Sun Microsystems SPARCengine Ultra AXi User manual

901 San Antonio Road
Palo Alto, CA 94303 USA
800-681-8845
Sun Microsystems, Inc.
SPARCengine™Ultra™AXi
OEM Technical Manual
Part No. 805-3158-03
May 1999

Please
Recycle
©1999 Sun Microsystems, Inc. All Rights reserved.
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROVIDED “AS IS” WITHOUT ANY EXPRESS REPRESENTATIONS OF WARRANTIES. IN ADDITION, SUN
MICROSYSTEMS, INC. DISCLAIMS ALL IMPLIED REPRESENTATIONS AND WARRANTIES, INCLUDING ANY WARRANTY OF MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE, OR NON-INFRINGEMENT OF THIRD PARTY INTELLECTURAL PROPERTY RIGHTS.
This document contains proprietary information of Sun Microsystems, Inc. or under license from third parties. No part of this document may be reproduced in any form or by
any means or transferred to any third party without the prior written consent of Sun Microsystems, Inc.
Sun, Sun Microsystems, the Sun Logo, SPARCengine, Ultra, Ultra AXi, Solaris, OpenBoot are trademarks or registered trademarks of Sun Microsystems, Inc. in the United States
and other countries. All SPARC trademarks are used under license and are trademarks or registered trademarks of SPARC International, Inc. in the United States and other
countries. Products bearing SPARC trademarks are based upon an architecture developed by Sun Microsystems, Inc.
The information contained in this document is not designed or intended for use in on-line control of aircraft, aircraft navigation or aircraft communications; or in the design,
construction, operation or maintenance of any nuclear facility. Sun disclaims any express or implied warranty of fitness for such uses.

Preface iii
Electromagnetic and Safety Information
Compliance with EMI and safety regulations for products including the
SPARCengine Ultra AXiis entirely the responsibility of OEMs. The SPARCengine
Ultra AXiis expected to pass FCC class B tests in a representative enclosure. The
printed wiring boards within the product are manufactured by UL recognized
manufacturers and have a flammability rating of 94-V0 or better.
Note that the product includes a lithium battery, the disposal of which is subject to
regulation in some jurisdictions.
The SPARCengine Ultra AXiis intended for inclusion in systems meeting the
following regulations:
■USA EMC FCC Class B
■USA Safety UL 1950
■Canadian EMC IC Class B
■Canadian Safety CSA C22.2 No 950
■European Union EMC CE Mark EN55022 & EN50082-1
■European Union Safety CE Mark EN60950
■Japanese EMC VCCI Class 2

iv SPARCengine Ultra AX i OEM Technical Manual • May 1999
Preface
The SPARCengine Ultra AXiproduct is a highly integrated, high performance
motherboard designed for the use of OEMs who want to develop products that have
UltraSPARC performance in a PC-ATX environment.
The SPARCengine Ultra AXi OEM Technical Manual describes the functions of the
SPARCengine Ultra AXimotherboard, its controls, indicators, connectors and
pinouts, boot sequence, diagnostics, troubleshooting, installation and removal
procedures, and its specifications. It also provides some of the critical mechanical
drawings for the motherboard and CPU module.
Who Should Use This Book
The SPARCengine Ultra AXi OEM Technical Manual is written for computer
hardware engineers, system programmers, computer technicians and others
involved in the integration of the Ultra AXimotherboard. References are provided
for further details.
How This Book Is Organized
The SPARCengine Ultra AXi OEM Technical Manual is organized as follows:
Chapter 1, “Introduction” explains the capabilities and major features of the Ultra
AXimotherboard.
Chapter 2, “Specification Summary” provides a summary of specifications of the
Ultra AXimotherboard.

v
Chapter 3, “Functional Description” provides a short description of the function of
each component on the Ultra AXimotherboard.
Chapter 4, “Sequence of Events at Power Up” details the sequence of events that
occur at Power Up and discusses interaction with OBP and Solaris where applicable.
Appendix A, “Jumpers, Headers, Connectors, and Adapters” describes the jumper
settings, header pinouts, connector pinouts, and adapters on the Ultra AXi
motherboard.
Appendix B, “Mechanical Drawings” provides the drawings for the I/O panel,
CPU module, Ultra AXimotherboard, Creator Graphics module and a thermal map
of the motherboard.
Appendix C, “Assembly, Installation and Initial Start Up Procedures” describes
how to assemble and install a motherboard in a typical ATX-type enclosure and
describes how to install the required software and initially start the system.
Appendix D, “OpenBoot Firmware” provides information on the OpenBoot
Firmware used in the Ultra AXisystem.
Appendix E, “System Software Solaris 2.6 Operating Environment” provides
information on the Solaris 2.6 Software used in the Ultra AXisystem.
Appendix F, “System Software SunVTS Validation Test Suite” provides
information on the SunVTS suitable for the Ultra AXisystem based on SunVTS 2.1
Ultra AXiversion.
Related References
System Architecture:
■The SPARC Architecture Manual, Version 9, David L. Weaver and Tom Germond,
editors, PTR Prentice Hall
■PCI System Architecture, by Shanley and Anderson, MindShare Press
Specifications and Standards
■ATX Specification Version 2.01
(http://www.data-tech.co.za/ATX-FORM.htm)
■PCI Local Bus Specification, Revision 2.1, PCI Special Interest Group, Portland
■IEEE Standard 1275-1994, Standard For Boot (Initialization, Configuration) Firmware,
Core Practices and Requirements
■IEEE Standard 1275.1-1994, Standard For Boot (Initialization, Configuration) Firmware,
ISA Supplement for IEEE P1754 (SPARC)

vi SPARCengine Ultra AX i OEM Technical Manual • May 1999
■IEEE Standard P1275.6/D4, Standard For Boot (Initialization, Configuration) Firmware,
64 Bit Extensions
■PCI Bus Binding to IEEE 1275-1994, Standard for Boot (Initialization, Configuration)
Firmware, Revision 1.0, 14 April 1994, Prepared by the Open Firmware Task Force
of the PCI Alliance
Integrated Circuit Specifications:
■UltraSPARC IIi User’s Manual
(805-0087-01)
■SME1040 Highly Integrated 64-bit RISC Processor, PCI Interface Data Sheet
(805-0086-02)
■STP2003QFP PCI Input Output Controller (PCIO) User’s Manual
(802-7837-01)
■STP2210QFP Reset/Interrupt/Clock Controller (RIC) User’s Manual
(805-0167-01)
■SME2411BGA-66 Advanced PCI Bridge (APB) User’s Manual
(805-1251-01)
Other Sun Publications
■Open Boot 3.X Command Reference Manual
(802-5837-10)
■Open Boot 3.X Command Supplement for PCI (Solaris 2.5.1, 8/97)
(805-1627-10)
■Writing Fcode 3.x Programs
(802-6287-10)
■ASM Utilization and Calibration Application Note
(805-4877-01)
■Sun VTS 2.1 Users Guide
(802-7299-10)
■SunVTS 2.1 Test Reference Manual
(802-7300-10)

vii
What Typographic Changes Mean
The following table describes the typographic changes used in this book.
Prompts in Command Examples
The following table shows the default system prompt and superuser prompt for the
C shell, Bourne shell, and Korn shell and OBP.
TABLE P-1 Typographic Conventions
Typeface or
Symbol Meaning Example
AaBbCc123 The names of commands, files,
and directories; on-screen
computer output
Edit your .login file.
Use ls -a to list all files.
machine_name% You have mail.
AaBbCc123 What you type, contrasted with
on-screen computer output machine_name% su
Password:
AaBbCc123 Command-line placeholder:
replace with a real name or
value
To delete a file, type rm filename.
AaBbCc123 Book titles, new words or
terms, or words to be
emphasized
Read Chapter 6 in User’s Guide. These
are called class options.
You must be root to do this.
TABLE P-2 Prompts
Shell Prompt
C shell prompt machine_name%
C shell superuser prompt machine_name#
Bourne shell and Korn shell
prompt $
Bourne shell and Korn shell
superuser prompt #
OBP Prompt ok

viii SPARCengine Ultra AX i OEM Technical Manual • May 1999

Contents ix
Contents
1. Introduction 1-1
1.1 Features 1-3
1.2 Determination of Serial Number and Version 1-5
1.2.1 Motherboard 1-5
1.2.2 CPU Module 1-6
1.2.3 Firmware 1-6
1.2.4 Software 1-6
1.3 Technical Support and Warranty 1-7
1.4 Independent Hardware Vendors (IHV) 1-7
1.5 Version History 1-8
1.5.1 Ultra AXi Board 1-8
1.5.2 CPU Module 1-8
1.5.3 OBP 1-9
1.5.4 Solaris 1-9
2. Specification Summary 2-1
2.1 Functional Specifications 2-1
2.1.1 CPU Module 2-2
2.1.2 Main Memory Modules 2-2
2.1.3 UPA64S Interface (Optional FFB) 2-3
2.1.4 Ultra-Wide SCSI Interface (SYM53C876) 2-4

x Contents
2.1.5 Ethernet 10/100 BASE-T Interface 2-5
2.1.6 PCI Connectors 2-5
2.1.7 Sun Keyboard and Mouse Interface 2-6
2.1.8 PS/2 Keyboard Interface 2-6
2.1.9 PS/2 Mouse Interface 2-6
2.1.10 Parallel Port Interface 2-6
2.1.11 Serial Port Interface 2-7
2.1.12 Floppy Disk Drive Interface 2-7
2.1.13 Non-Volatile Memory, Time-of-Day 2-8
2.1.14 Advanced System Monitoring 2-8
2.1.15 Default Power On/Off Jumper 2-11
2.1.16 Power On-Off Switch (front of enclosure) 2-12
2.1.17 Speaker (enclosure mounted) 2-12
2.1.18 Reset Switch (front of enclosure) 2-12
2.2 Power Requirements 2-13
2.3 Mechanical 2-13
2.4 Reliability 2-14
2.5 Environmental 2-14
2.6 EMI Compliance 2-15
2.7 U.L. Recognition 2-15
3. Functional Description 3-1
3.1 General Information 3-1
3.1.1 Terminology 3-2
3.1.2 Block Diagram 3-3
3.2 Layout Diagram 3-4
3.3 SPARCengine Ultra AXi Motherboard 3-5
3.3.1 CPU Module 3-5
3.3.2 Main Memory Modules 3-5
3.3.3 Flash Memory 3-6

Contents xi
3.3.4 TOD/NVRAM 3-6
3.3.5 FFB2 Graphics 3-6
3.3.6 Communication Ports 3-6
3.3.7 Printer Port 3-7
3.3.8 Sun Keyboard and Mouse 3-7
3.3.9 PS/2 Keyboard and Mouse 3-7
3.3.10 Floppy Drive 3-8
3.3.11 Ethernet Port 3-8
3.3.12 External and Internal SCSI Interface 3-8
3.3.13 PCI Bus Connectors 3-8
3.3.14 Memory Bus 3-9
3.3.15 UPA64S Bus 3-9
3.3.16 PCI 66 Bus 3-9
3.3.17 EBus2 3-9
3.4 Advanced System Monitoring (ASM) 3-9
3.4.1 Temperature Monitoring Points 3-10
3.4.2 Voltage Monitoring Nodes 3-10
3.4.3 Fan Control and Monitoring 3-10
3.4.4 OBP Functions for ASM 3-11
3.4.5 Solaris Driver Functions for ASM 3-11
3.5 Miscellaneous Information 3-12
4. Sequence of Events at Power Up 4-1
4.1 Configuration 4-1
4.2 Reset Cautions 4-3
A. Jumpers, Headers, Connectors, and Adapters A-1
A.1 Jumpers A-3
A.2 Headers A-4
A.2.1 Reset Switch Header J1501 A-4
A.2.2 Power On LED Header J1990 A-5

xii Contents
A.2.3 PS/2 Mouse Header J2500 A-5
A.2.4 PS/2 Keyboard Header J2501 A-5
A.2.5 PS/2 Speaker Header J3201 A-6
A.2.6 Power On-Off Switch Header J3301 A-6
A.2.7 Reserved (Do Not Use)J3302 A-6
A.2.8 12V Optional/Back Fan HeaderJ3602 A-7
A.2.9 12V CPU/Front Fan HeaderJ3603 A-7
A.3 Connectors A-8
A.3.1 ATX Power Connector J1901 A-8
A.3.2 Memory DIMMs J0301, J0302, J0303, J0304
J0401, J0402, J0403, J0404 A-9
A.3.3 UltraSPARC Module (Memory and UPA64S)
ConnectorJ0101 A-10
A.3.4 UltraSPARC Module (PCI-66) ConnectorJ0102 A-13
A.3.5 UPA64S (Vertical FFB) ConnectorJ0601 A-15
A.3.6 PCI 32-Bit Connectors J2001, J2002, J2003
J2101, J2102, J2103 A-18
A.3.7 Internal SCSI ConnectorJ1001 A-19
A.3.8 External SCSI ConnectorJ1003 A-20
A.3.9 Floppy Disk Drive Connector J1902 A-21
A.3.10 Serial Port Male Connector J1802 A-22
A.3.11 Parallel Port Female Connector J0901 A-23
A.3.12 EtherNet Transceiver Connector TPJ2301 A-24
A.3.13 Sun Keyboard and Mouse J0902 A-25
A.4 Adapters A-26
A.4.1 (PS/2) Keyboard and MouseJ2500 Mouse
AdapterJ2501 Keyboard A-26
A.4.2 Serial Port Channels A and B A-27
B. Mechanical Drawings B-1
B.1 Ultra AXi Motherboard Dimensions B-1
B.2 Height Profiles B-3

Contents xiii
B.3 Back Panel Connections B-6
B.4 Thermal Map B-7
B.5 UltraSPARC IIi CPU Module Mechanical Drawings B-9
C. Assembly, Installation and Initial Start Up Procedures C-1
C.1 Before You Start C-1
C.1.1 Materials Required C-2
C.1.2 Power Budgeting C-3
C.1.3 Software Installation Information C-4
C.1.4 Tools Required C-5
C.2 Typical Assembly C-5
C.2.1 DIMM Configuration Considerations C-16
C.3 Initial Power-On and Firmware Update C-26
C.4 Software Installation C-27
C.5 System Aging Test C-28
D. OpenBoot Firmware D-1
D.1 Minimum Requirements D-2
D.2 Additional OBP Features in Ultra AXi D-2
D.2.1 Additional Commands D-3
D.2.2 Additional Environment Variables D-3
D.3 Flash Memory and NVRAM Layout D-4
D.4 Power on Self-Test (POST) D-5
D.5 OpenBoot Diagnostics (OB Diag) D-6
D.6 Entering the OBP Environment D-7
D.7 Selected OBP Commands D-8
D.8 Configuration Variables D-9
D.9 Device Tree D-11
D.10 PCI Probe Lists D-12
D.11 Device Aliases D-13
D.12 OBP Video Drivers D-14

xiv Contents
D.12.1 Sun FFB Video Drivers D-14
D.12.2 PCI Video Drivers D-15
D.13 PS/2 Keyboard D-15
D.14 ASM Operation D-16
D.15 Field Upgrade of OBP D-16
D.15.1 Upgrading OBP When Operating in OBP D-17
D.15.2 Upgrading OBP When Operating in OS D-18
E. System Software
Solaris 2.6 Operating Environment E-1
E.1 Software Package E-1
E.1.1 Publications E-2
E.2 Technical Support E-2
E.3 Installation E-2
E.4 System Requirements E-2
E.5 Ultra AXi Platform Specifics E-3
E.5.1 Advanced System Monitoring (ASM) E-3
E.5.2 Video Drivers E-4
E.5.3 Set the Display Mode for OpenWindows or CDE E-5
E.5.4 PS/2 Keyboard Key Mapping E-7
E.5.5 PS/2 Mouse E-8
E.5.6 Speaker E-9
E.6 Adding PCI Cards and Drivers E-9
E.6.1 To Install a PCI Card E-10
E.6.2 To Verify the Board is Seen by the System E-10
E.6.3 To Obtain Additional Assistance E-10
E.7 Language Versions E-11
F. System Software
SunVTS Validation Test Suite F-1
F.1 Distribution F-1
F.1.1 Obtaining Documentation from the Web F-2

Contents xv
F.2 System Requirements F-2
F.3 Installing SunVTS F-2
F.4 Configuring and Running SunVTS F-3
F.5 Error Messages F-3
F.6 Ultra AXi Specific Implementation F-4
F.7 SunVTS Test Reference Manual Table of Contents F-4
F.8 Loopback Connectors F-6

xvi Contents

Figures xvii
Figures
FIGURE 1-1 Possible Configuration Examples 1-2
FIGURE 1-2 SPARCengine Ultra AXi Motherboard 1-4
FIGURE 1-3 Motherboard Serial Number, Version Number and Date Code Locations 1-5
FIGURE 1-4 CPU Module Serial Number and Date Code Locations 1-6
FIGURE 3-1 Ultra AXi Motherboard Block Diagram 3-3
FIGURE 3-2 Ultra AXi Layout 3-4
FIGURE A-1 Ultra AXi Jumper, Header, and Connector Layout A-2
FIGURE B-1 Ultra AXi Motherboard IO View B-1
FIGURE B-2 Ultra AXi Motherboard Top View B-2
FIGURE B-3 Height Profile Top View B-3
FIGURE B-4 Height Profile IO Side of Board (No CPU Fan) B-4
FIGURE B-5 Height Profile from Module End of Board (No CPU Fan) B-4
FIGURE B-6 Height Profile IO Side of Board (with CPU Fan) B-5
FIGURE B-7 Height Profile from Module End of Board (with CPU Fan) B-5
FIGURE B-8 IO Panel of the Ultra AXi Motherboard B-6
FIGURE B-9 Ultra AXi Motherboard Thermal Map B-7
FIGURE B-10 UltraSPARC IIi Straight Fin Heatsink Module (360 MHz and above) B-9
FIGURE B-11 UltraSPARC IIi Pin Fin Heatsink Module (360 MHz, 333 MHz, and 300 MHz) B-10

Figures xviii
FIGURE B-12 UltraSPARC IIi Pin Fin Heatsink Module (270 MHz) B-11
FIGURE B-13 UltraSPARC IIi Module With Pin Fin Heatsink B-12
FIGURE C-1 Ultra AXi IO Panel C-5
FIGURE C-2 Ultra AXi Motherboard Installation C-6
FIGURE C-3 UltraSPARC IIi Module C-6
FIGURE C-4 UltraSPARC-IIi CPU Module Insertion C-7
FIGURE C-5 Hold-down Installation for CPU Module with Pin Fin Heatsink C-8
FIGURE C-6 Hold-down Installation for CPU Module with Straight Fin Heat Sink C-9
FIGURE C-7 Hooking Up the CPU Fan Power Supply Wires to the J3603 Header C-10
FIGURE C-8 Ultra AXi PS/2 Keyboard and Mouse Adapter C-11
FIGURE C-9 IO Panel Connector Panel Fasteners C-11
FIGURE C-10 Ultra AXi Hard Drive Installation C-12
FIGURE C-11 Ultra AXi Floppy Drive Installation C-13
FIGURE C-12 Ultra AXi CD ROM Drive Installation C-14
FIGURE C-13 Ultra AXi DIMM Installation C-15
FIGURE C-14 DIMM Sockets Pair Assignments C-17
FIGURE C-15 Motherboard Power Connection C-21
FIGURE C-16 Floppy Drive Motherboard Connection C-21
FIGURE C-17 Internal SCSI Connector C-22
FIGURE C-18 Power On-Off Header C-23
FIGURE C-19 Power On LED Header C-23
FIGURE C-20 Speaker Header C-23
FIGURE C-21 Reset Switch header C-24
FIGURE C-22 Optional Fan Power Cable Motherboard Header (if available) C-24
FIGURE C-23 Optional Fan Power Cable Motherboard Header C-24
FIGURE C-24 ATI Video Boost PCI Card C-25
FIGURE D-1 OpenBoot Firmware Block Diagram D-1

Figures xix
FIGURE D-2 Ultra AXi CPU PROM Content Layout D-4
FIGURE D-3 Ultra AXi NVRAM Content Layout D-5

xx Figures
