Sun King Folding Frame Clothesline Post Kit User manual

Post Kit
Folding Frame
Clothesline
Product Manual

2Introduction
Congratulations
Congratulations on the purchase of your
new Sun King Folding Frame Clothesline Post Kit.
It is important that you read this Product Manual
thoroughly before installation and use. In this way
you will benet from all the design features and
enjoy safe use of the product. Thank you for
choosing Sun King.
Warning
• Do not allow children or pets to swing
on your Clothesline or items of laundry.
• Ensure when raising and lowering your
Clothesline that bystanders (in particular
children) are standing well clear.
• Do not use your Folding Clothesline
for any purpose other than to hang and
dry washing.
• Do not use your Clothesline if parts are
worn or damaged.
• Do not allow the frame to lower in an
uncontrolled manner as damage or
injury may result.
Patents and Registered Designs apply to
this product.
Please retain this Product Manual. Record the following
information for future reference.
Product Number (printed on carton):
Date of purchase:
Name and location of store:
Made in China

3
Installation
Step 2 – Select a suitable location
2.1 Select a suitable location for your Post
mounted Folding Frame Clothesline.
2.1 Ensure you have left sucient space
surrounding the Clothesline (Fig. 1).
We recommend 0.1m each side and
0.75m in front.
Product Dimensions
Product Width
(mm)
Depth
(mm)
Double Folding Frame
Clothesline 2250 1200
Single Folding Frame Clothesline 2250 1200
Carton contents
Part name Qty.
Post - xed 2
Cross brace 1
Product manual 1
Post kit accessory bag (includes):
2 x M8 x 75 ZP socket head screw
2 x M8 x 55 ZP socket head screw
4 x M8 ZP nyloc nuts
1 x hex key 6mm
8 x M8 washer
1
M8 nyloc nut
M8 washer
M8 x 55 socket
head screw
M8 x 75 socket
head screw
Step 1 – Unpacking the Folding
Frame Clothesline Post Kit
Check all components are in the carton
(refer to tables above for your model).
Fig. 1
Depth
Width
750mm
(30") minimum
100mm (4") minimum
Ensure area is free from pipes and obstructions

4Installation
Step 3 – Installing the Post Kit
3.1 You will require the following materials
and tools:
Pre-mix concrete
Coarse gravel
Spade
Tape measure
Spirit level
Recommended Installation Height
Post Hole Centres
Product Centres
(mm)
Double Folding Frame Clothesline 2200
Single Folding Frame Clothesline 2200
Ground Level
50mm
User’s Head Height
= Top of Bracket
Recommended Clearance
= User’s Head Height
+ 50mm
Post Height = User’s Head Height
+ 30mm
Refer to specific installation page
for details
Top of Bracket
User’s Head Height
30mm

5
Step 4 – Installing Fixed Posts
4.1 Having selected a suitable location, dig two
holes approximately 200mm diameter
x 600mm deep at hole centres to suit your
product (see Post Hole Centre Chart on pg.4).
Place approximately 150mm
of coarse gravel into the hole.
4.2 Place Posts into the hole. Push the base of the
Posts into the gravel until the recommended
height is achieved.
We recommend that the Spreader Bar of your
Folding Frame Clothesline is installed 50mm
above your typical user head height, therefore
the top of the Posts must be installed 30mm
above user head height (refer to diagram pg. 4).
4.3 Loosely fasten the Cross Brace to the top hole
in each Post using the M8 x 80mm socket head
bolts.
4.4 Support and check (using a spirit level and tape
measure) that the Posts are parallel
with each other and level, both vertically
and horizontally.
4.5 Concrete Posts into position. Concrete should
be damp enough to hold together when
squeezed in your hand. Pack the concrete rmly
and settle by poking with a thin stick. Slope the
top surface of the concrete away from the Posts
to provide drainage away from the Post.
4.6 Re-check Posts are parallel and level, then allow
concrete to set thoroughly for at least 24 hours
before nal product assembly.
Installation
Post – Fixed
200mm
450mm
Concrete
150mm
Gravel
600mm
Slope top
surface of
concrete away
from post.

6Warranty and Contacts
In addition to all rights and remedies to which you may be entitled under the New Zealand Consumer
Guarantees Act (1993) and any other relevant legislation, Holdfast NZ Limited warrants the product to be free
from defects in materials or workmanship for 10 years from the date of purchase.
In the event of a claim, you must take the product with proof of purchase and an explanation of the fault
to the place of purchase or contact Holdfast NZ Limited and provide your proof of purchase. All costs
associated with the return of the good (and other expenses incurred in claiming under this warranty) are your
responsibility. We will, at our option, either repair or replace the product if it has a defect in its materials or
workmanship.
Holdfast NZ Limited liability under this warranty is subject to Holdfast NZ Limited being satised that a defect
was caused by defective workmanship or materials and was not caused by or substantially contributed to
by other factors including (but not limited to) maintenance or repair, adjustments or modications of the
product in a manner not recommended by the manufacturers or any neglect, misuse or excessive use. For
the avoidance of doubt, this warranty does not cover acts of God, earthquake, cyclone, re, explosion, ood,
landslide, lightning, storm, tempest, drought or meteor, war, terrorism, restraint or damage to property by or
under the order of any government authority or industrial action.
You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be
of acceptable quality and the failure does not amount to a major failure.
For goods purchased within New Zealand, this warranty is provided by Holdfast NZ Limited ,
14 Avalon Drive, Nawton, Hamilton. Phone [phone].
Holdfast Contacts
HOLDFAST NZ LTD
14 Avalon Drive, SH 1, Nawton 3200
PO Box 4206, Hamilton East 3247
Hamilton, New Zealand
Ph: [phone], Fax [phone]
Free Phone: [phone]
Email: [email protected]
www.holdfast.co.nz
