FIVE-O SYSTEM INSTALLATION
Locate the plastic bags containing the Bypass Assemblies, Brass Adapters
and plastic fittings.
Each of the following items need to be put aside because you will not need
them during installation but you will need to leave them with homeowner
when installation is complete:
• The Five-O Series Warranty
• The Valve Installation and Operation Manual
• The Five-O Series System Guide
1. Determine Five-O Series installation location.
*NOTE* As you look at the rear of the Five-O Series control valve, the
inlet water line will always enter the hole on the LEFT SIDE of the bypass
valve assembly. The control valve assembly has an arrow indicating
water flow direction on top of the assembly.
2. If a recirculation pump is present, turn off power to prevent
damage.
3. Turn off the main water valve and drain water from the main line.
4. Cut and remove a section of the main incoming water line entering the
home where the system is to be installed to ensure the system is treating
all water entering the home (both hot and cold water). If a pressure
regulator is on the system, install the Five-O Series downstream of the
regulator. Allow this line to drain thoroughly.
5. You need to install the ball valve and hose bibb on the
outlet side of the unit see diagram page 3
6. Solder adapters in place on inlet and outlet piping.
7. Once cooled; apply nut, split ring and o-ring.
Do not over-tighten adapters!
8. After all soldering is finished and the adapters are securely attached
to the bypass assembly, then attach the bypass assembly to the control
valve and secure it using the black plastic fittings.
Five-O Series is now in place and ready for charging.
9. Place the bypass valve in the “Service” or “Bypass” position to test
solder joints.
10. SLOWLY Turn on water to test for leaks in pipes supplying the Five-O
Series system.
