*Temperature range is for operation in shaded location.
All Weather Outdoor LCD Television
Model 2310HD
Super Bright 23” LCD Screen, HD Ready
All-weather enclosure protects internal components
from rain, dirt, insects and scratches
Dual-fan airflow system keeps unit cool and dry in
temperatures up to 122 degrees F.
Internal thermostatically-controlled heater protects TV
in temperatures as low as -24 degrees F.
Innovative watertight cable entry system with pass-
through design keeps cables dry and allows for easy
hook-ups
Optional wall mounts and deck planter poles are
weatherized and include stainless steel hardware
5069 Maureen Lane, Unit A Moorpark, CA 93021
Patent pending. All rights reserved. (C) 2008 SunbriteTV LLC
866.357.8688
www.sunbritetv.com
Specifications may be subject to change.
Model 2310HD
SB-CM20 Ceiling mount with tilt and swivel includes adjustable extension column that
provides 5” to 11” above unit to ceiling. Also includes 4” x 4” designer ceiling
plate. Meets VESA standards.
SB-WM23 Articulating wall mount with tilt, swivel, pan and extends up to 9” from wall.
Meets VESA standards.
SB-DP20X Deck/Planter pole (requires purchase of wall mount). Special order item.
SB-FMT23 RadioFMTM, transmits audio from TV to FM radio
SB-DC23 Outdoor TV dust cover
TV Dimensions are:
23.51 in. W x 16.27 in. H x 4.90 in. D
Height dimension with table top stand is 17.14 in.
TV with optional wall mount measures 7.60 in. when folded flush against the wall.
SunBriteTV Model 2310HD
(All dimensions are in inches)
LCD Screen 23-inch diagonal TFT Active Matrix
Resolution 1366 x 768 WXGA
Aspect Ratio 16:9
Active Area 508.1 x 285.7 mm
Contrast Ratio 700:1
Response Time 8 milliseconds
Viewing Angle 160o by 140o
Input Connectors:
RF
HDMI
Video Composite
Video Component
PC
RS232 Serial
Antenna/CATV (NTSC, ATSC, QAM)
HDMI Input x1
S-Video x1 and Composite Video x1
L/R Audio Inputs x2
YCbCr/YPbPr x1 (supports HDTV inputs at 480i, 480P, 567i,
576P, 720P and 1080i) and audio L/R channels x1
15-pin D-sub VGA
Full-featured command set with discrete on/off, input
select and volume control
Input Power 100-240 VAC, 50-60 Hz 2.2A Max
Audio 10-watt x 2 channels, water-resistant speakers
L/R Audio output connector inside rear cover
Operating Temp. -24o to 122o F. (-31o to 50o C.) *
Non-op. Temp.
(Off-mode with
power applied)
-24o to 140o F. (-31o to 60o C.)
Accessories Included Water-resistant remote control with lithium battery
Removable table top stand
TV Dimensions 23.51 in. W x 16.27 in. H x 4.90 in. D
Weight 22 lbs., 25 lbs. with table top stand
Shipping Dimen-
sions
30.31 in. W x 19.49 in. H x 8.86 in. D
Shipping Weight 28 lbs.
Warranty One-year, in-factory, parts and labor
Optional Accessories
