Sun Microsystems SunSwift SPARCserver 1000 User manual

SPARCserver1000SystemBoardManual
Part No: 801-2900-12
Revision A, October 1994
Sun Microsystems Computer Corporation
2550 Garcia Avenue
Mountain View, CA 94043
U.S.A.

Please
Recycle
1993 and 1994 Sun Microsystems, Inc.
2550 Garcia Avenue, Mountain View, California 94043-1100 U.S.A.
All rights reserved. This product and related documentation are protected by copyright and distributed under licenses
restricting its use, copying, distribution, and decompilation. No part of this product or related documentation may be
reproduced in any form by any means without prior written authorization of Sun and its licensors, if any.
Portions of this product may be derived from the UNIX®and Berkeley 4.3 BSD systems, licensed from UNIX System
Laboratories, Inc., a wholly owned subsidiary of Novell, Inc., and the University of California, respectively. Third-party font
software in this product is protected by copyright and licensed from Sun’s font suppliers.
RESTRICTED RIGHTS LEGEND: Use, duplication, or disclosure by the United States Government is subject to the restrictions
set forth in DFARS 252.227-7013 (c)(1)(ii) and FAR 52.227-19.
The product described in this manual may be protected by one or more U.S. patents, foreignpatents, or pending applications.
TRADEMARKS
Sun, the Sun logo, Sun Microsystems, and Solaris are trademarks or registered trademarks of Sun Microsystems, Inc. in the
U.S. and certain other countries. UNIX is a registered trademark in the United States and other countries, exclusively licensed
through X/Open Company, Ltd. OPEN LOOK is a registered trademark of Novell, Inc. PostScript and Display PostScript are
trademarks of Adobe Systems, Inc. All other product names mentioned herein are the trademarks of their respective owners.
All SPARC trademarks, including the SCD Compliant Logo, are trademarks or registered trademarks of SPARC International,
Inc. SPARCstation, SPARCserver, SPARCengine, SPARCstorage, SPARCware, SPARCcenter, SPARCclassic, SPARCcluster,
SPARCdesign, SPARC811, SPARCprinter, UltraSPARC, microSPARC, SPARCworks, and SPARCompiler are licensed
exclusively to Sun Microsystems, Inc. Products bearing SPARC trademarks are based upon an architecture developed by Sun
Microsystems, Inc.
The OPEN LOOK®and Sun™ Graphical User Interfaces were developed by Sun Microsystems, Inc. for its users and licensees.
Sun acknowledges the pioneering efforts of Xerox in researching and developing the concept of visual or graphical user
interfaces for the computer industry. Sun holds a non-exclusive license from Xerox to the Xerox Graphical User Interface,
which license also covers Sun’s licensees who implement OPEN LOOK GUIs and otherwise comply with Sun’s written license
agreements.
X Window System is a product of the Massachusetts Institute of Technology.
THIS PUBLICATION IS PROVIDED “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE, OR NON-INFRINGEMENT.
THIS PUBLICATION COULD INCLUDE TECHNICAL INACCURACIES OR TYPOGRAPHICAL ERRORS. CHANGES ARE
PERIODICALLY ADDED TO THE INFORMATION HEREIN; THESE CHANGES WILL BE INCORPORATED IN NEW
EDITIONS OF THE PUBLICATION. SUN MICROSYSTEMS, INC. MAY MAKE IMPROVEMENTS AND/OR CHANGES IN
THE PRODUCT(S) AND/OR THE PROGRAM(S) DESCRIBED IN THIS PUBLICATION AT ANY TIME.

iii
Contents
Preface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
1. Before You Start. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
1.1 Tools Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
1.2 Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1.3 System Board Description. . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
1.4 System Board Block Diagram . . . . . . . . . . . . . . . . . . . . . . . 1-4
1.5 Replaceable Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
2. Removing and Replacing System Boards and Assemblies . . 2-1
2.1 Handling System Boards and Assemblies. . . . . . . . . . . . . 2-1
2.2 System Board. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.2.1 Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.2.2 Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
2.3 Using Standoffs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
2.4 SuperSPARC Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
2.4.1 Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7

iv SPARCserver 1000 System Board Manual—October 1994
2.4.1.1 SuperSPARC Module A . . . . . . . . . . . . . . . . . . 2-8
2.4.1.2 SuperSPARC Module B. . . . . . . . . . . . . . . . . . . 2-8
2.4.2 Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
2.5 SBus Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
2.5.1 Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
2.5.2 Installation or Replacement. . . . . . . . . . . . . . . . . . . . 2-12
2.5.2.1 Preparing for Installation . . . . . . . . . . . . . . . . . 2-13
2.5.2.2 Installing an SBus Card. . . . . . . . . . . . . . . . . . . 2-16
2.6 DSIMMs and NVSIMMs . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-17
2.6.1 Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-18
2.6.2 Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21
2.6.3 NVSIMMs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-22
2.7 OpenBoot PROMs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-23
2.7.1 Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-23
2.7.2 Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-23
2.8 TOD/NVRAM IC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-24
2.8.1 Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-24
2.8.2 Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-25
2.9 Restarting the System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-26
A. Configuring SIMMs and Jumpers . . . . . . . . . . . . . . . . . . . . . . . A-1
A.1 SIMM Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
A.1.1 SPARCserver 1000 and SPARCserver 1000E System
Board Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
A.1.2 Locating a Failing SIMM . . . . . . . . . . . . . . . . . . . . . . A-3

Contents v
A.2 Jumper Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3
B. Connector Pinouts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
B.1 Connector Locations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
B.2 Keyboard and Mouse Connector . . . . . . . . . . . . . . . . . . . . B-2
B.3 Serial Port Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-3
B.4 SBus Connectors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-4
B.5 Backplane Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-7
B.6 SuperSPARC Module Connectors . . . . . . . . . . . . . . . . . . . B-9
C. General Rules for System Configuration . . . . . . . . . . . . . . . . . C-1
C.1 Selecting Installation Locations . . . . . . . . . . . . . . . . . . . . . C-1
C.1.1 System Board Slots . . . . . . . . . . . . . . . . . . . . . . . . . . . C-1
C.1.2 SuperSPARC Modules . . . . . . . . . . . . . . . . . . . . . . . . C-2
C.1.3 SBus Cards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-3
C.1.4 SIMMs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-4
C.1.4.1 NVSIMMs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-6
C.2 Connecting Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-7
C.2.1 SCSI Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-7
C.2.2 Ethernet Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-7
C.2.3 Video Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-7

vi SPARCserver 1000 System Board Manual—October 1994

vii
Figures
Figure 1-1 End and Side Views of the System Board . . . . . . . . . . . . . . . . . 1-3
Figure 1-2 System Board Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Figure 2-1 Removing the System Board Retaining Screws . . . . . . . . . . . . 2-3
Figure 2-2 Removing the System Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Figure 2-3 Locking and Unlocking Standoffs. . . . . . . . . . . . . . . . . . . . . . . . 2-6
Figure 2-4 SuperSPARC Modules A and B Installed . . . . . . . . . . . . . . . . . 2-7
Figure 2-5 Installing SuperSPARC Module B . . . . . . . . . . . . . . . . . . . . . . . 2-9
Figure 2-6 SBus Card Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
Figure 2-7 Removing or Installing an SBus Card . . . . . . . . . . . . . . . . . . . . 2-12
Figure 2-8 SBus Card Rear Panel with Adapter. . . . . . . . . . . . . . . . . . . . . . 2-13
Figure 2-9 SBus Card Retainer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
Figure 2-10 DSBE/S SBus Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15
Figure 2-11 FSBE/S SBus Card. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15
Figure 2-12 Disabling and Enabling the Link Integrity Test . . . . . . . . . . . . 2-16
Figure 2-13 SIMMs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-18
Figure 2-14 NVSIMM (Battery Side) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-18

viii SPARCserver 1000 System Board Manual—October 1994
Figure 2-15 SIMM Socket Locations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-19
Figure 2-16 Unlocking a SIMM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-20
Figure 2-17 Creating Space to Remove a SIMM. . . . . . . . . . . . . . . . . . . . . . . 2-20
Figure 2-18 NVSIMM Jumper Locations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-22
Figure 2-19 OpenBoot PROMs on the System Board . . . . . . . . . . . . . . . . . . 2-24
Figure 2-20 TOD/NVRAM Location. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-25
Figure A-1 SIMM Group Locations on the System Board. . . . . . . . . . . . . . A-2
Figure A-2 Jumper Locations on the System Board . . . . . . . . . . . . . . . . . . . A-4
Figure B-1 Back and Top Views of the System Board . . . . . . . . . . . . . . . . . B-2
Figure B-2 Keyboard/Mouse Connector Pinout . . . . . . . . . . . . . . . . . . . . . B-2
Figure B-3 Serial Port A and B Connector Pinouts . . . . . . . . . . . . . . . . . . . B-3
Figure C-1 Locations of SuperSPARC Modules . . . . . . . . . . . . . . . . . . . . . . C-2
Figure C-2 SBus Card Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-3
Figure C-3 SIMMs and NVSIMM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-5
Figure C-4 SIMM Locations on the System Board . . . . . . . . . . . . . . . . . . . . C-6
Figure C-5 NVSIMM Jumper Locations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-7

ix
Tables
Table 1-1 Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Table 1-2 Replaceable Units for the System Board . . . . . . . . . . . . . . . . . . 1-5
Table 2-1 SIMM Variations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-17
Table A-1 SIMM Group Organization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3
Table A-2 System Board Jumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3
Table B-1 SBus Connector 1 (Connector J4901). . . . . . . . . . . . . . . . . . . . . . B-4
Table B-2 SBus Connector 2 (Connector J4902). . . . . . . . . . . . . . . . . . . . . . B-5
Table B-3 SBus Connector 3 (Connector J4903). . . . . . . . . . . . . . . . . . . . . . B-6
Table B-4 Backplane Connector (Connector J0200) . . . . . . . . . . . . . . . . . . B-7
Table B-5 SuperSPARC Module Connectors (Connectors J2000 and J2300) B-9
Table C-1 Example of Connector and Slot Priorities . . . . . . . . . . . . . . . . . C-3
Table C-2 Example of SBus Card Distribution . . . . . . . . . . . . . . . . . . . . . . C-4

xSPARCserver 1000 System Board Manual—October 1994

xi
Preface
This system board manual is written for a trained service provider who intends
to install the SPARCserver 1000™ or SPARCserver 1000E™ system board. In
general, the term SPARCserver 1000 refers to both the SPARCserver 1000 and
the SPARCserver 1000E system board. Where the SPARCserver 1000E is
different, this is explicitly noted.
When You Need Help with UNIX Commands
This manual does not include specific software commands or procedures. In
their place, a software task is named. Refer to the operating system
documentation that was shipped with your system when you need help with
commands or procedures such as:
•Shutting down the system
•Booting the system
•Configuring devices
•Other software procedures
Depending on the operating system you are using, complete descriptions of
commands and procedures can be found in:
•On-line AnswerBook™ documentation that comes with Solaris
•Other software documentation you received with your system

xii SPARCserver 1000 System Board Manual—October 1994
Document Conventions and Symbols
The following table describes the typefaces and symbols used in this book.
Related Documentation
These documents give information about installing and using the server or
related boards and peripherals.
Table P-1 Typographic Conventions
Typeface or Symbol Meaning Example
AaBbCc123 The names of commands, files, and directories; on-screen
computer output Edit your .login file. Use ls -a to list all files.
system% You have mail.
AaBbCc123 What you type, contrasted with on-screen computer output system% su
password:
AaBbCc123 Command-line placeholder:
replace with a real name or value To delete a file, type rm filename.
AaBbCc123 Book titles, new words or terms, or words to be emphasized Read Chapter 6 in User’s Guide.
These are called class options. You
must be root to do this.
Table P-2 Related Documents
Application Name Part Number
Diagnostics Open Boot PROM 2.x User‘s Guide 800-5674-xx
Open Boot Command Reference 800-6076-xx
User’s Guides SPARCserver 1000 Storage Device User’s Guide 801-2198-xx
POST User’s Guide 800-7487-xx
System and Network Administration for the Sun Workstation 800-1323-xx
Service, System SPARCserver 1000 System Service Manual 801-2895-xx
Service, Peripherals Memory Module Installation Manual 801-2888-xx
SCSI Disk Expansion Board Installation Manual 801-2196-xx
Safety, Other Data Center Regulatory Compliance Manual 801-2892-xx
Sun Site Preparation Guide Manual Set 825-1392-xx

xiii
Notes, Cautions, and Warnings
Warning – The SPARC module has a hot surface. Avoid contact. Surfaces are hot
and may cause personal injury if touched.
Warning – This equipment contains lethal voltage. Accidental contact can
result in serious injury or death.
Caution – Improper handling by unqualified personnel can cause serious
damage to this equipment. Unqualified personnel who tamper with this
equipment may be held liable for any resultant damage to the equipment.
Individuals who remove any outer panels to access this equipment must
observe all safety precautions and ensure compliance with skill level
requirements, certification, and all applicable local and national laws.
Procedures contained in this document must be performed by qualified
service-trained maintenance providers.
Note – Before you begin, carefully read each of the procedures in this manual.
If you have not performed similar operations on comparable equipment, do
not attempt to perform these procedures.
!

xiv SPARCserver 1000 System Board Manual—October 1994

1-1
BeforeYouStart 1
This chapter covers the procedures and information you need to know before
you begin installation or service on your SPARCserver 1000 system.
1.1 Tools Required •Sun ESD mat and grounding wrist strap
•#0 Phillips screwdriver
•#1 Phillips screwdriver
•Flat-blade screwdriver

1-2 SPARCserver 1000 System Board Manual—October 1994
1
1.2 Safety Precautions
To protect yourself and the equipment, observe the following precautions
when working on or in the server.
Table 1-1 Safety Precautions
Item Problem Precaution
AC cord ESD (Electrostatic
discharge) Ensure the AC cord connects the server to a grounded electrical outlet. The power cord provides a ground path for the unit to bleed off electrostatic voltage.
Wrist strap or
Foot strap ESD Wear a conductive wrist strap or foot strap when you handle printed circuit boards. Proper use of a conductive strap reduces the risk of damage to the
boards by discharging static electricity to ground.
ESD mat ESD The mat provides ESD protection when used with a wrist strap or foot strap.
The mat also cushions the board to prevent breakage of any small parts that
contact the bench surface.
PC boards ESD Handle the PC board by the edges only. Store the board in an antistatic bag.
Cover panels System damage
and overheating Install all cover panels after performing any service work on the system. The panels keep out foreign objects to prevent physical damage to internal parts and
guide airflow to prevent overheating.
Airflow
restrictor boards
(filler panels)
System damage
and overheating Install airflow restrictor boards in all unused card cage slots. Unused, open slots severely reduce the cooling capability of the system and can lead to equipment
damage from overheating.

Before You Start 1-3
1
1.3 System Board Description
Figure 1-1 shows the locations of major components on the system board.
Figure 1-1 End and Side Views of the System Board
All system boards are essentially the same; no jumper changes are necessary.
System boards can be moved to any slot, especially during troubleshooting.
However, the system board in card cage slot 0 is considered the system bus
master. The minimum configuration for this board requires a SPARC® module
in location A. If a serial-interface console is used, it must be plugged into
RS232 connector A on the system master. If a color monitor is used, a color-
graphics interface card must be installed in SBus slot 1 on the system master.
Also, by convention, system boards are installed in the lowest card cage slot
numbers first. Fill all SuperSPARC module A slots before using the B slots. Fill
all group 0 SIMMs before installing any group 1 SIMMs.
For comprehensive slot assignment rules and configuration priorities, refer to
Appendix C, “General Rules for System Configuration.”
SuperSPARC modules
SBus connectors
SIMMs

1-4 SPARCserver 1000 System Board Manual—October 1994
1
1.4 System Board Block Diagram
Figure 1-2 is a block diagram of the system board. The SuperSPARC modules,
SIMMs, and optional SBus cards are removable and can be replaced or moved
to another SPARCserver 1000 system board.
Figure 1-2 System Board Block Diagram
The components shown in solid outlines cannot be replaced in the field; if the
diagnostic self-tests report that a non-removable component failed, the entire
system board must be replaced.
DRAM
group
I/O
Cache
(IOC)
Memory
control
(MQH)
SBus
Intf.
(SBI)
Bus
watcher
(BW)
BIC
and
BARB
Data
Addr
SBus
SPARC module SPARC module
LEDS JTAG Control
SRAM
UARTs EPROM
BBC2
BootBus
CPU
Cache
control
XBus XBus
CPU
High
speed
cache
plus
parity Cache
control
High
speed
cache
plus
parity
TODC/NVRAM
Bus
watcher
(BW)
DRAM
group
Slot 3
On-board
ethernet
and SCSI
Slot 2
Slot 1
Page
table Data
Addr
XBus

Before You Start 1-5
1
1.5 Replaceable Units
The following items are system board components that can be replaced at
customer’s site.
Table 1-2 Replaceable Units for the System Board
FRU Part Number
SPARCserver 1000 System board, 0 processors, 0 SIMMs 501-2336
SPARCserver 1000E System board, 0 processors, 0 SIMMs 501-2668
SuperSPARC module * Various part numbers
OpenBoot PROM *
TOD/NVRAM 100-3528
SIMM, 8 Mbyte 501-1817
SIMM, 32 Mbyte 501-2196
1Mx9 NVSIMM 501-2197
Filler panel, SBus slot cutout 340-2305
Air restrictor board, card cage board slot 540-2388
*-See your Sun representative for latest part number.
xx -Denotes revision level of an assembly; the factory ships the applicable revision level.

1-6 SPARCserver 1000 System Board Manual—October 1994
1
