WEG MVW3000 Series Owner's manual

Motors | Automation | Energy | Transmission & Distribution | Coatings
Medium Voltage Frequency Inverter
MVW3000
Programming Manual

Programming Manual
Series: MVW3000
Software version: 1.0X
Language: English
Document Number: 10004771632 / 00
Build 744
Publication Date: 08/2017

Summary of Reviews
Version Revsion Description
1.0X 00 First edition.

Contents
Contents
QUICK REFERENCE OF PARAMETERS AND FAULTS ........................0-9
PARAMETERS .................................................................................................................. 0-9
MESSAGES OF ALARMS AND FAULTS .............................................................................. 0-33
1 SAFETY INSTRUCTIONS ...........................................................1-1
1.1 SAFETY WARNINGS IN THE MANUAL ......................................................................... 1-1
1.2 SAFETY WARNINGS ON THE PRODUCT ...................................................................... 1-1
1.3 IDENTIFICATION LABEL OF THE MVW3000.................................................................. 1-2
1.4 PRELIMINARY RECOMMENDATIONS .......................................................................... 1-2
2 GENERAL INFORMATION ..........................................................2-1
2.1 ABOUT THE MANUAL................................................................................................ 2-1
2.2 SOFTWARE VERSION ................................................................................................ 2-1
2.2.1 Available Models ............................................................................................. 2-1
3 KEYPAD (HMI) OPERATION .......................................................3-1
3.1 INSTALLATION OF THE GRAPHIC HMI IN THE CABINET................................................ 3-1
3.2 STARTING THE USE OF THE GRAPHIC HMI ................................................................. 3-2
3.2.1 Graphic HMI Basic Visualization Modes ............................................................. 3-3
3.2.2 Structure of the Parameter Groups .................................................................... 3-4
3.2.3 Sequential Access Mode .................................................................................. 3-5
3.2.4 Parameter Groups Access Mode ....................................................................... 3-6
3.3 PARAMETER EDITION ............................................................................................... 3-8
3.3.1 Numerical edition ............................................................................................ 3-8
3.3.2 Alphanumerical edition .................................................................................... 3-8
3.4 CONFIGURING THE GRAPHIC HMI ............................................................................. 3-9
3.4.1 LCD contrast .................................................................................................. 3-9
3.4.2 Configuring the HMI Commands ....................................................................... 3-9
3.4.3 Configuring the Monitoring Mode Read-Only Parameters .................................. 3-10
3.4.4 Configuring the On-line Graphic (Watch) Function ............................................. 3-10
3.5 ALARMS AND FAULTS ............................................................................................. 3-11
3.5.1 Alarms/Faults Screen..................................................................................... 3-11
3.5.2 Note Screen.................................................................................................. 3-12
3.5.3 Error Log ...................................................................................................... 3-12
3.6 HELP FUNCTION .................................................................................................... 3-13
4 DETAILED PARAMETER DESCRIPTION .......................................4-1
5 SPECIAL FUNCTIONS ...............................................................5-1
5.1 PID REGULATOR ...................................................................................................... 5-1

Contents
6 DIAGNOSTICS AND TROUBLESHOOTING ...................................6-1
6.1 ALARMS, FAULTS AND POSSIBLE CAUSES ................................................................. 6-1
6.2 INFORMATION FOR CONTACTING TECHNICAL SUPPORT .......................................... 6-56
6.3 PREVENTIVE MAINTENANCE ................................................................................... 6-56
6.3.1 Preventive Maintenance During Operation........................................................ 6-56
6.3.2 Preventive Maintenance with Complete Stop/De-energization ............................ 6-57
6.4 SAFE DE-ENERGIZATION INSTRUCTIONS ................................................................. 6-58

0
QUICK REFERENCE OF PARAMETERS AND FAULTS
QUICK REFERENCE OF PARAMETERS AND FAULTS
Software: V1.0X
Application:
Model:
Serial number:
Responsible:
Date: / / .
PARAMETERS
Param. Description Adjustable range Factory
setting
Pag.
P0000 Parameter access password 0 to 999 0 4-1
P0001 Motor speed reference Read-only parameter (rpm) - 4-1
P0002 Motor Speed Read-only parameter (rpm) - 4-1
P0003 Motor Current Read-only parameter (A) - 4-2
P0005 Motor Frequency Read-only parameter (Hz) - 4-2
P0006 VFD Status 0 = Booting
1 = Sub
2 = Inveter ready
3 = Motor Mag.
4 = Motor ready
5 = Up Ramp
6 = Down Ramp
7 = In reference
8 = Not used
9 = Coast
10 = Ride-Through
11 = Flying Start
12 = Test Mode
13 = Invertes test state
14 = Not used
15 = Not used
16 = Fault
17 = Alarm
18 = Calibration process
19 = Hold
20 = I Limit
21 = fast current limitation
22 = Ride-Through without interruption
23 = Hold 2
24 = Synchronized with the line
25 = Fast disable
26 = Trying to synchronize with the line
27 = Not used
28 = Not used
-4-2
P0007 Inverter output voltage Read-only parameter (V) - 4-3
P0009 Motor Torque Read-only parameter (%) - 4-3
P0010 Inverter output power Read-only parameter (kW) - 4-4
P0012 Digital inputs DI1 to DI10 status - - 4-4
P0013 Digital outputs DO1 to RL5 status - - 4-4
P0018 Value of analog input AI1 (single-pole,
MVC4)
Read-only parameter (%) - 4-4
P0019 Value of analog input AI2 (two-pole
MVC4 board)
Read-only parameter (%) - 4-4
MVW3000 | 0-9

0
QUICK REFERENCE OF PARAMETERS AND FAULTS
Param. Description Adjustable range Factory
setting
Pag.
P0020 Value of analog input AI3 (two-pole EBB
board)
Read-only parameter (%) - 4-4
P0021 Value of analog input AI4 (two-pole EBA
board)
Read-only parameter (%) - 4-4
P0022 Temperature on MVC3 board Read-only parameter (◦C) - 4-5
P0023 Software version of MVC4 board - - 4-5
P0028 Value of analog input AI5 (isolated
single-pole MVC4 board)
Read-only parameter (%) - 4-5
P0030 Temperature register channel 1 Read-only parameter (◦C) - 4-5
P0031 Temperature register channel 2 Read-only parameter (◦C) - 4-5
P0032 Temperature register channel 3 Read-only parameter (◦C) - 4-5
P0033 Temperature register channel 4 Read-only parameter (◦C) - 4-5
P0034 Temperature register channel 5 Read-only parameter (◦C) - 4-5
P0035 Temperature register channel 6 Read-only parameter (◦C) - 4-5
P0036 Temperature register channel 7 Read-only parameter (◦C) - 4-5
P0037 Temperature register channel 8 Read-only parameter (◦C) - 4-5
P0040 Value of process variable (PID) Read-only parameter (%) - 4-6
P0041 Active redundant ventilation set 0 = Set A is active
1 = Set B is active
2 = Set A is active - Set B has failed
3 = Set B is active - Set A has failed
4 = Set A is active - Sets A and B have failed
5 = Set B is active - Sets A and B have failed
6 = Set A automatic test
7 = Set B automatic test
-4-6
P0042 Time powered counter Read-only parameter (h) - 4-6
P0043 Time enabled counter Read-only parameter (h) - 4-7
P0044 MWh Counter Read-only parameter (MWh) - 4-7
P0045 Graphic HMI software version - - 4-7
P0066 MVC3 board software version - - 4-7
P0067 Error Register 1 to 100 0 4-7
P0068 Present Error - - 4-8
P0070 Status of the MVC3 board digital inputs
DI1, DI2, ..., DI16
- - 4-8
P0071 Status of MVC3 board relay digital out-
puts RL1 to RL8
- - 4-8
P0076 i x t Overload Read-only parameter (%) - 4-8
P0080 Date (dd/mm/yy) - - 4-8
P0081 Hour (24hs) - - 4-9
P0100 Acceleration time 0.0 to 999.0 s 100.0 s 4-9
P0101 Deceleration time 0.0 to 999.0 s 180.0 s 4-9
P0102 Acceleration time 2nd ramp 0.0 to 999.0 s 100.0 s 4-9
P0103 Deceleration time 2nd time 0.0 to 999.0 s 180.0 s 4-9
MVW3000 | 0-10

0
QUICK REFERENCE OF PARAMETERS AND FAULTS
Param. Description Adjustable range Factory
setting
Pag.
P0104 S Ramp 0.0 to 100.0 % 0.0 % 4-9
P0120 Reference Backup 0 = Inactive
1 = Active
14-10
P0121 Speed reference by the HMI keys 0 to 7200 rpm 90 rpm 4-10
P0122(2) Speed reference for JOG or JOG+ 0 to 8192 rpm 150 rpm 4-10
P0123(2) Speed reference for JOG- 0 to 8192 rpm 150 rpm 4-10
P0124(2) Multispeed reference 1 0 to 4095 rpm 90 rpm 4-12
P0125(2) Multispeed reference 2 0 to 4095 rpm 300 rpm 4-12
P0126(2) Multispeed reference 3 0 to 4095 rpm 600 rpm 4-12
P0127(2) Multispeed reference 4 0 to 4095 rpm 900 rpm 4-12
P0128(2) Multispeed reference 5 0 to 4095 rpm 1200 rpm 4-12
P0129(2) Multispeed reference 6 0 to 4095 rpm 1500 rpm 4-12
P0130(2) Multispeed reference 7 0 to 4095 rpm 1800 rpm 4-12
P0131(2) Multispeed reference 8 0 to 4095 rpm 1650 rpm 4-12
P0133(2) Minimum speed reference 0 to 7200 rpm 90 rpm 4-13
P0134(2) Maximum speed reference 0 to 7200 rpm 1800 rpm 4-13
P0136 Addition on the manual torque curve
(I x R)
0 to 100 0 4-14
P0137 Addition on the automatic torque curve 0 to 1000 0 4-15
P0138(2) Rated slip -10.0 to 10.0 % 0.0 % 4-16
P0139 Output current filter 0.0 to 16.0 s 0.2 s 4-17
P0140 Redundant ventilation selection 0 = Inactive
1 = Set A
2 = Set B
3 = Alternating A
4 = Alternating B
04-17
P0141 Number of hours for alternating ventila-
tion set
1 to 9999 h 720 h 4-18
P0142(1) Maximum Voltage 0.0 to 100.0 % 100.0 % 4-18
P0143(1) Intermediate output voltage 0.0 to 100.0 % 50.0 % 4-18
P0144(1) Output voltage at 3 Hz 0.0 to 100.0 % 8.0 % 4-18
P0145(1)(2) Field weakening speed 0 to 7200 rpm 1800 rpm 4-18
P0146(1)(2) Intermediate speed 90 to 7200 rpm 900 rpm 4-18
P0151(4) DC Link voltage regulation actuation
level
106 to 1200 V 1118 V 4-19
P0152 Proportional gain of the DC link voltage
regulator
0.0 to 9.99 0.0 4-20
P0156(2)(5) Overload current at 100 % 0.0 to 3420.0 A 154.0 A 4-21
P0157(2)(5) Overload current at 50 % 0.0 to 3420.0 A 126.0 A 4-21
P0158(2)(5) Overload current at 5 % 0.0 to 3420.0 A 70.0 A 4-21
P0159 Temperature alarm I x t 0 to 100 % 80 % 4-22
MVW3000 | 0-11

0
QUICK REFERENCE OF PARAMETERS AND FAULTS
Param. Description Adjustable range Factory
setting
Pag.
P0169 Maximum out current 0.0 to 270.0 A 189.0 A 4-22
P0177 Minimum flux on the motor 0 to 120 % 0 % 4-23
P0178 Rated flux on the motor 0 to 120 % 100 % 4-23
P0180 Starting point of the field weakening 0 to 120 % 85 % 4-23
P0181(1) Magnetization mode 0 = General enable
1 = Start/Stop
04-23
P0200 Password 0 = Inactive
1 = Active
14-24
P0201 Language selection 0 = Português
1 = English
04-24
P0202(1)(2) Control Type 0 = V/F 60 Hz
1 = V/F 50 Hz
2 = Adjustable V/F (refer to P0142 to P0146)
04-24
P0203(1) Special function selection 0 = None
1 = PID regulator
04-25
P0204(1) Load/Save Parameters 0 = Not Used
1 = Not Used
2 = Not Used
3 = Reset P0043: It resets the enabled time counter.
4 = Reset P0044: It resets the MWh counter.
5 = Load WEG - 60 Hz: It reset all the parameters to the
60 Hz factory default values.
04-25
P0206 Auto-reset time after fault 0 to 255 s 0 s 4-26
P0208(2) Reference scale factor 1 to 18000 1800 4-26
P0209(1) Motor phase loss detection 0 = Inactive
1 = Active
04-27
P0211 Disable by zero speed (Stop Logic) 0 = Inactive
1 = Active
14-27
P0212 Condition for disab. output by zero
speed
0 = P0001 (N*) > P0291 or P0002 (N) > P0291
1 = P0001 (N*) > 0
04-27
P0213 Time delay for zero speed disable 0 to 999 s 0 s 4-28
P0214(1)(7) Line phase loss detection 0 = Inactive
1 = Active
04-28
P0220(1) LOCAL/REMOTE selection source 0 = Always LOCAL
1 = Always REMOTE
2 = HMI
LOC
REM
key (LOCAL default)
3 = HMI
LOC
REM
key (REMOTE default)
4 = Digital Inputs DI2...DI10 (P0264...P0272)
5 = Serial (LOCAL Default)
6 = Serial (REMOTE Default)
7 = Fieldbus (LOCAL Default)
8 = Fieldbus (REMOTE Default)
9 = LOCAL PLC
10 = REMOTE PLC
11 = Graphic HMI
LOC
REM
key (LOCAL Default)
12 = Graphic HMI
LOC
REM
key (REMOTE Default)
11 4-28
MVW3000 | 0-12

0
QUICK REFERENCE OF PARAMETERS AND FAULTS
Param. Description Adjustable range Factory
setting
Pag.
P0221(1) Speed reference selection LOCAL situ-
ation
0 = Key and of service HMI
1 = Analog Input AI1’ (P0234 to P0236)
2 = Analog Input AI2’ (P0237 to P0240 and P0248)
3 = Analog Input AI3’ (P0241 to P0244).
4 = Analog Input AI4’ (P0245 to P0247)
5 = Sum of Analog Inputs (AI1’ + AI2’) > 0 (Negative
values are zeroed)
6 = Sum of Analog Inputs (AI1’ + AI2’)
7 = Electronic Potentiometer (E.P.)
8 = Multispeed (P0124 to P0131)
9 = Serial
10 = Fieldbus
11 = Analog Input AI5’ (P0721 to P0724)
12 = PLC
13 = Graphic HMI and key
13 4-29
P0222(1) Speed reference selection – REMOTE
situation
0 = Key and of service HMI
1 = Analog Input AI1’ (P0234 to P0236)
2 = Analog Input AI2’ (P0237 to P0240 and P0248)
3 = Analog Input AI3’ (P0241 to P0244).
4 = Analog Input AI4’ (P0245 to P0247)
5 = Sum of Analog Inputs (AI1’ + AI2’) > 0 (Negative
values are zeroed)
6 = Sum of Analog Inputs (AI1’ + AI2’)
7 = Electronic Potentiometer (E.P.)
8 = Multispeed (P0124 to P0131)
9 = Serial
10 = Fieldbus
11 = Analog Input AI5’ (P0721 to P0724)
12 = PLC
13 = Graphic HMI and key
04-29
P0223(1) Forward/Reverse Selection – LOCAL
Situation
0 = Always forward
1 = Always reverse
2 = HMI key (Forward default)
3 = HMI key (Reverse default)
4 = Digital Input DI2 (P0264 = 0)
5 = Serial (Forward default)
6 = Serial (Reverse default)
7 = Fieldbus (Forward default)
8 = Fieldbus (Reverse default)
9 = AI4 Polarity
10 = Forward PLC
11 = Reverse PLC
12 = Graphic HMI key (Forward)
13 = Graphic HMI key (Reverse)
12 4-30
P0224(1) Start/Stop Selection LOCAL Situation 0 = HMI
l
and
0
keys
1 = Digital input DIx
2 = Serial
3 = Fieldbus
4 = PLC
5 = Graphic HMI
|
and
O
key
54-30
P0225(1) Selection of JOG Source LOCAL Situa-
tion
0 = Disable
1 = HMI
JOG
key
2 = Digital inputs DI3 to DI10 (P0265 to P0272)
3 = Serial
4 = Fieldbus
5 = PLC
6 = Graphic HMI
JOG
key
64-31
MVW3000 | 0-13

0
QUICK REFERENCE OF PARAMETERS AND FAULTS
Param. Description Adjustable range Factory
setting
Pag.
P0226(1) Selection of Direction of ROTATION RE-
MOTE Situation
0 = Always forward
1 = Always reverse
2 = HMI key (Forward default)
3 = HMI key (Reverse default)
4 = Digital Input DI2 (P0264 = 0)
5 = Serial (Forward default)
6 = Serial (Reverse default)
7 = Fieldbus (Forward default)
8 = Fieldbus (Reverse default)
9 = AI4 Polarity
10 = Forward PLC
11 = Reverse PLC
12 = Graphic HMI key (Forward)
13 = Graphic HMI key (Reverse)
24-31
P0227(1) Start/Stop Selection REMOTE Situation 0 = HMI
l
and
0
keys
1 = Digital input DIx
2 = Serial
3 = Fieldbus
4 = PLC
5 = Graphic HMI
|
and
O
key
04-32
P0228(1) JOG Selection - REMOTE Situation 0 = Disable
1 = HMI
JOG
key
2 = Digital inputs DI3 to DI10 (P0265 to P0272)
3 = Serial
4 = Fieldbus
5 = PLC
6 = Graphic HMI
JOG
key
14-32
P0231 Actuation in the transition between Lo-
cal and Remote for the HMIG
0 = It keeps the motor state
1 = It keeps the HMI state
2 = It turns off the motor
04-35
P0232 Stop Selection 0 = Run/Stop
1 = General disable
04-35
P0233 Dead Zone 0 = Inactive
1 = Active
14-37
P0234 Analog input AI1 gain (unipolar MVC4
board)
0.0 to 9.999 1.0 4-38
P0235(1) AI1 Signal Type 0 = (0 to 10) V/(0 to 20) mA
1 = (4 to 20) mA
2 = (10 to 0) V/(20 to 0) mA
3 = (20 to 4) mA
04-38
P0236 Analog input AI1 offset (unipolar MVC4
board)
-100.0 to 100.0 % 0.0 % 4-39
P0237(1) AI2 signal function 0 = P0221/P0222
1 = Not Used
2 = Maximum torque current
3 = PID process variable
04-39
P0238 Analog input AI2 gain (bipolar MVC4
board)
0.0 to 9.999 1.0 4-39
P0239(1) AI2 Signal Type 0 = (0 to 10) V/(0 to 20) mA
1 = (4 to 20) mA
2 = (10 to 0) V/(20 to 0) mA
3 = (20 to 4) mA
4 = (-10 to +10) V
04-40
P0240 Analog input AI2 offset (bipolar MVC4
board)
-100.0 to 100.0 % 0.0 % 4-40
P0241(1) AI3 signal function 0 = P0221/P0222
1 = Not Used
2 = Maximum torque current
3 = PID process variable
04-40
MVW3000 | 0-14

0
QUICK REFERENCE OF PARAMETERS AND FAULTS
Param. Description Adjustable range Factory
setting
Pag.
P0242 Analog input AI3 gain (bipolar EBB
board)
0.0 to 9.999 1.0 4-41
P0243(1) AI3 Signal Type 0 = (0 to 10) V/(0 to 20) mA
1 = (4 to 20) mA
2 = (10 to 0) V/(20 to 0) mA
3 = (20 to 4) mA
04-41
P0244 Analog input AI3 offset (bipolar EBB
board)
-100.0 to 100.0 % 0.0 % 4-41
P0245 Analog input AI4 gain (bipolar EBA
board)
0.0 to 9.999 1.0 4-41
P0246(1) AI4 Signal Type 0 = (0 to 10) V/(0 to 20) mA
1 = (4 to 20) mA
2 = (10 to 0) V/(20 to 0) mA
3 = (20 to 4) mA
4 = (-10 to +10) V
04-42
P0247 Analog input AI4 offset (bipolar EBA
board)
-100.0 to 100.0 % 0.0 % 4-42
P0248 Analog input AI2 filter (bipolar MVC4
board)
0.0 to 16.0 s 0.0 s 4-42
P0251 AO1 Function 0 = Motor speed reference
1 = Total Reference
2 = Motor Speed
3 = Not used
4 = Not used
5 = Motor Current
6 = Value of process variable (PID)
7 = Output Active Current
8 = Inverter output power
9 = PID Reference
10 = Not used
11 = Trace function channel 1
12 = Trace function channel 2
13 = Trace function channel 3
14 = Trace function channel 4
15 = Trace function channel 5
16 = Trace function channel 6
17 = Trace function channel 7
18 = Trace function channel 8
19 = Inverter Temperature
20 = PLC
21 = Inverter output voltage
24-42
P0252 Analog output AO1 gain (MVC4 or EBB
board)
0.0 to 9.999 1.0 4-43
P0253 AO2 Function 0 = Motor speed reference
1 = Total Reference
2 = Motor Speed
3 = Not used
4 = Not used
5 = Motor Current
6 = Value of process variable (PID)
7 = Output Active Current
8 = Inverter output power
9 = PID Reference
10 = Not used
11 = Trace function channel 1
12 = Trace function channel 2
13 = Trace function channel 3
14 = Trace function channel 4
15 = Trace function channel 5
16 = Trace function channel 6
17 = Trace function channel 7
18 = Trace function channel 8
19 = Inverter Temperature
20 = PLC
21 = Inverter output voltage
54-43
MVW3000 | 0-15

0
QUICK REFERENCE OF PARAMETERS AND FAULTS
Param. Description Adjustable range Factory
setting
Pag.
P0254 Analog output AO2 gain (MVC4 or EBB
board)
0.0 to 9.999 1.0 4-43
P0255 AO3 Function 0 = Motor speed reference
1 = Total Reference
2 = Motor Speed
3 = Not used
4 = Not used
5 = Motor Current
6 = Value of process variable (PID)
7 = Output Active Current
8 = Inverter output power
9 = PID Reference
10 = Not used
11 = Trace function channel 1
12 = Trace function channel 2
13 = Trace function channel 3
14 = Trace function channel 4
15 = Trace function channel 5
16 = Trace function channel 6
17 = Trace function channel 7
18 = Trace function channel 8
19 = Inverter Temperature
20 = PLC
21 = Inverter output voltage
24-43
P0256 Analog output AO3 gain (EBA board) 0.0 to 9.999 1.0 4-44
P0257 AO4 Function 0 = Motor speed reference
1 = Total Reference
2 = Motor Speed
3 = Not used
4 = Not used
5 = Motor Current
6 = Value of process variable (PID)
7 = Output Active Current
8 = Inverter output power
9 = PID Reference
10 = Not used
11 = Trace function channel 1
12 = Trace function channel 2
13 = Trace function channel 3
14 = Trace function channel 4
15 = Trace function channel 5
16 = Trace function channel 6
17 = Trace function channel 7
18 = Trace function channel 8
19 = Inverter Temperature
20 = PLC
21 = Inverter output voltage
54-44
P0258 Analog output AO4 gain (EBA board) 0.0 to 9.999 1.0 4-44
P0259 AO5 Function 0 = Motor speed reference
1 = Total Reference
2 = Motor Speed
3 = Not used
4 = Not used
5 = Motor Current
6 = Value of process variable (PID)
7 = Output Active Current
8 = Inverter output power
9 = PID Reference
10 = Not used
11 = Trace function channel 1
12 = Trace function channel 2
13 = Trace function channel 3
14 = Trace function channel 4
15 = Trace function channel 5
16 = Trace function channel 6
17 = Trace function channel 7
18 = Trace function channel 8
19 = Inverter Temperature
20 = PLC
21 = Inverter output voltage
24-44
MVW3000 | 0-16

0
QUICK REFERENCE OF PARAMETERS AND FAULTS
Param. Description Adjustable range Factory
setting
Pag.
P0260 Analog output AO5 gain (unipolar iso-
lated MVC4 board)
0.0 to 9.999 1.0 4-44
P0261 AO6 Function 0 = Motor speed reference
1 = Total Reference
2 = Motor Speed
3 = Not used
4 = Not used
5 = Motor Current
6 = Value of process variable (PID)
7 = Output Active Current
8 = Inverter output power
9 = PID Reference
10 = Not used
11 = Trace function channel 1
12 = Trace function channel 2
13 = Trace function channel 3
14 = Trace function channel 4
15 = Trace function channel 5
16 = Trace function channel 6
17 = Trace function channel 7
18 = Trace function channel 8
19 = Inverter Temperature
20 = PLC
21 = Inverter output voltage
54-44
P0262 Analog output AO6 gain (unipolar iso-
lated MVC4 board)
0.0 to 9.999 1.0 4-45
P0263(1) DI1 Function 0 = Not Used
1 = Start/Stop
2 = General Enable
3 = Fast Stop
14-47
P0264(1) DI2 Function 0 = Forward/Reverse
1 = Local/Remote
04-47
P0265(1) DI3 Function 0 = Not used
1 = Local/Remote
2 = General Enable
3 = JOG
4 = No External Fault
5 = IncreaseEP
6 = Ramp 2
7 = Not used
8 = Forward Run
9 = Sinusoidal Filter Circuit Breaker
10 = JOG+
11 = JOG-
12 = Reset
13 = Fieldbus
14 = 3 Wire Start
15 = Manual/Automatic
16 = No External Alarm
17 = Not used
18 = Not used
19 = Parameterization Disabling
20 = Not used
21 = RL2 Timer
22 = RL3 Timer
23 = No Alarm in the Redundant Ventilation Set A
24 = No Alarm in the Redundant Ventilation Set B
25 = Initiates Synchronous Transfer
26 = Ventilation OK
04-47
MVW3000 | 0-17

0
QUICK REFERENCE OF PARAMETERS AND FAULTS
Param. Description Adjustable range Factory
setting
Pag.
P0266(1) DI4 Function 0 = Not used
1 = Local/Remote
2 = General Enable
3 = JOG
4 = No External Fault
5 = Decrease EP
6 = Ramp 2
7 = Multispeed
8 = Forward Run
9 = Sinusoidal Filter Circuit Breaker
10 = JOG+
11 = JOG-
12 = Reset
13 = Fieldbus
14 = 3 Wire Stop
15 = Manual/Automatic
16 = No External Alarm
17 = Not used
18 = Not used
19 = Parameterization Disabling
20 = Load User 1/2
21 = RL2 Timer
22 = RL3 Timer
23 = No Alarm in the Redundant Ventilation Set A
24 = No Alarm in the Redundant Ventilation Set B
25 = Initiates Synchronous Transfer
26 = Ventilation OK
04-47
P0267(1) DI5 Function 0 = Not used
1 = LOC/REM
2 = General Enable
3 = JOG
4 = No External Fault
5 = IncreaseEP
6 = Ramp 2
7 = Multispeed
8 = Stop
9 = Sinusoidal Filter Circuit Breaker
10 = JOG+
11 = JOG-
12 = Reset
13 = Fieldbus
14 = 3 Wire Start
15 = Manual/Automatic
16 = No External Alarm
17 = Not used
18 = Not used
19 = Parameterization Disabling
20 = Not used
21 = RL2 Timer
22 = RL3 Timer
23 = No Alarm in the Redundant Ventilation Set A
24 = No Alarm in the Redundant Ventilation Set B
25 = Initiates Synchronous Transfer
26 = Ventilation OK
34-47
MVW3000 | 0-18

0
QUICK REFERENCE OF PARAMETERS AND FAULTS
Param. Description Adjustable range Factory
setting
Pag.
P0268(1) DI6 Function 0 = Not used
1 = Local/Remote
2 = General Enable
3 = JOG
4 = No External Fault
5 = Decrease EP
6 = Ramp 2
7 = Multispeed
8 = Stop
9 = Sinusoidal Filter Circuit Breaker
10 = JOG+
11 = JOG-
12 = Reset
13 = Fieldbus
14 = 3 Wire Stop
15 = Manual/Automatic
16 = No External Alarm
17 = Not used
18 = Not used
19 = Parameterization Disabling
20 = Not used
21 = RL2 Timer
22 = RL3 Timer
23 = No Alarm in the Redundant Ventilation Set A
24 = No Alarm in the Redundant Ventilation Set B
25 = Initiates Synchronous Transfer
26 = Ventilation OK
64-47
P0269(1) DI7 Function 0 = Not used
1 = Local/Remote
2 = General Enable
3 = JOG
4 = No External Fault
5 = Not used
6 = Ramp 2
7 = Not used
8 = Stop
9 = Not used
10 = JOG+
11 = JOG-
12 = Reset
13 = Fieldbus
14 = 3 Wire Start
15 = Manual/Automatic
16 = Not used
17 = Not used
18 = Not used
19 = Parameterization Disabling
20 = Not used
21 = RL2 Timer
22 = RL3 Timer
23 = Initiates Synchronous Transfer
24 = Ventilation OK
04-47
MVW3000 | 0-19

0
QUICK REFERENCE OF PARAMETERS AND FAULTS
Param. Description Adjustable range Factory
setting
Pag.
P0270(1) DI8 Function 0 = Not used
1 = Local/Remote
2 = General Enable
3 = JOG
4 = No External Fault
5 = Not used
6 = Ramp 2
7 = Not used
8 = Stop
9 = Not used
10 = JOG +
11 = JOG -
12 = Reset
13 = Fieldbus
14 = 3 Wire Stop
15 = Manual/Automatic
16 = Motor Thermistor
17 = Not used
18 = Not used
19 = Parameterization Disabling
20 = Not used
21 = RL2 Timer
22 = RL3 Timer
23 = Initiates Synchronous Transfer
24 = Ventilation OK
04-47
P0271(1) DI9 Function 0 = Not used
1 = Local/Remote
2 = General Enable
3 = JOG
4 = No External Fault
5 = Not used
6 = Ramp 2
7 = Not used
8 = Stop
9 = Not used
10 = JOG +
11 = JOG -
12 = Reset
13 = Fieldbus
14 = 3 Wire Stop
15 = Manual/Automatic
16 = No External Alarm
17 = Not used
18 = Not used
19 = No Motor Fault
20 = No Motor Alarm
21 = No Alarm in the Redundant Ventilation Set A
22 = No Alarm in the Redundant Ventilation Set B
23 = Initiates Synchronous Transfer
24 = Ventilation OK
04-47
MVW3000 | 0-20
