Sunrise Spas 2019 Owner’s Manual
INDEX
Table of Contents
BRAND CONFIGURATION TABLE...............................................................................................................................................................................................................................3
CONGRATULATIONS ON THE PURCHASE OF YOUR NEW SPA..................................................................................................................................................3
SAFETY SIGN..................................................................................................................................................................................................................................................................................4
ATTENTION: SPA OWNER...................................................................................................................................................................................................................................................4
CONDITIONS OF WARRANTY AND CONSUMER OBLIGATIONS...................................................................................................................................................5
YOUR PERSONAL SPA DATA..........................................................................................................................................................................................................................................6
IMPORTANT SAFETY INSTRUCTIONS.....................................................................................................................................................................................................................7
READ AND FOLLOW ALL INSTRUCTIONS..........................................................................................................................................................................................................8
SAVE THESE INSTRUCTIONS..........................................................................................................................................................................................................................................8
IMPORTANT SAFETY INSTRUCTIONS FOR SPAS WITH AUDIO SYSTEMS.........................................................................................................................9
INSTALLATION INSTRUCTIONS ................................................................................................................................................................................................................................10
ELECTRICAL CONNECTION GENERAL INFORMATION .....................................................................................................................................................................12
NORTH AMERICAN (60HZ) MODELS...................................................................................................................................................................................................................13
115 VOLT CORD CONNECTION................................................................................................................................................................................................................................14
CORD AND PLUG CONNECTED...............................................................................................................................................................................................................................14
230 VOLT SUPPLY CONNECTION..........................................................................................................................................................................................................................16
WHAT’S INSIDE YOUR SPA ...........................................................................................................................................................................................................................................19
WHAT’S UNDER YOUR SPA (THE EQUIPMENT).......................................................................................................................................................................................22
START-UP.......................................................................................................................................................................................................................................................................................23
VL240 CONTROL PANEL USER GUIDE.............................................................................................................................................................................................................26
TP600 CONTROL PANELUSER GUIDE..............................................................................................................................................................................................................28
BLUETOOTH READY SYSTEM OPERATION..................................................................................................................................................................................................41
ACCESSING FILTER CARTRIDGES.........................................................................................................................................................................................................................41
MAINTENANCE..........................................................................................................................................................................................................................................................................42
FILTER SYSTEM........................................................................................................................................................................................................................................................................44
DRAINING YOUR SPA.........................................................................................................................................................................................................................................................45
WINTERIZING YOUR SPA ................................................................................................................................................................................................................................................46
TROUBLESHOOTING YOUR SPA.............................................................................................................................................................................................................................47
WATER TREATMENT GUIDE.........................................................................................................................................................................................................................................54
Sunrise Spas 2019 Owner’s Manual
DOC: OM-SUNRISE-19
3
BRAND CONFIGURATION TABLE
Note:
The factory default for spas using the TP600 keypad is Simplified Menus. However, more keypad settings and
features are possible on some spas by accessing the Standard menus within the spa pack. A spa pack set up change
is required to access these settings and features within the standard menus.
Ask your dealer about the set up change required and additional keypad instructions.
CONGRATULATIONS ON THE PURCHASE OF
YOUR NEW SPA
We have tried to compile a complete, easy to understand manual all about your spa and its' maintenance. Years of
research and development have gone into producing the superior quality product you have purchased. Your spa is
made from the highest quality material and latest technology available today. Pride and meticulous attention to detail
have resulted in the spa you have chosen. With proper care, your spa will provide many years of comfort and pleasure.
Please take a few minutes now to read all of the instructions before you install your spa. This owner's manual will help
you understand your spa, so you will get the most from your investment. For service and advice, do not hesitate to call
your authorized dealer. Your questions will be welcomed by friendly and knowledgeable staff.
May you have as much pleasure and enjoyment using your new spa, as we had making it for you.
We understand there are many choices in the marketplace when you are
considering adding a spa to your home, so thank you for choosing a spa by Leisure
Manufacturing Inc. Enjoy!
Line
Model
Frame/Bottom
Filter
Keypad User Guide
Sunrise
670 EZ Polysteel/Tray Whitewater VL240
770 EZ Polysteel/Tray Whitewater VL240
780 EZ Polysteel/Tray Whitewater VL240
670 S/SR Polysteel/Tray Whitewater (Dual) TP600 Simplified
770 S/SR Polysteel/Tray Whitewater (Dual) TP600 Simplified
780 S/SR Polysteel/Tray Whitewater (Dual) TP600 Simplified
870 S/SR/SX Polysteel/Tray Whitewater (Dual) TP600 Simplified
880 S/SR/SX Polysteel/Tray Whitewater (Dual) TP600 Simplified
970 S/SR/SX Polysteel/Tray Whitewater (Dual) TP600 Simplified
980 S/SR/SX Polysteel/Tray Whitewater (Dual) TP600 Simplified
4
DOC: OM-SUNRISE-19
Sunrise Spas 2019 Owner’s Manual
SAFETY SIGN
IMPORTANT NOTICE: SAFETY SIGN
Enclosed with this Owner’s Manual is a Safety Sign. This sign must be permanently installed in a location that is visible
to all spa users. It is the spa owner’s responsibility to remind all users about safe spa use, particularly occasional users
of the spa, who may not be aware of the various health and safety issues.
To obtain additional or replacement copies of the safety sign, contact your dealer.
ATTENTION: SPA OWNER
In the immediate vicinity of the spa, a sign must be posted stating the following:
1) The spa’s address
2) Location of the nearest telephone with posted emergency numbers
3) Nearest available police department, fire department and ambulance/rescue unit
Sunrise Spas 2019 Owner’s Manual
DOC: OM-SUNRISE-19
5
CONDITIONS OF WARRANTY AND CONSUMER
OBLIGATIONS
As a new spa owner, you have specific obligations in regards to the installation and safe use of this spa. Failure to do
so may result in a loss of warranty coverage not to mention personal injury to those using this spa.
Inspect the spa upon its arrival for damage. If you are being made aware of this for the first time, your
spa may not have been delivered in its original factory packaging. If this is the case, please take time to
inspect your spa and report any damage or missing items to your dealer.
1) Install the spa both physically and electrically, in accordance with any local codes.
2) Provide suitable access to all sides of the spa. Any custom built enclosure, either above or below a deck
surface, must be able to be removed with relative ease.
3) Provide sufficient work area around the spa’s perimeter especially the side the spa’s equipment is located on.
4) Regularly check operation of the spa in regard to filtration, jet pump operation and the heating system.
5) Report any concern to the dealer. Any problem that arises towards the end of particular warranty coverage
should be documented and reported to the dealer
6) Maintain the water’s chemical balance and clean/replace the system’s cartridge filter(s) as instructed by the
dealer and/or Leisure Manufacturing Inc.
7) Drain and refill the spa on a regular basis as instructed by the dealer and/or Leisure Manufacturing Inc.
8) Winterize and store the spa and its’ components in accordance with the manufacturer’s printed instructions.
9) Care for and maintain the spa cabinet, hard cover and acrylic surface as outlined in these instructions.
10)Ask your dealer to record the spa’s serial number on your bill of sale.
11)Provide a copy of your bill of sale, if requested by the dealer or Leisure Manufacturing Inc.
6
DOC: OM-SUNRISE-19
Sunrise Spas 2019 Owner’s Manual
YOUR PERSONAL SPA DATA
Before you begin the installation of your new spa please take a few minutes to fill out the details of your spa. This
information will become invaluable later should you have a question for your dealer or should you need to make a
warranty claim. Ask your dealer to assist you in recording this information.
Model Year
Model Name/Number
Spa Serial#
Jet Pump(s) Size (HP, SPL, Watts etc.)
Heater size (kw)
Filter Cartridge (Model Number/Size)
Topside Control/Keypad
Spa Pack Model #
Spa Pack Serial #
Dealer Name
Date of Purchase
We strongly recommend that you attach your bill of sale to this manual after installation is complete. Keep it in a
safe place for future reference. You may also wish to attach any notes you have made about the dealer delivery,
dealer start up demo or any other notes that may be of benefit in the future.
Sunrise Spas 2019 Owner’s Manual
DOC: OM-SUNRISE-19
7
IMPORTANT SAFETY INSTRUCTIONS
WARNINGS
DANGER:
Risk of Accidental Drowning. Extreme caution must be exercised to prevent unauthorized access by
children. To avoid accidents, ensure that children cannot use this spa unless they are supervised at all times.
DANGER:
Risk of Injury. The suction fittings in this spa are sized to match the specific water flow created by the
pump. Should the need arise to replace the suction fittings or the pump, be sure that the flow rates are compatible.
Never operate spa if the suction fittings are broken or missing. Never replace a suction fitting with one rated less than
the flow rate marked on the original suction fitting.
DANGER:
Risk of Electric Shock. Install at least 5 feet (1.5m) from all metal surfaces. As an alternative, a spa may be
installed within 5 feet of metal surfaces if each metal surface is permanently connected by a minimum 8 AWG
(8.4mm2) solid copper conductor to the wire connector on the terminal box that is provided for this purpose.
DANGER:
Risk of Electric Shock. Do not permit any electrical appliance, such as a light, telephone, radio, or television,
within 5 feet (1.5m) of a spa.
WARNING:
To reduce the risk of injury:
a) The water in a spa should never exceed 40°C (104°F). Water temperatures between 38°C (100°F) and 40°C
are considered safe for a healthy adult. Lower water temperatures are recommended for young children and
when spa use exceeds 10 minutes.
b) Since excessive water temperatures have a high potential for causing fetal damage during the early months of
pregnancy, pregnant or possibly pregnant women should limit spa water temperatures to 38°C (100°F).
c) Before entering a spa, the user should measure the water temperature since the tolerance of water
temperature-regulating devices varies.
d) The use of alcohol, drugs, or medication before or during spa use may lead to unconsciousness with the
possibility of drowning.
e) Obese persons and persons with a history of heart disease, low or high blood pressure, circulatory system
problems or diabetes should consult a physician before using a spa.
f) Persons using medication should consult a physician before using a spa since some medication may induce
drowsiness while other medication may affect heart rate, blood pressure, and circulation.
CAUTION:
Maintain water chemistry in accordance with the manufacturer's instructions.
8
DOC: OM-SUNRISE-19
Sunrise Spas 2019 Owner’s Manual
READ AND FOLLOW ALL INSTRUCTIONS
When using this equipment, basic safety precautions should always be followed. Including the following:
a) A green coloured terminal or a terminal marked G, GR, Ground, Grounding or the international grounding
symbol is located inside the supply terminal box or compartment. To reduce the risk of electric shock, this
terminal must be connected to the grounding means provided in the electric supply service panel with a
continuous copper wire equivalent in size to the circuit conductors supplying this equipment.
b) At least two lugs marked "BONDING LUGS" are provided on the external surface or on the inside of the
supply terminal box or compartment. To reduce the risk of electric shock, connect the local common bonding
grid in area of the hot tub or spa to these terminals with an insulated or bare copper conductor not smaller
than No.6 AWG.
c) All field-installed metal components such as rails, ladders, drains or other similar hardware within 3m (10ft) of
the spa or hot tub shall be bonded to the equipment grounding bus with copper conductors not smaller than
No.6 AWG.
DO NOT connect your spa to an extension cord.
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
Hyperthermia
Prolonged immersion in hot water may induce hyperthermia. Hyperthermia occurs when the internal temperature of
the body reaches a level several degrees above the normal body temperature of 37°C (98°F). The symptoms of
hyperthermia include drowsiness, lethargy, and an increase in the internal temperature of the body. The effects of
hyperthermia include:
•Unawareness of impending hazard
•Failure to perceive heat
•Failure to recognize the need to exit spa
•Physical inability to exit spa
•Fetal damage in pregnant women
•Unconsciousness and danger of drowning
WARNING:
The use of alcohol, drugs or medication can significantly
increase the risk of fetal hyperthermia.
Sunrise Spas 2019 Owner’s Manual
DOC: OM-SUNRISE-19
9
IMPORTANT SAFETY INSTRUCTIONS FOR
SPAS WITH AUDIO SYSTEMS
CAUTION:
Risk of Electric Shock. Do not leave compartment door open.
CAUTION:
Risk of Electric Shock. Replace components only with identical components.
Do not operate the audio/video controls while inside the spa.
WARNING:
Prevent Electrocution. Do not connect any auxiliary components to the system (example: cable, additional
speakers, headphones, additional audio/video components etc).
These units are not provided with an outdoor antenna. When provided, it should be installed in accordance with article
810 of the National Electrical Code, ANSI/NFPA 70.
Do not service this product yourself as opening or removing covers may expose you to dangerous voltage or other risk
of injury. Refer all servicing to qualified service personnel.
If the power supply connections or power supply cord(s) are damaged; if water is entering the audio/video
compartment or any electrical equipment compartment area; if the protective shields or barriers are showing signs of
deterioration; or if there are signs of other potential damage to the unit, turn off the unit and refer servicing to a
qualified service personnel.
This unit should be subjected to periodic routine maintenance (example: once every 3 months) to make sure that the
unit is operating properly.
10
DOC: OM-SUNRISE-19
Sunrise Spas 2019 Owner’s Manual
INSTALLATION INSTRUCTIONS
Remember, your new spa is a powerful piece of electrical and plumbing equipment. You owe it to yourself, your family
and your friends to install it correctly and safely. Before attempting to hook-up or use your spa, please read the
following instructions.
ATTENTION:
This spa is intended for outdoor use, however it can be installed indoors when
precautions are taken to ensure the spa is installed and located in such a manner that
any water that could leak, splash or be released as humidity will drain away harmlessly.
POSITIONING OF YOUR SPA - CONSIDERATIONS
Your spa is completely self-contained. Therefore, you can situate it just about anywhere; on a patio, in or on a deck, in
a basement or sunroom. It comes completely pre-plumbed and water tested from the factory. Never lift or carry the spa
by the plumbing. Damage could occur which would not be covered under warranty.
You should take into account the following when selecting prospective spa sites in order to maximize enjoyment.
To avoid any personal injury or damage to your spa, have 4-5 people ready to assist you to move the spa to its' final
location. Use a moving dolly and/or straps to more evenly distribute the spa's weight. Never lift or carry the spa by its'
plumbing.
SITE CONSIDERATIONS
Local codes Local building, property and electrical codes may affect your installation.
Delivery access to location Gates, overhangs, fences, gas meters, and AC units may become obstructions.
You may need to access from a neighbour's yard or employ a crane.
Vegetation in spa area Trees, bushes, flowers etc. can all add to spa maintenance.
Spa location relative to buildings The location could add to your spa maintenance (removing snow from cover) and
increase operating costs.
Fences, tree lines More privacy during use and serves as a wind break but may also add more
maintenance.
Spa step out location Any surface that is slippery when wet could be dangerous for bathers both
entering and exiting the spa.
Spa Direction View when using a lounger & ease of access for servicing.
Downspouts and natural
drainage of land These may flood the spa area, damage spa or create a safety hazard to bathers.
Outside water supply and
draining location You will need a place to safely drain the spa and a way to refill it easily.
Optional accessories These may take up added space that you must plan for (cover remover/holder).
Sunrise Spas 2019 Owner’s Manual
DOC: OM-SUNRISE-19
11
SPA SUPPORT
Whatever the support is, it must be:
a) A continuous, level surface, above grade, capable of handling 80 lbs. per sq. ft. that will not be compromised by
changes in the water table or water sitting in the area.
b) Such that the weight of the spa, water and bathers is not supported by the spa lip.
c) In full contact with the bottom of the spa
ACCEPTABLE SPA SUPPORT BASES
Concrete Pad 4" to 6" thick with provision for run off
Patio Stones, Pavers etc. Levelled with proper preparation of the earth
Wooden Deck Floor Incl. centre support uprights in concrete and joists spaced 12" on centre
Engineered Plastic Spa Pad Following pad manufacturer's instructions
Unacceptable Spa support bases include crushed gravel, stone dust, bare earth, platform built directly onto earth.
Damage caused by improper spa installation will void factory warranty.
Do NOT locate your spa in a low run-off area since melting snow or rain can cause pump and equipment damage.
WATER SHOULD ALWAYS DRAIN AWAY FROM THE SPA.
See next page for dimensions that can be used to determine the proper location of submerged conduits in concrete
slab installations. All dimensions are made from the outside of the spa's frame with the access panels removed.
12
DOC: OM-SUNRISE-19
Sunrise Spas 2019 Owner’s Manual
ELECTRICAL CONNECTION GENERAL
INFORMATION
A. LOCATING A CONDUIT WITHIN A CONCRETE PAD
If your intent is to bring a conduit and power wires up under the spa we suggest that it
enter the spa cavity in the front, left corner; 6” (15cm) Dimension A in from the left
and 6” (15cm) Dimension B up from the front. See A & B on the diagram below. This
location will allow you to stay clear of spa pumps and other equipment while giving you
a short and easy access to the left side of the spa pack, where the electrical entry hole
and terminal block are located.
B. SUPPLY CABLE ENTRY INTO SPA EQUIPMENT AREA
•You may enter the spa cavity at any other point around spa provided you have reviewed the location and
determined there is no interference. You may also decide to enter at an adjoining wall (depending on the
positioning of the spa) and route a conduit along the spa kicker. Ask your electrician for his/her advice in
these matters.
•In all cases the best side for entry of the supply cable is the side to your left when you are standing at the
equipment panel.
•Right side entry is possible; however, this may involve additional supply cable, parts and time.
HOW TO PASS THE CABLE THROUGH THE SPA ENCLOSURE
Polysteel Frame with Polyethylene Bottom and Polysteel Panels
a) You can choose to notch the polysteel panel so you can pass the cable/conduit through and still be able to
remove/replace the panel for servicing. You should consider securing the cable or conduit to the spa’s metal
frame where cable/conduit passes through the cabinet.
b) You may also route a cable up under the corner. The curved panel is flexible enough and there is enough
space to run the cable this way. Removing the corner may help you to do this easier.
c) On a concrete pad where you have a conduit or cable coming up within the perimeter of the spa, you can
easily cut an opening in the polyethylene bottom to access the cable or conduit/wires. See above table for
recommended opening location.
You may wish to insulate any opening or cut-out you make in the spa’s cabinet panel or corner or bottom to keep cold
air and small animals out.
Sunrise Spas 2019 Owner’s Manual
DOC: OM-SUNRISE-19
13
NORTH AMERICAN (60HZ) MODELS
Please note the following important information:
When using this electrical equipment, basic safety instructions should be followed, including the following:
Read and Follow ALL Directions
1) Electrical installation must be carried out by a qualified electrician strictly in accordance with local governing
codes.
2) A terminal marked "ground" is located within the control box. To reduce the risk of electric shock this terminal
must be connected to the grounding means provided in the electric supply service panel with a continuous
copper wire equivalent in size to the circuit conductors supplying the equipment.
3) At least two lugs marked "bonding lugs" are provided on the external surface of the control box. To reduce the
risk of electric shock connect the local common bonding grid in the area of the hot tub or spa to these
terminals with an insulated or bare copper conductor not smaller than No. 6 AWG.
4) All field installed metal components such as rails, ladders, drains or other similar hardware within 3m (10 ft.) of
the spa or hot tub shall be bonded to the equipment grounding bus with copper conductors not smaller than
No. 6 AWG.
5) Test the ground fault circuit interrupter before each use of the spa.
6) Before servicing any electrical components of the system make sure that the power supply is switched off.
ATTENTION: ELECTRICIAN & SPA OWNER
PICO FUSE
Balboa Spa packs contain a special fuse, referred to a “Pico fuse”.
This special fuse is designed to open (burn out) if:
a) There is any problem with how the electrical supply is connected
b) There is a power surge to the spa pack
This fuse is not replaceable and the entire spa pack is considered destroyed.
WARNING!
THIS IS NOT A CONDITION THAT IS COVERED UNDER THE
SPA PACK MANUFACTURER’S WARRANTY OR
LEISURE MANUFACTURING’S COMPREHENSIVE SPA WARRANTY.
14
DOC: OM-SUNRISE-19
Sunrise Spas 2019 Owner’s Manual
1) 115 VOLT CORD CONNECTION
This unit has been built, tested and approved with a cord connected 115VAC built in Ground Fault Circuit Interrupter
(GFCI).
The cord must only be plugged into a receptacle that is connected to a
dedicated 15A breaker or fuse.
DO NOT extend the connection by the use of an extension cord. This will
void the warranty and could cause damage to the spa and its’ users.
GFCI Test Procedure:
1. With the GFCI plugged into a grounded 115VAC, 15A outlet press
the yellow TEST button.
2. The spa should shut off and a small light between the TEST and
RESET buttons should be lighted.
3. Press the red RESET button to reset the GFCI and start the spa.
FAMILIARIZE yourself with the test procedure for the GF CI. TEST the GFCI upon every use of the spa.
If the GFCI does not shut the spa off when the TEST button is pressed or does not start up when the RESET button is
pressed DO NOT USE THE SPA. Contact your dealer and/or a qualified electrician immediately. Take steps to ensure
that no person(s) can use the spa while the problem is being reviewed and corrected.
Note:
In new installations, GFCI trippings due to mis-wiring are very common.
If the breaker is properly wired, GFCI trippings can occur when the total amount of current drawn by the spa exceeds
the rating of the breaker. Such an occurrence, however, is very unlikely, since each output of the spa pack is
individually fused and fuses will blow before the GFCI trips. A current leak to the ground will also make the GFCI trip. If
one or more of the components is faulty and there is a leak of more than 5 mA, the GFCI will trip to prevent
electrocution.
2) CORD AND PLUG CONNECTED
- CONVERTIBLE UNITS USING VS SERIES SPA PACK
This spa was factory made as a 120 VAC spa. Its’ power input can be converted to a 240VAC permanent connection.
This must be done by employing a qualified electrician and in accordance with local electrical codes.
Note:
This 240V conversion allows the heater to operate as 4Kw @ 240V. The jet pump, ozone and AV outputs
remain 120V.
CAUTION:
Connect only to a circuit protected by a Class A Ground Fault Circuit Interrupter
when converting to the permanent connection mode.
Sunrise Spas 2019 Owner’s Manual
DOC: OM-SUNRISE-19
15
To convert from the factory 120VAC to 240VAC permanent connection follow these instructions:
1. Remove the 120VAC cord with GFCI (if applicable) at the terminal block and ground bar. ( 3 connection
points)
To connect to a 240VAC permanent supply from a class A GFCI:
Connect White (Neutral/N), Black (Hot/L1), Red (Hot/L2) and Green (ground wire/GRN) to the input
terminal block as shown on the wiring diagram inside the spa pack cover. See the spa ratings label for current,
wire size and breaker requirements.
2. Remove the white jumper wire connecting J11 on the WHT AC bank (area 1) to J32 on the RED AC bank
(area 3). See diagram below.
3. Before powering up the spa, locate the dipswitch bank in the lower, right corner of the circuit board.
4. Locate dipswitch #10 and move it to the OFF position (DOWN).
5. Reset Persistent memory
Any time you change a DIP Switch, other than A1, you must reset Persistent Memory for your new DIP Switch
Settings changes to take effect. If you do not reset Persistent Memory, your system may function improperly.
To Reset Persistent Memory:
A. Power down by disconnecting power source from spa
B. Put a jumper across J43, covering both pins
(See illustration)
C. Power up by connecting power source to spa
D. Wait until “Pr” is displayed on your panel
E. Power down again
F. Remove jumper from J43
(May also move to cover 1 pin only)
G. Power up again
STEP 2
STEP 3-4
STEP 5
To Reset Persistent Memory:
•Power down by disconnecting power source from spa
•Put a jumper across J43, covering both pins
(See illustration)
•Power up by connecting power source to spa
•Wait until “Pr” is displayed on your panel
•Power down again
•Remove jumper from J43
(May also move to cover 1 pin only)
•Power up again
16
DOC: OM-SUNRISE-19
Sunrise Spas 2019 Owner’s Manual
3) 230 VOLT SUPPLY CONNECTION
CAUTION:
Electrical installation must be carried out by a qualified electrician strictly in
accordance with local governing codes.
Use only Class A Ground Fault Circuit Interrupter.
TYPICAL NORTH AMERICAN GFCI
Several different models of GFCIs are
available on the market.
Note that our illustrations are generic.
BP SERIES SPA PACK
Power Requirements
240VAC, 60Hz, Class A GFCI-protected service
4 wires (Hot-Line 1, Hot-Line 2, Neutral, Ground)
For current requirements & breaker rating see nameplate on spa.
Power Up Screen
Each time the system powers up, a series of numbers is displayed. After the start-up
sequence of numbers, the system will enter Priming Mode. Next, refer to the User Guide
for your keypad at the back of this manual.
Sunrise Spas 2019 Owner’s Manual
DOC: OM-SUNRISE-19
17
18
DOC: OM-SUNRISE-19
Sunrise Spas 2019 Owner’s Manual
Wire Size and Over Current Protection (Canada/US)
Amp rating of spa
Supply Wire type and size
Over Current
Protection (amps)
More than
To
60C copper, AWG
75C copper, AWG
16 20 10 10 25
20
24
10
10
30
24
28
8
10
35
28
32
8
8
40
32
36
6
8
45
36 40 6 8 50
40 48 4 6 60
Note:
If your GFCI trips immediately on start-up or during the opening use of the spa, DO NOT USE THE SPA and
take precautions to ensure that no one uses the spa, while you contact your dealer/electrician. GFCI trips on newly
installed spas are predominantly caused by mis-wired GFCIs.
SPECIAL NOTE: DISCONNECT SWITCH
This unit must be connected to a disconnect that de-energizes power to the entire unit for servicing, maintenance or
the like. The disconnect switch, with marked "OFF" position, must be located within sight from the equipment and at
least 5ft. (1.52m) from the inside walls of the spa.
SPECIAL NOTE: EMERGENCY SWITCH
This unit is intended for use in a single family dwelling. When used in locations other than a single family dwelling, a
clearly labelled emergency switch, readily accessible to the occupants and at least 5ft. (1.52m) away from the unit,
shall be provided as part of the installation.
Sunrise Spas 2019 Owner’s Manual
DOC: OM-SUNRISE-19
19
WHAT’S INSIDE YOUR SPA
HYDROTHERAPY JETS
A variety of jet sizes and internal styles are used in unique seating patterns to achieve superior hydrotherapy in
individual spa models. Therefore, not every jet described or pictured below is in every model. Not all jet internal styles
are available in all jet sizes.
To adjust the water volume, simply turn the jet face clockwise to the off position or counter clockwise to the maximum
position. If you move too hard to maximum you will release the internal from the jet body.
Jet Type
Size
Adjustable Flow
Where it is most often used
Ozone/Cluster 1 ½” (38mm) No Seat backs, neck & shoulders, palm jets
Cluster 2 ¼” (56mm) Yes Palm jets, loungers, seat backs, calves, neck collars
Mini 3 5/16” (84mm) Yes Seat backs, footwells, loungers
Poly
3 ⅝” (92mm)
4 ⅜” (105mm)
Yes Seat backs, footwells, loungers
Power 5 ¼” (133mm) Yes Seat backs, footwells, loungers
Nozzle Type
Hydrotherapy Effect
Description
Fixed Stream
A steady, non-adjustable stream of water.
Neck Jets
A soft tissue therapy jet. Draws up to 3x the air of a
standard jet. Double, triple or multiple streams of air &
water mixed for soothing comfort. Non volume
adjustable.
20
DOC: OM-SUNRISE-19
Sunrise Spas 2019 Owner’s Manual
OTHER INTERNAL FITTINGS
Suctions
These multi-holed, anti-vortex fittings in the footwell provide the intake water for the pump(s). A
powerful suction is produced here when the jet pumps are turned on. On systems with a
circulation pump, the bypass suction fitting (smaller than regular suction), may have little to no
suction on it, since the circulation pump has a lower flow than the jet pump and the suction is
only active as the filter(s) become clogged.
All suctions in our spas are VBG compliant for your safety.
Perimeter LED Lighting
These round or hex shaped, multi-faceted fittings, located on the vertical spa wall and deck of
the spa, are the lenses for the LED light outputs.
Ozone/AquaNova Returns
These special thru wall fittings return water to your spa that has passed through the ozone or
AquaNova system. If you do not have either ozone or AquaNova on your spa, these fittings will
not be present.
Whitewater
(Sunrise)
Skimmer/Filter
This is the housing for your cartridge filter(s) and provides skimming action to remove surface
debris. Some models have a removable basket from which debris can be dumped.
Nozzle Type
Hydrotherapy Effect
Description
Directional
A steady volume adjustable stream of water with
adjustable nozzle direction
Rifled
A volume adjustable stream of water that gives the feel
of a rotating stream of water without moving parts.
Roto/Twin Roto
A volume adjustable jet with a fixed split nozzle that uses
the water flow to deliver dual streams of water in a
rotating pattern.
Massage
A volume adjustable stream of water that rotates. The
combination of the moving inner mechanism and front
face gives an ever changing pattern to the massage.
This manual suits for next models
20
