Superior G1SP3000 User manual

1# 2#
Parts List
7 Pieces
1
T4*5/8'' Screw
3#
Leg Support Board A
4 Pieces
4 Pieces
Hockey Puck
8#7#
6#5#4#
9# 10#
15#14#
11# 12#
13# 18#17#16#
19# 21#
4 Pieces 4 Pieces
Leg Support Board B 4 Pieces Leg Support Board C Leg Base
4 Pieces
16 Pieces
F4*1-3/4" Screw
20#
Butturfly Bolt
12 Pieces
Felt Pad
4 Pieces
2 Sets
Pusher
4 Pieces
1 Piece
Control Box
Power Adapter
1 Piece
2 Pieces
Puck Catcher
1 Set
"U" Bracket
1 Piece
T4*1/2" Screw
8 Pieces
23#22# 24#
25# 26# 28#27# 29# 30#
16 Pieces
5/16"*1-1/8'' Hex Bolt
5/16"*23mm Washer
16 Pieces
31#
P3*5/16" Screw
4 Pieces
Blower And Wire
Wrench
1 Piece
Side Panel
2 Pieces
End Panel -A
1 Piece
End Panel -B
1 Piece
Scorer Unit 1 Set
1/2/3 MM Shims
1/4'' * 3/4''
2 Pieces
Catcher Cover
With Socket
Leg Support Board D
24 Pieces
F4*1-1/4" Screw 8 Pieces
F4*5/8" Screw
Connecting Box
With Wire
1 Piece
(pre-installed)
32#
1/4" *3/4’’Bolt
24 Pieces
4mm Allen Key
1 Piece

2
32
14 5
15
2
1
4
3
2
1
STEP: 1
FIG.1 LEG PANEL ASSEMBLY
3. Attach the Leg Support Board C (#3) between the Leg Support Board A(#1) and the Leg
Support Board B(#2) using eight Allen Key Bolts (#32).
4. Place Leg Support Board D(#4) at the edges of Leg Support Board A(#1) and a Leg Support
Board B(#2). Then screw with six Screws (#14)
5. Attach the Leg Base(#5) to the Legs using four Screws(#15) per Leg Base.
6. Repeat the steps above for the other Leg Panels.
1. Find a clean, level place to assemble your Air Hockey table.The table will be assembled
upside down and then turned over to the upright position.This game table is heavy and
tuning it over will require at least four adults.
2. Remove all of the contents from box and verify that you have all of the listed parts as
shown on the Parts List. Carefully cut or tear the four carton corners so that the bottom
of the box can act as your work area.
Tools required: Wrench ( Provided )
Screwdriver - Flat Head

3
STEP: 2
STEP: 3
Main cabinet
8
7
8
6
11
11
7. Attach the two side panels (#8) to the table using four Butterfly Bolts (#11) per side panel.
8. Attach the End panel-A (#6) and the End Apron-B (#7) to the table using two Butterfly Bolts (#11)
per end apron. See Fig2.
9. Attach the catcher cover (#9) to outside of the End Aprons using two screws (#31) per catch cover.
10. Attach the Puck catchers (#10) to the inside of End Aprons using three screws (#19) per Puck catcher.
11.Insert the Blower (#23) into the air box underneath the table. Then attach it to the table using five
screws (#18).
Inside Outside
31
9
10
19
23
18
6

4
Leg
13 12
Leg
STEP: 4
12.Attach the four legs to the table top using four Bolts (#13) and four Washers (#12) per leg.

5
STEP:5A
STEP:5B
27
Playingfield-back Scorer wire
16
16
27
27
STEP: 5
13.Attach the scorer Unit (#27) to the side top rails of the table using four screws (#16).

6
Adapter wire
18
19
26
Socket
25
Scorer wire
Main cabinet
Connecting wire
Scorer wire
Scorer base box
STEP:6A
STEP:6B
Connecting wire
STEP: 6
14.Attach the Control Box (#26) to the End Panel-B using two screws (#18).

21 20
21
STEP:6C
27
27
24
26
28
Scorer base box
STEP: 7
15.Remove the paper from the back of the Hockey Felt Pad (#21) and Attach them to the bottom
of the Hockey Puck Pushers(#20).
