Superior Radiant TA series Manual

03/14 LT096
Series TA/TX/TXR Infrared Heater
Installation, Operation and Service Instructions
Installer
Read and thoroughly understand these Instructions before attempting any installation.
Owner
Retain this Manual for reference.
Improper installation, adjustment, alteration, service or maintenance can cause injury, death or property
damage. Read the installation, operation and service instructions thoroughly before installing or servicing
this equipment.
563 Barton Street, Stoney Creek, Ontario L8E 5S1
www.superiorradiant.com
WARNING
FOR YOUR SAFETY
If you smell gas:
1. Open windows
2. Don’t touch electrical switches
3. Extinguish any open flame
4. Immediately call your gas supplier
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
Si vous sentez une odeur de gaz:
1. Ouvrez les fenetres
2. Ne touchez pas aux interupteurs
electriques
3. Eteignez tout flamme nue
4. Contactez immediatment votre
fournisseur de gaz
CONSIGNES DE SECURITE
Il est interdit d‘utiliser des liquides
inflammables ou degageant des vapeurs
inflammables, a proximites de tout appareil
fonctionnent au gaz.
CONSIGNES DE SECURITE

CAUTION: FIRE OR EXPLOSION HAZARD
Maintain clearance to combustible constructions as further specified in this manual. Failure
to do so could result in a serious fire hazard. Heaters should not be located in hazardous
atmospheres containing flammable vapors or combustible dusts. Signs should be provided in
storage areas specifying maximum safe stacking height.
CAUTION: MECHANICAL HAZARD
This equipment expands and contracts with each operating cycle. The gas connection,
suspension hardware and the installation itself must safely allow this movement. Failure to
do so could result in serious fire or explosion hazard.
CAUTION: FIRE OR EXPLOSION HAZARD
This heater is equipped with an automatic ignition device. Do not attempt to light the burner
by hand. Failure to comply could result in a serious fire and personal injury hazard.
CAUTION: MECHANICAL HAZARD
Do not use high pressure (above 1/2 psi) to test the gas supply system with the burners
connected. Failure to do so could result in damage to the burner and its control components
requiring replacement.
CAUTION: SERVICE LIFE RISK
Do not install equipment in atmospheres containing halogenated hydrocarbons or other
corrosive chemicals. Failure to do so may lead to premature equipment failure and
invalidation of the warranty. Additionally, it is recommended that the equipment be installed
with a slope downward and away from the burner of ¼" in 10' to allow start-up condensate
drainage.

Series TA/TX/TXR Page 3 Jan 07, 2015
Table of Content
INTRODUCTION...................................................................................................................................................................... 4
INSTALLATION CODES ...................................................................................................................................................................... 4
General Installation and Gas Codes...................................................................................................................................... 4
Aircraft Hangar Installation .................................................................................................................................................. 4
Public Garage Installation..................................................................................................................................................... 4
Parking Structures................................................................................................................................................................. 4
Gas Supply Lines ................................................................................................................................................................... 5
Electrical ............................................................................................................................................................................... 5
Venting ................................................................................................................................................................................. 5
GENERAL SPECIFICATIONS ..................................................................................................................................................... 6
GAS SUPPLY .................................................................................................................................................................................. 6
Inlet Pressure ........................................................................................................................................................................ 6
Manifold Pressure................................................................................................................................................................. 6
Inlet Connection.................................................................................................................................................................... 6
ELECTRIC SUPPLY............................................................................................................................................................................ 6
FLUE AND OUTSIDE AIR CONNECTION ................................................................................................................................................ 6
DIMENSIONAL CHARTS .......................................................................................................................................................... 7
CONFIGURATIONS.................................................................................................................................................................. 8
CLEARANCE TO COMBUSTIBLES ............................................................................................................................................. 9
INSTALLATION...................................................................................................................................................................... 11
INSTALLATION SEQUENCE............................................................................................................................................................... 11
VENTING / COMBUSTION AIR DUCTING............................................................................................................................... 25
GENERAL REQUIREMENTS .............................................................................................................................................................. 25
UN-VENTED OPERATION ............................................................................................................................................................... 25
VENTED OPERATION ..................................................................................................................................................................... 26
Horizontal Venting.............................................................................................................................................................. 26
Vertical Venting .................................................................................................................................................................. 26
Common Vertical Venting................................................................................................................................................... 26
Common Horizontal Venting............................................................................................................................................... 27
COMBUSTION AIR SUPPLY (OPTIONAL)............................................................................................................................................. 28
OUTDOOR INSTALLATION .................................................................................................................................................... 29
GAS PIPING .......................................................................................................................................................................... 30
GENERAL REQUIREMENTS .............................................................................................................................................................. 30
ELECTRICAL WIRING ............................................................................................................................................................. 31
GENERAL REQUIREMENTS .............................................................................................................................................................. 31
TXR WIRING DIAGRAM ................................................................................................................................................................. 33
BURNER OPERATION............................................................................................................................................................ 34
STARTING SEQUENCE OF OPERATION ............................................................................................................................................... 34
MAINTENANCE ............................................................................................................................................................................ 34
TROUBLESHOOTING............................................................................................................................................................. 35
BLOWER MOTOR FAILS TO RUN ...................................................................................................................................................... 35
NO GAS SUPPLY........................................................................................................................................................................... 35
BURNER DOES NOT LIGHT.............................................................................................................................................................. 35
BURNER DOES NOT STAY LIT .......................................................................................................................................................... 35
TROUBLESHOOTING CHART ............................................................................................................................................................ 36
REPLACEMENT PARTS .......................................................................................................................................................... 37
WARRANTY.......................................................................................................................................................................... 38

Series TA/TX/TXR Page 4 Jan 07, 2015
Important
These instructions, the layout drawing, local codes and ordinances, and applicable standards such as
apply to gas piping and electrical wiring comprise the basic information needed to complete the
installation, and must be thoroughly understood along with general building codes before proceeding.
Only personnel who have been trained and understand all applicable codes should undertake the
installation. SRP Representatives are Factory Certified in the service and application of this
equipment and can be called on for helpful suggestions about installation.
Introduction
Superior Radiant Products is a company in the infrared heating industry founded on the principles of
product quality and customer commitment.
Quality commitments are evidenced by superior design, a regard for design detail and an upgrade of
materials wherever justifiable.
Customer commitment is apparent through our ready responses to market demands and a never ending
training and service support program for and through our distributor network.
Superior Radiant offers its 15 years of infrared expertise in a cost effective unitary heater design as
culmination of that commitment. Series TA/TX/TXR models are field assembled, low intensity infrared
heaters that are easy to install and maintain, and which were engineered with significant input from our
customers. They are designed to provide economical operation and trouble-free service for years to come.
Installation Codes
Installations must comply with local building codes, or in their absence, the latest edition of the national
regulations and procedures as listed below.
General Installation and Gas Codes
Heaters must be installed only for use with the type of gas appearing on the rating plate, and the
installation must conform to the National Fuel Gas Code, ANSI Z223.1/NFPA 54 in the US and
CAN/CGA B149.1 and B149.2 Installation Codes in Canada.
This heater maybe approved for either indoor or outdoor installation. Not for use in residential dwellings,
refer to Rating plate.
Aircraft Hangar Installation
Installation in aircraft hangars must conform to the Standard for Aircraft Hangars, ANSI/NFPA 409 in the
US and CAN/CGA B149.1 and B149.2 Installation Codes in Canada.
Public Garage Installation
Installation in public garages must conform to the Standard for Parking Structures, NFPA-88A or
Standard for Repair Garages, NFPA 88B, in the US and CAN/CGA B149.1 and B149.2 Installation
Codes in Canada.
Parking Structures
Technical requirements are outlined in ANSI/NFPA 88B (USA)

Series TA/TX/TXR Page 5 Jan 07, 2015
Introduction
Gas Supply Lines
Gas supply pipe sizing must be in accordance with the National Fuel Gas Code, ANSI Z223.1/NFPA 54
in the US and CAN/CGA B149.1 and B149.2 Installation Codes in Canada.
A 1/8" NPT plugged tap must be installed in the gas line connection immediately upstream of the burner
farthest from the gas supply meter to allow checking of system gas pressure.
Electrical
All heaters must be electrically grounded in accordance with the National Electric Code, ANSI/NFPA 70
in the US, and the Canadian Electric Code, CSA C22.1 in Canada, and must comply with all local
requirements.
Venting
Refer to the National Fuel Gas Code, ANSI Z223.1/NFPA 54 in the US and CAN/CGA B149.1 and
B149.2 Installation Codes in Canada for proper location, sizing and installation of vents as well as
information on clearance requirements when penetrating combustible walls for venting purposes.

Series TA/TX/TXR Page 6 Jan 07, 2015
General Specifications
General Specifications
Gas Supply
Inlet Pressure
Natural Gas:
Minimum
Maximum
5.0" W.C.
14.0" W.C.
Propane Gas:
Minimum
Maximum
11.5" W.C.
14.0" W.C.
Manifold Pressure
Natural Gas:
3.5" W.C.
2.4" W.C.
(High Rate)
(Low Rate)
Propane Gas:
10.5" W.C.
6.2" W.C.
Inlet Connection
Natural Gas or Propane: 1/2" female NPT
Electric Supply
120 VAC, 60 HZ, 1 Amp: 36" cord with grounded 3 prong plug
Flue and Outside Air Connection
4" O.D. male connection for flue adapter and outside air (optional) provided at the heater

Series TA/TX/TXR Page 7 Jan 07, 2015
Dimensional Charts
Figure 1: Overall Dimensional Information
Figure 2: Component Dimensional Information
14"
36"
12"
12"
9"
15"
16"
6"
10' - 4"
10'
24"
18"
U-BEND
24"
18"
ELBOW
16" WHEN INSTALLING, ORIENT
BAND CLAMP LOCK BOLTS
TO TOP, AT 10 O'CLOCK
OR 2 O'CLOCK POSITION
COUPLING
12"
10' - 4"
TUBE
10'
4', 6' OR 8'
REFLECTOR
BAFFLE SECTION

Series TA/TX/TXR Page 8 Jan 07, 2015
Configurations
Table 1: Configuration Information
Note:
-Baffles are always placed in the last section of radiant tube.
-Baffles are either aluminized or stainless steel sections 6' long.
-When only 6' is required an aluminized steel baffle is installed, except on the TA/TX/TXR-40
where a special 6' stainless steel baffle with a red identification tab must be installed.
-When 12' is required the aluminized steel baffle is lengthened forward (toward the burner) with a
6' stainless steel section.
Part numbers for reference are:
CT016 Baffle for TA/TX/TXR-40 only, 6' long, stainless steel with red identification tab.
CT007 Baffle 6' long, aluminized steel
CT006 Baffle extension, 6' long stainless steel.
The following special configurations are also approved:
60,000 BTU/Hr 15' heat exchanger with 6' Stainless steel baffle with red tab (Natural Gas Only)
80,000 BTU/Hr 40' heat exchanger with no baffle or 6' aluminized baffle.
100,000 BTU/Hr 40' or 50' heat exchanger with no baffle or 6' aluminized baffle
125,000 BTU/Hr 40' or 50' heat exchanger with 6 aluminized baffle
150,000 BTU/Hr 60' heat exchanger with NO baffle
205,000 BTU/Hr 50' heat exchanger with a 4' baffle at 40', and a 8' baffle at 50'. (See Figure 3)
Figure 3: Baffle Location TA/TX/TXR-205 Models
Model
High Rate
(BTU/Hr)
Low Rate
(BTU/Hr)
Heat Exchanger Length
(ft.)
Baffle
Length (ft.)
Minimum
Maximum
TA/TX/TXR-40
40,000
30,000
10'
20'
6'
TA/TX/TXR-60
60,000
45,000
20'
30'
6'
TA/TX/TXR-80
80,000
60,000
20'
30'
12'
TA/TX/TXR-100
100,000
75,000
20'
30'
12'
TA/TX/TXR-125
125,000
95,000
30'
50'
12'
TA/TX/TXR-150
150,000
115,000
40'
60'
6'
TA/TX/TXR-175
175,000
130,000
50'
60'
-
TA/TX/TXR-205
205,000
160,000
60'
70'
-
TA/TX/TXR-220
220,000
165,000
60'
70'
-
50'
Fold
Over
40'
3'-6"
PN CT026
7'-6"
PN CT027
Fold
Over
BAFFLE LOCATION FOR ALL 205,000 BTU/Hr, 50 ft. UNITS ONLY
(P/N CT095 Baffle Kit)

Series TA/TX/TXR Page 9 Jan 07, 2015
Clearance To Combustibles
A general clearance of 18” (0.5 m) in every direction is recommended for servicing only around each
Burner, Vacuum Pump, and End Vent Cap air supply (at the far end of each Radiant Branch) also to
ensure adequate air flow in and around the Heating System.
In addition to this it is very important to observe the minimum clearance to combustibles at all
times to avoid any possibility of property damage or personal injury.
WARNING
Clearances as marked on the heater body must be maintained from vehicles parked beneath. Signs
should be posted identifying any possible violation of the clearance distances from the heater in all
vehicle areas.
Maximum allowable stacking height in storage areas should be identified with signs or appropriate
markings adjacent to the thermostat or in a conspicuous location.
Table 2 lists the minimum clearance to combustible materials for various installation configurations. Note
that standard clearances also apply to installation above T-bar ceilings and above decorative grills.
Additional clearance may be required for glass, painted surfaces and other materials which maybe
damaged by radiant or convective heat.
Combustible materials are considered to be wood, compressed paper, plant fibres, plastics, Plexiglas or
other materials capable of being ignited and burned. Such materials shall be considered combustible
even though flame-proofed, fire-retardant treated or plastered.
Elbows and U-bends are un-heat treated aluminized material and are typically installed without reflectors.
Reflector miter kits are available for U-bends and elbows.
Adequate clearance to sprinkler heads must be maintained.
The stated clearance to combustibles represents a surface temperature of 90°F (50°C) above room
temperature. Building materials with low heat tolerance (such as plastics, vinyl siding, canvas, tri-ply,
etc…) maybe subject to degradation at lower temperatures. It is the installer’s responsibility to assure
that adjacent materials are protected from degradation.
Note 1:
Bottom Shields are approved for all burner sizes. The “below” clearance (dimension C in Table 2)
may be reduced by 25% when an approved Bottom Shield is used.
Note 2:
Reduced clearances downstream from the burner are approved for all configurations. Dimensions “B”,
“C”, and “D” in Table 2 can be reduced for locations 25' (7.6 m) or more downstream from a burner,
before the next burner, maximum reduction is 50%

Series TA/TX/TXR Page 10 Jan 07, 2015
Clearance to Combustibles
Table 2: Minimum Clearance to Combustibles
Model No.: TA / TX / TXR
Reflector Configurations
Dim
40
60
80
100
125
150
175
205
220
Horizontal
A
CDB
A
B
C
D
2"
18"
45"
18"
2"
25"
58"
25"
2"
26"
62"
26"
2"
30"
67"
30"
4"
33"
71"
33"
4"
36"
74"
36"
6"
40"
78"
40"
6"
44"
80"
44"
6"
46"
83"
46"
45° Reflector Tilt
D
A
B
C
A
B
C
D
4"
4"
40"
38"
4"
4"
50"
46"
4"
4"
58"
50"
4"
4"
67"
58"
6"
4"
70"
63"
6"
4"
71"
64"
8"
4"
74"
67"
8"
4"
78"
72"
8"
4"
81"
77"
One Side Extension
D
A
C
B
A
B
C
D
2"
4"
50"
35"
2"
4"
58"
38"
2"
4"
63"
42"
2"
4"
73"
45"
4"
4"
76"
50"
4"
4"
78"
52"
6"
6"
80"
54"
6"
6"
84"
56"
6"
6"
84"
58"
Two Side Extension
D
A
BC
A
B
C
D
2"
9"
50"
9"
2"
16"
58"
16"
2"
18"
64"
18"
4"
18"
71"
18"
4"
22"
78"
22"
4"
24"
80"
25"
6"
26"
82"
26"
6"
29"
86"
29"
6"
31"
88"
31"
U-Tube, Horizontal
D
A
B
C
A
B
C
D
-
-
-
-
2"
25"
59"
22"
2"
28"
62"
26"
2"
30"
71"
30"
4"
34"
74"
33"
4"
37"
76"
36"
6"
40"
78"
40"
6"
45"
82"
44"
6"
46"
88"
46"
U-Tube, Opposite 45°
D
A
B
C
A
B
C
D
-
-
-
-
4"
46"
51"
16"
4"
50"
54"
18"
4"
54"
64"
18"
4"
63"
69"
22"
4"
64"
71"
24"
8"
67"
74"
26"
10"
72"
78"
29"
10"
74"
81"
32"
Unvented
Above
End
12"
26"
12"
26"
18"
26"
18"
26"
18"
26"
18"
32"
18"
32"
18"
32"
18"
32"
Vented
End
18"
18"
18"
18"
18"
18"
18"
18"
18"

Series TA/TX/TXR Page 11 Jan 07, 2015
Installation
Installation Sequence
Generally, there is no unique sequence for installation of the burner or heat exchanger. A review of the
job site will usually indicate a logical installation order. However, time and expense can be saved if
installation is begun at the most critical dimension, watching for interference from overhead doors,
cranes, auto lifts etc. Figure 4 provides a general overview of the components utilized in the installation,
as well as their general relationship.
Figure 4: General Overview of Installation
A general ordered sequence for installation is provided below for reference.
HANGERS INSTALLATION
Suspension mechanism must allow for lateral tubing expansion. A minimum 12" length welded
link chain with a working load limit of at least 200 lbs. is recommended (refer to Figure 5 for
more details). SRP recommends and make available “quick links” for connecting chain. If
any open ended “S” hooks and turnbuckles are used, the open ends must be closed to avoid
unhooking chain with inadvertent contact.
Locate hanging chain at predetermined suspension points in the structure. It is required that the
first 2 hangers be about 8' to 9' away. Thereafter, 10' apart on average is acceptable for the
remainder of the heat exchanger. At no time should hangers be more than 12' apart, (see Figure 6).
Combustion
Tube
Heat Exchanger
3"
Loose
Screws
Fasten Endcap
with Screws
Reflector Overlap
Approx. 8"
Burner
Assembly
Tight
Screws
Gasket
Tube
Flange
Install "J" Bolt
at first hanger
Loose
Screws
Reflector
End Cap
Tight
Screws
Bend Tab
over End
of Tube
Vent
Adapter
Tube
Coupling
Tube & Reflector
Hangers
Tube
**Install Baffle(s) as required
in the last section of tube or
as specified in this manual
Close all chain links
"S" hooks, "J" bolts
and turnbuckles or
any open connection.

Series TA/TX/TXR Page 12 Jan 07, 2015
Installation
Figure 5: Suspension Mechanism
Install the tube and reflector support hanger on the chain with “S-hooks” refer to Figure 5 &
Figure 6.
Figure 6: Hanging Points
Place the first (flanged, aluminized) tube in the first two hangers (Figure 7). Be sure the flange is
toward the intended burner location. The other end of the tube should have the first coupling
already loosely fitted.
Concrete Beam
Turnbuckle
Beam Clamp
24"
Min.
3/8"
Threaded
Rod
I-Beam
I-Beam
12"
Min.
Anchor
Chain link
12"
Min.
Truss
Eye Bolt
Note:
Close all "S" hooks,
chain links, "J" bolts
and turnbuckles or
any open connection.
8' to 9'
10'
10'
Burner
Side
"First Hanger"
Venting
Side
"Last Hanger"
Close all open ended
"S" hooks, chain links
and turnbuckles or any
open connection.

Series TA/TX/TXR Page 13 Jan 07, 2015
Installation
TUBE INSTALLATION
Always use all the hangers supplied. As a rule the combustion tube (first tube) utilizes 2 hangers
and thereafter 1 hanger per 10' section. It is required that the first hanging point be 2"to 8"
from the burner mounting flange, and tube weld seam must face down, refer to Figure 7 for
more details.
Figure 7: Installation of First section of Flanged Tube
For all remaining tubes, fit the end of the tube with a coupling refer to Figure 8, (the coupling
should be loose).
Figure 8: Installation of Heat Exchanger Tube and Coupling
8' - 9'
Tube & Reflector
Hangers
Combustion
Tube
Coupling Should Be
Loosely Fitted
Locate Tube and
Reflector Hangers
every 10' thereafter.
10'
Tube
Flange
2"-8"
10'
Install "J" Bolt
at first hanger
Tube Weld
Seam Facing
Down
Close all open ended
"S" hooks, chain links,
and turnbuckles or any
open connection.
10'
Close all open ended
"S" hooks, chain links,
and turnbuckles or any
open connection.
Coupling
(loosely fitted)
Heat
exchanger
tube Tube weld
seam facing
down

Series TA/TX/TXR Page 14 Jan 07, 2015
Installation
Tighten the cradle loops of the first hanger with the “J-Bolt” found in the burner box, to snugly
hold the combustion tube from rotating see Figure 9.
Note: For all coupling joints, ensure that the tube joint is in the center of the coupling
length, and that the overlap joint of the coupling is above the centerline of the tube. Also
ensure that the weld seam on ALL tubes is facing down.
Note: In order to obtain smoothly sealed coupling liners, tighten each of the coupling
bands progressively and alternately. Tightening one band completely before the other may
result in an undesirable wrinkle in the liner (refer to Figure 9). Be sure not to over torque
the coupling. (Torque coupling to 15-25 lbf-ft).
Figure 9: “J” and Coupling Bolt Installations
Continue placing tubes, couplings and reflectors to complete the heater assembly. Ensure heat
exchanger sections line up straight. Couplings should be tightened as heat exchanger is placed,
since it is more difficult to do so once the reflector is in position.
Installation of Reflector Hangers
and "J" Bolt
Place Tube in the
Reflector Hanger
as shown.
Reflector Hanger
Install "J" Bolt at the
First Hanger Only.
When Installing, Orient
Band Clamp Lock Bolts
to Top, at 10 o'clock
Or 2 o'clock Position to
Avoid Contact with the
Reflector.
Tube weld
seam
Tube
weld
seam
Installation of Tube Coupling
Torque to 15-25 ft.-lbs
Note:
Close all open ended "S" hooks, chain links,
and turnbuckles or any open connection.

Series TA/TX/TXR Page 15 Jan 07, 2015
Installation
HEATER AND BAFFLE INSTALLATION
Locate the burner gasket provided, bolt the burner in place on the tube flange with provided
hardware. Burner must never be installed in a tilted position. The sense electrode of the burner
cup should be in the 12 o’clock position (Figure 10).
Figure 10: Burner Gasket Installation
If required for your heater model (refer to Table 1), install the baffle at the end of the heat
exchanger. The small tab on the baffle is folded over the end of the tube and clamped in place by
the vent connector and vent system, refer to Figure 11.
Note: Baffles are always placed at the end of the last heat exchanger tube length, with the
exception of the special configuration 205,000 BTUH with a 50' tube length, refer to
Figure 3 for more details.
Note: Baffles are either one or two sections (each section is 6' in length). Multiple sections are
simply clipped together. Where stainless and aluminized sections are supplied, always
place the stainless steel section closest to the burner. The easiest installation method is to
pull the baffle through the tube using a long wire.
Figure 11: Baffle Installation
Bend Tab
over End
of Tube
at 6 O'clock
position
Vent
Adapter Install Baffle
as required in
last section
of tube
Note:
Close all open ended "S" hooks, chain links,
and turnbuckles or any open connection.
Burner
Assembly
Gasket
Tube
Flange
Note:
Close all open ended "S" hooks, chain links,
and turnbuckles or any open connection.
Note:
Burner MUST NEVER be
tilted sideways.
Only install as shown.

Series TA/TX/TXR Page 16 Jan 07, 2015
Installation
A general overall view of the tubes and reflector hangers are shown in Figure 12 below
Figure 12: Overall view of Tubes and Reflector Hangers
Tube & Reflector
Hangers
Install Baffle
as required in
last section
of tube
Heat
Exchanger
Tube
Tube
Coupling
Vent
Adapter
Bend Tab
over End
of Tube
Install "J" Bolt
at first hanger
Tube
Flange
Gasket
3"
to
6"
Combustion
Tube Burner
Assembly
Tube
Coupling
10' Flanged
Tube
8' - 9'
Locate Tube and
Reflector Hangers
every 10' thereafter.
*Note: (30' system shown
here, the same principle
should be followed for 40', 50'
systems or more)
Refer to Installation Sequence
for more details.
10' Tube
10' Tube

Series TA/TX/TXR Page 17 Jan 07, 2015
Installation
REFLECTOR INSTALLATION
Slide a reflector section into place within the support hanger, (Figure 13).
Figure 13: Reflector Installation
Install reflector support brackets, one at each reflector overlap position, and one in the middle of
each 10' reflector length. Figure 14 shows the installation of the reflector support bracket.
Figure 14: Reflector Support Bracket Installation
Slide Reflector through
the Hanger and Reflector
Support as shown.
Note:
Close all chain links "S" hooks,
"J" bolts and turnbuckles or any
open connection.
1. Place Reflector Bracket
underneath the tube.
2. Hook the Spring Clip with
the Reflector Bracket and rotate
over the tube.
3. Push down the Spring Clip
and slide underneath the
Reflector Bracket. Reflector Bracket
Spring Clip
Reflector Bracket
Tube

Series TA/TX/TXR Page 18 Jan 07, 2015
Installation
Note: Reflectors should overlap adjacent reflectors 4" to 6". Be sure not to tile reflector sections;
that is, reflector sections must be either above both adjacent reflector sections, or below both
adjacent reflector sections. Refer to Figure 15.
Figure 15: Reflector Overlap Illustration
Reflector
Support
Loose
Screws
Tight
Screws
Loose
Screws Tight
Screws
Reflector Overlap
Approx. 6"
Fasten Endcap
with Screws
Heater End
Vent
Termination
End

Series TA/TX/TXR Page 19 Jan 07, 2015
Installation
Secure every second reflector overlap together with a minimum of 2 - #8 x 3/8" long screws (not
supplied), and secure reflector to the reflector bracket at this point by tightening down #8 x 1¼"
screws supplied with reflector brackets (Figure 16). The remaining reflector overlap joints and
reflector brackets are left loose to accommodate system movement.
Figure 16: Reflector Supports Installation and Reflector Overlap
Install End Cap as shown in Figure 4 and Figure 17.
Figure 17: Reflector End Cap Installation
Secure every SECOND reflector
overlap with a minimum of 2
#8 x 3/8" long screws
on each side
Secure reflector to reflector
bracket by TIGHTENING
#8 x 1 1/4" long screws every
other overlap on each side.
Note:
Close all chain links "S" hooks, "J" bolts
and turnbuckles or any open connection.
LOOSE screws
Insert End Cap into Reflector
and Secure it with #8 x 3/8" Screws
Note:
Close all chain links "S" hooks, "J" bolts
and turnbuckles or any open connection.

Series TA/TX/TXR Page 20 Jan 07, 2015
Installation
ELBOW AND “U-TUBE”INSTALLATION
If required by the heater layout, install 90° elbows or U-tube where indicated. Refer to Figure 18
for details.
Note: Elbows or U-tubes are typically installed without reflectors. To reduce the above
clearance to combustibles distance use miter reflectors (see Figure 19) and refer to
Clearance to Combustibles information.
Figure 18: 90° Elbow and U-Tube Assembly Detail
Elbows or U Tubes must be located not less than 10' from the burner in TA/TX/TXR-100 and
smaller models, not less than 15' from the burner in TA/TX/TXR-125 to TA/TX/TXR-150, and not
less than 20' from the burner in TA/TX/TXR-175 and larger models.
Endcap
Elbow Detail
Couplings
Hanger
Location
U-Bend Detail
Couplings
Endcap Endcap
Hanger
Location
Endcap
Hanger
Location
