Sundstrom SR 501 EX Operating and maintenance instructions

Drawn up by:
2010-05-05 / PA
OI06R-2018 SR 501 EX
Revision:
02
Reviewed:
2014-02-28 /PA
Page:
1 of 2
Maintenance instruction for EX-battery SR 501 EX
(Art. No. R06-2002)
For the longest battery lifetime SR 501 EX should have regular charging and discharging
cycles. Best results are achieved with full discharge directly followed with a full charge.
Charge the battery in accordance with paragraph 2, below.
When the battery is not used for a long time, the following should be considered:
The battery contains a protection circuit that consume power from the battery.
This allows the battery to be deeply discharged if stored for a long time, which can cause
damage to cells.
Prolonged maintenance charge is also not recommended as this can also be harmful to the
cells. Instead, we recommend a scheduled charge under paragraph 3.
1 Removing the battery
Place the fan unit upside down. Grip the
fan unit with one hand with the thumb
placed over the battery.
Raise the battery cover a few centimetres
and push with the thumb and withdraw the
battery.
2 Charging the battery
2.1 Connect the charger cable to the
battery
Connect the battery to the battery charger.
Make sure that the pin on the cord’s plug
is fitted into the groove on the battery.
2.2 Fully charge the battery
Connect the charger plug to a wall socket.
Charge the battery to full capacity at room
temperature, about 2 hours.
Green LED lights up when fully charged
battery.

Drawn up by:
2010-05-05 / PA
OI06R-2018 SR 501 EX
Revision:
02
Reviewed:
2014-02-28 /PA
Page:
2 of 2
2.3 Unplug the charger from the battery
3 Storage of battery
3.1 Charge the battery
Charge the battery in accordance with
paragraph 2.
3.2 Store the battery i room temperature
3.3 Repeat charging regularly
Repeat charging after 6 to 8 weeks as long
as the storage continues.
3.4 Fully charge the battery before planned
usage.
4 Battery gasket
Check that the gasket around the opening
to the battery terminals on the underside of
the battery is undamaged.
To make the battery mounting and
dismounting easier grease the gasket with
Vaseline.
