SUNGOO SUNGOO mobile navigation 35.01 User manual

User's manual
SUNGOO Mobile Navigation 35.01
English (UK)
October 2007

This symbol showing a crossed-through refuse container signifies that,
within the European Union, the product must be disposed of as sorted
waste. This applies both to the product itself, as well as to all
accessories that carry this symbol. This product may not be disposed
of with unsorted household waste.

User's manual SUNGOO Mobile Navigation 35.01
User's manual Table of Contents III
Table of Contents
1Introduction.......................................................................................6
1.1 About this manual ..................................................................................6
1.1.1 Conventions.............................................................................6
1.1.2 Symbols ...................................................................................6
1.2 Legal notice ...........................................................................................6
1.2.1 Liability.....................................................................................6
1.2.2 Trademarks..............................................................................6
2Before you begin...............................................................................7
2.1 Scope of Delivery...................................................................................7
2.2 Description of the SUNGOO Mobile Navigation 35.01 ..........................8
2.3 Preparing SUNGOO Mobile Navigation 35.01 for use...........................8
2.3.1 Charging the rechargeable battery ..........................................8
2.3.2 Memory card............................................................................9
2.3.3 Preparing the navigation system for use .................................9
2.4 Navigation with GPS............................................................................11
2.5 Important safety information ................................................................12
2.5.1 Navigation safety information ................................................12
2.5.2 Safety information for the navigation device..........................12
2.5.3 Safety guidelines when installing in your car .........................13
3Operating the navigation software................................................14
3.1 Volume.................................................................................................14
3.2 Information...........................................................................................14
3.3 Software keyboard ...............................................................................16
3.4 Lists......................................................................................................16
3.5 Options.................................................................................................17
3.6 Menus ..................................................................................................17
3.7 Switching on SUNGOO Mobile Navigation 35.01................................17
4Navigation .......................................................................................17
4.1 Starting SUNGOO Mobile Navigation 35.01........................................18
4.1.1 Initialising the GPS-receiver ..................................................18
4.2 Specifying a new destination ...............................................................19
4.2.1 Specifying the destination country .........................................19

User's manual SUNGOO Mobile Navigation 35.01
IV Table of Contents User's manual
4.2.2 Destination address ...............................................................19
4.2.3 Special destinations...............................................................20
4.2.4 Quick access to special destinations .....................................22
4.2.5 Information about the destination ..........................................23
4.3 Selecting a saved destination ..............................................................24
4.3.1 Last Destinations ...................................................................24
4.3.2 Favourites ..............................................................................24
4.4 Navigating homewards ........................................................................24
4.5 Determining destinations on the map ..................................................25
4.6 Starting navigation ...............................................................................25
5Managing Destinations...................................................................27
5.1 Saving a destination ............................................................................27
5.2 Defining a destination as home address..............................................27
6Routes with stages .........................................................................27
6.1 Route planning.....................................................................................28
6.1.1 Entering the starting point......................................................28
6.1.2 Entering route points..............................................................28
6.1.3 Editing route points ................................................................29
6.2 Managing routes ..................................................................................29
6.2.1 Saving routes.........................................................................30
6.2.2 Loading routes .......................................................................30
6.3 Navigation............................................................................................30
6.3.1 Calculating and displaying routes ..........................................30
6.3.2 Simulating routes ...................................................................30
6.3.3 Starting navigation .................................................................31
7Options ............................................................................................32
8Working with the map.....................................................................34
8.1 Maps ....................................................................................................34
8.2 Map in Preview mode ..........................................................................34
8.3 Map in Navigation mode ......................................................................35
8.4 Reality View .........................................................................................38
8.5 Map in Destination search mode .........................................................39
8.5.1 Operating in Destination search mode ..................................40
9Useful functions..............................................................................41
9.1 GPS status, storing the current location ..............................................41

User's manual SUNGOO Mobile Navigation 35.01
User's manual Table of Contents V
9.2 Turn-by-Turn List .................................................................................41
9.2.1 Blocking route sections..........................................................42
9.2.2 Removing blocks and using original routes ...........................42
9.3 TMC (Traffic Information).....................................................................42
9.3.1 Displaying traffic messages ...................................................42
9.3.2 TMC Settings .........................................................................43
9.4 Logbook ...............................................................................................44
10 Configuring SUNGOO Mobile Navigation 35.01 ...........................44
11 Appendix .........................................................................................46
11.1 Technical data .....................................................................................46
11.2 Declaration of Conformity ....................................................................47
12 Index ................................................................................................48

User's manual SUNGOO Mobile Navigation 35.01
- 6 - Introduction
1 Introduction
1.1 About this manual
1.1.1 Conventions
For better legibility and clarification, the following styles are used in this
manual:
Bold and italics: Registered names, company and product descriptions.
SMALL CAPITALS: Window and dialogue box titles.
Bold: Highlighting of important parts in the text.
Underlined: Descriptions of buttons, input fields and other elements
on the user interface.
1.1.2 Symbols
The following symbols refer to specific passages of text:
Instructions and tips for operating the software
More detailed information and explanations
Warnings
1.2 Legal notice
1.2.1 Liability
The software and the manual are subject to change without notice.
NAVIGON AG is not liable for the accuracy of the information contained
in this manual or for damages resulting from the use of this manual.
We always appreciate any suggestions that will allow us to offer
improved performance of our products in the future, or information
regarding malfunction.
1.2.2 Trademarks
All brands and trademarks mentioned in this document are possibly
registered by third parties and are subject to the current legislation and

User's manual SUNGOO Mobile Navigation 35.01
Before you begin - 7 -
to the rights of their respective owners without reservation. All
mentioned names of products, societies, or brands may be registered
trademarks of their respective owners. Every right that is not explicitly
accorded is reserved.
The absence of the explicit labelling of registered trademarks used in
this manual does not imply that the brand is not subject to the rights of a
third party.
►Windows and ActiveSync are trademarks of the Microsoft
Corporation.
►NAVIGON is a registered trademark of NAVIGON AG
►Sungoo is a registered trademark of Media-Saturn-Holding GmbH.
2 Before you begin
2.1 Scope of Delivery
Please check that the contents of the delivery are complete. If the
contents are incomplete, please notify us within 14 days of
purchasing. The purchased product includes the following:
►SUNGOO Mobile Navigation 35.01 navigation device
►Car cradle
►Car charger cable ( 12V-adapter for the vehicle's cigarette lighter)
►USB cable
►TMC antenna
►SD-card containing software and navigation maps
►Manual
►CD with manuals (PDF, including languages not printed)

User's manual SUNGOO Mobile Navigation 35.01
- 8 - Before you begin
2.2 Description of the
SUNGOO Mobile Navigation 35.01
1 Touch screen
2 Mini-USB-socket for car charger cable / USB cable
3 LED
4 Headset socket (also used to connect TMC-antenna)
5 Slot for SD-memory card
6 On/Off/Standby
7 Connection for external GPS-antenna
2.3 Preparing SUNGOO Mobile Navigation 35.01 for
use
2.3.1 Charging the rechargeable battery
►Connect the car charger cable to the navigation device and to the
vehicle’s cigarette lighter. (see also "Supplying power to the
navigation device", on page 11)

User's manual SUNGOO Mobile Navigation 35.01
Before you begin - 9 -
The LED of the SUNGOO Mobile Navigation lights orange during
charging.
The LED lights green when the SUNGOO Mobile Navigation is fully
charged.
Note: It takes approx. 4-5 hours to charge the device when the battery
is flat.
A fully charged battery enables 4 hours of use.
2.3.2 Memory card
You will find the memory card containing the navigation software
inserted in the device.
Inserting a memory card
►Insert the memory card provided into the device (see image). Press
the card into the device until it locks into place.
Removing the memory card
Should it be necessary to remove the memory card from the device,
please proceed as follows:
1. Switch the navigation device off by pressing the
(On/Off/Standby) switch for at least 6 seconds.
2. Press the memory card gently into the device until the lock
disengages.
2.3.3 Preparing the navigation system for use
Caution! Please be sure to refer to the safety information in chapter
"Important safety information" on page 12.

User's manual SUNGOO Mobile Navigation 35.01
- 10 - Before you begin
Assembling the cradle
►Assemble the cradle as shown in the diagram. No tools are required
for this.
Securing the cradle
1. Clean that part of the windscreen to which you would like to secure
the cradle. The windscreen must be dry and free of dirt and grease.
2. Place the suction cup of the cradle provided against the
windscreen.
3. Press the lever on the suction cup towards the windscreen.
Securing the navigation device to the cradle
►Insert the navigation device into the cradle by first placing it on the
lower projections and then tilting it backward slightly until the latch
clicks into place.

User's manual SUNGOO Mobile Navigation 35.01
Before you begin - 11 -
Supplying power to the navigation device
Included in delivery of the SUNGOO Mobile Navigation is a car
charger cable with which power can be supplied to the navigation
device via the vehicle's cigarette lighter.
The car charger cable is connected to the
SUNGOO Mobile Navigation via the mini-USB-socket on the
bottom of the device.
Caution! The car charger cable is to be connected to cigarette lighters
with an operating voltage of 12V only.
Connecting the TMC-antenna
The SUNGOO Mobile Navigation has an integrated TMC-receiver. For
optimal reception, you should use the TMC-antenna provided.
1. Connect the TMC-antenna to the headset socket on the
right hand side of the SUNGOO Mobile Navigation.
2. Secure the antenna to the windscreen using the suction cups.
2.4 Navigation with GPS
GPS is based on a total of 24 satellites that circle the earth and, in
doing so, are constantly transmitting their position and time. The GPS
receiver receives this data and calculates its own geographical position
on the basis of the information transmitted by the various satellites.
For a sufficiently precise positioning it is necessary to obtain the data
from at least three satellites. With the data from 4 or more satellites the
altitude above sea level can also be ascertained. The determination has
an accuracy of about 3 yards.
Once the navigation device has determined your position, this position
can be used as a starting point for route calculation.
The map data on your navigation device includes the geographical
coordinates of all digitally recorded points of interest, streets and
places. This enables the device to calculate a route between a starting
point and a destination.
The calculation of the current position and its representation on the map
takes place once every second. So your current position is always
shown on the map.

User's manual SUNGOO Mobile Navigation 35.01
- 12 - Before you begin
2.5 Important safety information
In your own interest, please read the following notices and safety
information carefully before starting up your navigation system.
2.5.1 Navigation safety information
Use navigation system at your own risk.
Caution! To prevent accidents, do not operate the navigation system
while driving.
Caution! Do not look at the display unless it is absolutely safe to do so!
Caution! Traffic regulations have priority over any instructions from the
navigation system.
Caution! Only follow the instructions of the navigation system when the
circumstances and the road traffic regulations allow you to do so! The
navigation system will guide you to your destination even if you deviate
from the calculated route.
Caution! Check that the cradle is secured and adjusted properly before
each journey.
Note: If you have not understood the spoken instructions, or you're not
sure about what to do next, you can refer briefly to the map or arrow
view of your navigation system.
2.5.2 Safety information for the navigation device
Caution! Protect the device from moisture. The device is neither
waterproof nor is it protected against splash water.
Caution! Do not run cables directly next to safety-relevant devices and
supply lines.
Caution! After installation, check all safety-relevant equipment in the
car.
Caution! Unplug the navigation device's power supply when you park
the vehicle. The navigation device requires power in standby-modus,
and may drain the vehicle's battery.

User's manual SUNGOO Mobile Navigation 35.01
Before you begin - 13 -
Caution! Do not open the navigation device's casing under any
circumstances.
Caution! Do not expose the navigation device to extreme heat or cold.
This may damage the device or impair its function.
Caution! Use only the charger provided or one that has been approved
of by the manufacturer.
Connect the charger to a suitable power supply. The voltage
requirements can be found on the device case and/or the packaging.
Note: Ensure that there are no kinks in the cable and that it will not be
damaged by any sharp objects.
Note: To clean the navigation device, use a moist cloth only.
Note: Do not unplug by pulling on the cable. Doing so could damage
the cable!
Note: Create a backup of the data contained on the memory card
provided.
Note: The memory card must remain inserted in the device during
operation of the navigation system.
Note: Use SD- or MMC-memory cards only! Ensure that memory card
contacts are clean and undamaged.
2.5.3 Safety guidelines when installing in your car
Caution! Secure the cradle and the TMC-antenna in such a way that
the driver's visibility is not impaired.
Caution! Do not attach the cradle within the deployment zone of
airbags.
Caution! When installing the cradle, ensure that it does not represent a
risk in the event of an accident.

User's manual SUNGOO Mobile Navigation 35.01
- 14 - Operating the navigation software
Caution! Do not run cables directly next to safety-relevant devices and
power supplies.
Caution! After installation, check all safety-relevant equipment in the
car.
Caution! The car charger cable is to be connected to cigarette lighters
with an operating voltage of 12V only.
3 Operating the navigation software
3.1 Volume
The volume of the spoken driving instructions can be adjusted during
navigation.
You have started navigation. The map is open in Navigation or
Destination search mode.
1. Tap the (Volume)button.
The volume bar opens. It contains three buttons for adjusting the
volume:
(Louder), (Quieter), (Volume on/off).
2. Tap the (Volume)button again.
The volume bar closes.
3.2 Information
Symbols located at the top of the screen are used to display
information.
GPS
The GPS symbol can show the following GPS-reception status:
No GPS: The built-in GPS receiver is not operational. Contact customer
service if the problem persists.
No Signal: Data is being received from less than three satellites.
Position cannot be calculated.

User's manual SUNGOO Mobile Navigation 35.01
Operating the navigation software - 15 -
GPS Ready: Data is being received from at least three satellites.
Position can be calculated.
For more detailed information regarding GPS status, please refer to
chapter "GPS status" on page 41.
Energy
The Energy symbol can display the following conditions of the built-in
battery:
The device is being supplied by an external power source. The battery
is being charged.
The device is being supplied by its internal battery. The battery charge
is sufficient.
The device is being supplied by its internal battery. The battery charge
is low.
Direction
The Direction symbol shows you in which direction you are currently
heading. It can show the following points of the compass: N, NE, E, SE,
S, SW, W and NW.
TMC (Traffic Information)
The SUNGOO Mobile Navigation has an integrated TMC-receiver
which provides the navigation system with up to date traffic messaging.
If necessary, it can alter the route dynamically in order to avoid a traffic
jam for example.
Note: This function is only available if TMC traffic messages are being
transmitted in the country in which you are travelling. This is not the
case in all countries.
The TMC symbol can display the following TMC-reception status:
No Symbol:There is no TMC receiver connected, or the connected or
built-in TMC receiver is not operational.
Tuning: The TMC-receiver is operational, but cannot find a station that
is transmitting TMC signals.
TMC on Standby: Traffic messages can be received.

User's manual SUNGOO Mobile Navigation 35.01
- 16 - Operating the navigation software
For details on TMC functionality, please refer to chapter "TMC (Traffic
Information)" on page 42.
3.3 Software keyboard
A software keyboard appears on the screen when text entries are
necessary.
All entries can be made on the software keyboard using the fingertips.
Only capital letters can be entered.
When entering town or street names you need not enter any special
characters or umlauts. The navigation system fills in these characters
for you automatically. If, for example, you are searching for “Würzburg”,
then simply enter "WURZBURG". Special characters may be helpful
when naming saved destinations and itineraries, however.
Special keys
enters a space character.
deletes the character in front of the cursor.
opens the numeric keypad.
opens the letter keyboard.
opens the special character keyboard. As soon as you have
entered a special character, the letter keyboard reappears
automatically.
3.4 Lists
Often, lists appear from which you can select an entry. This is the case,
for example, when you enter a location.
As soon as you enter the first letter, the largest city in the country
specified which begins with this letter appears.
As soon as you enter the second letter, a list appears with all locations
that begin with the letters entered.
If you enter additional letters, the list adapts to your entries. It only
contains entries that begin with the text that has been entered or
contain the text in the name. The more letters you enter, the shorter the
list will become.

User's manual SUNGOO Mobile Navigation 35.01
Navigation - 17 -
You can toggle the list by means of the (Up)and (Down)
buttons.
In order to accept an entry from the list, simply tap on it.
The list closes as soon as you have accepted an entry.
3.5 Options
Some windows offer options that lead to further functions.
A description of all available options can be found in chapter "Options"
on page 32.
3.6 Menus
Some buttons have menus which open when activated.
Tap on a menu button to execute its function.
If you would like to quit the options list without selecting a function, tap
on the button you used to open the menu.
3.7 Switching on SUNGOO Mobile Navigation 35.01
►Press the (On/Off/Standby) switch for at least 6 seconds.
4 Navigation
Use navigation system at your own risk.
Caution! Please be sure to refer to the safety information in chapter
"Important safety information" on page 12.
Impaired GPS reception
If GPS reception is impaired, navigation will be interrupted. The
navigation software remains active.
As soon as GPS reception is restored, the navigation system calculates
any change of position which has occurred in the meantime. Navigation
may simply be continued.
Arriving at your destination
When you have reached the specified destination, a message to this
effect will be displayed.

User's manual SUNGOO Mobile Navigation 35.01
- 18 - Navigation
Only your current position (triangle in orange) will now be shown on the
map.
4.1 Starting SUNGOO Mobile Navigation 35.01
1. Switch your navigation device on.
Each time the navigation device has been switched off completely
(by pressing the (On/Off/Standby) switch for at least 6 seconds)
the following message appears when the software is started again:
"Please note that the road traffic regulations are prior to the
instructions of the navigation system. Please do not operate the
device while driving."
2. After you have read and fully understood the text, tap the OK
button.
3. If you do not accept these instructions, then tap the Cancel button
in order to quit the navigation software.
The MAIN WINDOW will open. You can reach all of the navigation
software functions via the MAIN WINDOW.
4.1.1 Initialising the GPS-receiver
Note: It can take up to 20 minutes to initialise the integrated GPS
receiver for the first time.
Each time you switch on the receiver after this, the GPS reception will
start within one minute.
If the navigation device has been switched off for more than a week, the
next initialisation can take up to 10 minutes.
As soon as the navigation device has been switched on, initialisation of
the GPS-receiver will begin.
In the right-hand top corner of the display, you will see the GPS symbol.
As soon as data from at least 3 satellites is received, the symbol
changes to GPS Ready.
Note: If the GPS symbol displays GPS Ready after considerably less
than 20 minutes, it is advisable to leave the receiver switched on for at
least a further 15 minutes so as to ensure reliable operation.
Caution! If you have connected the navigation device to the power
supply via the vehicle's cigarette lighter, remove the connector before
you leave the vehicle standing for a longer period of time.
As the GPS receiver requires a constant supply of power, it could drain
the vehicle´s battery.

User's manual SUNGOO Mobile Navigation 35.01
Navigation - 19 -
Opening the Main Window
The MAIN WINDOW opens when the navigation software starts.
If another window is open, tap the (Back) button. The previous
window will open.
Tap the (Back) button repeatedly, until the MAIN WINDOW opens.
4.2 Specifying a new destination
New destinations for the SUNGOO Mobile Navigation are all
destinations that you have not yet navigated, or you have not yet
stored.
You can enter an address here, select a special destination, or select a
destination from the quick search function.
When you enter a new destination for the first time, the COVERED
COUNTRIES list opens.
Tap on the country in which your destination lies.
4.2.1 Specifying the destination country
Above the right-hand upper corner of the uppermost entry field of the
ADDRESS, POI IN A CITY, and POI OF NATIONAL SIGNIFICANCE windows,
is the Country button. It shows the country code of the country from
which navigation destinations can currently be entered.
If your destination is in a different country, then proceed as follows:
1. Tap the Country button.
The COVERED COUNTRIES list opens.
2. Tap on the country in which your destination lies.
The COVERED COUNTRIES list closes again.
The symbol will display the country code of the destination country.
Note: Only countries of which at least a part is represented on the
currently loaded map may be selected.
4.2.2 Destination address
1. In the MAIN WINDOW, tap on New Destination > Enter an Address.
The INPUT SEQUENCE menu opens when you enter addresses for
the USA or Canada (and the corresponding map has been
selected).

User's manual SUNGOO Mobile Navigation 35.01
- 20 - Navigation
1a Select whether you would like to enter the street first and then the
location (Street First), or first the location and then the street (City
First).
Note: For the following instructions, it is assumed that you have
selected City First as the order for entering addresses.
The ADDRESS window opens.
2. Enter the name or the postal code of the destination location.
3. Enter the name of the destination street. You can also enter the
name of a well-known object, e.g. "Olympic stadium" or "Eiffel
tower".
4. Enter the house number. If you don't know the number of the
house, or you specified an object in the preceding step, then leave
the field empty.
If you don't know the house number, but know the name of a nearby
side street, then tap on the Cross Street field and enter the name of
this street. The navigation system will calculate a route to the
intersection of the streets you have specified.
Note: It is not necessary to enter all the address details.
If you specify the town only, the navigation system will calculate a route
to the town centre.
If you specify the town and street without specifying a house number or
side street, the navigation system will calculate a route to the centre of
the street specified.
5. Tap the Start Navigation button.
The map opens in Preview mode.
Note: For detailed information on how to start navigation, please refer
to chapter "Starting navigation" on page 25.
4.2.3 Special destinations
Special destinations, also called POIs (Points Of Interest) for short, are
useful addresses that are catalogued according to particular criteria.
Special destinations include ports, airports, restaurants, hotels, petrol
stations, public buildings, doctor's surgeries, hospitals, shopping
centres, etc.
Special destinations can be displayed on the map by means of a
symbol. In the MAIN WINDOW, tap on Options > Settings > POI to select
the categories to be displayed on the map.
