Stoane Lighting Surface Mounted Bollard User manual

Mike Stoane Lighting Ltd
20 Dryden Road Bilston Glen Ind Est.
Loanhead Midlothian EH20 9LZ UK
T: [phone]
F: [phone]
[email protected]
www.mikestoanelighting.com
VAT No GB682885284
Limited Company 188910
Surface Mounted Bollard
Installation and Maintenance
Instructions
IMPORTANT: All wiring connections must be made before switching on mains power.
European Conformity
Please retain these instructions for future reference
This product should not be disposed of in your general waste IP66 Dust tight and protected against powerful jets of water.
Class III - Extra Low Voltage
Indoor Use Only
MSL Star 2.8VF1W @ 350mA
Surface Mounted Bollard.pdf 1 01/04/2020 09:31:17

Electrical Supply
Installation must be carried out by a qualified electrician in
accordance with BS 7671:2008 Wiring Regulations.
230/240V AC 50/60Hz mains supply to a suitable SELV
LED Driver.
Site conditions: LED equipment is more susceptible to
static damage and overvoltage than previous technology.
Before handling or connecting to the mains supply ensure
that all MSL products are protected from static discharge
and that the mains supply is to regulation. (230V +10
-6%)
Mains cables must be double insulated, strain relieved
and separated from E.L.V output cables.
This unit requires a constant current driver. 350mA Max.
Observe polarity:
Positive (+) is marked as RED.
Incorrect supply or reverse polarity can cause irreparable
damage.
All connections must be made before switching on mains.
If the supply is energised prior to making the connections
to the fitting then the resulting surge will damage the LED.
Multiple LEDs should be wired in series, refer to driver
instructions for minimum/maximum load.
All lighting equipment is delicate and easily damaged
through misuse or inappropriate installation (mechanical
or electrical). Repairs and replacements may cause
delays and will be chargeable. Contact MSL for support if
required. For full warranty terms & conditions please visit
our website.
The IP rating stated is applicable only when the fitting has
been installed as per these instructions.
The light source contained in this luminaire shall only be
replaced by the manufacturer or his service agent or a
similar qualified person.
The entire dimming control circuit source must be of SELV
insulation class.
Ensure supply driver and connectors are housed indoors
OR in a suitably IP rated enclosure. Cable ends must be
suitably waterproofed. Inspect supply cables before
installation to ensure there is no damage which will allow
water to enter the fitting.
Care must be taken when handling any ingress protection
seals, glands or "O" rings to ensure they are kept clean,
unblemished and replaced exactly in their required
location and suitably fastened home.
Installation
Check that the mounting surface is suitable for the
installation of this fitting.
Step 1 Make mains connections to SELV LED driver
and extra low voltage connections to the
fitting.
Step 2 Secure the fitting to the mount surface with 2
suitable fixings.
After opening the sealed portion of the luminaire for
any reason, MSL recommends running the fitting for
15 minutes with the lid open to expel moisture before
closing it up. This will prevent condensation on the
lens and protect the fitting from corrosion.
WARNING: Do not look at exposed LED lamps in
operation. Eye injury can result.
Cleaning:
Fully isolate the fitting and allow to cool.
Clean the fitting with a slightly damp lint free cloth
from a mild solution of soap and water. The fitting
must be completely dry before reconnecting power.
Incompatible or abrasive chemicals can damage the
fitting, contact MSL for advice if required.
Warning: Acrylic is a fragile material, handle with
care.
Never attempt to clean acrylic with anything other than
a mild solution of soap or detergent and water.
Acrylic is susceptible to chemical attack, seriously
compromising structural integrity if incompatible
solutions are used.
Surface Mounted Bollard.pdf 2 01/04/2020 09:31:18

12
Make ELV connections to
the fitting via the supplied
connectors.
75mm
