Sunsea AIoT SIMCom SIM8200G User manual

SIM8200G EVB
User Guide
SIMCom Wireless Solutions Limited.
Building B, SIM Technology Building, No.633, Jinzhong Road
Changning District, Shanghai P.R.China
Tel: [phone]
[e-mail]
www.SIMcom.com
5G Module

SIM8200G-EVB_User Guidelines_V1.01
www.simcom.com 2/26
Document Title:
SIM8200G EVB User Guide
Version:
V1.01
Date:
2020-08-28
Status:
Draft Version
GENERAL NOTES
SIMCOM OFFERS THIS INFORMATION AS A SERVICE TO ITS CUSTOMERS TO SUPPORT THE
APPLICATION AND ENGINEERING EFFORTS THAT USE THE PRODUCTS DESIGNED BY SIMCOM.
THE INFORMATION PROVIDED IS BASED ON THE REQUIREMENTS SPECIFICALLY FROM THE
CUSTOMERS. SIMCOM HAS NOT UNDERTAKEN ANY INDEPENDENT SEARCH FOR ADDITIONAL
RELEVANT INFORMATION, INCLUDING ANY INFORMATION THAT MAY BE IN THE CUSTOMER’S
POSSESSION. FURTHERMORE, THE SYSTEM VALIDATION OF THE PRODUCT DESIGNED BY
SIMCOM WITHIN A LARGER ELECTRONIC SYSTEM REMAINS THE RESPONSIBILITY OF THE
CUSTOMER OR THE CUSTOMER’S SYSTEM INTEGRATOR. ALL SPECIFICATIONS SUPPLIED
HEREIN ARE SUBJECT TO CHANGE WITHOUT NOTICE.
COPYRIGHT
THIS DOCUMENT CONTAINS THE PROPRIETARY TECHNICAL INFORMATION WHICH IS THE
PROPERTY OF SIMCOM LIMITED, COPYING OF THIS DOCUMENT, GIVING IT TO OTHERS, THE
USING OR COMMUNICATION OF THE CONTENTS THEREOF ARE FORBIDDEN WITHOUT THE
OFFICIAL AUTHORITY BY SIMCOM. OFFENDERS ARE LIABLE TO THE PAYMENT OF THE DAMAGES.
ALL RIGHTS ARE RESERVED IN THE EVENT OF GRANT OF A PATENT OR THE REGISTRATION OF A
UTILITY MODEL OR DESIGN. ALL SPECIFICATIONS SUPPLIED HEREIN ARE SUBJECT TO CHANGE
WITHOUT NOTICE.
SIMCom Wireless Solutions Limited
Building B, SIM Technology Building, No.633 Jinzhong Road, Changning District, Shanghai P.R.China
Tel: [phone]
Email: [e-mail]
For more information, please visit:
https://www.SIMcom.com/download/list-863-en.html
For technical support, or to report documentation errors, please visit:
https://www.SIMcom.com/ask/ or email to: [e-mail]
Copyright © 2020 SIMCom Wireless Solutions Limited All Rights Reserved.

SIM8200G-EVB_User Guidelines_V1.01
www.simcom.com 3/26
Version History
Data
Version
Description of change
Author
1.00
2019.09.18
Draft Version
Changshun Tan Hong Yu
1.01
2020.08.28
Modify format
Yanping Yang

SIM8200G-EVB_User Guidelines_V1.01
www.simcom.com 4/26
Directory
Version History.............................................................................................................................................................. 3
Directory................................................................................................................................................................ 4
1 The Purpose of This Article.......................................................................................................................... 5
2 Evaluation Board Set......................................................................................................................................6
2.1 SIM8200G Series Evaluation Suite Overview............................................................................................. 6
2.2 Interface Introduction....................................................................................................................................... 9
2.2.1 Interface Introduction......................................................................................................................... 10
2.2.2 Jumper Interface Introduction........................................................................................................... 12
2.2.3 Antenna Interface Introduction..........................................................................................................15
2.2.3 Other Interface Introduction.............................................................................................................. 16
3 Installation and Communication............................................................................................................... 19
3.1 Driver Installation............................................................................................................................................19
3.1.1 USB-to-UART Driver Installation...................................................................................................... 19
3.1.2 Module USB Interface Driver Installation........................................................................................19
3.2 Program Download Process.........................................................................................................................20
3.3 Accessory Installation.................................................................................................................................... 22
3.4 AT Command Communication..................................................................................................................... 23
3.4.1 Device Powered.................................................................................................................................. 23
3.4.2 UART Serial Communication............................................................................................................ 23
3.4.3 USB Communication.......................................................................................................................... 26

SIM8200G-EVB_User Guidelines_V1.01
www.simcom.com 5/26
1 The Purpose of This Article
Based on the SIMCom development suite, developers will quickly become familiar with and validate each
module's hardware and software capabilities.
The purpose of this article is to introduce the interface and usage of the development suite.
This document will be updated from time to time according to the debugging situation; Please make sure
you are using the latest version.

SIM8200G-EVB_User Guidelines_V1.01
www.simcom.com 6/26
2 Evaluation Board Set
2.1 SIM8200G Series Evaluation Suite Overview
The evaluation suite includes the EVB suite and TE suite.
1) SIM8200G-EVB board；
2) SIM8200G-TE board
3) SIM8200G-WF-FB board（WIFI board）
4) SIM8200G-CODEC board（audio board）
5) SIM8200G-EN-FB board（Ethernet board）
6) 5V DC power adapter；
7) TYPE-C USB 3.1/2.0 (data cable)；
8) Micro 5pin USB 2.0 (data cable)；
9) Antenna cable.
Figure 1 The EVB suite

SIM8200G-EVB_User Guidelines_V1.01
www.simcom.com 7/26
SIM8200G EVB development board front figure (no installing function board).
Figure 2 SIM8200G EVB without installing function board (front view)
The following is the diagram on the back of the SIM8200G EVB development board.
Figure 3 SIM8200G EVB without installing function board (back view)

SIM8200G-EVB_User Guidelines_V1.01
www.simcom.com 8/26
The following shows the front and back of the SIM8200G TE board：
Figure 4 SIM8200G TE (front view)

SIM8200G-EVB_User Guidelines_V1.01
www.simcom.com 9/26
Figure 5 SIM8200G TE (Back view)
To ensure proper validation of module functions, please purchase the correct kit model. The order
information for the SIM8200G module development suite is as follows:
Table 1: The order information for the SIM8200G module development suite
Kit
Part number
Remark
8XG000-SIM8200G-EVBKIT
S2-108RH
SIM8200G model EVB development kit
8XG000-SIM8200G-TEKIT
S2-108RG
SIM8200G model TE development kit
2.2 Interface Introduction
Through the introduction of the above section, we can see that many interfaces and signal test points are

SIM8200G-EVB_User Guidelines_V1.01
www.simcom.com 10 /26
reserved on the EVB baseplate, and this section mainly introduces the corresponding feature description.
2.2.1 Interface Introduction
1）The following table is a brief description of the interface functions of the SIM8200G-EVB board.
Table 2: Description of SIM8200G-EVB interface functions
Position
Description 1
Description 2
Position
Description 1
Description 2
A
SIM8200G TE
board interface
The installation
direction is as
shown in the
picture，
disassemble
horizontally and
vertically.
B
CODEC board
interface
The installation
direction is as
shown in the
picture，
disassemble
horizontally and
vertically.
C
WF-FB board
interface
WIFI/BT function
board. The
installation
direction is as
shown in the
picture，
disassemble
horizontally and
vertically.
D
EN-FB board
interface
AR8035 RGMII
Ethernet board.
The installation
direction is as
shown in the
picture，
disassemble
horizontally and
vertically.
E
(U)SIM card
interface
SIM8200
(U)SIM2
interface；
Support for hot
plug (insert high
level)
F
SD card
interface
SIM8200G SD
card interface
G
DB9 serial port
SIM8200G uart1.
H
Forced download
point
The two test
points are
short-connected
and then
powered on into
forced download
mode.
R
Jumper pIN
See the
description in the
next chapter for
details
J
USB to UART
SIM8200G
debug UART
K
SLEPP_IN
switch
Default direction
to the edge of the
board
L
RJ11
Codec audio
output interface
for phone
handle
M
Headphone
Codec audio
N
RESET key
SIM8200G

SIM8200G-EVB_User Guidelines_V1.01
www.simcom.com 11 /26
jack
output interface,
3.5MM American
standard
hardware reset
signal
O
Power key
SIM8200G
power key
P
1.8V LDO enable
selector switch
By default, the
rubber column is
turned in the
direction of the
plate edge. The
switch fluctuates
to the direction
of the board by
default, 1.8V is
turned on by
default.
Q
USB2.0
interface
SIM8200G
USB2.0 interface;
Jumper selection
is required, see
jumper
description of
SIM8200G TE
board p position
for details.
R
LED lights area
See details in
later chapters
S
Power enable
switch
Development
board power
supply enable
switch, power
supply open ON
gear.
T
The power
supply interface
Development
board power
supply interface,
4.5 ~ 5.5V / 3A
2）The following table describes the functions of the SIM8200G_TE board interface.
Table 3: Description of SIM8200G-TE interface functions
Position
Description1
Description 2
Position
Descriptio 1
Description 2
a
SIM8200G
module
b
USB3.1/2.0
interface
SIM8200G USB
interface；Need
to confirm the
jumper at p
position.
c
(U)SIM card
interface
SIM8200G
(U)SIM1 interface;
With Cato,
support hot plug
(high when
d
Battery
interface
SIM8200G
Battery circuit
interface，See
the battery
interface

SIM8200G-EVB_User Guidelines_V1.01
www.simcom.com 12 /26
inserted).
description
section for
details.
e
RF port
ANT3
f
RF port
ANT7
g
RF port
ANT2
h
RF port
ANT4
i
RF port
ANT1
j
RF port
ANT5
k
RF port
ANT6
l
RF port
ANT0
m
Jumper test
points
SLEEP signal
jumper, floating by
default.
n
Jumper test
points
VDDPX2
jumper; floating
by default.
o
Jumper test
points
Forced download
point, the two test
points are
short-connected
and then powered
on into forced
download mode.
p
Jumper test
points
USB 2.0
selection
jumper, see
description in
later chapters
for details.
q
Jumper test
points
VDDPX8 jumper;
floating by default.
r
Test points
RST:SIM8200G
hardware reset
test point.
PWR：
SIM8200G
Power key test
point.
s
Jumper test
points
mmW
SIM8200G module VBAT voltage range is 3.3V to 4.3V, the typical value is 3.8V.
All GPIO (including UART) pin levels of the SIM8200G module are 1.8V. Pay attention to match the
external master pin levels.
2.2.2 Jumper Interface Introduction
It mainly describes the interface with jumper selection or switch status. Please check the jumper selection
and switch status according to the actual situation during use.
1）Position “S” is the main power supply switch for EVB, and the power supply in the direction of ON is
turned ON, and the power supply in the direction of OFF is turned OFF.
Note

SIM8200G-EVB_User Guidelines_V1.01
www.simcom.com 13 /26
Figure 6 Power supply switch
2）Position “P” USB 2.0 channel selection: as shown in the figure below, the test points at the position “P”
on the SIM8200G TE board are used to select the USB2.0 signal. When using the USB interface of the
EVB board, please short-connect the yellow frame together, and use the TE version of the USB
interface ,please short-connect the red frame with each other.
Figure 7 USB 3.1/2.0 channel selection
3）Position “I” codec I2C jumper：The I2C signals of the audio codec need to add a jumper cap to the
position “I” on the EVB board. To use the audio function, you need to confirm whether the jumper at this
position is correct.
Figure 8 Codec I2C jumper

SIM8200G-EVB_User Guidelines_V1.01
www.simcom.com 14 /26
4）Position “I” for the I2C2 interface jumper of the sensor peripheral of EVB, Insert the jumper cap as
shown in the figure below, and you can also debug other peripherals here.
Figure 9 Sensor I2C jumper
5）Position “I”, the SPI interface of the EVB board needs to be jumpered according to the following jumper
to connect with the SPI FLASH on the EVB board; You can also connect other peripherals for debugging.
Figure 10 SPI jumper
6）Forced download point: Both TE board and EVB board, as shown in the following figure (in the yellow
frame), the two test points in the frame are shorted together and then powered on, and the SIM8200G
enters the download mode.
Figure 11 Forced download point

SIM8200G-EVB_User Guidelines_V1.01
www.simcom.com 15 /26
7）Position “K” is a SLEEP switch.Turning to the side of the board triggers SIM8200G to enter SLEEP.
Turning to the side of the board triggers SIM8200G to wake up.
Figure 12 SLEEP switch
2.2.3 Antenna Interface Introduction
For detailed antenna design, please refer to the document SIM8200G_LGA Antenna Port Mapping and
Design Guide_V1.00；The antenna interface of SIM8200G is briefly described in the following picture and
table：
Table 4: SIM8200G antenna interface
Position
Description 1
Description 2
Position
Description 1
Description 2
e
RF port
ANT3
f
RF port
ANT7
g
RF port
ANT2
h
RF port
ANT4
i
RF port
ANT1
j
RF port
ANT5
k
RF port
ANT6
l
RF port
ANT0
Figure 13 Antenna interface

SIM8200G-EVB_User Guidelines_V1.01
www.simcom.com 16 /26
Table 5: Description of SIM8200G antenna interface
ANT interface
ANT0
AL1
AIO
LTE low/middle/high band signal
send and receive;
N41 signal send and receive;
N79 signal diversity receive
617MHz~960MH
z
1710MHz~2690M
Hz
4400MHz~5000M
Hz
ANT1
BA25
AI
LTE middle/high band signal
diversity receive;
N41&N77 signal diversity
receive
1710MHz~2690M
Hz
3300MHz~4200M
Hz
ANT2
BA41
AIO
LTE low/middle/high band signal
diversity receive;
N79 signal send and receive
617MHz~960MH
z
1710MHz~2690M
Hz
4400MHz~5000M
Hz
ANT3
AY51
AIO
LTE middle/high band signal
diversity receive;
N41 signal diversity receive;
N77 signal send and receive
1710MHz~2690M
Hz
3300MHz~4200M
Hz
ANT4
BA33
AIO
N41 signal send and receive;
N77 signal diversity receive
2496MHz~2690M
Hz
3300MHz~4200M
Hz
ANT5
BA19
AIO
N77 signal send and receive
3300MHz~4200M
Hz
ANT6
AY1
AI
N79 signal diversity receive;
GNSS signal receive ;
1166MHz~1229M
Hz
1565MHz~1610M
Hz
4400MHz~5000M
Hz
ANT7
BA47
AIO
N79 signal send and receive
4400MHz~5000M
Hz
2.2.3 Other Interface Introduction
1）The definition of the RJ11 interface of the EVB board “L” is shown in the figure below. Connect the
phone handle to verify the audio. Please check whether the definitions match.

SIM8200G-EVB_User Guidelines_V1.01
www.simcom.com 17 /26
Figure 14 RJ11 interface
2）The definition of the battery interface on the TE board is as follows.
Figure 15 battery interface
3）The LED light is briefly described below (the indicator software on the EVB board is not tuned and
cannot be used temporarily).
LED-1: EVB Power signal light
LED-2: WAKEUP_OUT signal light
LED-3: STATUS signal light
LED-4: NET_STATUS signal light
LED-5~8: Reserved

SIM8200G-EVB_User Guidelines_V1.01
www.simcom.com 18 /26
Figure 16 LED light

SIM8200G-EVB_User Guidelines_V1.01
www.simcom.com 19 /26
3 Installation and Communication
3.1 Driver Installation
The USB interface position on the EVB board is point “J”, and USB to UART interface, Debug Uart interface
for SIM8200G. The true USB physical interface of SIM8200G module is the USB interface on TE board and
the location is point “b” or point “Q” on EVB board.
3.1.1 USB-to-UART Driver Installation
The USB-to-UART chip on the EVB board is a product of Silicon Labs. The following link can get its driver.
https://www.silabs.com/products/development-tools/software/usb-to-uart-bridge-vcp-drivers
After installing the driver correctly, you can see the following virtual USB port, COM27, COM28.
Figure 17 UART port
Table 6: UART interface description
Interface
type
Port
number
module serial
port
Remark
SCI
COM 21
Debug UART
Used to capture the serial port LOG
3.1.2 Module USB Interface Driver Installation
Please contact SIMCom technical support for the correct driver file, SWD and SIMCom USB driver.
Install the SIMCom USB driver. After the module is powered on, the port COM will have 3 driver ports to
install. You can install them by browsing SIMCom_USB_Driver \ Windows7. After the driver is properly
installed, there will be 4 virtual USB ports under the device manager port.
ADB port：Use ADB commands and software updates
AT port：For the communication with AT command
Audio port: For Audio function
Diagnostics port：For debug
NMEA port：For GPS service

SIM8200G-EVB_User Guidelines_V1.01
www.simcom.com 20 /26
Figure 18 Device manager port
3.2 Program Download Process
1）First enter the download mode according to the method described in Article (6) of 2.2.2, and connect
the USB2.0 interface on the EVB board or TE board (for detailed jumper selection, please refer to the
method selection of Article (2.2) of 2.2.2) ), 9008 is displayed on the USB port.
Figure 19 download mode port
2）QFIL tool settings
Select Configuration-> FireHose Configuration. The following Download Configuration screen appears.
Please select Device Type as nand, if you need to wipe all, please check “Erase All Before Download”.
