Superchips 2705 MAX Micro Tuner Installation manual

Page 1 of 12 Form 0131K 10/10/2005 


 2609 South Sanford Ave1790 East Airport Blvd.,. Sanford, FL. 32773 [phone]
http://www.Superchips.com Ph. 888-CAR-CHIP
Superchip & Superchips are registered trademarks of Superchips, Inc.
Superchips Model 2705 MAX MicroTuner
2001-2003 GM Trucks with
6.6L Duramax Diesel Engines
Vehicle Programming Instructions
PLEASE READ THIS ENTIRE INSTRUCTION SHEET BEFORE YOU PROCEED
Thank you for choosing the Superchips Model
2705 MAX MicroTuner, a state-of-the-art
instrument that allows you to install a Superchips
performance program specifically tuned for your
GM Duramax diesel truck and your driving
requirements.
You can select between “HI-PERF” for maximum
horsepower gain, “PERF-TOW” when you are
towing less than 6000 lbs, and “TOW-SAFE” if you
are towing more than 6000 lbs.
You can optionally raise the vehicle speed
limiter. Allows for correction to compensate for
aftermarket tire sizes on model year 2002 and
2003 vehicles.
This product is intended for use on unmodified
stock engines and stock transmissions.
Remove any performance enhancing electronic
devices and make sure the PCM has been
returned to STOCK if you have used another
manufacturer’s programmer before using the
MAX MicroTuner.
Caution
Towing while the “HI-PERF” tuning level is selected may cause damage to your vehicle
engine, transmission or exhaust system that is not covered by your vehicle warranty or the
Superchips warranty.
About Maximum Trailer Weight
The original manufacturer of your vehicle has specified a Maximum Trailer Weight for your
vehicle. It may be found in your vehicle owner’s manual.
This Superchips product is designed to increase your engine power and performance. It
does not change the engine, suspension or drive train characteristics that limit the maximum
trailer weight your vehicle is designed to tow. Towing trailer weights above the maximum
trailer weight specified by the vehicle manufacturer may cause transmission or other
damage.
If you wish to tow greater than the maximum trailer weight for your vehicle, modifications to
your vehicle may need to be made. Consult your performance auto mechanic for the proper
vehicle modifications.
Damage caused by towing weights greater than the maximum trailer weight specified for
your vehicle shall not be the responsibility of Superchips, Inc.
Page 2 of 12 Form 0131K 10/10/2005 


 2609 South Sanford Ave1790 East Airport Blvd.,. Sanford, FL. 32773 [phone]
http://www.Superchips.com Ph. 888-CAR-CHIP
Superchip & Superchips are registered trademarks of Superchips, Inc.
Refund Policy
If for any reason during the first thirty (30) days after your purchase of a new Superchips product
(“Product”), you may return it to the place you bought it for a full refund of the purchase price, credit or a
replacement Product at the dealer’s discretion. This Guarantee does not apply to products purchased
from on-line Internet auctions nor does it apply to Products purchased used. Follow these procedures to
get your refund or replacement.
1. If you are returning a MicroTuner or Flashpaq, use the MicroTuner or Flashpaq to return
your vehicle to the stock settings for the vehicle. Instructions are included in the user
manual.
2. Put the Product back in its original packaging.
3. Make a copy of your sales receipt. The sales receipt must be from the location where you
purchased your Product and must include the name of the business, its address, and the
part number or description of the applicable Superchips Product. Invoices, credit card
statements, or sales receipts from an online payment service company will not be accepted.
4. Return the Product in its original packaging with a copy of the sales receipt to the place of
purchase.
Superchips, Inc.
Limited Warranty
What is Covered? This warranty covers any defects in materials or workmanship in any product sold by
Superchips or its affiliates through its authorized dealers (“Product”).
How Long Does the Coverage Last? This warranty lasts for one (1) year from the date of purchase.
Coverage terminates if you sell or otherwise transfer ownership of the Product.
What will Superchips Do? Superchips will repair or replace the defective or malfunctioning Product or
any defective or malfunctioning part thereof at no charge. This warranty covers parts and labor only.
Superchips will reimburse you for all reasonable shipping charges within the first thirty (30) days of
purchase.
What Does This Warranty Not Cover? This warranty does not cover any problem that is caused by
abuse, misuse, acts of God, or improper installation or repair by non-Superchips personnel. This
warranty does not cover Products purchased used nor does it apply to Products purchased from on-line
auctions or entities that are not Superchips’ authorized dealers. This warranty does not cover damage to
your vehicle. Use of the Product to change the performance characteristics of your vehicle could
invalidate the warranty provided by the vehicle manufacturer. Consult your vehicle warranty before using
the Product on your vehicle. SUPERCHIPS SHALL NOT BE LIABLE TO YOU FOR ANY
CONSEQUENTIAL, SPECIAL, OR INCIDENTAL DAMAGES. SOME STATES DO NOT ALLOW THE
EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
How Do You Get Service? If something goes wrong with your Product during the warranty period, use
the following procedure to return the Product to Superchips.
1. Call Superchips’ Customer Service at 1-888-227-2447 Monday through Friday from 8:00 am
to 5:00 pm EST to request a Return Authorization (“RA”) number.
2. Mark the outside of the shipping package with the RA number. Packages that are not
marked with the RA number will be refused.
3. Make a copy of your sales receipt. The sales receipt must be from the location where you
purchased your Product and must include the name of the business where you purchased
the Product and the address of such business. Invoices, credit card statements, or sales
receipts from an online payment service company will not be accepted.
4. Send the Product, postage paid, the copy of the sales receipt, a brief written description of
the problem, and your contact information to:
Superchips, Inc.
1790 East Airport Blvd
Sanford, FL 32773
Attn: Warranty Claims
We will inspect the Product and either repair it or replace it with a new or rebuilt Product. We reserve the
right to use refurbished parts when making repairs.
Your Rights Under State Law: This warranty gives you specific legal rights, and you may also have
other rights which vary from state to state.

Page 3 of 12 Form 0131K 10/10/2005 


 2609 South Sanford Ave1790 East Airport Blvd.,. Sanford, FL. 32773 [phone]
http://www.Superchips.com Ph. 888-CAR-CHIP
Superchip & Superchips are registered trademarks of Superchips, Inc.
OnStar is a registered trademark of the General Motors Corporation
Your Vehicle and Service Centers
If you need to return your vehicle to a service center, restore the vehicle program to its STOCK
program as described below at Step 8. The service center might reprogram your vehicle with
an updated STOCK program without your knowledge. If your vehicle has not been returned to
its STOCK program prior to service, the Superchips MAX MicroTuner will no longer be able to
program your vehicle. Such a failure is not covered by the Superchips warranty.
Vehicle Preparation – Very Important!
Before connecting the MAX MicroTuner to your vehicle remove any accessories plugged
into the cigarette lighter or accessory power ports. If an aftermarket audio system with
amps is present, power to the amps must be turned off. Radio, day time running lights and
interior lights, cell phones, etc. all need to be turned off as the MAX MicroTuner needs full
battery voltage to program. Ensure your vehicle battery is fully charged and not connected
to a battery charger. Do not leave the MAX MicroTuner connected and unattended for any
length of time to prevent unnecessary battery drain. Do not remove the programming cable
during any programming sequence.
This product is intended for use on unmodified stock engines. Remove any performance
enhancing electronic devices and make sure the PCM has been returned to STOCK if you
have used another manufacturer’s programmer before using the MAX MicroTuner.
1. Connecting the MAX MicroTuner to your vehicle
With the ignition switch in the OFF or LOCK position, locate
the diagnostic connector under the dash to the left of the
steering wheel and connect the MAX MicroTuner cable to
the diagnostic connector.
(See Figure 1)
When connected, the MAX MicroTuner will run a self-test,
displaying several start-up messages. Following the start up
messages, if the MAX MicroTuner has been previously
used to program a vehicle, it will beep and display:
MicroTuner is
VIN Locked
This indicates the MAX MicroTuner has been previously
used to program a vehicle and cannot program another.
The MAX MicroTuner will continue to operate normally on
the original vehicle and may be used as a DTC Reader on
other GM vehicles.
Figure 1
Important Note Regarding Storage of Your MAX MicroTuner
It is recommended that you not store your MAX MicroTuner in your vehicle if ambient
temperatures in your area fall below 32oF. Excessively low temperatures can cause
malfunction or damage to the MAX MicroTuner that is not warranted by
the
Superchips, Inc.
Important Note Regarding Storage of Your MAX Micro TunerA Comment
About Vehicle Shifting
It is recommended that you not store your MAX Micro Tuner in your vehicle if ambient
temperatures in your area fall below 32oF. Excessively low temperatures can cause
malfunction or damage to the MAX Micro Tuner that is not warranted by the Superchips,
Inc.
Your vehicle “lear
ns
” your transmission shift points during the first 30 miles after the
Important Note for 2003 and Later Ford Expeditions & Lincoln NavigatorsVehicles with
OnStar
A special procedure is required to disable the fuel system inallow programming of your
vehicle
if
you have O
n
S
tar. Please see Section
9
11
of this manual
.
Page 4 of 12 Form 0131K 10/10/2005 


 2609 South Sanford Ave1790 East Airport Blvd.,. Sanford, FL. 32773 [phone]
http://www.Superchips.com Ph. 888-CAR-CHIP
Superchip & Superchips are registered trademarks of Superchips, Inc.
OnStar is a registered trademark of the General Motors Corporation
The MAX MicroTuner then displays the following messages:
Begin with Ign.
OFF Press>
Turn Ignition ON
Do NOT START Eng
Press >
To Continue…
Turn the ignition switch to the ON or RUN
position. DO NOT START THE ENGINE. Press
the ‘>’ key on the keypad. The MAX MicroTuner
will beep and display the message:
A= TUNE VEHICLE
B= DIAGNOSTICS
2. Selecting Tune Vehicle / Diagnostics
Press the ‘A’ key on the keypad to continue with the tuning process.
Press the ‘B’ key to read and/or clear any Diagnostic Trouble Codes from the
vehicle. See DTC Reader Instructions and Code Interpretation in the separate
manual for that purpose provided with your MAX MicroTuner.
3. Vehicle Programming
If the ‘A’ key has been pressed, the MAX MicroTuner will beep and display the message:
Initialization…
Please Wait…
Establishing
Communications…
The MAX MicroTuner is establishing communications with and identifying the vehicle
computer.
If Your Vehicle has OnStar
If your vehicle is found to be equipped with OnStar, a warning message will be displayed:
OnStar still
Active!
Unplug Tuner
Pull Fuse
Try Again!
See Section 9 for instructions concerning disabling OnStar. Once the OnStar fuse has been
pulled, start over again at Step 1. You will not be able to go any further than this point until
OnStar is inactive.
If your vehicle is not equipped with OnStar, or OnStar has been de-activated, the MAX
MicroTuner will continue identifying the vehicle computer.
Figure 2
IMPORTANT NOTE
Do not interrupt the MAX MicroTuner programming cycle or disconnect it from your vehicle
until the programming cycle is complete. The entire programming cycle can take several
minutes.

Page 5 of 12 Form 0131K 10/10/2005 


 2609 South Sanford Ave1790 East Airport Blvd.,. Sanford, FL. 32773 [phone]
http://www.Superchips.com Ph. 888-CAR-CHIP
Superchip & Superchips are registered trademarks of Superchips, Inc.
OnStar is a registered trademark of the General Motors Corporation
If the MAX MicroTuner has not yet been used to program a vehicle, no vehicle ID will be stored
in the MAX MicroTuner. In such a case, the MAX MicroTuner will begin saving the STOCK
program for the vehicle. If a vehicle ID has been previously stored in the MAX MicroTuner, and
if the vehicle ID matches the vehicle ID stored in the MicroTuner, the MAX MicroTuner will go
directly to the Return to Stock Sequence at Step 8 that follows.
4. Saving the Original STOCK Program for the Vehicle
The manufacturer’s original STOCK program is first saved in the MAX MicroTuner to allow
the vehicle to be reprogrammed to STOCK condition if necessary. The STOCK program will
be automatically saved the first time the vehicle is programmed and after each time it has
been returned to stock. After communications have been established with the vehicle the
MAX MicroTuner will beep and start saving the STOCK program. This will take about three
minutes. The MAX MicroTuner will blink the message:
SAVING STOCK
The bottom line of the displays shows the progress of programming.
When completed, the MAX MicroTuner will display the message:
Stock Saved!!!
Press ‘>’
Upon completion of saving the STOCK program, the MAX MicroTuner checks to see if the
vehicle ID saved with the STOCK program can be found in the internal database. If the
vehicle ID is found, the MAX MicroTuner begins the process of Installing the Superchips
Performance Program at Step 5. If the saved vehicle ID is not found in the database, the
MAX MicroTuner will sequentially display the messages:
Tuner Requires
An Update…
Error Num 41
Call Superchips!
Unplug the MAX MicroTuner from the vehicle and contact Superchips. The MAX
MicroTuner may still be used as a Diagnostic Trouble Code Reader.
5. Installing the Superchips Performance Program
The 2705 MAX MicroTuner allows for three levels of performance tuning.
Selecting the Tuning Level
The “HI-PERF”tuning level provides the most aggressive performance gains. This level of
performance permits No Towing !
The “PERF-TOW” tuning level provides engine and transmission tuning enhanced for towing
applications. The “PERF-TOW” tuning level should be selected when your vehicle is used for
towing less than 6,000 lbs.
Use the “TOW SAFE” tuning level if towing over 6,000 lbs. Maximum trailer weight of a
stock vehicle is specified by the original manufacturer. Towing loads greater than this may
cause elevated exhaust gas temperatures and may damage the vehicle. Damage caused
by towing weights greater than the maximum trailer weight specified for your vehicle, or
EGT in excess of 1200oF shall not be the responsibility of Superchips, Inc.
Caution
Towing while the “HI-PERF” tuning level is selected may cause damage to your vehicle engine,
transmission or exhaust system that is not covered by your vehicle warranty or the Superchips
warranty.
Caution
Page 6 of 12 Form 0131K 10/10/2005 


 2609 South Sanford Ave1790 East Airport Blvd.,. Sanford, FL. 32773 [phone]
http://www.Superchips.com Ph. 888-CAR-CHIP
Superchip & Superchips are registered trademarks of Superchips, Inc.
See the important insert regarding “Maximum Trailer Weight” in the packaging materials for
your MAX MicroTuner for more information.
The MAX MicroTuner will Display the following:
Tuning Level:
xxxxxxxx
Pressing ‘<’ and ‘>’ on the keypad changes the tuning level setting.
Pressing ‘YES’ on the keypad saves the indicated tuning level setting.
If “HI-PERF” tuning is selected, the MAX MicroTuner beeps once and displays:
Towing a Trailer
YES or NO
If the ‘YES’ key is pressed to indicate you plan to tow with the vehicle, the MAX
MicroTuner beeps and displays:
Can’t Tow using
HI-PERF Tuning!
Press >
to Continue…
If “PERF-TOW” tuning is selected, the MAX MicroTuner beeps once and displays:
Towing Over 6000
lbs? YES or NO
If the ‘YES’ key is pressed to indicate you plan to tow over 6000 lbs, the MAX
MicroTuner beeps and displays:
Use Tow Safe
Only
Press >
to Continue…
Pressing ‘>’ will then restart tuning selection.
If “PERF-TOW” tuning is selected, you will not be towing more than 6,000 lbs.
Editing the Tire Height Option Setting
The Tire Height Option is available for model years 2002 and 2003 vehicles. The option
allows the MAX MicroTuner to correct the Speedometer/Odometer when other than
STOCK tires are installed. The Tire Height Option allows you to set the Tire Height to
STOCK or to a range of 26.00 to 38.00 inches in ¼” increments. Tire height should be
measured from the top of the tire at its highest point to the ground.
The MAX MicroTuner will beep and display the message:
TIRE Height:
xx.xx
The present Tire Height setting is displayed. Use ‘<’ or ‘>’ to change the Tire Height setting
and ‘YES’ to save the Tire Height Custom Option setting.
Editing the Speed Limiter Option Setting
The Speed Limiter option allows the user to set the vehicle Speed Limiter to:
•Use the Superchips Performance Program raised setting.
•Use the STOCK setting.
The MAX MicroTuner will beep and display the message:

Page 7 of 12 Form 0131K 10/10/2005 


 2609 South Sanford Ave1790 East Airport Blvd.,. Sanford, FL. 32773 [phone]
http://www.Superchips.com Ph. 888-CAR-CHIP
Superchip & Superchips are registered trademarks of Superchips, Inc.
Raise SPEED LIM?
YES or NO
The current Speed Limiter setting will flash. Use ‘<’ or ‘>’ to change the
setting and ‘YES’ to save the Speed Limiter Custom Option setting.
The MAX MicroTuner will beep and display the message:
Please Wait…
After a brief wait The MAX MicroTuner will beep again and display the message:
Install Tuning?
YES or NO
Press ‘YES’ on the MAX MicroTuner keypad to continue with the Programming
process at Step 6.
Press ‘NO’ to return to Selecting Tune Vehicle / Diagnostics at Step 2.
6. Programming Section
The MAX MicroTuner will beep and display the message:
Install Tuning
The bottom line of the display shows the programming progress.
Once the programming sequence has been successfully accomplished on a vehicle, the
MAX MicroTuner becomes LOCKED to that vehicle. The MAX MicroTuner may not be used
to tune any other vehicle. The MAX MicroTuner may be used on other GM vehicles as a
DTC Reader.
7. End of Programming Sequence
When the programming sequence is completed the MAX MicroTuner beeps and will display
the following messages:
Clearing DTC’S
Please Wait…
Tuning Installed
Turn Ign OFF
Turn the ignition OFF(LOCK), and do the following:
Press the ‘>’ Key
to Continue…
Press the ‘>’ key to continue. The MAX MicroTuner will display the following messages:
Please Wait…
Remove the 2705
MAX Tuner…
Remove the cable from the diagnostic port.
Start Vehicle
IMPORTANT NOTE
Do not interrupt the MAX MicroTuner programming cycle or disconnect it from your vehicle
until the programming cycle is complete. The entire programming cycle can take several
minutes.
Page 8 of 12 Form 0131K 10/10/2005 


 2609 South Sanford Ave1790 East Airport Blvd.,. Sanford, FL. 32773 [phone]
http://www.Superchips.com Ph. 888-CAR-CHIP
Superchip & Superchips are registered trademarks of Superchips, Inc.
OnStar is a registered trademark of the General Motors Corporation
8. Return to Stock Sequence
The Return to Stock Sequence is used to reprogram a vehicle previously tuned with the
Superchips MAX MicroTuner with its original stock tuning. Follow the steps described in
Connecting the Superchips MAX MicroTuner to Your Vehicle at Section 1. Following the
typical start up messages, if the MAX MicroTuner has been previously used to program a
vehicle, the MAX MicroTuner will beep and display:
MicroTuner is
VIN Locked
This indicates the MAX MicroTuner has been previously used to program a vehicle. It
should not be used program another vehicle. The MAX MicroTuner will continue to operate
normally on the original vehicle.
Turn the ignition switch to the ON position. Press the ‘>’ key on the keypad. The MAX
MicroTuner will beep and display the message:
A= Tune Vehicle
B= Diagnostics
Press the ‘A’ key on the keypad to continue with the tuning process.
Press the ‘B’ key to read and/or clear any Diagnostic Trouble Codes.
If the ‘A’ key is pressed, the MAX MicroTuner will beep and display the message:
Initialization…
Please Wait…
After establishing communications, the MAX MicroTuner will display the following message:
RETURN to STOCK?
YES or NO
If ‘NO’ is pressed, the MAX MicroTuner will return to Installing the Superchips
Performance Program at Step 5.
If the ‘YES’ key is pressed when the MAX MicroTuner will beep once and display the
following message:
Return To STOCK
The bottom line of the display shows the programming progress.
Important Note for 2003 and Later Ford Expeditions & Lincoln NavigatorsVehicles with
OnStar
A special procedure is required to disable the fuel system inallow programming of your
ve
hicle
if you have O
n
S
tar. Please see Section
9
11
of this manual
.

Page 9 of 12 Form 0131K 10/10/2005 


 2609 South Sanford Ave1790 East Airport Blvd.,. Sanford, FL. 32773 [phone]
http://www.Superchips.com Ph. 888-CAR-CHIP
Superchip & Superchips are registered trademarks of Superchips, Inc.
When the programming sequence is completed the MAX MicroTuner beeps and will display
the following messages:
Clearing DTC’S
Please Wait…
Returned to Stock
Turn Ign OFF
Turn the ignition OFF, and do the following:
Press the ‘>’ Key
to Continue…
Press the ‘>’ key to continue. The MAX MicroTuner will display the following messages:
Please Wait…
Remove the 2705
MAX Tuner…
Remove the cable from the diagnostic port.
Start Vehicle
Page 10 of 12 Form 0131K 10/10/2005 


 2609 South Sanford Ave1790 East Airport Blvd.,. Sanford, FL. 32773 [phone]
http://www.Superchips.com Ph. 888-CAR-CHIP
Superchip & Superchips are registered trademarks of Superchips, Inc.
No Start after Programming? Don’t Panic!
In some vehicles equipped with the passive Vehicle Anti-Theft System or VATS, once the
MAX MicroTuner begins saving the factory stock program, the THEFT light begins blinking
rapidly and may even blink in short and long pulses to alert the user to a problem. Since
the Superchips Max MicroTuner is communicating directly with the PCM, no other devices
may interrupt. As a result, the VATS module flags this as an error or theft condition and
goes into ‘THEFT’ mode. After the MAX MicroTuner has completed the programming
cycle, the PCM is still fully able to communicate and appears normal. However, the vehicle
may be in a No Start Condition and the THEFT light will be blinking rapidly.
Corrective Procedure
This procedure should recover the vehicle and allow it to be started. Therefore, it is
recommended that the MAX MicroTuner programming cycle be completed prior to
recovery. i.e. The user should allow the MAX MicroTuner to upload the stock program and
should select their choice of performance files and any user options, if available. Following
instructions, they should complete the programming process.
Once the vehicle has been programmed with the selected performance program, complete
the following steps to reset the VATS Theft condition if necessary.
Disconnect the Superchips MAX MicroTuner & cable from the vehicle computer interface
connector.
If the vehicle will not start and the Theft Light is blinking rapidly
1. Remove the Ground (-) cable from the battery post for a period of thirty minutes
to allow the vehicle DTC codes and Theft codes to clear.
2. Re-attach the Ground cable to the battery and start the vehicle as you normally would.
Error Notification
In the event recovery is successful and you are able to start your vehicle, you may now
attempt to use the MAX MicroTuner to program your vehicle again. Follow the on-
screen prompts. If recovery is unsuccessful, or for any reason the MAX MicroTuner fails
to complete its programming cycle, an error message will be displayed on the unit.
Please make note of the message displayed and contact Superchips Customer Service.
If you need assistance please contact your local dealer or call Superchips Customer
Service at [phone], M-F 8:00 AM till 5:00 PM. EST.

Page 11 of 12 Form 0131K 10/10/2005 


 2609 South Sanford Ave1790 East Airport Blvd.,. Sanford, FL. 32773 [phone]
http://www.Superchips.com Ph. 888-CAR-CHIP
Superchip & Superchips are registered trademarks of Superchips, Inc.
OnStar is a registered trademark of the General Motors Corporation
9. Special Instructions to Allow Programming in vehicles with OnStar
GM trucks or SUVs equipped with OnStar communications or other devices may interrupt
the programming of your vehicle with the Superchips MAX MicroTuner. This may cause the
Superchips MAX MicroTuner to display a “No Response” message or “Error Code 50”.
To prevent these interruptions from occurring during programming, follow these additional
steps before using the Superchips MAX MicroTuner.
Model Years 2001 & 2002 OnStar Fuse Locations
1. Ensure vehicle is off with keys removed from the ignition.
2. Locate the fuse panel behind the battery under the hood on the driver’s side. Find the
Fuse Marked SE01 as shown below. Remove the fuse.
REM
OVE
SEO1 FUSE
REMOVE
SEO1 FUSE
Page 12 of 12 Form 0131K 10/10/2005 


 2609 South Sanford Ave1790 East Airport Blvd.,. Sanford, FL. 32773 [phone]
http://www.Superchips.com Ph. 888-CAR-CHIP
Superchip & Superchips are registered trademarks of Superchips, Inc.
OnStar is a registered trademark of the General Motors Corporation
Model Year 2003 OnStar Fuse Locations
1. Ensure vehicle is off with keys removed from the ignition.
2. Locate the fuse panel behind the battery under the hood on the driver’s side. Find the
Fuse Marked INFO as shown below. Remove the fuse.
Important!
After programming has completed, ensure the vehicle ignition is off and the keys are
removed from the ignition. Reinstall the fuses back into their correct positions. Start your
vehicle normally.
REMOVE
INFO FUSE
REMOVE
INFO FUSE
