Sunje Hi-Tek SPE-100 User manual

Ultrastable Surface Voltmeter SPE-100 Instruction Manual
SunJe Hi-Tek Co., Ltd
- 2 -
INDEX
1. Please make sure you read before use ......................................................................................................... 3
2. Overview and Main Characteristics ............................................................................................................... 4
3. Components Description ................................................................................................................................ 5
4. Operating Method ............................................................................................................................................ 8
4.1 How to use static voltage measurement instrument ........................................................................................................................ 8
5. Specifications ................................................................................................................................................... 9
6. The List of Accessories ................................................................................................................................... 9
7. External Dimension ........................................................................................................................................ 10
8. Warranty .......................................................................................................................................................... 11
9. Contacts in the event of Repair and Failure ................................................................................................. 12

Ultrastable Surface Voltmeter SPE-100 Instruction Manual
SunJe Hi-Tek Co., Ltd
- 3 -
1. Please make sure you read before use
■Thank you for choosing Ultrastable Surface Voltmeter SPE-100 of Sunje Hi-Tek.
■This product has been designed and manufactured to be used as the part for the electronics industry.
■Please read this manual before you treat the SPE-100.
■Keep the product manual at hand so that you can refer to it anytime and anyplace.
■We cannot be responsible for improper installation and operation.
The matters of safety
• It may fail to function properly if someone drops or any misuse of the product.
• Please connect to Ground for precise measurement.
• 9V Battery only. (rectangular shaped battery)
• Do not separate or renovate it personally.
Ultrastable Surface Voltmeter SPE-100 Instruction Manual
SunJe Hi-Tek Co., Ltd
- 4 -
2. Overview and Main Characteristics
SPE-100 is a non-contact static voltage measurement sensor. Therefore you can measure
the static voltage without contact charged object.
It can measure surface voltage in range of ±19.999[kV].
SPE-100 has high sensitive sensor that enables to measure static voltage of charged object
by 1V in range of ±19.999[kV].
It measures static voltage of charged object accurately and speedy
(error range ±2%, Sampling Speed 0.5 sec.)
Static voltage sensor is separable, so it works in various environments. Also, it has rotating
stabilizer that enables for stable data measuring and long-term fixed measuring.
It is possible to monitor static voltage externally by signal output function.

Ultrastable Surface Voltmeter SPE-100 Instruction Manual
SunJe Hi-Tek Co., Ltd
- 5 -
3. Components Description
3.1 Measurement equipment body
■Front / Left side
1. Ground
This is an earth connecting socket. You must connect it before you measure.
2. Output Connector
Please connect Output Cable provided with the product to send output signal outside.
(output range ±19.999[kV], reduction ratio 1:1000)
3. Electrostatic indicating LCD
This is measured static voltage display LCD. Measurement range is ±19.999[kV].
4. Mode Select Knob
Knob can be set up in three steps.
First step (OFF Mode): Turn off.
Second step (19999 Mode): It can measure in range of ±19999[V] in 1V unit.
Third step (1999.9 Mode): It can measure in range of ±1999.9[V] in 0.1V unit.
Ultrastable Surface Voltmeter SPE-100 Instruction Manual
SunJe Hi-Tek Co., Ltd
- 6 -
■Front / Right side
5. Sensor Connector
This connector is to connect static voltage sensor.
6. 0V adjustment knob
This knob is for adjustment to 0V when first using it. Please adjust it by turning left and right.
(possible range: ±15V)

Ultrastable Surface Voltmeter SPE-100 Instruction Manual
SunJe Hi-Tek Co., Ltd
- 7 -
3.2 Static Voltage Sensor
1. Sensor Cap
The sensor cap is for adjust offset. Please cap securely in place over the end of the probe.
Please remove Sensor Cap before measure.
2. Static Voltage Sensor
This is static voltage of charged object measuring sensor. Please keep this sensor away from any particles.
3. Sensor Connector
Please connect to sensor connector of main body. The length of sensor cable is 90cm (standard).
Optional 400cm length or extension cable is available for user’s measuring circumstance.
※Sensor Cable Length
- Standard Cable : 90cm
- Extension Cable(Option) : 400cm
Ultrastable Surface Voltmeter SPE-100 Instruction Manual
SunJe Hi-Tek Co., Ltd
- 8 -
4. Operating Method
4.1 How to use static voltage measurement instrument
1) Grounding product
Please connect a ground wire to SPE-100 for accurate measurement.
2) 0V adjustment
If grounded, set up the Mode Select Knob to 1999.9, and apply black sensor cap (conductive plastic) at the tip
of probe. Then, start adjust it by turning adjustment knob left and right until it displays 0000.00.
3) Measurement
Separate the sensor cap after setting up the knob in 19999 or 1999.9 Modes depending on the environment.
And read the display while keeping the distance between charged object and static voltage sensor in 1 in.
(25.4mm)

Ultrastable Surface Voltmeter SPE-100 Instruction Manual
SunJe Hi-Tek Co., Ltd
- 9 -
5. Specifications
The specification values are listed below: specifications are subject to change without notice.
Category Descriptions Remarks
Model SPE-100
Range / Resolution at 1” 0 to ±19.999[kV] / 1V
0 to ±1.9999[kV] / 0.1V
Accuracy ±2% of reading
Capacitance (to ground)
of Sensor 60 nF
Sensitivity if used to
sense charge 0.1V or 1V, depending on range
Drift Less than 0.5 V (1 year period) at 25.4mm(1 Inch)
Sampling Speed 0.5 sec
Environmental 0℃to 40℃(30℉to 110℉) 0-85% RH
Size Static Voltage Sensor 72(H) X 31(Diameter) [mm]
Body 75(W) X 122(H) X 50(D) [mm]
Weight 330 g without battery
Battery 9 Volt Alkaline / "Low Battery" indicator included
Cable Length 90 cm standard AT cable special option :
400cm
Warranty 1Year
6. The List of Accessories
Please check the components (modification, breakdown, etc.) when you receive SPE-100.
If you find malfunction, modification or breakdown, please contact to our service center.
Body
SPE-100
1ea
Static
V
oltage
Sensor
SVS-PE-1-001
1ea /
90cm(Standard)
400cm(Option)
Sensor Cap
SSC-PE-1-001
1ea
Ground Cable
SGC-PE-2-001
1ea / 4.8m
Output Cable
SOC-PE-1-001
1ea / 1.8m
Ultrastable Surface Voltmeter SPE-100 Instruction Manual
SunJe Hi-Tek Co., Ltd
- 10 -
7. External Dimension
7.1 Measurement equipment body
7.2 Static Voltage Sensor

Ultrastable Surface Voltmeter SPE-100 Instruction Manual
SunJe Hi-Tek Co., Ltd
- 11 -
8. Warranty
8.1 Warranty Period
The warranty period of the product is for one year after the purchase of the product.
8.2 Warranty Scope
In case failure due to the problem of the product occurs during the above warranty period, after-sales service is
provided free of charge. However, failures due to the following conditions are excluded from the scope of
warranty.
■Failures due to inappropriate conditions, environments, handling, and usage not conforming to the
descriptions in the user’s manual and the specifications attached separately.
■Failures not due to our product’s defects but due to the designs of customer’s equipments or software.
■Failures due to modification or change by user’s own will.
■Failures that are determined to have been prevented if consumables described in the user’s manual, etc. had
been maintained or replaced correctly.
■Failures due to external causes including disasters such as fire, earthquake and flood, and abnormal voltage.
The scope of warranty is valid within warranty period. We are not responsible for the secondary damage
(equipment breakdown, opportunity loss, profit loss, etc.) due to our product’s failure.
8.3 Application scope of product
This product has been designed and manufactured as a product for general industrial use. Therefore, this
product can not be used for the purpose related to atomic power generation, aviation, railway and medical
equipments that have great influence on human life or properties. However, customers can apply our products
to the above mentioned purposes after they fully understand the specifications of the product through
consultation with us.
Ultrastable Surface Voltmeter SPE-100 Instruction Manual
SunJe Hi-Tek Co., Ltd
- 12 -
9. Contacts in the event of Repair and Failure
SUNJE HI-TEK CO., LDT
HeadOffice&factory
189-5, Cheonggwang-Ri, Ilgwang-Myeon, Gijang-Gun, Busan, Korea
T)[phone]
F) [phone]
Central Sales Office
#306, Core B/D,1025-15, Youngtong-Dong, Youngtong-Gu, Suwon, Gyeonggi-Do, Korea
T) [phone]
F) [phone]
Southern Sales Office
1F, Sinheung B/D,1001-4, Inui-Dong, Gumi, Gyengsangbuk-Do, Korea
T) [phone]
F) [phone]
Sunje Technology Co., Ltd
2F, No.6, Lane.102, Sinhe Rd, Sinfong Township, Hsinchu County, Taiwan 30472
T) [phone]
F) [phone]
Sunje Japan Co., Ltd
1-13-4-801, Tamatsukuri, Chuo-Ku, Osaka 540-0004, Japan
T) [phone]
F) [phone]
Homepage : www.sunstat.com E-mail : sunsta[email protected]
