Sunshine Solar CSC Series User manual

CSC Series
PURE SINE WAVE INVERTER WITH CHARGER

1. INTRODUCTION
Thank you for choosing our CSC series Pure sine wave Inverter with Charger (herein after called
CSC). The perfect combination of a pure sine wave inverter and a 3 stage battery charger.
When the mains power fails, it converts the battery's DC to AC to support household electrical
appliance's. When the mains power is on, it auto switches to use the mains AC power and the 3
stage battery charger will monitor the state of the batteries and auto adjust as required (constant
current, constant voltage, floating charge).
With a transfer time of less than 15 ms AC appliance operation is uninterrupted.
2. FEATURES
·Fully auto. protection functions: Earth Leakage Protection, Reverse Polarity, Overload, Over
Voltage, Over Temperature, Low Voltage, Short Circuit.
·Transfer time between bypass and inverter mode less 15ms, no interruption to your
appliance's when mains power is off.
·Three LED indicators: Power, Fault, Charger
·Pure sine wave output, THD<3%
·AVS protection function: low voltage, over voltage, time delay
3. SAFETY FIRST
To ensure reliable service, it must be installed and used properly. Please read the installation
and operating instructions thoroughly prior to installation and use. Pay special attention to the
WARNINGS and CAUTIONS statements in this manual. The CAUTION statements advise against
certain conditions and practices that may result in damage in your CSC. The WARNINGS
statements identify conditions or practices that may result in personal injur y. Read all
instructions before using this CSC!
·Sparking may occur when connecting the unit to the battery, make sure no flammable
fumes are present before making any connections.
·Remove appliance plug from outlet socket and turn off CSC before working on the appliance.
And do not expose CSC to the water, rain ,snow or spray environment.
·This is not a toy please keep away from children.
·Do not install any other object into the air vents.
·No user-serviceable components inside. Do not attempt to open the CSC by yourself.
· Do not operate this CSC if it is wet, and do not install it in engine compartment- please
install it in a well ventilated area, to avoid too high temperature.
· Do not connect live AC main power to the CSC's AC outlets, it may cause the CSC's
permanent damage.
· Please pay special attention to the connecting method part in this manual, avoid polarity
reverse connection.
!
WARNING!
To reduce the risk of fire, electric shock, explosion or
!
WARNING!
To reduce the risk of fire, electric shock, explosion
1. Introduction
2. Features
3. Safety First
4. Operation environment
5. Product materials list and indication
6. Installation
7. AVS protection function
8. Protection function
9. Operating tips
10. Trouble shooting
11. Cleaning, care and maintenance
12. Disposal
13. Specification
14. Warranty
15. Icon indication

NOTE:
· You can use one or more batteries. Preferably use 100 Ah or larger batteries for long back-up
time.
· If grid power is available, AC bypasses the inverter & power-for the electrical appliances is
provided by the mains (inverter switched on) for battery charging.
· If grid power fails, the CSC conver t the batter y DC power to AC power-for the electrical
appliances. (the inverter must be switched on).
7.1. There are cables with terminal rings included, use the cables to connect the unit directly to
the batteries.
The input terminals on the rear side of the unit are Red-positive and Black-Negative 6- .
Connect the red cable to the red terminal and the positive pole of the battery.
Connect the black cable to the black terminal and the negative pole of the battery.
Where units are supplied with four cables two red, two black all four must be connected .
Make sure all connections are solid and secured. Poor connections may cause the cables and
terminals to overheat and shorten the battery backup time. (ensure that the inverter and
charger mode are OFF before connecting to the battery).
WARNING!
· Reverse polarity will burn the fuse or may cause damage to the CSC avoid at all cost as
damage caused by wrong connection is not cover by our warranty.
·The CSC must be connect only to batteries with a normal output voltage of 12 volts. The
power source can be a 12V battery or several 12V batteries connected in parallel
to increase the backup time. The unit will not operate from a 6 volt battery, and will sustain
permanent damage if connected to a 24 volt battery.
·Keep ventilation when using batteries. Batteries may generate flammable gas during
charging or discharging.
4. OPERATION ENVIRONMENT
For best operating performance, the CSC should be placed on flat surface, such as ground or
other solid surface, install the CSC in a location that is:
·DRY. Do not allow water and/ or other liquids to come into contact with the CSC. In all
marine applications, do not install the CSC below or near the waterline and keep the CSC
away from moisture or water.
·COOL. Ambient air temperature should be between 30° F (-1°C ) non-
condensing, and 105 ° F (40 °C). Do not place the CSC on or near a heating
vent or any pieces of equipment which is generating heat above room temperature. Keep
the CSC away from direct sunlight, if at all possible.
·VENTILATED. Keep the area surrounding the CSC clear to ensure free air circulation around
the unit, do not place items on or over the CSC during operation. A fan is helpful if the CSC is
operating at maximum power outputs for extended periods of time. The units will shut down
if the internal temperature exceeds operating temperatures and restart after it cools.
·SAFE. Do not use the CSC near flammable materials or in any location s that may
accumulate flammable fumes of gasses.
5. PRODUCT MATERIALS LIST AND INDICATION
5.1. CSC600~CSC1000W
5.2. CSC1500~CSC2000W
1
2
4 1 5
6+
7
6-
3
5
11 8 9 10
6. AVS PROTECTION FUNCTION
·Lower voltage protection: when the mains power is lower than 170VAC, the CSC shall be shut
down to protect it. Once voltage increase to normal range, The CSC restarts automatically.
·High voltage protection: When the mains power is too high, the CSC shut down automatically.
Restarts once voltage is down to normal range.
·Time delay: The restart protection delay is 17 seconds this time delay function avoids damage
to the unit when AC grid power failure is frequent.
7. Installation
Indication:
8. AC Power Cord
9. Charger LED
10. Ventilation Hole
11. Slots for installation
12. DC Cable with Ring
13. DC Fuse
14. AC Fuse
15. User Manual
1. AC Outlet
2. Power LED
3. Fault LED
4. ON/OFF Switch
5. Cooling Fan
6. DC Input Terminal (Red-Positive)
DC Input Terminal (Black-Negative)
7. Grounding Terminal
DC Cable with
DC
User
AC
DC Cable with
DC
User
AC
PUBLIC POWER
BATTERY
AC LOAD
CSC
12
13
14
15
12
13
14
15

·Sparking may occur when connecting the unit to the battery, make sure no flammable
fumes are present before making any connections.
·Please use the DC cables supplied to ensure best performance.
7.2. Connect the grounding terminal to earth if possible for added safety.
WARNING!
Before using the CSC, use a grounding cable. There is a terminal fitted with a nut in
the CSC's output panel. Please choose heavy duty, green and yellow insulated cable driven into the
ground at a depth of 1-2m or more.
7.3. Plug into the mains power, when the charger LED is on the CSC will charge your battery.
7.4. Plug your AC appliance into the CSC's outlet.
Make sure your appliance is turned off before connecting to the unit. Please turn your
appliances on one by one. Now your appliance are functioning if the rated power is overloaded, the
red LED will come on and the inverter will shut down. To reset, reduce the load and if the
appliance requires power within CSC's rated power the inverter willl restart automatically.
WARNING!
We advise that you do not use appliance/s with a power rating more than 90% of the
CSC's rated power.
Although there is a overload protection in CSC, this may damage the unit.
8. PROTECTION FUNCTION
The CSC is designed with a universal protection circuit that provide added safety features not only for
your AC appliances, batteries but also for itself.
IV Auto.3 stage charge
9. OPERATING TIPS
9.1. Rated Versus Actual Current Draw of Equipment
Most electrical tools, appliances and audio/video equipment have labels that indicate the
power consumption in amps or watts. Be sure that the power consumption of the item you
wish to operate is rated within CSC wattage or less. (if the power consumption is rated in amps
AC, simply multiply by the AC volts to determine the wattage ). The CSC (inverter mode) will
shut down if it is overloaded. The appliances causing the overload must be removed before the
CSC will restart. Resistive loads are the easiest for the CSC to run. However larger resistive
loads such as electric stoves or heaters, usually require more wattage than the inverter can
deliver. Inductive loads, such as TV's and stereos, require more current to operate than
do resistive loads of the same wattage rating. Induction motors, as well as some televisions,
may require 2 to 6 times their wattage rating to start up. The most demanding in the category are
those that start under load, such as compressors and pumps. Testing is the only definitive way
to determine whether a specific load will run. To restart the unit after a shutdown due to
overloading, remove the overload and if necessary turn the power switch OFF then ON.
9.2. Power Tools and Microwave Ovens Won't Start
Read the information panel on each power tool carefully to accurately determine the tool's
input wattage. The wattage output may be sufficient to operate most power tools and microwave
ovens but remember that the power needed to start the power tool may be as much as 2 to 6
times its continuous wattage requirements.
9.3. The AC output waveform of the CSC (inverter mode) is know as the“pure sine
wave”.
Figure 1: Modified Sine Wave and Pure Sine Wave Comparison
(%)
time
Stage 1
Stage 2
Stage 3
Battery charged% Charging current
This eliminates most shutdown from
momentary overload.
The inverter part automatically re-start
when overload remove.
Output that momentarily dips in
voltage and quickly recovers.
Automatically restart
Alarm activated when battery is discharge
to 10.6V/21.2V.
The CSC shuts down when the battery is discharge
to 10V/20V ( prevents damage to the battery)
The CSC shut down when the load has
electric leakage.
Bypass
and
Inverter
Mode
Protection
Low Voltage Alarm
Over Voltage Protection
Earth Fault Protection
The CSC will shuts down when overheated.
The CSC shuts down when output short circuit
happen
By fuse open.
This eliminates failed cold start under load.
The CSC shuts down when the loading power
exceeds it's power rating
Over temperature
Protection
Overload Protection
Short Circuit Protection
Reverse Polarity Protection
Gradual voltage ramp-Up
during inverter start-up
Soft Start
Circuit
Stage 1. Constant Current- Rapid charge the
battery with constant high current.
Fit for heavy-loaded condition.
Stage 2. Constant Voltage-Moderate charge the
battery with constant voltage. this allow the
battery to well absorb the charge and maximum
battery's life.
Stage 3. Floating Charge-After the battery
charged to around 99% full.
The charger automatically switch to “floating-
mode” that keeping the battery in well condition.
Auto 3 stage battery
charging
Charger
Mode
Protection

Fuse burned Change fuse or contact technical
support(refer to the part 10.4)
Over temperature protection
Overload protection
Remove or reduce load, wait for CSC to cool
Remove or reduce load or use more big
power CSC
Reduce load or remove short circuit
Fuse burned
Contact Seller for repair or changed
PCB broken
Change battery or re- connect the
battery
Battery's defective or
poor connection
Change fuse or contact technical
support(refer to the part 10.4)
Short circuit protection
Change the battery or charging for it
POSSIBLE CAUSE SUGGESTED REMEDY
Battery over discharge,
low battery protection.
No AC
output
Red LED lit,
green LED
not lit or beep
sound alarm
Red and green
LED not lit
No AC
output
No AC
output
Red and green
LED not lit
TROUBLE
-360 -270 -180 -90 090 180 270 360
MODIFIED
SINE WAVE
PURE SINE WAVE
Phase(degrees)
10.2. When public power on, the problem happened in bypass and charger
10.3. Other
11. CLEANING, CARE AND MAINTENANCE
Always disconnect the power inverter from the 12V/24V power source and the external
appliance from the socket before starting any cleaning or maintenance. Keep all air inlets and
vents free of dirt and dust. Clean the power inverter with a moistened cloth. Do not use
abrasive utensils for cleaning. Store the power inverter in a dry place, well ventilated and in a
temperature range between 0°C and 40°C. Do not store in direct sunlight, near heater,
radiators or under moist and wet environment conditions.
12. DISPOSAL
9.4. Battery's Back up time depends on the appliances you will be using.
The batteries must provide between 10.5 and 15.5 volts DC (if 12V CSC) and must be able to
supply the necessary current to operate the load. The power source should be a good condition
deep-cycle Lead-acid battery. To obtain a rough estimate of the current (in amperes ) the
power source must deliver, simply divide the power consumption of the load (in watts AC ) by
10. Example: if a load is rated at 100 watts AC, the power source must be able to deliver:
100/10=10A On larger applications the power source may be several batteries connected in
parallel. It is important to make sure the cables are suitable sized. This manual does not
describe all of the possible types of battery configurations, battery charging configurations and
battery isolation configurations.
9.5. Battery Charger
We recommend you use deep cycle batteries. If you hear the low voltage protection alarm,
please stop using the appliance, when the battery is fully charged, you can use it again.
Please plug into the mains power to charge the battery.
The battery operation time depends on the battery capacity(Ah) and the loading power (Watt)
The method to calculate the operation time is:
Battery capacity (Ah) x input voltage(V)/ loading power(W)
Example:
Battery capacity= 150Ah
Input voltage= 12V
Loading power= 600W
(150Ah x 12V)/600W= 3H
10. TROUBLE SHOOTING
10.1. When mains power fails and the Inverter switch is ON, the problem happened in the
inverter mode.
Stop to use it or switch off the charger
mode or adjust AC voltage
AC input voltage under
170V/70V
Switch off 10 minutes for cool down
Using time too long,
high temperature
CSC beep long time but
still on working
Tighten connection or re-connect
the AC power
Poor AC wire connection
Change fuse or contact technical
support(refer to the part 10.4)
built In fuse burned
It will be auto stop the charge or
you switch off charger mode
Battery will be fully
charged soon
When the public power
available, inverter mode
can't be switch to charge
mode
SUGGESTED REMEDYPOSSIBLE CAUSETROUBLE
Use a larger battery or connect more
batteries in parallel to increase the
back up time
AC loads power
consumption is higher
than the rated power
Replace the battery
Battery is old or defective
Charge for the battery
Battery over discharge
Power dissipation caused by
the too long or thin cable
Use more shorter/heavier DC cables
Unplug the fault load
Earth fault protection
Contact seller for repairing or change
Strong collision cause
the circuit loosen
Battery run time is less
than expected
No AC
output
Red and green
LED lit
Reading voltmeters can't
get accurate data
Use a true RMS reading
voltmeters
CSC output show low
voltage
It will working when in charge
mode, fully charged it will auto
stop
It is normal
Cooling fan not working
When AC main power failure, it
could be working in inverter
mode, but it no working
Contact seller for repairing or
replace it
Cooling fan not working
SUGGESTED REMEDYPOSSIBLE CAUSETROUBLE

15A
7A
Constant Current, Constant Voltage; Floating Charge(Auto.3 Stage)
630-700W 1100-1200W 1600-1700W 2100-2200W
earth leakage polarity reverse, over voltage, low voltage, overload,
overheat short circuit protection
low voltage, over voltage, time delay
D. Exposure to unsuitable environment conditions ( including but not limited to damage due
to lightning strikes)
E. Unauthorized or abnormal use or operation
F. Negligence or accidents
G. Material or workmanship not provide by us
H. This warranty does not cover costs related to removal,installation, or troubleshooting of
your electrical systems we will, as an option, use new and / or reconditioned parts in
performing warranty repair and in building replacement products.
We reserve the right to use parts or products of original or improved design in the repair or
replacement. If we repair or replace a product, its warranty continues for the remaining portion
of the original warranty period. All replaced products and all parts removed from repaired
products become the property of us.
14.1. Buyer (customer) information:
!
St an da rds O rg an iz ation o f
Ni ge ri a Conformity Assessment
Programme
The Restriction of the use of
certain hazardous substances in
electrical and electronic equipment
Conform to European
standards
Layer
Limited
Read the instruction before using your product.
Handle
with Care
For indoor
use only
14.2. You will need to provide the following information for your warranty and repair of the
device:
●this table or manual.
●copy of the till receipt( invoice, receipt) with the date of purchase.
●reason for the complaint or a description of the fault.
●returns number authorising the return
Our factory authorized the dealer to sign or stamp, and for this table to come
into effect it should be signed or stamped by the dealer.
Old electrical appliances are recyclable. Do not dispose of them in the domestic waste!
Take to your local recycling centre. Dispose of the packing material in an environmentally
friendly way.
13. SPECIFICATION
14. Limited product warranty and exclusions:
We provides a limited warranty that covers defects of the products you ordered caused by
material or manufacturing faults. The warranty period is for 12 months and begins on the date
of purchase by the original end user.
This limited warranty is made only to the original purchase of the unit, and is not transferable
to any subsequent owner.
We will, as an option, repair or replace the defective component(s) free of charge, provide that
our factory is notified of the defect during the warranty period and a dated proof of purchase
is provided. We reserve the right to inspect the faulty component(s) and determine if the
defect is due to material or manufacturing flaws. We also reserve the right to charge for
service time if the defect is not due to material or manufacturing flaws or is not for some other
reason subject to this limited warranty.
The warranty does not cover defects or damages caused by :
A. Normal wear and tear
B. Shipping or transportation damages
C. Improper use or installation
Signature:
Customer Name
Products model
Product No.
Date of Purchase
Contact Number
E-mail Address
Contact Number:
Selling Company:
Product model
Product Number
Pure Sine
220±10% 50Hz or 110V±10% 60Hz (refer product's cable)
>60°C auto. shutdown
MODEL CSC600 CSC1000 CSC1500 CSC2000
600W
1200W
1000W
2000W
1500W
3000W
2000W
4000W
Rated Power
Surge Power
Ac output
Wave form
Output
12V(10-15V) or 24V(21-30V)
170-250V(220V) or 70-150V (110V)
DC Input
AC Input range
Max. Current 12V
24V
10A
5A
Charge Way
Transfer time
Overload
Over Temperature
Other
AVS Protection
Input
Protection
Function
Charger
<25ms<15ms
