superbrightleds UBL 60 Series User manual

Underwater LED Boat Light
WIFI-CON
User Manual
Part Number:
Important: Read all instructions prior to installation. UBL-x60
Features
Parts Included
Recommended Tools (not included)
Caution
Specications
316L Marine Grade Stainless Steel
Poly-Carbonate Lens
5 Ft Power Wire (18AWG)
Internal Driver
Over-Temp Protection
Waterproof IP68
Underwater Boat Light
1- (UBL-x60)
2- M5 Machine screws
2- M5 Flat washers
2 - M5 Locking Nuts
2 - M5 Self Tapping screws
2- Neoprene washers
Drill and Drill Bits
#2 Phillips Screwdriver
Heavy Grit Sandpaper
Pencil (Wax Pencil recommended for berglass)
Isopropyl/Denatured Alcohol
Lint Free Cloths
Masking Tape
Marine Sealant
LIGHTS MUST BE SUBMERGED TO AVOID OVERHEATING.
USE OUT OF WATER WILL DECREASE LED LIFETIME AND CAUSE EARLY
FAILURE.
LIGHTS HAVE OVER TEMPERATURE PROTECTION (FOR TESTING
PURPOSES ONLY) AND WILL SHUT OFF WHEN MAX TEMP (194 F / 90 C)IS
REACHED.
DO NOT OPERATE LIGHTS OUT OF WATER FOR MORE THAN 2 MINUTES
FOR TESTING.
LIGHTS WILL BE HOT IF OPERATED OUT OF WATER FOR EXTENDED
PERIODS.
INSTALLATION OF LIGHTS MUST BE DONE WHILE BOAT IS OUT OF WATER
AND DRY.
SBL IS NOT RESPONSIBLE FOR ANY INJURY OR PROPERTY DAMAGE
INCURRED DUE TO IMPROPER INSTALLATION.
Installation Instructions
4400 Earth City Expy, St. Louis, MO 63045 866-590-3533 superbrightleds.com
60W LED Underwater Boat Light
Input Voltage 9 ~ 32 VDC
Current Draw 2.8 A @ 13.5VDC
Total Power Consumption 37.8W @ 13.5VDC
Operating Temperature -22°F~122°F (-30°C~50°C)
Available Colors Red, Green, Blue, White
LED Lifetime 50,000 Hours
Warranty 3 Years
Dimensions Dia. ø 3.69in (9.4cm),
Thickness 0.67in (1.7cm )
Weight 1.43 lb (0.65kg)
TIP: Know your hull; most common type is berglass.
Wood, metal and carbon ber are other less common hull types.
For metal or carbon ber hull, rst be sure to mount an insulating
material between metal or carbon ber surfaces and lights to
prevent galvanic corrosion.
If uncertain about type of hull, please contact boat manufacturer
for assistance.
1. Determine desired mounting location on boat’s transom.
Water Line (at idle)
Water Line (at speed)
RS-X
Butt Connector
(PSC-1210)
Fuse Holder (WMFH)
Fuse (MAF-x)
Black (-)
Red (+)
Battery
UBL-x60
Overheat
OK Water Line (at idle)
Water Line (at speed)
OK
OK
Be sure to check actual draft water level if operating LED
lights at speed. (See Diagram Below)
Recommended mounting depth between 6-8” below
waterline for best e󰀨ect. Be sure that mounting location is
free of any obstructions before drilling through hole. Mark
center of desired location.

Underwater LED Boat Light
WIFI-CON
User Manual
Part Number:
Important: Read all instructions prior to installation. UBL-x60
4400 Earth City Expy, St. Louis, MO 63045 866-590-3533 superbrightleds.com
2. Drill 1/4” through hole in center of desired
location and feed power wire through hole into
boat. Hold light ush against transom, mark
location for mounting screws, then remove light.
Drill pilot holes for mounting screws to prevent
cracking in berglass hulls.
3. Use heavy grit sandpaper to rough up the
surface and to remove any debris from drilling.
Clean area using alcohol and lint free cloth.
4. Apply uniform layer of marine sealant to back
side of light, especially around mounting holes
and wire connection. Also apply marine sealant
to transom surface around pilot and through
holes.
5. Feed power wire back through 1/4” hole into boat
and press light against transom using uniform
pressure. Install mounting screws with included
neoprene washers and tighten light to transom.
6. Use sealant that has squeezed out from beneath
light to create complete seal around outer edge
of light. Remove any excess sealant.
7. Connect positive (RED) wire to positive battery
terminal through fuse to switch (see diagram
below). Connect negative (BLACK) wire to
negative battery terminal. Marine grade heat
shrink butt connectors and ring terminals are
recommended.
8. Ensure light is solidly attached to hull and that
marine sealant has fully cured prior to putting
boat in water. Lights may be tested briey while
out of water. Lights will overheat and shut down if
operated out of water for more than testing.
Installation Instructions (continued)
Wiring Diagram
Water Line (at idle)
Water Line (at speed)
RS-X
Butt Connector
(PSC-1210)
Fuse Holder (WMFH)
Fuse (MAF-x)
Black (-)
Red (+)
Battery
UBL-x60
Overheat
OK Water Line (at idle)
Water Line (at speed)
OK
OK
