Nexo VNI-UBRK8 User manual

- Read this document before using.
- Keep this document.
- Observe all warnings and cautions.
PAGE 1 OF 2
VNI-UBRK8
DP3439/Rev01 - DI
Bracket « U » for PS8
Contents:
X1
X3 (M5x25)
X3 (M5)
Weight: 2.4 kg / 5.3 lb

- Read this document before using.
- Keep this document.
- Observe all warnings and cautions.
PAGE 2 OF 2
Dimensions:
Use:
IMPORTANT
Ensure that the surface –wall or ceiling –is strong enough to hold 4 times PS cabinet weight and
that the screws 12mm diameter and corresponding plugs required to fix the “U” bracket on the
wall or under the ceiling are properly dimensioned.
•12mm diameter screws (not provided) are required to secure the “U” Bracket on the wall or ceiling.
•Remove the 2 screws on upper and 1 on lower side of PS8.
•Position the PS8 inside the “U” Bracket to desired angle; “U” Bracket oblong holes must be properly aligned with
panels holes; Use 2 holes or 1 and the oblong hole to adjust the angle.
•Use the screws and washer provided to connect “U” bracket to cabinet.
WARNING: Screws must be secured using Loctite 243TM
•NEXO cannot accept responsibility for accidents caused by any factor other than defects in this product itself.
•Please check the web site nexo-sa.com for the latest update.
