temperature with ease and accuracy
Three removable
storage baskets Conveniently organize your items while keeping the temperature stable when the door is opened
One piece interior liner Enjoy easy clean-up with a one piece liner that won't hold a mess in hidden crevices
No internal fans Static cooling system
Reversible door Keep your options flexible with a reversible door that is easy to switch when your arrangement changes;
not available on stainless steel doors

Specifications:
Height 33.5"
Width 23.63"
Depth 23.5"
Capacity 3.2 cu.ft.
Ext Depth with Handle 25.13"
Interior Height 1 24.25"
Interior Width 1 17.75"
Interior Depth 1 16.5"
Comp Step Height 6.5"
Comp Step Width 17.5"
Comp Step Depth 5.5"
Shipping Weight 102.0 lbs.
Canadian Electrical Safety ULC
US Electrical Safety UL
Voltage/Frequency 115 V AC/60 Hz
Amps 1.3
Reversible Yes
Door Swing RHD
Drawers true
Drawer Quantity 3
Defrost Type Manual
Depth with door at 90° 46.13"
Thermostat Type Dial
Condensor Location Rear of Unit
Low Side PSI 70.0
Level Legs Quantity 2
High Side PSI 235.0
Freon Type R134a
Freon Oz 2.7
Compressor Warranty 5Years
Parts/Labor Warranty 1 Year
Sanitation ETL-S
