SUPER NOVA HA051 User manual

INSTALLATION INSTRUCTION
MODEL：
HA051
HA051-T1
HA051-T6 Max VESA: 200 X 200 mm/8X8"
Please read this instruction carefully before installation.
Fits for most 14-32 inches Plasma, LCD and LED TVs.
Weight capacity: 25 kg (55 lbs)
Thank you for purchase!
We strive to provide products and services of exceptional quality.
We sincerely invite you to write an unbiased review. For parts missed or installation problems,
please contact us at telephone: (USA) Mon - Fri 9am - 5pm (Pacific time)[phone]
or email us by , [e-mail]
so that we may solve the issue for you.
TV MOUNT

8"
Drywall with Wood Studs
Solid Concrete Wall
WARNING!
Safety Warning: Thank you for choosing Supernova TV mount. For the safe application of the model
HA051/HA051-T1/HA051-T6, and preventing yourself or others from danger or property loss,
please read through this manual before use. If you do not understand these instructions or have any
doubt over the safety of the installation, please contact the qualified contractor or Supernova
customer service. Please check carefully before assembly to ensure no parts missed or damaged.
Our customer service representative will assist you timely in installation to solve the issue of parts
shortage or damage. Replacement parts will send to your home by the carrier. Please do not use
defective parts. Incorrect installation may result in product damage or bodily injury. Do not apply
this product to any purpose not indicated by Supernova. We shall bear no responsibility for
any damage or injury resulted from incorrect installation, incorrect assembly or misuse.
MAX
200mm
MAX
200mm
DOES THE MOUNT FIT MY TV?
1: Measure your TV VESA size.
The TV VESA equal to/greater
than 75x75mm and equal to/less
than 200x200mm, it will fit your TV.
2: TV weigh (including accessories) .
The TV weigh not more than 25kg (55 lbs),
it will fit your TV.
(55 lbs)
25 kg
3: The wallstructure.
CAUTION: DO NOT install the mount into drywall alone.

WHAT’S IN THE BOX?
Wall plate x 1pc
Part list:
Wall mounting hardware:
Bracket x 2pcs
Log bolt x 4pcs
TV mounting hardware:
M4 x 10mm bolt
x 4pcs
M5 x 10mm bolt
x 4pcs
M6 x 10mm bolt
x 4pcs
M5 x 35mm bolt
x 2pcs
Concrete wall anchor x 4pcs
Washer
x 4pcs
Bubble level
x 1pc

Wall plate installation in wood stud or concrete wall.
To avoid potential body injury or property damage:
1. Wall mount must be installed into wood stud's center, not drywall alone.
2. The wall must be capable of supporting enough the weight of TV plus mount.
3. All lag bolts MUST BE firmly tightened to prevent unwanted movement of the wall plate.
Ensure the wall plate is securely fastened to the wall before continuing on to the next step.
Failure to follow this instruction will possibly lead to TV falling off from wall, and would possibly
cause bodily injuries or property loss.
WALL PLATE INSTALLATION
TheBack of TV
The Front of TV
3 different size choose 1
Choose the right screw size for the screw hole
Washer
Bolts
Bracket
Step:1
8"
Concrete wall
Drywall with wood stud
Step:2
Select TV hardware andAttach brackets to the back of the TV:
Carefully lay your TV on a non-abrasive surface, or lay it with a padding underneath
it so as not to damage the screen.
Bubble in the middle Bubble in the middle
Log bolt Log bolt
Concrete wall anchor

MAX:200mm
MAX:200mm
110mm
270mm
30mm
230mm
25 mm
Front view
Side view
Hang the TV on the wall plate:
Step:3
Hang the top hooks of the brackets over the top bar of the wall mount. Make sure the hooks
securely lock in the bar.
Use the longest M5 bolt, tighteningup on the lower bar.
Product dimensions:
M5 x 35mm bolt

Take down the TV from the mount
Step:4
Unlock the two M5 bolt, on the lower bar.
Pull the bottom ofTV slightly from the wall,
Boost up the TV, release the brackets from the bar, take down the TV.
Customer service:
If you have any questions about the installation/ missing parts/ replacement etc...
please contact us at telephone: (USA)Mon - Fri 9am - 5pm (Pacific time)[phone]
or email us by , [e-mail]
so that we may solve the issue for you.
