SUNRAY Avalon User manual

Avalon Three Head Solar Lamp Post
Instruction Manual
Model Nos.: 312016
Please keep this instruction manual for future reference
Read the instructions and precautions before use of this product
For warranty information, please refer to the back page of
this instruction manual.
Due to ongoing product development
the actual product or products may vary from
the illustrations or photos shown within this manual.
NOTE: This product is intended for residential, non-commercial use.
Made in China
©2017 J&J Global, LLC.
Distributed by:
J&J Global, LLC.
Carrollton, TX 75006
For Manuals, Replacement Parts or Customer Service visit:
www.ezreplacement.com
Additional Limitations
Limited Warranty
J & J Global (Seller) warrants to the original Buyer only, that each product will be free from defects in material and
workmanship for a period of one (1) year from date of purchase. SELLER’S SOLE OBLIGATION AND BUYER’S
EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE THE REPAIR OR REPLACEMENT OF PARTS, WITHOUT
CHARGE, WHICH ARE DEFECTIVE IN MATERIAL OR WORKMANSHIP. ANY PARTS AS DETERMINED BY THE SELLER
WHICH HAVE BEEN MISUSED; ABUSED OR DAMAGED EITHER DIRECTLY OR INDIRECTLY FROM REPAIRS OR
ALTERATIONS ATTEMPTED BY UNAUTHORIZED PERSON; IMPROPER MAINTENANCE, NEGLECT OR ACCIDENT ARE
NOT COVERED BY THIS LIMITED WARRANTY. This warranty does not apply to damage, heat-induced coloration
changes, scratching or alteration due to normal use or weathering. To make a claim under this Limited Warranty,
email [email protected] or visit www.ezreplace- ment.com for warranty questions and claims.
THIS LIMITED WARRANTY DOES NOT APPLY TO ACCESSORY OR CONSUMABLE ITEMS RELATED TO THIS PRODUCT.
ALL IMPLIED WARRANTIES SHALL BE LIMITED IN DURATION TO ONE (1) YEAR FROM DATE OF PURCHASE. IN NO
EVENT SHALL SELLER BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT
LIMITED TO LIABILITY FOR LOSS OF PROFITS, ARISING FROM THE SALE OR USE OF THIS PRODUCT.
If any provision of this Limited Warranty is for any reason held to be invalid or unenforceable, such provision shall
not a ect any other provision herein, this Limited Warranty shall be construed as if such invalid and/or unenforce-
able provision had never been contained herein.
This warranty gives you special legal rights, and you may also have other rights which vary from state to state.
This warranty contains the entire agreement between Seller and Buyer and supercedes any and all prior
agreements, arrangements, or understandings between the parties relating to product warranty.

PARTS & HARDWARE LIST
PART # DESCRIPTION QUANTITY
A Lantern Body 3
B Lantern Top 3
C Lantern Bracket 1
D Upper Post 2
E Middle Post 1
F Lower Post 1
G Lamp Post Base 1
H Upper Planter 1
I Bottom Planter Base 1
J Support Ring 1
K Screw 3
L Small Screw 6
M Flat Washer 3
N Hex Nut 6
O Accorn Nut 3
P Hex Bolt
Q J Bolt
R Mounting Plate
S Bulb
3
3
1
3
AB
C
Please dispose of batteries properly.
Consult your local telephone listings for
a battery recycling center in your area.
Recycling
Care Instructions
1. Clean any dirt and debris from the solar panels. the panels cannot recharge if light is obstructed.
Use a soft cloth to clean the panels. Do not use abrasives or chemicals that might scratch or
damage the UV coating.
2. In a region where snow and ice are likely and the light assembly is covered with snow for an
extended period of time, the batteries will require recharge for at least 8 hours.
DE
F
Carefully remove the contents from the package. If any parts are missing do not
attempt to use the product until they have been obtained and correctly installed.
1 6
Parts Detail
GHI
J
K
LMNOPQR S
Recycling
Ambient temperature
maximum 40oC (105oF)
Protect batteries
against heat and fire
risk of explosion
Do not dispose of
batteries in
household waste
Do not throw
batteries into water

Figure 1
ASSEMBLY INSTRUCTIONS
Lantern Assembly
1. (SEE FIGURE 1) Screw the bulb (S) into the
lantern top (B).
2. Repeat wiht the other lantern body (A).
3. Place lantern top (B) onto lantern body (A) secure
with two small screws (L).
4. Repeat with the other lantern body (A).
5. Thread lantern body (A) onto lantern bracket (C)
and turn clockwise to tighten.
6. Repeat with the other lantern body (A).
Planter Base Assembly
Note: If using ground mounting instead of
planter base mounting refer to "Ground
Mounting" on page 3.
1. (SEE FIGURE 3) Attach lamp post base (G) to
bottom planter (I) using hex bolts (P),
mounting plate (R), Flat washer (M), and hex
nut (N). Make sure the mounting plate, flat
washer and hex nut are secured to the hex
bolt on the underside of the bottom planter
base (I).
Figure 3
25
Instructions For First Time Use
Allow lantern to charge for at least 8 hours in full sunlight with the ON/OFF switch in the
OFF position. The ON/OFF switch is located under the solar panel (See Figure 7, page 5). Once the
batteries are fully charged, set the ON/OFF switch to ON. If the lantern doesn't turn on after initial
charging, ensure batteries are making contact with the terminals.
Where To Place the Solar Light
Place the solar light in an area where it will receive direct sunlight for at least 8 hours per day.
The number of hours light is illuminated is directly proportional to the number of hours of sunlight
it receives. If the light is placed in a shaded area, it will not be able to fully charge and its burn time
will be limited. Do not place the light near other outdoor lighting like porch or streetlights. These
may fool the sensor and keep the light from coming on, or cause it to turn off automatically.
OPERATING SOLAR LIGHT
P
MN
G
I
Figure 7
Battery Replacement
NOTE: The batteries in your solar lantern come
preinstalled from the factory.
1. (SEE FIGURE 7) Remove the screws from the
top of the lantern head (A). Battery compartment
is located under the top of the lantern head.
2. Carefully lift the lantern top off the housing.
Remove the three screws on the bottom of the
lantern top. Separate the battery compartment
from the top of the lantern head.
3. Remove old batteries.
4. Replace old batteries with new ones of the
same rating. Reference polarity direction
inside battery compartment.
5. Replace the solar panel on the housing and
secure with screws retained from step 2.
6. The rechargeable batteries need to be fully
charged before operating light assembly.
See "Operating Solar Light" to restore solar
light assembly to full operation.
Batteries
Lantern Head Top
Screws
Solar Light
Panol
R
On/Off Switch
A
L
B
S
A
C

Figure 6
3 4
Lamp Post Assembly
1. (SEE FIGURE 6) Attach lower post (F) to
lamp post base (F) using 3 screws (L) if you
have not already done so in “Support Ring
Assembly” on page 3.
2. Attach the middle post (E) to the lower post (F)
turnimng clockwise.
3. Attach the upper post (D) to the middle
post (E), turning clockwise.
4. Attach the second upper post (D) to the first
upper post, turning clockwise.
5. Attach the lantern assembly (C) to the upper
post (D), turning clockwise.
Figure 4
Figure 5
Support Ring Assembly
1. (SEE FIGURE 4) Attach lower post (F) to post
base (G) using screws (K) in 3 places. Lower
the support ring (J) down the post until it rests
on the top of the upper planter (H). To complete
the solar lamp post with planter go to
"Lamp Post Assembly" steps 2, 3 and 4
on page 4.
Alternate Ground Mounting
1. (SEE FIGURE 5) Thread hex nut (N) onto the
J-bolt (Q). Make sure the hex nut is threaded
down the J-bolt far enough for the top of the
J-bolt to fit through the mounting plate (R) and
the lamp post base (G) with enough threads to
secure the base to the J-bolts with
acorn nuts (O). Repeat the step for other J-bolts.
2. Using the mounting plate (R) as a guide insert
the J-bolts with hex nuts into a wet concrete
pad until the hex nuts are below pad level.
3. Place the mounting plate (R) onto the J-bolts
forming a mounting bracket.
4. Align the lamp post base (G) holes with the
J-bolts and secure with the acorn nuts (O).
Note: Refer to "Lamp Post Assembly" on page 4.
J
F
H
Concrete
Pad
Level
O
G
N
Q
R
CAUTION: To prevent product damage or
personal injury from tip-over, lamp post
planter base must be placed on a flat,
level surface and be filled with
4 in. (minimum of 40lbs.) of gravel or stone.
K
G
C
L
G
E
F
D
D
