SUNTEC TM-5H User manual

Operating Manual
Thank you for purchasing the SUNTEC products.
To ensure best results and use for a long time, it is
important that you read, understand and follow
these instructions in this manual carefully before
using.
This manual should be retained for future reference.
The following words and symbols, found in this
manual, alert you to hazards to the operator, service
personnel or the equipment. The words are defined
as follows; WARNING: This symbol refers to a
potential hazard which could result in serious injury
or death. CAUTION: This symbol refers to a potential
hazard or unsafe practice which may result in minor
or moderate injury or product or property damage.
Safety Precautions
However, indicated CAUTION may result in serious
condition by situation, it is important that you follow
the instruction in this manual carefully.
Conveyor Toaster
TM-5H

！WARNINGWARNING
The products which
electric power is over
1.0kw must plag a
properly(grounded)
indlvidual receptacle.
It could result in fire
by ignition.
Do not cover the
product with a cloth
or plastic bag while
you are using it.
It could result in fire.
Ensure to unplug the
product while you
don't use it.
It could result in fire
or electric shock.
Do not touch the
product with wet
hands.
It could result in
electric shock.
Never clean the
product by sprinkling
water.
It could result in
electric shock or
product damage.
Do not use the
product outside in
the rain or wet area.
Use the product in a
light place.
It could result in
accident or burn if
you use it in a dark
room.
Do not use the
product near
flammable gas or
liquid.
It could result in
explosion or fire.
It could result in
electric shock.

！WARNINGWARNING
Never touch the plate
or around while the
product is working
because there are
very hot.
It could result in burn..
Ensure to unplug and
get cold the product
when you move it.
It could result in
electric shock or
burn.
Must be plugged
directly into a
properly grounded.
(Never connect with
gas pipe)
It could result in
electric shock by
trouble or electric
leakage.
Do not overhaul,
repair or reconstruct
the product except
service personnel.
It could result in
ignition or injury by
unusual
performance.
Always clean the edge
of a plug when it is
dirty or dusty. It could result in fire.
！CAUTIONCAUTION
Nobody allows
touching the product
or code and keep
anyone away from
workshop except
workers.
It could result in injury
or burn.
Please note the
thickness and the
length of bread.
There is fear of Hi a
fire in the upper part.

！CAUTIONCAUTION
Always keep cleaning
the workshop.
It could result in
obstruction of safety
or efficient work.
Check the supply
cord regularly. If it is
damaged, it must be
replaced with a new
cord assembly
available from the
suppliers agent.
It could result in
electric shock or
ignition by short
circuit.
Place on a horizontal
and strong surface at
the desired location.
Set up with not
slipping down.
It could result in injury
or burn by the product
falls down.
Do not place near
water or oil.
It could result in
electrical shock, fire,
trouble or
transformation.
Stop to use the
product when it
appears smoke, smell
or other unusual
things.
Be sure to attach this
manual, if you hand
over the product.
It's necessary that new
user works safety and
uses correctly.
Contact with the sales
agent after turning off
the switch and pulling
out the plug for
ｐreventing trouble or
accident.
Before First UseBefore First Use
・Please put it on the horizontal, strong place so that installation features
may avoid imperfect ventilation.
・A minimum clearance of 10 cm is required between other equipments.
・Must be plugged directly into a properly grounded. Improper grounding
could result in electrical shock or accident. Never connect with gas pipe.
・Don't place near water or oil. It could result in electrical shock, fire,
accident or transformation.

Parts DescriptionParts Description
Color Contrl
Entrance
Front Discharge
Description：Electric Conveyor Toaster
Model：TM-5H
Power：AC100V
Electricity
Measurements：290(W)×420(D)×420(H)
Entrance：175(W)×89(H)
Shipping Weight:16kg
Capacity:150slices per hour.
Switch/
Thermostat
Pilot Lanp
About the Switch/Thermostat
☆The power at the saving mode
becomes 25% usually.
One side
Both sides Power Save Mode
STBY
BUNS
BREAD
OFF
Consumption：1480W

Set-upSet-up
Stop Pins
Toast Crumb
Tray
Figure 1.
Figure 2.
Figure 3.
・Install the legs.
If unit is not level, use 9/16"(14mm)
open-end wrench to adjust the foot
of each leg until unit is level.
・Toast Feed Ramp
The toast feed ramp is installed
at the factory and can be used in
tow positions. See Figure 1.
1.When in the upright position,
the toaster is set for automatic feed.
Bread products enter the toaster by
placing them on the feed ramp and
releasing.
2.For manual feeding of product,
tip the feed ramp until it
rests on top of the unit.
In this position bread
products can be manually
loaded by placing them directly
on the conveyor belt.
・Toast Crumb Tray
Install toast crumb tray
directly conveyor belt and
below the stop pins. Insert
until the front of the crumb
tray meets the stop pins.
See Figure 2.
・Front/Rear Discharge
The toaster can be configured
to discharge in the front or rear.
User can pull up the rear discharge
door for front discharge
（See Figure 3) and push down the
rear discharge door for rear discharge.

OperationOperation
1.Plug toaster into a properly grounded electrical
outlet of the correct voltage, size and plug
configuration.
2.Place the On/Off switch in the On position.
3.Turn the Color Control to the lightest position while
the unit heats up.
Note:Allow approximately 15 to 20 minutes for a
warm-up period.
4.After warm-up period, set the Color Control to the
medium position and toast two slices of bread
product then re－adjust the Color Control to the
desired setting.
Note:To toast moist products such as English Muffins,
rye bread or whole wheat, slow the convveyor by
turning the Color Control knob to a darker setting
(clockwise)
1.Plug toaster into a properly grounded electrical
outlet of the correct voltage, size and plug
Configuration.
2.Rotate the Rotary switch in the high-heat position.
3.Turn the Color Control to the lightest position while
` the unit heats up.
Note:Allow approximately 15 to 20 minutes for a
warm-up period.
4.After warm-up period, set the Color Control to the
medium position and toast two slices of bread product
then re-adjust the Color Control to the desired setting.
The toaster can go into a Power Save mode by turning
the rotary selector into power save mode. The toaster is
operating at 25% power.
Note：To place toaster back into full opration turn the
selector back into TOAST. Unit is back up to full
power within 5 minutes.
For model equipped with rocker switchFor model equipped with rocker switch
For model equipped with rotary selectorFor model equipped with rotary selector
Power Save ModePower Save Mode

SafetySafety
・This product should not be cleaned with water.
It's very dangerous.
・Wipe off the product with a dry cloth and always
keep clean.
・If the plates don't work sufficiently, contact with
your agency. To change the plates is at your cost.
・A warranty should be retained carefully, it's writtn
a serial number of the product.
・Should attach a warranty with the product when
you order the repair of the product under warranty.
・This manual should be retained carefully for future
reference.
・Unit is not weatherproof. For safe and proper
operation locate the unit indoors where the ambient
air temperature is a minimum of 21℃ and a maximum
of 29℃.
・The toasting of coated or buttered products such as
garlic bread, cheese sandwiches and sweet rolls is NOT
recommended. Residue will reduce toaster performance
and could possibly ignite inside the toaster.
・Some exterior surfaces on the unit will get hot.Use
caution when touching these areas to avoid injury.
・To avoid damage to the unit or injury to personnel
always operate toaster with crumb tray installed.
CleaningCleaning
To avoid any injury, turn the power switch off,
unplug the unit from the power source and allow
to cool before performing any cleaning.
To preserve the bright finish of the unit, it is
recommended that the exterior surfaces be
wiped daily with a damp cloth. Stubborn stains
may be removed with a good stainless steel
cleaner or a non-abrasive cleaner. Hard to reach
areas should be cleaned with a small brush and
mild soap. Use only non-abrasive cleaners.
Remove from unit and wash with soap and water,
then rinse.To avoid any injury, do not remove the
crumb tray for cleaning until is cool.
Press in the two wire spokes and remove guide
from unit. Wipe clean with a soft, damp cloth or
soak the guide in a mild solution of 1cup ammonia
and 1 gallon of water （227milliliters and 3.785 liters）.
Re-install guide by aligning wire spokes with holes
in toaster.
ExteriorExterior
Toast Crumb Tray & Toast Collector PanToast Crumb Tray & Toast Collector Pan
Toast Feed RampToast Feed Ramp

2-8-12Mukojima, Sumida-ku, Tokyo
131-0033 Japan
Telephon No.81-3-6746-9797
Facsimile No.81-3-6746-9669
After Service After Service
This product is attached the warranty.
（Excluded Teflon plates）
■Limited Warranty
・Should read and retain the warranty
carefully.
This warranty is valid only in Japan.
This warranty is invalid to use the
product in other countries.
・The warranty runs for one year from
the date of purchasing.
■Request for Repair
・When the product doesn't work well,
contact with your agency and request
to check the product.
・If it's under warranty, should attach
the warranty with the product.
・When you order to repair, should
attach a memo which is written a
breakdown condition of the product.
SUNTEC CO., LTD
