VENTILATOR USER GUIDE
MODEL 716WT

2
VentilatorUserGuide-716WT.docx
REV. 06/09/17
This manual covers the description, cautions, operation and maintenance of the Super Vac Hydraulic Positive Pressure Ventilator
Model 716WT
Please take the time to read this manual before operating the ventilator.
Save this guide for future reference.
CONTENTS
1. BREAKAGE OR DAMAGE DURING SHIPMENT .................................................................................................................................................. 3
2. GENERAL DESCRIPTION AND SPECIFICATIONS............................................................................................................................................... 4
3. PRODUCT SAFETY PRECAUTIONS.................................................................................................................................................................. 5
4. BEFORE OPERATING VENTILATOR................................................................................................................................................................ 5
5. OPERATION................................................................................................................................................................................................ 6
6. INLET AND DISCHARGE POSITION .............................................................................................................................................................. 8
7. PARTS LIST................................................................................................................................................................................................ 9
8. EXPLODED VIEW DRAWING ........................................................................................................................................................................ 10
9. WARRANTY............................................................................................................................................................................................... 12
10. CONTACT INFORMATION .......................................................................................................................................................................... 13

3
VentilatorUserGuide-716WT.docx
1. Breakage or Damage During Shipment
The transportation company is fully responsible for all shipping damage and will resolve problems promptly if you handle it
correctly. Please read these instructions carefully.
Examine the contents of all shipping cases. If you find any damage, call your transportation agent at once and have them make a
description on the freight or express bill describing the damage and the number of pieces. Then write us and we will send you the
original bill of lading. Get a claim blank from the express or truck company. Fill the claim form out. Attach the claim blank to the
original bill of lading together with a copy of our invoice. Attach a memo on which you show the value of the damaged goods. Mail
or hand these papers to your local transportation agent. They will process your claim with reasonable promptness.
Please note, we cannot and will not enter claims for damages. If we filed claim here, it would be sent to your local freight agent for
verification and investigation. This time can be saved by your filing the claim directly. Every consignee is on the ground floor and
in contact with the local agent who inspects the damaged goods, and thus, each claim can be given individual attention.
Since our goods are packed to comply with the regulations of all railroad, truck, and express companies, we cannot allow deduction
from any invoice because of any damage, however, be sure to file your claim promptly. Our goods are sold F.O.B. factory. We take
receipt from the transportation company certifying that the goods were delivered to them in good order, and our responsibility
ceases.
It is seldom that any breakage or damage occurs in any of our shipments, and in no case will the customer be out any expense if
they follow the above instructions.
Be sure to keep all damaged goods subject to examination of the truck or express company inspector, who may call on you some
time later. These damaged goods, of course, will belong to them, and they will inform you what to do with them. If you dispose of
these damaged goods, your claim may not be paid.

4
VentilatorUserGuide-716WT.docx
REV. 06/09/17
2. General Description and Specifications
Super Vac ventilators are specifically designed to provide a convenient and portable source of air. Super Vac positive pressure
ventilators are tested to AMCA PPV Standard 240-95, for use in extreme conditions.
Specifications1
Model#
Engine
HP
Height x Width x Depth
Weight (lbs.)
716WT
POK
5.5
15.25” X 20” X 19.75”
66
1 Specifications are subject to change without notification. Refer to model decal affixed to ventilator to determine
actual specifications.
This ventilator is designed for high powered air movement. Super Vac’s propeller produces a greater intake of air and eliminates
turbulence at the tips. Each blade is statically balanced for high efficiency and long life.
This document is designed to function as a quick start guide and not an in-depth comprehensive instructional manual. Please read
all accompanying documents shipped with your ventilator. Due to the many features of powered equipment thorough familiarity
with the operating controls is essential to assure safe and trouble free operation.

5
VentilatorUserGuide-716WT.docx
3. Product Safety Precautions
Ø Do not use the ventilator for purposes other than its’ intended use.
Ø Wear eye and ear protection when operating the ventilator.
Ø Never operate ventilator while fatigued.
Ø Do not disassemble or modify the ventilator in any way. Doing so may lead to mechanical failure or personal injury.
Ø Do not wear loose clothing that could become entangled in the operating ventilator.
Ø Never permit anyone to operate ventilator without proper instruction.
Ø Do not operate ventilator without proper inlet or outlet guards in place. If guards are missing or damaged, contact factory
for replacements.
Ø Do not place fingers or other foreign objects through inlet or outlet guards. Should a foreign object enter the ventilator,
immediately stop engine. Be certain all mechanical motion has stopped.
Ø Do not place or operate ventilator on unsteady tables, slanted surfaces or other unstable surfaces.
Ø Do not use chock blocks to increase the angle of the ventilator, severe injury could occur.
4. Before Operating Ventilator
§ A complete inspection of the ventilator should be made prior to operation.
§ Check all threaded fasteners for proper tightness.
§ Inspect inlet and outlet guards for damage or missing pieces. Replace damaged or missing guards before operating ventilator.

6
VentilatorUserGuide-716WT.docx
REV. 06/09/17
5. Operation
Check ventilator inlet and outlet guards for obstructions. Check and remove
from immediate surrounding area any objects that could be drawn into the
ventilator intake.
Place ventilator in desired location before starting.
The two graphs allow you to establish with precision the best utilization of
the apparatus.
Graph 1 depicts rotational speed and water consumption depending on
input feed pressure.
Graph 2 depicts the usable horsepower depending on the driving torque.
Example: If the inlet pressure of the water supplied to the motor is 174 psi,
and the resisting torque of the driven machine is 7.4 lb/ft, the rotational
speed is 4560 rpm, water consumption is 117 gpm (graph 1) and the usable
power is 5.5 HP (graph 2)

7
VentilatorUserGuide-716WT.docx
Inlet Pressure
Water Flow
Air Flow
BAR
PSI
GPM
LPM
CFM
CMH
3.3
50
55
208
5168
8781
6.7
100
78
295
10112
17179
10.0
150
98
371
16178
27487
13.3
200
110
416
19100
32450
16.7
250
130
492
22470
38177
The maximum feed pressure is 300 psi (20 bar).

8
VentilatorUserGuide-716WT.docx
REV. 06/09/17
6. Inlet and Discharge Position
As delivered, the standard position of the inlet and discharge connections on your 716WT allow for easier connection of water supply lines. This
positioning does not allow full range of tilt positions.
If your application requires the use of the two back tilt positions the inlet and discharge blocks on the water turbine motor may be rotated 90 degrees.
Using a 3mm hex key (not supplied) remove the 4 screws on the block , turning the block to the desired location , reinstalling the 4 screws. Use care to
assure the o-ring is in place for proper seal. Torque screws to 3 lbs./in ( .33 N-m), check for leaks, re-torque as required.
STANDARD POSITION
ROTATED POSITION

9
VentilatorUserGuide-716WT.docx
7. Parts List
1
012-10285
1
GUARD, 716, FRONT, FINISHED
2
032-15540
6
SCREW, 10-24 X 1/2, PHIL PH, PATCH, BLAC
3
032-10754
2
WASHER, 1/4, LOCK, ZINC
4
032-10745
2
BOLT, 1/4-20 X 1 1/4, HEX HEAD, ZINC
5
008-10193
1
KEYSTOCK 3/16X13/8"SQ.(BLADE-BUSH)
6
008-10187
1
BUSHING, BLADE, HQ 3/4, MAUREY
7
003-10055
1
BLADE, 16", 7 BLADE, GAS, FINISHED
8
032-10787
4
WASHER, 5/16, LOCK, ZINC
9
032-10779
4
BOLT, 5/16-24 X 1 1/4, HEX HEAD, ZINC
10
018-14030
1
SHROUD, 716, W GUARD PAINTED
11
032-10750
3
NUT, HEX, 1/4-20, NYLOK, ZINC
12
032-10752
3
WASHER, 1/4, FLAT, ZINC
13
018-15035
1
MOTOR MOUNT, 716, GAS, PAINTED
14
032-10725
3
SCREW, 1/4-20 X 5/8, PHILLIPS RH, ZINC
15
032-14565
2
BOLT, 3/8-16 X 4 1/2, SKTHD BUTTON, ZINC
16
005-10136
4
BUSHING, REDUCER, 3\4 X 1/2
17
008-13374
2
WHEEL, URETHANE, PPV FANS, NEW DESIGN
18
032-11129
2
WASHER, 3/8, SAE FLAT, ZINC
19
032-11133
2
NUT, HEX, 3/8-16, NYLOK, ZINC
20
008-10189
4
PLUG, FINISHING, 1", SQ RIBBED, BLACK
21
018-10431
1
FRAME, 716, PAINTED
22
032-14564
2
BOLT, 3/8-16 X 2 1/2, SKTHD BUTTON, ZINC
23
008-10212
2
WASHER, FLAT, NYLON, WHEEL SPACER
24
032-11129
2
WASHER, 3/8, SAE FLAT, ZINC
25
032-11133
2
NUT, HEX, 3/8-16, NYLOK, ZINC
26
008-10192
2
SPRING, A-180-S VALCO 40 PCS. PER LB.
27
032-14564
2
BOLT, 3/8-16 X 2 1/2, SKTHD BUTTON, ZINC
28
032-11129
2
WASHER, 3/8, SAE FLAT, ZINC
29
032-14559
2
NUT, HEX CAP, 3/8-16, NICKEL PLATED
30
019-17014
1
HANDLE, 716, PAINTED
31
008-14586
2
CAP, NEOPRENE, BLACK, HANDLE TAB
32
032-11133
2
NUT, HEX, 3/8-16, NYLOK, ZINC
33
024-13284
1
SPRING, COMPRESSION, TILT LEVER
34
008-10219
1
KNOB, 716, TILT LEVER
35
019-15084
1
TILT LEVER, 716, PAINTED
36
024-13284
1
SPRING, COMPRESSION, TILT LEVER
37
023-10512
1
POK WATER TURBINE MOTOR, 5.5 HP
38
032-10777
1
BOLT, 5/16-24 X 3/4, HEX HEAD, ZINC
39
032-10791
1
WASHER, 5/16, FENDER, ZINC
40
032-10787
1
WASHER, 5/16, LOCK, ZINC
41
025-13429
1
DECAL YELLOW SAFETY
42
025-13430
1
DECAL SERIAL NUMBER, GREY
43
025-13426
1
DECAL, SUPER VAC, VERT LTRS, BLACK REFLT
44
025-15162
1
DECAL, HONDA ENGINE DIAGRAM, BLK ON WHT
45
032-10790
4
NUT, HEX, 5/16-18, NYLOK, ZINC
46
032-10786
4
WASHER, 5/16, FLAT, ZINC
47
032-10770
4
BOLT, 5/16-18 X 1 1/2, HEX HEAD, ZINC

10
8. Exploded View Drawing

POSITIVE PRESSURE VENTILATOR
11
VentilatorUserGuide-716WT.docx
REV 06/09/17

12
9. Warranty
Limited Warranty
Five Years
Super Vacuum Manufacturing Company warrants that the equipment is free from defects in materials and workmanship when used and operated for a
period of five years. The responsibility of Super Vacuum Manufacturing Company under this limited warranty is limited to the repair and replacement of
any parts which are found defective and which are returned to Super Vacuum Manufacturing Company at 1303 East 11th Street, Loveland, Colorado
80537 with transportation charges prepaid (C.O.D. shipments will not be accepted).
Prior to returning defective parts to SUPER VACUUM MANUFACTURING COMPANY, the original purchaser shall make a claim in writing to SUPER
VACUUM MANUFACTURING COMPANY at the above address indicating the model number and type of defect. No parts or equipment will be received
by SUPER VACUUM MANUFACTURING COMPANY for repair or replacement under this warranty without specific written authority from it in
advance.
Any parts damaged by improper installation, overloading, abuse or accident of any type or cause are not covered by this warranty.
All equipment manufactured by us is pre-run and tested before leaving our plant, and is shipped in good working order and condition. We therefore extend
to the original purchasers the following Limited Warranty for the period of five years from the original date of purchase:
1. This warranty does not apply to defects caused by accident, misuse, neglect, or wear and tear, nor can we be held responsible for incidental
and consequential expense and loss, nor does this warranty apply to equipment where alterations have been executed without our knowledge
or consent. These conditions are readily discernable when the equipment is returned to us for inspection.
2. On all component parts not manufactured by SUPER VACUUM MANUFACTURING COMPANY, their warranty is to the extent that the
manufacturer of such component warrants them to SUPER VACUUM MANUFACTURING COMPANY, if at all. Look in your local
business phone directory for the nearest repair station for the brand of parts you have or write to us for the address.
3. If equipment received is found to have been damaged in transit, a claim should be made against the carrier within three days, as we assume
no responsibility for such damage.
4. Any service other than our Authorized Service voids this warranty.
5. This warranty is in lieu of and is intended to exclude all other warranties, express or implied, oral or written, including any warranties of
MERCHANTIBILITY or FITNESS for a particular purpose.

POSITIVE PRESSURE VENTILATOR
13
VentilatorUserGuide-716WT.docx
REV 06/09/17
10. Contact Information
For parts or service information, contact:
Super Vacuum Manufacturing Company, Inc.
3842 Redman Drive
Fort Collins, CO 80524
Phone: [phone]
970-297-7100
FAX: [phone]
Internet: www.supervac.com
