Superabrasive LAVINA ELITE L3213EB User manual

LAVINA ELITE L3213EB
User Manual
Tech Support Line: 800-987-8403 | www.superabrasive.com | [email protected]

SuperabrasiveOwner’s Manual Original Language –Lavina ®3213EB /3213EBHV 1/2022
2

SuperabrasiveOwner’s Manual Original Language –Lavina ®3213EB /3213EBHV 1/2022
3
WARRANTY AND RETURNS
WARRANTY POLICY FOR LAVINA®ЕMACHINES
A warranty card must be submitted to Superabrasive within 30 days of purchase in order for the foregoing warranty
to apply.
You can either mail a hard copy of the warranty card or submit it electronically - see page 2.
Superabrasive warrants, from the time of delivery and receipt by the original customer, new and unused products
sold by Superabrasive or Superabrasive-appointed distributors or dealers. Goods shall be free from defects in
materials and workmanship. Superabrasive or a Superabrasive-appointed repair facility shall either replace or repair
any defects in the Goods resulting from faulty design, materials, or workmanship. Products repaired or replaced
during the warranty period shall be covered by the foregoing warranty for the remainder of the original warranty
period, or ninety (90) days from date of the repair or shipment of the replacement, whichever is longer. Spare parts
for repair will be either new or equivalent to new.
Warranty period shall be 2 years from the time of delivery and receipt by the original customer, or 600 operating
hours on the machine - whichever occurs first. Superabrasive will cover the shipping charges for the transportation of
the machine to Superabrasive (or an approved repair facility) and back to the customer (within the 48 contiguous
States) in the event that the damage occurs and is reported within 200 operating hours. Shipping charges, if covered
by Superabrasive, must be agreed upon in advance and approved by Superabrasive. Thereafter, the customer will
have to cover the shipping charges to Superabrasive and back. Superabrasive will not warranty Goods after a period
of 2 years from the time of delivery and receipt by the original customer, or 600 operating hours on the machine -
whichever occurs first.
Superabrasive shall not be liable for any defects that are caused by circumstances that occur after the Goods have
been delivered and whilst the Goods are in the possession of the purchaser. Furthermore, the warranty does not
include normal wear and tear or deterioration. Wear parts are not warranted. Superabrasive is not liable for defects
arising out of use of non-OEM parts.
The Warranty is void if the purchaser has not followed the maintenance plan stipulated by the machine’s manual and
warranty card. The warranty is void if the purchaser repairs said Goods himself, or if repairs are conducted by a
repair facility that is not approved by Superabrasive. Superabrasive’s liability does not cover defects which are
caused by faulty maintenance, incorrect operation, faulty repair by the purchaser, or by alterations conducted without
Superabrasive’s prior written consent. The same applies to any alterations of the Goods or services performed by
another party other than Superabrasive, a Superabrasive-appointed distributor, or a Superabrasive-approved repair
facility. The warranty is not applicable on a defect that arises due to tools or parts that are not original to
Superabrasive. Replaced defective parts shall be placed at Superabrasive’s disposal and shall become property of
Superabrasive. If such defective parts are replaced
within the warranty period, the shipping charges will be covered by Superabrasive. In warranty complaint cases,
when no defects are found for which Superabrasive is liable, Superabrasive shall be entitled to compensation for the
labor, material cost, and shipping charges, incurred by Superabrasive as as a result of the complaint.
The warranty herein is non-transferable, and only applies to the original owner or purchaser of the machine.
RETURN POLICY FOR LAVINA®ЕMACHINES
The Lavina®Еmachines may be returned, subject to the following terms:
In no case, a machine is to be returned to Superabrasive Inc. for credit or repair without prior authorization. Please
contact Superabrasive Inc. or your local distributor for an authorization and issuance of a return authorization
number. This number along with the serial number of the machine must be included on all packages and
correspondence. Machines returned without prior authorization will remain property of the sender and
Superabrasive Inc. will not be responsible for them. No machines will be credited after 90 days from the date of
invoice.
All returns must be shipped freight prepaid. Returned machines may be exchanged for other equipment or parts of
equal dollar value. If machines are not exchanged, they are subject to a fifteen percent (15%) restocking fee.

SuperabrasiveOwner’s Manual Original Language –Lavina ®3213EB /3213EBHV 1/2022
4
WARRANTY AND RETURNS.......................................................................3
1. GENERAL INFORMATION......................................................................5
MANUFACTURER......................................................................................5
GENERAL DESCRIPTION............................................................................5
MACHINE CHARACTERISTICS....................................................................5
LAVINA®3213E/3213EHV MAIN DESIGN ..................................................5
ENVIRONMENTAL CONDITIONS ...............................................................5
ELECTRICAL CONNECTION........................................................................6
VACUUM CONNECTION............................................................................6
TECHNICAL DATA......................................................................................6
VIBRATIONS..............................................................................................6
NOISE EMISSIONS.....................................................................................6
LABEL DATA..............................................................................................6
CUSTOMER SERVICE.................................................................................6
2. SAFETY ISTRUCTIONS............................................................................7
RECOMMENDED USE ...............................................................................7
PROHIBITED USE.......................................................................................7
PREPARATION FOR WORK........................................................................7
PROTECTION DEVICES ..............................................................................7
ARREST FUNCTIONS .................................................................................7
SAFE USE ..................................................................................................7
RESIDUAL RISKS........................................................................................7
BEFORE YOU BEGIN..................................................................................7
OPERATING MACHINE..............................................................................7
AFTER WORK IS COMPLETED....................................................................7
THE WORK AREA ......................................................................................7
PERSONAL PROTECTIVE EQUIPMENT (PPE)..............................................7
OPERATOR................................................................................................8
3. HANDLING AND TRANSPORTATION .....................................................8
3.1 POSITIONING THE HANDLE.................................................................8
3.2 USING THE STEERING BRACKET..........................................................8
3.3 FLIPPING THE MACHINE UP................................................................8
3.5 HANDLING THE GUARD ......................................................................9
3.5.1 DISMOUNTING THE GUARD ..........................................................10
3.6 THIRD WHEEL...................................................................................10
3.7 LIFTING.............................................................................................11
3.8 STORAGE ..........................................................................................11
4. OPERATION ........................................................................................11
4.1 PRELIMINARY CONTROLS .................................................................11
4.2 CONTROL OF THE WATER FLOW ......................................................11
4.3 ADJUSTING AND MOUNTING TOOLS................................................12
4.4 vacuum connection ..........................................................................12
4.5 CONTROL BOARD .............................................................................13
4.6 STARTING THE MACHINE..................................................................13
4.7 OPERATING THE MACHINE...............................................................13
4.8 STOPPING THE MACHINE .................................................................13
4.9 ALARM..............................................................................................14
5. TOOLS AND ACCESSORIES ..................................................................14
TOOL HOLDER KEY..................................................................................14
SECURITY PLATE FOR QUICKCHANGE PADS............................................14
7. MAINTENANCE AND INSPECTION.......................................................16
CHECK DAILY ..........................................................................................16
CHECK EVERY 200 WORKING HOURS .....................................................16
CHECK EVERY 400 WORKING HOURS .....................................................16
VACUUM ................................................................................................16
WATER LEAKS.........................................................................................16
ELECTRICAL SYSTEM...............................................................................16
MECHANICAL PARTS...............................................................................16
LAVINA®32EB ELECTRICAL SCHEMES WITH YASKAWA INVERTER 200-240
VOLT.......................................................................................................17
LAVINA®32EBHV ELECTRICAL SCHEMES WITH YASKAWA INVERTER 380-
480 VOLT................................................................................................19
8. TROUBLESHOOTING...........................................................................21
INDEX OF PROBLEMS AND SOLUTIONS ..................................................21
8.1 REPLACING POWER CORD AND PLUGS.............................................21
8.2 MOTOR CONNECTION......................................................................21
8.3 DISMOUTING TOOL HOLDERS TO CHANGING V-RINGS AND FELT
RINGS .....................................................................................................21
8.4 DISASSEMBLING AND MOUNTING TOOL HOLDERS TO CHANGING
BUFFERS AND ELASTIC ELEMENT ...........................................................22
8.5 SEPARATING THE HEAD FROM THE CARRAGE.................................. 23
8.6 REPLACING THE MOTOR .................................................................. 24
8.7 FAULT DIAGNOSIS INVERTER YASKAWA V1000 ............................... 25
8.8 CORRECTING SAG OF USED PLANETARY CHAIN ............................... 27
8.9 MOUNTING NEW PLANETARY CHAIN............................................... 28
8.10 REPLAING THE FRONT KEY JOINT OF THE PLANETARY PULLEY....... 28
8.11TENSIONING AND REPLACING THE TRANSMISSION BELT ............... 29
8.12 REPLACING THE PULLEYS ............................................................... 30
8.13 REPLACING THE PLANETARY DRIVING CHAIN WHEEL AND CENTRAL
CHAIN WHEEL AND PLANETARY TENSIONER ......................................... 30
9. DISPOSAL ........................................................................................... 31
10. MANUFACTURER’S CONTACTS......................................................... 31
11. SPARE PARTS.................................................................................... 32
11.1 LAVINA®3213E GENERAL PARTS .................................................... 32
11.2 LAVINA®3213E THIRD WHEEL ..................................................... 33
11.3 LAVINA®32EB FRONT FRAME PARTS.............................................. 33
11.4 LAVINA3213EB CARRIAGE ............................................................ 35
11.5 LAVINA®3213EB FRAME AND STEERING BRACKET PARTS........... 36
11.6 LAVINA® 32EB WATER TANK ....................................................... 36
11.7 LAVINA® 32EB WATER INSTALLATION............................................ 36
11.8 LAVINA® 32EB EXTERNAL WATER VALVE....................................... 36
11.9 TOP COVER L32EB PARTS............................................................... 37
11.10 LAVINA® 32EB GUARD ASSEMBLY................................................ 37
11.11 TOP COVER L32EB........................................................................ 38
11.12 LAVINA® 3213E PLANETARY CHAIN PARTS................................... 38
11.13 LAVINA® 3213E BOTTOM COVER PARTS...................................... 39
11.14 LAVINA®3213E TOOL HOLDER PARTS /see also fig.8.4.13/ .......... 39
11.15 LAVINA® 3213E TRANSMISSION BELT PARTS ............................... 40
11.16 LAVINA® 3213E CENTRAL SHAFT BEARNING PARTS..................... 41
11.17 LAVINA® 3213E DRIVING PULLEY UNIT PARTS ............................. 41
11.18 LAVINA® 3213E PLANETARY TENSIONING UNIT........................... 41
11.19 LAVINA®32E MOTOR FAN PARTS ............................................... 42
11.20 LAVINA®3213EB; 3213EBHV CONTROL BOARD ASSEMBLY......... 43
11.21 LAVINA®3213EB CONTROL BOX................................................... 44
11.22 LAVINA®3213EBHV CONTROL BOX .............................................. 45

Superabrasive Owner’s Manual Original Language –Lavina ®3213EB/3213EBHV 1/2022
5
1. GENERAL INFORMATION
This owner’s manual is intended for the operator of the Lavina®3213E/3213EHV machine, the servicing technician, and
anyone else involved with operating or servicing the machine. We recommend that you read the instructions very
carefully and follow them strictly. The manual includes information about assembling, using, handling, adjusting and
maintaining your Lavina®3213E/3213EHV floor grinding and polishing machine.
MANUFACTURER
Superabrasive was founded in 1987, as a manufacturer of high quality diamond tools for the stone and concrete
industry. Today, Superabrasive is one of the world’s leading companies in the production of diamond tools and floor
grinding machinery. At Superabrasive, we strive to deliver the very best solutions to our customers, and enable them to
work more efficiently.
GENERAL DESCRIPTION
The Lavina®3213E/3213EHV machine is intended for grinding, polishing and buffing concrete, marble, granite,
limestone and terrazzo surfaces with diamond tools.
The Lavina®3213E/3213EHV is a machine, which can be used wet or dry.
For best results, use only tools manufactured or recommended by Superabrasive and its distributors.
WARNING!
The Lavina®3213E/3213EHV machine is manufactured and fitted for the above-
mentioned applications only! Every other use may possess risks to the persons
involved.
MACHINE CHARACTERISTICS
The Lavina®3213E/3213EHV is made of two main component sections:
LAVINA®3213E/3213EHV MAIN DESIGN
The two main component sections are the carriage and main head.
The handle on the frame is adjustable in height and
enables the operator to work in a correct and safe
posture.
The controls are positioned on top of the handle
(fig.1.1)
Two LED lights (Fig.1.2) enable the operator to work
in darker areas. The lamps are with magnet holder
can be adjusted in different positions.
.A LED light (Fig.1.3) lights the grinded floor behind
the machine. The lamp holder can be adjusted to
different positions.
Lighting system does not replace adequate overhead lighting.
The electrical box contains the electric switches and inverters. The motor feeding cable is plugged in the socket
located on the bottom of the box.
The main feeding cable is connected with a plug and socket on the side of the box
(fig.1.4).
The water tank is on the opposite side of the frame, so that the weight of the water
has no influence on the operation of the machine. The water from the tank is
supplied by a pump. The frame weight, on the other hand, is fully absorbed by the
driving wheels.
The motor is mounted on the base plate and drives the three grinding heads with a
belt system.
The planetary head is driven by a duplex roller chain.
ENVIRONMENTAL CONDITIONS
The temperature range for operating the Lavina®3213E/3213EHV outdoors is between 41°F and 86°F or 5°C and 30°C.
Never use the Lavina®3213E/3213EHV during rain or snow when working outdoors. When working indoors, always
operate the machine in well-ventilated areas.
Figure 1.1
Figure 1.4
Figure 1.2
Figure 1.3

Superabrasive Owner’s Manual Original Language –Lavina ®3213EB/3213EBHV 1/2022
6
ELECTRICAL CONNECTION
The voltage (Volt) and current (Ampere) are displayed on a label on the electrical control box to avoid any incorrect
connection. Refer to these before connecting the power. To avoid electrical shocks, make sure the ground power supply
is functioning properly.
VACUUM CONNECTION
A connection for a vacuum dust extractor is located on the carriage. The Lavina®3213E/EHV does not include a
vacuum dust extractor. The customer must purchase the vacuum dust extractor separately. The hose of the vacuum
extractor must be Ø 76 mm/ 3 inch. The vacuum dust extractor must be adapted for floor grinders and have a minimum
air displacement of 600 m3/h with a negative vacuum of 21 kPa.
TECHNICAL DATA
VIBRATIONS
The vibrations of the machine are within the limits of directives and harmonized standards from the European Union
when the
Lavina® 3213E/3213EHV is operated with the recommended tools and in normal conditions.
NOISE EMISSIONS
The noise emissions are within the limits of directives and harmonized standards from the European Union when the
Lavina® 3213E/3213EHV is operated with the recommended tools and in normal conditions. However, the operator must
wear ear protectors.
LABEL DATA
The data on the label provides the correct Voltage and kW (needed for operational purposes);
Weight (needed for transportation purposes); production year and serial number (needed for maintenance purposes).
CUSTOMER SERVICE
For customer assistance and technical support call your local distributor or call Superabrasive Inc. at 1-800-987-8403 or
visit us at: www.superabrasive.com , where you can download a copy of this manual.
LAVINA®3213E
LAVINA® 3213EHV
Voltage/Hz
3ph x 200-240 V 50/60Hz
3ph x 440-480 V 50/60Hz
Amperage
60 Amps
32 Amps
Power
15 kW
20 HP
15 kW
20 HP
Tool holder rpm
400-650 rpm
400-650 rpm
Working width
814mm
32”
814mm
32”
Tool holder diameter
3 x 335 mm
3 x 13.2”
3 x 335 mm
3 x13.2”
Direction of rotation
The heads have counter-clockwise / left rotation
Weight
673 kg
1484lbs
673 kg
1484lbs
Weight position
Pos.1
Pos.2
Pos.3
Pos.4
Pos.1
Pos.2
Pos.3
Pos.4
Grinding pressure
255 kg
299 kg
337,5 kg
384,5 kg
255 kg
299 kg
337,5kg
384,5 kg
562 lbs
660 lbs
744 lbs
848 lbs
562 lbs
660 lbs
744 lbs
878 lbs
Grinding pressure
with third wheel
269 kg
313 kg
351.5 kg
398.5 kg
269 kg
313 kg
351.5 kg
398.5 kg
593 lbs
690 lbs
775 lbs
878 lbs
593 lbs
690 lbs
775 lbs
878 lbs
Application
wet and dry
wet and dry
Vacuum hose port
Cam lock E300
Water attachment
Quick change for ¾” hose
Water tank capacity
46 l
12 gal
46 l
12 gal
Water feed
Peripheral
Peripheral
Cable length
17.4 m
57 ft
17.4 m
57 ft
Machine LxWxH
2460x862x1302 mm
92”x34”x52”
2460x862x1302 mm
92”x34”x52”
Packing crate
LxWxH
1600x950x1604 mm
63”x37”x63,2”
1600x950x1604 mm
63”x37”x63,2”

Superabrasive Owner’s Manual Original Language –Lavina ®3213EB/3213EBHV 1/2022
7
2. SAFETY ISTRUCTIONS
RECOMMENDED USE
The Lavina® machine is designed and manufactured to
grind and polish concrete, terrazzo and natural stone floors.
It can be used for renovations as well as for polishing. The
machine is designed for dry or wet use. When using it dry,
use a vacuum of appropriate size. For more information,
please refer to the chapter on handling the vacuum
connection.
PROHIBITED USE
The machine MUST NOT be used:
For applications apart from the ones stated in the General
Description chapter.
For unsuitable materials.
In environments which:
Possess risks of explosion
Possess high concentration of powders or oil substances in
the air
Possess risks of fire
Feature inclement conditions.
Possess electromagnetic radiation.
PREPARATION FOR WORK
Make sure that:
You have closed the work area, so that no person
unfamiliar with operating the machine can enter the area
The tool plate and tools are adjusted to the machine
properly
There are no missing parts of the machine
The machine is in upright working position
The protection devices are working properly.
The electrical cable is free to move and follow the machine
easily. In order to keep the electrical cable from being
damaged, no vehicle should cross the zone where electrical
cables are situated.
PROTECTION DEVICES
The machine is equipped with
several protection devices including the following:
An emergency stop button
A protection skirt and a hood for protecting the tool plates.
These devices protect the operator and/or others persons
from potential injuries. Do not remove them. On contrary,
before using the machine, please ensure that all protection
devices are mounted and function properly.
ARREST FUNCTIONS
Methods of arresting of the
machine are following:
Button to stop the motor (category 1)
Emergency button (category 1)
SAFE USE
The Lavina® is designed to reduce any risks correlated with
its use. However, it is not possible to fully eliminate the
risks of an accident with the machine. Unskilled or
uninstructed operator may cause correlated residual risks.
Such risks are:
Position Risks due to operator’s incorrect working position
Entanglement Risks due to wearing inappropriate
working clothes
Training Risks due to lack of operational training
NOTE: In order to reduce all consequences of the
above-mentioned risks, we advise that machine
operators will follow the instructions in the manual at all
times.
RESIDUAL RISKS
During the normal operating and maintenance cycles,
the operator is exposed to few residual risks, which
cannot be eliminated due to the nature of the operations.
BEFORE YOU BEGIN
Working area must be clear from any debris or objects.
A first-time operator must always read the manual and
pay attention to all safety instructions.
All electric connections and cables must be inspected for
potential damages.
Ground wire system of the power supply must be also
inspected.
Perform general daily inspections of the machine and
inspect the machine before each use.
Always inspect the safety devices:
The emergency break must be clear and working
The tool protector must be working
The machine must be clean
Never operate the machine in the rain!
Confirm that there are no missing parts especially after
transportation, repair or maintenance.
Before filling the water tank with water, make sure the
machine is not working and the main switch is turned off.
Before turning on the machine make sure that the base
is placed on the floor, the machine MUST NOT be in an
upright position when turned on!
OPERATING MACHINE
Never work with the machine without visual contact with
it.
Never run the machine when you are situated between
the handles of the wheel
When operating the Lavina® 32E/32EHV, make certain
that there is no one, but you around the machine.
Never leave the machine unattended while working.
The electrical cable must move freely and must be
damage-free.
The water hose must move freely and must be damage-
free.
Check if the floor, you work on, is not too uneven. If this
is the case, it may damage the machine.
AFTER WORK IS COMPLETED
Clean the machine and its surroundings properly
Empty and clean the water tank
Unplug the machine and wind up the electrical cable
Store the machine in a safe place
THE WORK AREA
Make certain that people or vehicles do not enter the
work area.
Avoid cables and hoses being in the way.
Always check the floor for debris
PERSONAL PROTECTIVE EQUIPMENT (PPE)
Always wear safety shoes when working with the
machine.

Superabrasive Owner’s Manual Original Language –Lavina ®3213EB/3213EBHV 1/2022
8
All personnel in the immediate work area must wear safety
glasses with side shields. Always wear safety gloves when changing the tools. Always wear clothes suitable for the work environment.
OPERATOR
The operator Lavina®32E machine must have an adequate
technical knowledge and preparation.
The operator must know the machine’s work environment.
Only one operator at a time can work with the machine.
The operator must be properly trained and well instructed
prior operating the machine.
The operator must understand all the instructions in this
manual.
The operator must understand and interpret all the
drawings and designs in manual.
The operator must know all sanitation and safety
regulations pertaining to the operation of
The operator must have floor grinding experience.
The operator must know what to do in case of emergency.
3. HANDLING AND TRANSPORTATION
3.1 POSITIONING THE HANDLE
By loosening the swivel bolt (Fig. 3.1-2), one can turn
the steering bracket (Fig. 3.1-3) to a new position. To
turn the steering bracket down (Fig. 3.3) you have to
loosen the swivel bolt (Fig. 3.1-2) and push it in, for
security reasons.
To change the handle positions pull the knob (Fig. 3.1-1, Fig. 3.4), and move the
handle up or down.
By loosening the swivel bolt (Fig. 3.1-2), one can turn the steering
bracket (Fig. 3.1-3) to a new position. To turn the steering bracket down
(Fig. 3.3), loosen the swivel bolt (Fig. 3.1-2) and push it in,
for security reasons.
3.2 USING THE STEERING BRACKET
The handle can be positioned in in three
different positions:
Transport position to store or to
transport or to hoist the machine (fig.
3.2)
Working position (fig. 3.3) and Flipping
position (fig. 3.4)
3.3 FLIPPING THE MACHINE UP
To change the tools, put the handle in the flipping (upright) position (Fig. 3.6), grab the steering bracket and pull the
machine down using all bodyweight (one foot on the control box can help). Put the bracket down on the floor (Fig. 3.7)
and change
tools. One foot
on the control
box can help
again while
putting the
machine back.
Figure 3.1
Figure
8.3.6
Figure 3.3
Figure 3.2
Figure 3.4
Figure 3.5

Superabrasive Owner’s Manual Original Language –Lavina ®3213EB/3213EBHV 1/2022
9
3.4 HANDLING WEIGHTS
The machine has two built in weights. Each one could stay in four different positions (Fig. 3.6)
Put the weights in pos.1 when the machine is in position to change the working tools.
The weights are locked in pos.2, pos.3 and pos.4 (Fig. 3.7).
The pressure on the working tools is different in each of the four weights positions. See theTechnical Data/
3.5 HANDLING THE GUARD
The self-leveling guard is designed to always have a contact on the surface with brush no matter the height of the
tool used. During transport the guard can be hung up so it does not drag on the floor.
Figure 3.6.4
Figure 3.6.2
Figure 3.6.3
Figure 3.6,1
Figure 3.7
Figure 3.8.1
Figure 3.8.2
Figure 3.8.3
Figure 3.8.4

Superabrasive Owner’s Manual Original Language –Lavina ®3213EB/3213EBHV 1/2022
10
3.5.1 DISMOUNTING THE GUARD
After dismounting the guard the machine could pass through
32 inch (815 mm) wide doors.
1. Unscrew the two bolts about 1-1.5 turn /Fig. 3.9-2; Fig.
3.9-3;/.to disconnect the vacuum connector/Fig. 3.9-4/ from
the carriage.
2. Put the machine in position to change the tools / Fig. 3.5/.
3.Unscrew the bolt holding the guard / Fig. 3.10.1/ and the
two bolts on the back stoppers/ Fig. 3.10.2/
4.You can dismount the guard as shown on / Fig. 3.10.3/ and
/ Fig. 3.10.4/
3.6 THIRD WHEEL
Lavina® 3213E has a third wheel for easier handling. It has two positions (fig.3.11.1 or fig.3.11.2) and is mounted and
dismounted with a pin assembly (fig.3.11.3).
Figure 3.11.1
Figure 3.11.2
Figure 3.11.3
Figure 3.10.1
Figure 3.10.2
Figure 3.10.3
Figure 3.10.4
Figure 3.9
Figure 3.9

Superabrasive Owner’s Manual Original Language –Lavina ®3213EB/3213EBHV 1/2022
11
3.7 LIFTING
Lifting the machine by crane is possible by using the
handles of the carriage (fig. 3.11). The design is rated
only for the weight of the machine. Do not lift any other
loads on the machine. Always use hoisting equipment
rated for 800 kg (1300 lbs) or greater.
3.8 STORAGE
Always store and transport the Lavina® 3213EB/3213EBHV in a dry place. Never transport the Lavina®
3213EB/3213EBHV unprotected; it may be damaged if transported unprotected during rain or snow.
When the temperature may fall to 32oF (0oC) or less during the
storage of the machine, water should be emptied from the system
using the following steps:
-Pull out the hose of the tank (Fig.3.13)
-Using compressed air, blow out excess water from the system at
each position of the tap water ball valve (Fig.3.13).
4. OPERATION
4.1 PRELIMINARY CONTROLS
Inspect the working area as explained in the safety instructions. For wet use, fill the water tank with the electrical cable
disconnected. Connect the vacuum extractor and ensure that the vacuum hose is clear and able to follow the machine
easily. Plug in the machine and make sure that the power cord is free to follow the working direction of the Lavina 32E.
4.2 CONTROL OF THE WATER FLOW
The water system is designed to supply water directly on the
tools. The water supply is coming either from the tank or from
external water source:
-water supply from the tank:
Put the internal water valve into position „ON” (along the axis
of the machine) Figure 4.2 and close the external valve Figure 4.3,
so the water could flow from the tank through the internal valve over
the tools.
You can adjust the water flow by putting the internal valve in an
intermediate position.
- external water supply:
Put the internal water valve into position „OFF” Figure 4.1 and
open the external valve Figure 4.4, so the water could flow through
the external valve over the tools.
You can adjust the water flow by putting the external valve in an intermediate position.
ALWAYS USE CLEAN WATER TO PROTECT THE SYSTEM FROM DIRT.
Figure 3.12
Figure 3.13
Figure 4.1
Figure 4.2

Superabrasive Owner’s Manual Original Language –Lavina ®3213EB/3213EBHV 1/2022
12
4.3 ADJUSTING AND MOUNTING TOOLS
The Holder A64 in the LAVINA® E can work
with either 3 or 6 rubber buffers, which will alter
its elasticity (3 will be more flexible than 6). You
can make the change after dismounting the
holder as per the instructions in
TROUBLESHOOTING.
In the Lavina 3213GE, the holder is initially
mounted with 6 buffers.
Mount the tools only after ensuring that there is
enough diamond bond material left. Be sure
that the plates
are always clean before mounting.
WARNING: Always Secure the Quick
Change tools with the security plate
(Fig.4.6), lock with the tool holder key (Fig.4.6) and make sure that the butterfly is securely locked at 90 degrees.
Always use the tool holder key (Fig.5.3).
4.4 VACUUM CONNECTION
To connect a vacuum cleaner, the Lavina 32EB is supplied with vacuum hose Cam
Lock inlet E300 / vacuum hose diam. 3 in (76mm).
Figure 4.8
Figure 4.6
Figure 4.7
Figure 4.5
Figure 4.3
Figure 4.4

Superabrasive Owner’s Manual Original Language –Lavina ®3213EB/3213EBHV 1/2022
13
4.5 CONTROL BOARD
1. Emergency button used to stop the motor in case of
emergency
2. STOP button which stops the motor.
3. RUN button. Start the motor (ready ON/OFF switch must
be ON).
4. READY led lights green when the power is on
5. ALARM/Reset button resets the alarm of the inverter.
Button lights blue when the inverter goes into alarm mode.
6. LED lights switch.
7. QR code. When you scan it with your phone for
example, it will redirect your browser to Lavina manuals
page.
8. READY ON / OFF switch. The switch returns to its starting
position after being released.
If you want to start the motor it must be ON as it puts the
inventor into standby mode (it glows when it’s turned
ON). If it’s off the inventor will be out of standby mode
and you cannot start the motor.
9. Cup holder.
10. Potentiometer controls the RPM of the
grinding plates on a range.
11. Digital Tachometer indicates the revolution
per minute of the grinding plates (not the
revolution per minute of the entire unit).
12. Phone holder
13. Hour meter
14. USB charger
15. Lever of valve for water supply from the
tank
16. HIGH VOLTAGE marking /When it is present
the machine is for high voltage power supply/
4.6 STARTING THE MACHINE
Strictly follow the instructions in "SAFETY INSTRUCTIONS".
NEVER WORK WITH THE MACHINE WITHOUT MAINTAINING VISUAL CONTACT WITH IT.
First, follow the directions in the chapter on Safety Devices and Safety Instructions. If working wet, add water to
the floor surface. If working dry, instead switch on the vacuum unit. Next, pull the emergency stop (Fig.4.9-1) to ensure
that the machine can be started. Check the potentiometer (Fig.4.9-11) and ensure that it is set at the working speed.
Finally, hold the machine firmly and turn the start button (Fig.4.9-3)
4.7 OPERATING THE MACHINE
Guide the machine in straight lines across the floor, slightly overlapping the previously completed surface with
each new line. Work at a constant speed allowing the tools time to work at a speed appropriate for the tools’ grit size.
Avoid vibrations. Do not stop the Lavina® 32E/32EHV machine in one spot while the tools are still working because they
will leave marks on the floor surface. When working wet, select the destination of the water feed with the water tap (fig.
4.2-1) and periodically run the pump (fig. 4.9-5) to release water onto the floor surface. Starting the pump is possible
only if the machine motor is on. When working dry, check the floor surface periodically for dust accumulation. Check
regularly to see if your vacuum works properly
4.8 STOPPING THE MACHINE
The stopping of the machine must be done gradually until the motor stops. Do not stop moving the machine
before the motor comes to rest as the tools could damage the surface. To stop, switch the off switch (Fig.4.9-6). Use the
Emergency button (Fig.4.9-1) only in emergency or to fully disconnect power
Remember not to hold the machine in one spot before turning off the motor.
Figure 4.9

Superabrasive Owner’s Manual Original Language –Lavina ®3213EB/3213EBHV 1/2022
14
4.9 ALARM
The Alarm light ((Fig.4.9 -15) will light if the inverter goes in alarm mode. The most common failure is motor overload. To
reset the mode, push the reset button ((Fig.4.9-14).
5. TOOLS AND ACCESSORIES
TOOL HOLDER KEY The tool holder key (Fig. 5.1) is used for adjusting, mounting and dismounting of the
tools.
Always use the key for mounting.
Item number is A03.00.00.00
SECURITY PLATE FOR QUICKCHANGE PADS
Plate (Fig.5.2) used to secure the “Quickchange” pads.
Item number is A64.00.01
Security plate for RING TOOLS
Plate (Fig.5.3) used to ensure the “Ring” tools.
Item number is A85.00.00
Figure 5.1
Figure 5.2
Figure 5.3

Superabrasive Owner’s Manual Original Language –Lavina ®3213EB/3213EBHV 1/2022
15
6. POPULAR TOOLS
The heads have counter-clockwise / left rotation.
Use the blue PCDs and Carbide Scrapers.
RECOMMENDED TOOLS
QuickChange System and Tooling feature extremely fast and
convenient tool changes, and a long tool life, providing for great
long‐term cost savings. The QuickChange pads are produced in four
different bonds for super hard, hard, medium and soft concrete, in
a variety of grit sizes. They are offered with 1 or 2 buttons or
rectangular segments, which allows you to customize the aggressiveness of the cut.
Calibra grinding discs: our popular ceramic bond discs are designed for the removal of
difficult scratches and they save you valuable time by eliminating the need for multiple
passes with metal tools.
They can be used wet or dry, and are best for hard concrete applications. They are 3‐inch,
with included Velcro back attachment.
NATO®polishing discs feature a special resin formula designed for both wet and dry
applications and a unique design with wide channels allowing for work on a cleaner
surface and ensuring a quality polish. Available in 3 and 4 in sizes. They are with Velcro
attachment.
V‐HARR®Premium Polishing Pads are designed for mechanically polishing and restoring
concrete; also ideal for terrazzo and hard stone floors. V‐HARR® pads are offered in a
wide variety of diameters and grit sizes to accommodate many applications. Dry use is
strongly recommended.
Shine Pro®are high quality diamond‐integrated pads for floor maintenance. Available in a
variety of sizes, they are great for daily use. When used wet, they require only water (no
wax or chemicals needed), making them a very environmentally‐friendly solution for
maintaining floors.
Hybrid and resin tool rings
Exceptional flexibility with a thick layer of flexible foam.
Quick and easy magnetic attachment directly to the grinding heads.
Offered in 9” and 13” – compatible with lavina grinders and trowels
Use Only Superabrasive’s Recommended Tools. For More Tooling Options, Visit www.superabrasive.com

Superabrasive Owner’s Manual Original Language –Lavina ®3213EB/3213EBHV 1/2022
16
7. MAINTENANCE AND INSPECTION
Keep your machine clean. Cleaning the machine on a regular basis will help detect and solve potential problems before
they cause damage to the machine. Most importantly, check and clean the tool plate connections, power cord and plugs,
vacuum hoses and water tank.
CHECK DAILY After operating the Lavina® 3213Е/3213ЕHV, the operator should conduct a
visual inspection of the machine. Any defect should be solved immediately. Pay attention
to power cords, plugs and vacuum hoses loose bolt or screws.
Tool holders: Buffers and elastic element are consumables and must be visually checked
daily and replaced if needed. The key lock holders (butterflies) on the tool holders should
be also checked.
Check the rubber buffers and make sure the holders are secure. The flange
holding the buffers (Fig.7.1-1) has to be firmly secured to the unit. A gap seen here
indicates loose screws securing the holder. The screws have to be tightened immediately
to safely operate the machine. Working with loose screws could cause serious damage to
the machine. The tightening force on the screws should be 22-25N.m (16-18ft∙lbf).
It is very important to regularly check the screws that secure the “QuickChange” holder to
the safety part (Fig.7.1- 2), so that the holder will not fly away if the buffers get damaged.
The “QuickChange” should also be cleaned.
CHECK EVERY 200 WORKING HOURS
Every 200 working hours, the operator should inspect all parts of the machine carefully. Most importantly, inspect and
clean the tool plate connections, power cord plugs, vacuum hoses and water tank/filter. Also, check the water flow of the
pump. Check the guard assembly. Ensure the wheels are clean and rotate properly. Inspect the control buttons. If there
are defective control parts, they should be replaced immediately. Replace any worn vacuum or water hoses.
Open the service cover on the motor base (to check the planetary chain. Lubricate the chain with chain lubricant and
correct the sag if needed. (For sagging correction see TROUBLESHOOTING 8.4)
Dismount the tool holders (See TROUBLESHOOTING) and replace any parts (elastic element, buffers, sealer caps, “O”
rings) showing any damage.
For more information, refer to chapter troubleshooting below.
CHECK EVERY 400 WORKING HOURS
In addition to checks made every 200 hours, check if sealers and bearings are in good condition and change if needed.
VACUUM
As stated previously, frequently check hoses and other parts for clogging.
WATER LEAKS
Replace any leaking parts immediately as the water could damage your machine
ELECTRICAL SYSTEM
Dust should not enter the control box, as it will destroy the contacts. Remove (blow out) any dust present.
MECHANICAL PARTS
Parts such as the belt, seal rings, cap rings, spiders and buffers and guard assembly are subject to wear and should be
replaced as needed.
OPERATION
INTERVAL
Daily
Every 200
Hrs.
Every 400
Hrs.
Inspect power cords, plugs and vacuum hoses, loose bolt or
screws.
X
Check the rubber buffers, elastic element and fixing of the
holders
X
Inspect and clean the tool plate connections
X
Inspect and clean water tank, filters mesh and misting nozzle
X
X
Inspect the seal rings and bearings of the grinding units
X
Check the planetary chain and lubricate
X
X
Replace Felt-Ring and V‐rings
X
Check belts and bearings
X
Figure 7.1

Superabrasive Owner’s Manual Original Language –Lavina ®3213EB/3213EBHV 1/2022
17
LAVINA®32EB ELECTRICAL SCHEMES WITH YASKAWA INVERTER 200-240 VOLT
The motor is connected in “Delta” (triangle) 230 Volt, reminder for the wire connection of the motor.

Superabrasive Owner’s Manual Original Language –Lavina ®3213EB/3213EBHV 1/2022
18
Control circuit
Inputs and Outputs

Superabrasive Owner’s Manual Original Language –Lavina ®3213EB/3213EBHV 1/2022
19
LAVINA®32EBHV ELECTRICAL SCHEMES WITH YASKAWA INVERTER 380-480 VOLT
The motor is connected in “Star” 380 Volt,
reminder for the wire connection of the motor.

Superabrasive Owner’s Manual Original Language –Lavina ®3213EB/3213EBHV 1/2022
20
Control circuit
Inputs and Outputs
