sunjoe SWJ802E Installation guide

What is the size of the end nut holding the bar cover on my unit?
The end nut beneath the end nut cover that holds the bar cover on to your unit is a size 13mm
metric flange hex nut. Any 13mm socket or spanner wrench will be able to remove or tighten
this end nut.
What type of oil does my unit take?
Your Saw Joe SWJ802E uses regular Bar and Chain Oil, available for purchase on our website
under model number SWJ-OIL.
How do I clean debris/residue from inside the unit?
Using the supplied flat-tip blade screwdriver, remove the end cover nut cap from the
chain/sprocket end cover to expose the end cover nut.
Using the supplied hex key wrench, unscrew the end cover nut and remove the chain/sprocket
end cover.
Remove any debris trapped under the end cover, around the sprocket, and between the chain
links. If available, use compressed air to remove any fine debris from the mounting surface,
bar, and chain.
If necessary, remove the cutting bar and chain from the mounting surface to clean any
residue, then replace.
Replace the chain/sprocket end cover by inserting the rear tab of the end cover first into the
rear tab slot on the mounting surface, and position the cover onto the saw head.
Tighten the end cover nut by hand. Remove all slack from the chain by turning the chain
tension screw clockwise until the chain seats snugly against the bar with the drive links in the
bar groove.
Tighten the end cover nut using the hex key wrench, then replace the end cover nut cap to
secure the chain/sprocket end cover.
What bar does my unit use?
Your Saw Joe SWJ802E uses an SWJ-8BAR 8-inch bar, available for purchase on our website.
What chain does my unit use?
Your Saw Joe SWJ802E uses an SWJ-8CHAIN 8-inch chain, available for purchase on our
website.
How loud is my Saw Joe SWJ802E?
Your Saw Joe SWJ802E has a decibel rating of 105 dB.
FAQ

Protect ground level amenities (e.g. clear space over your swing-set, remove hazards from
above your carport, prevent debris from littering your pool, etc.)Instead of a traditional
chainsaw to cut bundles of branches or clean up broken tree limbs
No need for a smoke mask, ear protection, gas can, gasoline, 2-cycle oil, ethanol-shield fuel
additive, carburetor clean-out, sparkplug replacement, and seasonal fuel preservatives and
stabilizers. Avoid renting a bucket lift, scissor lift, or boom lift to safely reach tall limbs.
What is the file size for sharpening the chain on my Saw Joe Pole Saw?
Your Saw Joe Pole Saw uses an Oregon 91PX chain that is sharpened with a 5/32" sized file.
How do I adjust the chains tension?
Adjust tension with a screwdriver by turning the tensioning peg screw clockwise or
counterclockwise to achieve proper tension.
The correct tension is achieved when the chain in the middle of the bar can only be lifted by
approximately 3-4 mm.
What are the best uses for my SWJ802E Pole Chain Saw?
Cut hanging branches over walkways and entrance ways
Get rid of branches too close to your roof to protect your home in advance of weather hazards
Safely trim limbs hanging in rain gutters to prevent clogging and damage
Trim away overgrown branches on trees to beautify your property and create a cleaner,
brighter and more spacious outdoor living space
Cut branches that block sunlight from nourishing your garden and flower beds
As a quicker and safer alternative to using a ladder and a hand saw
