Superior P0055-DRG User manual

1
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
RETAIN THESE INSTRUCTIONS
FOR FUTURE REFERENCE
FOR YOUR SAFETY: Do not store or use gasoline
or other flammable vapors or liquids in the vicin-
ity of this or any other appliance.
FOR YOUR SAFETY: What to do if you smell gas:
• DO NOT light any appliance.
• DO NOT touch any electrical switches.
• DO NOT use any phone in your building.
• Immediately call your gas supplier from a
neighbor’s phone.
Follow your gas suppliers instructions.
• Ifyourgassuppliercannotbereached,callthe
fire department.
Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
WARNING:IFTHEINFORMATIONINTHISMANUAL
IS NOT FOLLOWED EXACTLY, A FIRE OR EXPLO-
SION MAY RESULT CAUSING PROPERTY DAM-
AGE, PERSONAL INJURY OR LOSS OF LIFE.
POURVOTRESÉCURITÉ: Nepasentreposerniutiliser
d'essencenid'autrevaperursouliquidesinflammables
dans le voisinage de cet appareil ou de tout autre
appareil.
POUR VOTRE SÉCURITÉ: Que faire si vous sentez une
odeur de gaz:
• Ne pas tenter d'allumer d'appareil.
• Netouchezàaucuninterrupteur. Nepasvousservir
des téléphones se trouvant dans le batiment où
vous vous trouvez.
• Evacuez la piéce, le bâtiment ou la zone.
• Appeflez immédiatement votre fournisseur de gaz
depuis un voisin. Suivez les instructions du
fournisseur.
• Si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service dos incendies.
L'installationetservicedoitêtreexécutéparunqualifié
installer, agence de service ou le fournisseur de gaz.
AVERTISSEMENT: ASSUREZ-VOUS DE BIEN SUIVRE
LESINSTRUCTIONSDONNÉDANSCETTENOTICEPOUR
RÉDUIRE AU MINIMUM LE RISQUE D'INCENDIE OU
POUR ÉVITER TOUT DOMMAGE MATÉRIEL, TOUTE
BLESSURE OU LA MORT.
B-VENT
GHC/GRD-5500 SERIES
MODELS
HOMEOWNER'S CARE AND
OPERATION INSTRUCTIONS
WH Report No. J20046562
B-VENTED GAS FIREPLACES
P/N 725,029M REV. C 07/2004
tlovilliM sledoM cinortcelE sledoM
N0055-CHG2-EN0055-CHG
P0055-CHG2-EP0055-CHG
N0055-DRG2-EN0055-DRG
P0055-DRG2-EP0055-DRG
GRD-5500 SHOWN

2NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
TABLE OF CONTENTS
Introduction ..................................... page 2
General Information......................... page 2
Operation/Care of Your Appliance.... page 3
Gas Controls/Control
Compartment Access ...................... page 3
Combustion Air Controls ................. page 4
Maintenance .................................... page 5
Manual Limit Switch ........................ page 5
Burner Adjustments......................... page 5
Flame Appearance and Sooting..... page 5
Adjustment ................................... page 5
Maintenance Schedule..................... page 6
Log and Rockwool Placement ......... page 7
Millivolt Appliance Checkout............ page 7
Electronic Appliance Checkout......... page 7
Wiring Diagrams.............................. page 9
Warranty.......................................... page 9
Product Reference Information ....... page 9
Replacement Parts .......................... page 9
Lighting Instructions – Millivolt ....... page 10
Lighting Instructions – Electronic .... page 12
Troubleshooting Guide – Millivolt ..... page 14
Troubleshooting Guide – Electronic .. page 15
Accessory Components ................... page 16
Replacement Parts List ..................... page 17
WARNING: IMPROPER INSTALLATION,
ADJUSTMENT, ALTERATION, SERVICE
OR MAINTENANCE CAN CAUSE INJURY
ORPROPERTYDAMAGE. REFERTOTHIS
MANUAL. FOR ASSISTANCE OR ADDI-
TIONAL INFORMATION CONSULT A
QUALIFIED INSTALLER, SERVICE
AGENCY OR THE GAS SUPPLIER.
These appliances are designed to operate on
natural or propane gas only. The use of
other fuels or combination of fuels will de-
grade the performance of this system and
may be dangerous.
For elevations of 0-2000 ft. (0-610 m.) the
GHC/GRD-5500 input is 24,000 BTU/HR for
both natural and propane gases.
WARNING: THESE FIREPLACES ARE
VENTEDDECORATIVEGASAPPLIANCES.
DO NOT BURN WOOD OR OTHER MATE-
RIAL IN THESE APPLIANCES.
CONGRATULATIONS!
In selecting this Superior B-vented gas appliance you have chosen the finest and most
dependable fireplace to be found anywhere. A beautiful, prestigious, alternative to a
wood burning fireplace. Welcome to a Family of tens of thousands of satisfied Superior
Fireplace Owners.
Please read and carefully follow all of the instructions found in this manual. Please pay
special attention to the safety instructions provided in this manual. The Homeowner's
Care and Operation Instructions included here will assure that you have many years of
dependable and enjoyable service from your Superior product.
INTRODUCTION
The millivolt appliances are designed to oper-
ateon either naturalor propanegas. A millivolt
gas control valve with piezo ignition system
provides safe, efficient operation.
The electronic appliances are designed to op-
erate on either natural or propane gas. An
electronic intermittent pilot system provides
safe, efficient operation. External electrical
power is required to operate these units.
Installation must conform to local codes. In
the absence of local codes, installation must
comply with the current National Fuel Gas
Code, ANSI Z223.1 (NFPA 54). (In Canada, the
currentCAN/CGAB149installationcode.) Elec-
trical wiring must comply with local codes. In
the absence of local codes, installation must
be in accordance with the National Electrical
Code, NFPA 70 - (latest edition). (In Canada,
thecurrentCSAC22.1CanadianElectricCode.)
DO NOT ATTEMPT TO ALTER OR MODIFY
THE CONSTRUCTION OF THE APPLIANCE OR
ITS COMPONENTS. ANY MODIFICATION OR
ALTERATION MAY VOID THE WARRANTY,
CERTIFICATIONANDLISTINGSOFTHISUNIT.
GENERAL INFORMATION
Note: Installation and repair should be per-
formedby aqualified serviceperson.The appli-
ance should be inspected annually by a quali-
fied professional service technician. More fre-
quent inspections and cleanings may be re-
quired due to excessive lint from carpeting,
bedding material, etc. It is imperative that the
control compartment, burners and circulating
airpassagewaysofthe appliancebe keptclean.
S'assurer que le brùleur et le compartiment
des commandes sont propres. Voir les in-
structions d'installation et d'utilisation qui
accompagnent l'apareil.
Provide adequate clearances around air open-
ings and adequate accessibility clearance for
service and proper operation. Never obstruct
the front openings of the appliance.
Duetohightemperaturestheappliance should
be located out of traffic and away from furni-
ture and draperies. Locate furniture and win-
dow coverings accordingly.
Nominal operating pressures for the manifold
side of the gas control system are; 3.5 inches
water column (6.54 MmHg) for natural gas
models and 10 inches water column (18.69
MmHg) for propane gas models.
Do not use these appliances if any part has
beenunder water.Immediately call aqualified,
professional service technician to inspect the
appliance and to replace any parts of the
control system and any gas control which
have been under water.
Ne pas se servir de cet appareil s'il a étéplongé
dans l'eau, complètement ou en partie. Appeler
untechnicienqualifiépour inspecter l'appareilet
remplacertoute partiedu systèmede contrôleet
toute commande qui ont étéplongés dans l'lau.
Table 1 shows the units' factory-installed
gasorificesizeforinstallationsat elevations
of 0-2000 feet (0-610 meters).
Table 1
These appliances comply with National Safety
StandardsandaretestedandlistedbyWarnock
Hersey (Report No. J20046562) to ANSI ANSI
Z21.50 - 2000 (in Canada, CSA 2.22 - 2000),
and CAN/CGA-2.17-M91 in both USA and
Canada, as vented gas fireplaces.
CHG DRG seireS
ezisecifirO noitavelE teeF )sretem(
.taN.porP
0055 34#45# 0002-0 )016-0(

3
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Millivolt appliances may be fitted at time of
manufacture with either a Robertshaw millivolt
gascontrol valve orRobertshaw electronic gas
control valve. Both valves have been tested
with and approved for use with these appli-
ances and are listed accordingly.
A ¹⁄₈" NPT test gage connection is provided on
either gascontrol valveadjacent tothe outlet to
the main burner.
Minimuminlet gaspressure tothe applianceis
4.5 inches water column (8.55 MmHg) for
naturalgasand11incheswatercolumn(20.55
MmHg) for propane for the purpose of input
adjustment.
Maximum inlet gas supply pressure to the
appliance is 10.5 inches water column (19.95
MmHg) for natural gas and 13.0 inches water
column (24.25 MmHg) for propane.
The appliance must be isolated from the gas
supply piping system (by closing its individual
manualshut-off valve) duringany pressure test-
ing of the gas supply piping system at test
pressures equal to orless than ¹⁄₂ psig(3.5 kPa).
The appliance and its individual shut-off valve
must be disconnected from the gas supply
piping system during any pressure testing of
that system at pressures in excess of ¹⁄₂ psig
(3.5 kPa).
These appliances must not be connected to a
chimney or flue serving a separate solid fuel
burning appliance.
WARNING: FAILURE TO COMPLY WITH
THEINSTALLATION ANDOPERATINGIN-
STRUCTIONS PROVIDED IN THIS DOCU-
MENTWILLRESULTIN ANIMPROPERLY
INSTALLED AND OPERATING APPLI-
ANCE, VOIDING ITS WARRANTY. ANY
CHANGE TO THIS APPLIANCE AND/OR
ITS OPERATING CONTROLS IS DANGER-
OUS. IMPROPERINSTALLATIONORUSE
OF THIS APPLIANCE CAN CAUSE SERI-
OUS INJURY OR DEATH FORM FIRE,
BURNS, EXPLOSION OR CARBON MON-
OXIDE POISONING.
Carbon Monoxide Poisoning: Early signs of
carbon monoxide poisoning are similar to
the flu with headaches, dizziness and/or
nausea. If you have these signs, obtain fresh
air immediately. Turn off the gas supply to
the appliance and have it serviced by a
qualified professional, as it may not be op-
erating correctly.
WARNING: B-VENTAPPLIANCESARENOT
DESIGNED TO OPERATE IN NEGATIVELY
PRESSUREDENVIRONMENTS(PRESSURE
WITHIN THE HOME IS LESS THAN PRES-
SURES OUTSIDE). SIGNIFICANT NEGA-
TIVELY PRESSURED ENVIRONMENTS
CAUSED BY WEATHER, HOME DESIGN,
OR OTHER DEVICES MAY IMPACT THE
OPERATION OF THESE APPLIANCES.
NEGATIVE PRESSURES MAY RESULT IN
POOR FLAME APPEARANCE, SOOTING,
DAMAGE TO PROPERTY AND/OR SEVERE
PERSONAL INJURY. DO NOT OPERATE
THESEAPPLIANCESINNEGATIVELYPRES-
SURED ENVIRONMENTS.
WARNING: CHILDREN AND ADULTS
SHOULD BE ALERTED TO THE HAZARDS
OFHIGHSURFACETEMPERATURES.USE
CAUTION AROUND THE APPLIANCE TO
AVOID BURNS OR CLOTHING IGNITION.
YOUNG CHILDREN SHOULD BE CARE-
FULLY SUPERVISED WHEN THEY ARE IN
THE SAME ROOM AS THE APPLIANCE.
WARNING: DO NOT PLACE CLOTHING
OR OTHER FLAMMABLE MATERIALS
ON OR NEAR THIS APPLIANCE.
AVERTISSEMENT: SURVEILLER LES
ENFANTS. GARDER LES VÊTEMENTS,
LESMEUBLES,L'ESSENCEOUAUTRES
LIQUIDES ÀVAPEUR INFLAMMABLES
LIN DE L'APPAREIL.
Figure 2
Figure 1
GHC-5500
OPERATION AND CARE OF YOUR
APPLIANCE
Applianceoperationmustbecontrolledthrough
a remotely located wall switch (factory-sup-
plied). Separate switches may provide inde-
pendent control for the remote controlled fire-
place operation (optional equipment).
Gas Controls/Control Compartment
Access
See Figure 1 for the location of the gas control
valve and piezo ignitor (millivolt units) .
Control Compartment Access - GRD-5500
Units
The lower control compartment access panel
has been designed to cover the control com-
partment from view. Lighting instructions are
displayed on the back side of the cover for easy
reference. To attach the panel to the appliance,
hook both ends of the panel over the two
brackets mounted on each side of the front
combustion opening. The cover should hang
from the brackets with the flared edge at the
bottom allowing for a small air gap between the
cover and the appliance. To remove, lift the
panel and pull away from the unit.
ControlCompartmentAccess-GHC-5500Units
The GHC lower control compartment access is
provided by removing the three louvers .
To remove the louvers, pull them straight out
from the unit. To replace, tilt each of them with
the top edge over the top of each peg and snap
the lower edge to lock in place.
See Figure 2.
Piezo
Ignitor
Millivolt
Gas Valve
Louver
Pegs Louvers

4NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
CAUTION: DO NOT ATTEMPT TO TOUCH THE
DOORSWITHYOURHANDSWHILETHEFIRE-
PLACE IS IN USE. ALWAYS USE DOOR
HANDLES. DOORS WILL BECOME VERY HOT
WHEN FIREPLACE IS IN USE.
Figure 4
Figure 3
2. Keep lower control compartment clean by
vacuuming or brushing at least twice a year.
More frequent cleaning may be required due
to excessive lint from carpeting, bedding ma-
terials, etc. It is important that control com-
partments, burners and circulating air pas-
sageways of the appliance be kept clean.
3. Always turn off gas to the pilot (millivolt
appliances)before cleaning.Before re-lighting,
refer to the lighting instructions in this manual.
Appliance lighting instructions may also be
found on the pull-out label located near the
gas valve in the control compartment.
4. Always keep the appliance area clear and
free from combustible materials, gasoline and
other flammable liquids.
5. Remember, Millivolt appliances have a con-
tinuous burning pilot flame. Exercise caution
when using products with combustible vapors.
6. Clean the optional glass doors only when
necessary. Wipe surface with clean, damp-
ened, soft cloth. Follow with dry, soft towel as
desired. Take care not to scratch the glass
surface.
Operation of millivolt and electronic gas con-
trol systems are different. Before lighting and
operatingyourappliancedetermineifyouhave
a millivolt or electronic appliance. Millivolt
appliances will be fitted with the gas control
valve shown in Figure 3. Appliances with
electronic systems will be fitted with the elec-
tronic valve shown in Figure 4. Familiarize
yourself with the differing controls for the
valve your appliance uses.
Millivolt Appliance Lighting
To light millivolt appliances refer to the de-
tailed lighting instructions found in both En-
glish and French on pages 10 and 11 of these
instructions respectively. Appliance lighting
instructions may also be found on the pull-
out label located near the gas valve in the
control compartment. Refer to Figure 1 for
the piezo ignitor location used with your
appliance.
Your appliance comes supplied with remote
wall switch or can be used with an optional
remote control kit. The appliance main burner
may be turned on and off with the wall switch
or remote control.
Electronic Appliance Lighting
To light electronic appliances refer to the de-
tailed lighting instructions found in both En-
glish and French on
pages 12 and 13 of these
instructions respectively. Appliance lighting
instructions may also be found on the pull-
out label located near the gas valve in the
control compartment.
Your appliance comes supplied with remote
wall switch or can be used with an optional
remote control kit. The appliance main burner
may be turned on and off with the wall switch
or remote control.
1. When lit for the first time, this appliance will
emit a slight odor for an hour or two. This is
due to the “burn-in”of internal paints and
lubricants used in the manufacturing process.
WARNING: FIREPLACES EQUIPPED
WITH OPTIONAL ACCESSORY DOORS
SHOULDBE OPERATED ONLYWITHTHE
DOORSFULLY OPENORFULLYCLOSED
(FIGURE 5 ). THIS APPLIANCE MAY
ONLY BE FITTED WITH DOORS CERTI-
FIED FOR USE WITH THE APPLIANCE.
Appliances may be installed with an outside
(make-up air) vent system that is designed to
provide the appliance with outside make-up
air for combustion when in operation. The
shut-off lever for the outside air system is
standard on all appliances but should not be
operated if the complete system is not in-
stalled. Refer to Figure 6 for GHC/GRD-5500
series units.
Thehand operated shut-off lever islocated in the
left side of the fireplace opening behind the
screen. To open, pull all the way. The outside air
damper should be fully open when the fireplace
is in use and completely closed when the fire-
placeis not being used. Thiswill prevent outside
cold air from entering the dwelling.
Figure 5
Outside Combustion Air Controls
Combustion Air Control Lever
on GHC/GRD-5500 Series Units
Figure 6
WARNING: DO NOT OPERATE THE
SHUTOFF LEVER UNLESS A COMPLETE
OUTSIDE AIR VENT SYSTEM HAS BEEN
INSTALLED WITH YOUR APPLIANCE.
WARNING: DO NOT USE ABRASIVE
CLEANERS. NEVER CLEAN THE GLASS
WHEN IT IS HOT.
AVERTISSEMENT: POUR UTILISATION
UNIQUEMENT AVEC LES PORTES EN
VERRE CERTIFIÊES AVEC L'APPAREIL.
CONTROL KNOB
MILLIVOLT GAS CONTROL VALVE
M
C
P
O N
O F F
ON/OFF SWITCH
ELECTRONIC GAS CONTROL VALVE
Glass Doors
Fully Open or
Fully Closed
(Bi-Fold Doors)
Combustion Air Control Lever

5
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
WARNING: AIR SHUTTER ADJUSTMENT
SHOULD ONLY BE PERFORMED BY A
QUALIFIED PROFESSIONAL SERVICE
TECHNICIAN.
Figure 8
Maintenance
The appliance and venting system should be
thoroughly inspected before initial use and at
least annually by a qualified service techni-
cian. Propermaintenance and usewill require
more frequent, less extensive inspections and
servicing by the homeowner.
Generally, annual inspections should be per-
formedbyaqualifiedservicetechnician. More
frequent periodic inspections and cleanings
should be performed by the homeowner. Any
discrepancies discovered by the homeowner
should result in a call to a qualified service
technician to effect the repair or correction.
Refer to the maintenance schedule for mainte-
nance tasks, procedures, periodicity and by
whom they should be performed.
IMPORTANT: TURNOFFGASANDANYELEC-
TRICAL POWER BEFORE SERVICING THE
APPLIANCE.
MANUALLY-RESET BLOCKED FLUE SAFETY
SWITCH
This appliance is equipped with a manually-
reset blocked flue safety switch. Refer to
Figure 7 for its location. If during appliance
operation, the flame goes out (independently
of the burner on/off wall switch), it may be due
to the operation of this safety limit switch.
First allow the appliance to cool. Then reset
the safety switch by pushing the red reset
button on the back of the switch.
CAUTION: THE ELECTRONIC APPLIANCE
SHOULD BE TURNED OFF BEFORE REMOV-
ING THE LIMIT SWITCH.
To access the safety limit switch reset button,
remove the two screws. Pull out limit switch
withlowvoltage wiresattached,push thereset
button, then reinstall the limit switch. At this
time turn the electronic appliance back on.
The appliance should then relight and remain
lit. If this does not occur, turn off the appli-
ance and call a qualified service technician.
Burner Adjustments
Flame Appearance and Sooting
Proper flame appearance is a matter of taste.
Generally most people prefer the warm glow of
a yellow to orange flame. Appliances operated
with air shutter openings that are too large, or
with long vertical vent runs, will exhibit flames
that are blue and transparent. These weak, blue
and transparent flames are termed anemic.
Adjustment
To adjust the flame, position the air shutter to
the nominal setting
(Figure 8 ). Allow the
burner to operate for at least 30 minutes.
Observe the flame continuously. If it appears
weak or sooty as previously described, adjust
the air shutter open or closed until desired
effect is achieved.
Orifice
Air Shutter
Burner Tube
Adjusting
Set Screw
Nominal Air Shutter Settings:
Natural Gas - Closed
Propane Gas - 1/6 in. (1.59 mm) Open
Figure 7
Limit Switch Screws
Manual Reset Limit Switch
Lintel
Extention
Firebox Wrapper
If the air shutter opening is too small sooting
may develop. Sooting is indicated by black
puffsdevelopingat thetipsof verylongorange
flames.Sootingresultsinblackdepositsform-
ing on the logs, appliance inside surfaces and
onexterior surfaces adjacentto thevent termi-
nation. Sooting is caused by incomplete com-
bustion in the flames and a lack of combustion
air entering the air shutter opening.
To achieve a warm yellow to orange flame with
an orange body that does not soot, the shutter
opening must be adjusted between these two
extremes.
No smoke or soot should be present. Reposi-
tion the log set if the flames impinge on any of
them.
If sooting conditions exist, the air shutter
opening on the main burner can be adjusted.
Normally, the more offsets in the vent system,
the greater the need for the air shutter to be
opened further.

6NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Periodically (After the Burning Season)
Maintenance Task Accomplishing Person Procedure
Cleaning Firebox Interior
Check Flame Patterns and Flame Height
Checking Vent System
Cleaning Optional Glass Doors
Homeowner
Homeowner
Homeowner
Homeowner
Carefullyremove logs, Rockwool and volcanic
stone if used. Vacuum out interior of the
firebox. Clean firebox walls and log grate.
Replace logs, Rockwool and volcanic stone as
detailed in this manual.
Refer to Figure 10 on page 7 and verify the
flame pattern and height displayed by the
appliance conforms to the picture. Flames
must not impinge on the logs.
Inspect the vent system at the top and at the
base (within the firebox) for signs of blockage
or obstruction. Look for any signs of disloca-
tion of the vent components.
Clean as necessary following the directions
provided in this manual. DO NOT TOUCH OR
ATTEMPT TO CLEAN DOORS WHILE THEY
ARE HOT.
Maintenance Schedule
Annually (Before the onset of the Burning Season)
Maintenance Task Accomplishing Person Procedure
Inspecting/Cleaning Burner, Logs
and Controls
Check Flame Patterns and Flame Height
Inspecting/Cleaning Pilot and Burner
Checking Vent System
Appliance Checkout
Replacing Rockwool Ember Materials
Qualified Service Technician
Qualified Service Technician
Qualified Service Technician
Qualified Service Technician
Qualified Service Technician
Homeowner/Qualified Services Technician
Inspect valve and ensure it is properly operat-
ing. Check piping for leaks. Vacuum the
controlcompartment,fireplacelogsandburner
area.
Refer to
Figure 10 on page 7 and verify the
flame pattern and height displayed by the
appliance conforms to the picture.
Refer to Figure 11 on page 7. Remove any
surface build-up on pilot and burner assem-
bly. Wipe the pilot nozzles, ignitor/flame rod
and hood. Ensure the pilot flame engulfs the
flame sensor as shown.
Inspect the vent system at the top and at the
base (within the firebox) for signs of blockage
or obstruction. Look for any signs of disloca-
tion of the vent components.
Perform the appropriate appliance checkout
procedure detailed in this manual.
Remove old ember materials and vacuum the
rockwoolplacementarea. Placenewrockwool
as described in this document.

7
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
WARNING: THE SIZE AND POSITION OF
THELOG SETWASENGINEEREDTOGIVE
YOUR APPLIANCE A SAFE, RELIABLE
ANDATTRACTIVEFLAMEPATTERN. ANY
ATTEMPTTO USE A DIFFERENT LOG SET
INTHEFIREPLACEWILLVOIDTHEWAR-
RANTY AND WILL RESULT IN INCOM-
PLETE COMBUSTION, SOOTING, AND
POOR FLAME QUALITY.
WARNING: LOGS GET VERY HOT AND
WILL REMAIN HOT UP TO ONE HOUR
AFTER GAS SUPPLY IS TURNED OFF.
HANDLE ONLY WHEN LOGS ARE COOL.
TURN OFF ALL ELECTRICITY TO THE
APPLIANCE BEFORE YOU INSTALL
GRATE AND LOGS.
WARNING: THIS APPLIANCE IS NOT
MEANT TO BURN WOOD. ANY ATTEMPT
TO DO SO COULD CAUSE IRREPARABLE
DAMAGE TO YOUR APPLIANCE AND
PROVE HAZARDOUS TO YOUR SAFETY.
Logs and Rockwool (Glowing Embers)
Placement
The logs are packaged within the firebox.
The bag of rockwool is in the lower control
compartment. Remove the rockwool from
the packaging and tear into dime size pieces
(Figure9) .Spread across the burner infront
of the front log. See Figure 10. Do not use
more than is necessary to cover the burner.
When properly positioned, the rockwool will
unevenly cover approximately 85% of the
front of the burner with no appreciable gaps.
Theseappliances areequipped with abeautifully
crafted four (4) piece ceramic fiber log set. The
logs, shown in
Figure 12 on page 8 , are to be
positioned precisely as shown. Any modifica-
tion to the to the lay of these logs may result in
sooting, property damage and injury or death.
Figure 9
Millivolt Appliance Checkout
The gas control system on these appliances is
a millivolt standing pilot type. It consists of a
pilotburner, a piezo ignitor, a gas control valve,
a burner assembly and an ON/OFF wall switch.
A temperature limit switch is wired in series
with the millivolt wall switch and gas control
valve. If a higher than normal temperature is
sensed due to a blocked vent or prolonged
downdraft, the limit switch will open and cause
the burner to shut off.
The pilot flame should be steady, not lifting or
floating. Flame should be blue in color with
traces of orange at the outer edge.
The top ³⁄₈" (9 mm) at the pilot generator
(thermopile) should be engulfed in the pilot
flame
(Figure 11).
Figure 11
If the pilot flame pattern is not as shown in
Figure 11 , adjust it as follows:
1. Remove the pilot adjustment cap located on
the main gas valve.
2. Adjust the pilot screw to provide properly
sized pilot flame
(Figure 10 ) . Turn counter
clockwise to enlarge pilot flame and clockwise
to reduce the pilot flame. DO NOT attempt to
adjust pilot flame more than one half turn.
3. Replace the pilot adjustment cap.
Replace logs if removed for pilot inspection.
To light the burner; rotate the gas valve control
knobcounterclockwisetothe“ON”positionand
then turn “ON”the remote wall switch.
Electronic Appliance Checkout
The gas control system on these appliances is
an electronic low voltage gas control valve with
an intermittent ignitor. It consists of a low
voltage gas control valve, an intermittent igni-
tionsystem,anelectroniccontrolmodule,trans-
former and a burner assembly. A temperature
limit switch is wired in series with the gas
control valve. If a higher than normal tempera-
ture is sensed, due to a blocked vent or pro-
longed downdraft, the limit switch will open
and cause the burner to shut off.
The pilot flame should be steady, not lifting or
floating. Flame should be blue in color with
traces of orange at the outer edge.
To light the burner, push the gas control lever
in and toward the left to the “ON”position.
Turn ‘ON’the remote wall switch. Ensure the
ignitor lights the pilot. The pilot flame should
engulf the ignitor.
WARNING: PILOT FLAME PATTERN
ADJUSTMENT SHOULD ONLY BE PER-
FORMED BY A QUALIFIED PROFES-
SIONAL SERVICE TECHNICIAN.
Figure 10
³⁄₈" (10 mm)
Rockwool

8NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Carefully position and center the fiber logs
onto the burner grate with the longer log in
front and the shorter log all the way to the
backofthefireplace.Placethetwo(2)smaller
fiber logs across the two (2) lower logs in the
manner illustrated (Figures 12 ) .
CAUTION: THESE CERAMIC FIBER LOGS
MUST BE HANDLED CAREFULLY. THEY
WILL STAND UP INDEFINITELY TO EX-
TREMETEMPERATURES.HOWEVER,THEY
ARE VERY FRAGILE AND ARE SUSCEP-
TIBLE TO CRUSHING AND/OR BREAKAGE
IF HANDLED ROUGHLY.
Figure 12
GHC/GRD-5500
LOG PLACEMENT
a
b
d
c
.oNNOITPIRCSED.oNtraP
)etelpmoC(teSgoL1073M31
.amottoB,raeR,goL1003M31
.bmottoB,tnorF,goL1013M31
.ctfeL,poT,goL1023M31
.dthgiR,poT,goL1033M31

9
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
WIRING DIAGRAMS
Wiring diagrams are provided here for refer-
ence purposes only. This information is also
provided on schematics attached directly to
the appliance on a pullout panel located within
the control compartment.
CAUTION: LABEL ALL WIRES PRIOR TO DIS-
CONNECTION WHEN SERVICING CONTROLS.
WIRINGERRORSCANCAUSEIMPROPERAND
DANGEROUS APPLIANCE OPERATION.
Electronic System Wiring
(Without Forced Air Kit)
Electronic System Wiring
(With Forced Air Kit)
WARRANTY
Your gas appliance is covered by a limited
twenty year warranty. You will find a copy of
the warranty accompanying this manual.
Please read the warranty to be familiar with its
coverage.
Retain this manual. File it with your other
documents for future reference.
Normally, all parts should be ordered through
your distributor or dealer. Parts will be shipped
at prevailing prices at time of order.
If you encounter any problems or have any
questions concerning the installation or appli-
cation of this system, please contact your dis-
tributor, or LHP directly:
LHP
1110 West Taft Avenue
Orange, CA 92865
PRODUCT REFERENCE INFORMATION
We recommend that you record the following
important information about your fireplace.
Please contact your dealer for any questions
or concerns. For the number of your nearest
dealer, please call 800-731-8101
REPLACEMENT PARTS
A complete parts list is found at the end of this
manual. Use only parts supplied from the
manufacturer.
Your Fireplace's Model Number _______________________________________
Your Fireplace's Serial Number ________________________________________
The Date On Which Your Fireplace Was Installed __________________________
The Type of Gas Your Fireplace Uses ___________________________________
Your Dealer's Name_________________________________________________
When ordering repair parts, always give the
following information:
1. The model number of the appliance.
2. The serial number of the appliance.
3. The part number.
4. The description of the part.
5. The quantity required.
6. The installation date of the appliance.
Electronic System Wiring
(Without Forced Air Kit)
Limit
Switch
Thermopile
ON/OFF Wall
Switch
TH
TP TH
TP
1. If any of the original wire as supplied must be replaced,
1. it must be replaced with Type AWM 105°C –18 GA. wire.
2. 120V, 60Hz –Less than 3 amps.
LIMIT SW. ON/OFF SW
GND
Ignitor
Junction Box
Transf.
120 V.
W
BK
Gas Valve
MC
BL
BK
24 V
MV
TH
TR
GND
PV
IGN
Ignition Control
Factory Wired Field Wired
P
PV/MV
GND
WBL
BK W
GHC/GRD-5500
Robertshaw Ignition Control Equipped
24V
LOW
VOLTAGE
120 VAC
BK
BK W
GHC Series Only
Green
Ground
Screw
R
BK
R
1. If any of the original wire as supplied must be replaced,
1. it must be replaced with Type AWM 105°C –18 GA. wire.
2. 120V, 60Hz –Less than 3 amps.
LIMIT SW ON/OFF SW
GND
W
Ignitor
Junction Box
Transf.
120 V.
W
BK
Gas Valve
MC
BL
BK
24 V
MV
TH
TR
GND
PV
IGN
Ignition Control
Factory Wired Field Wired
P
PV/MV
GND
WBL
BK
W
GHC-5500
Robertshaw Ignition Control Equipped
24V
LOW
VOLTAGE
120 VAC
BK
BK
Opt
Blower
WALL BLOWER SW
BK
Green
Ground
Screw
Appliance
Ground
Screw
R
BK
R
1. If any of the original wire as supplied must be replaced,
1. it must be replaced with Type AWM 105°C –18 GA. wire.
2. 120V, 60Hz –Less than 3 amps.
LIMIT SW ON/OFF SW
120 VAC. BK
GND
NEU. W
Ignitor
Junction Box
Transf.
120 V.
W
BK
Gas Valve
MC
BK
24 V
MV
24V
GND
PV
Ignition Control
Factory Wired Field Wired
P
PV/MV
G
BL
BK
W
GHC/GRD-5500
(Honeywell Ignition Module Equipped)
24V
Low Voltage
BK
GND
(Burner)
24V
TH-W
(OPT.)
SPARK
W
BL
R
Green
Ground
Screw
BK
R

10 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
LIGHTING INSTRUCTIONS –MILLIVOLT GAS VALVE
WARNING:IFYOUDONOTFOLLOWTHESEINSTRUCTIONSEXACTLY,AFIREOREXPLOSION
MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
FOR YOUR SAFETY READ BEFORE LIGHTING
A. This appliance has a pilot which must be lighted with a piezo
ignitor. When lighting the pilot, follow these instructions
exactly.
B. BEFORE OPERATING smell all around the appliance area for
gas. Be sure to smell next to the floor because some gas is
heavier than air and will settle on the floor.
WHAT TO DO IF YOU SMELL GAS
•Extinguish any open flame.
•Open windows.
•Do not light any appliance.
•Do not touch any electrical switches.
TO TURN OFF GAS TO APPLIANCE
1. Turn remote wall switch “OFF.”The pilot will remain lit for
normal service.
2. For complete shutdown, turn remote wall switch to “OFF.”
3. Access the lower control compartment.
4. Depress gas control knob slightly and turn clockwise
to “OFF.”Do not force.
5. Close lower control compartment.
LIGHTING INSTRUCTIONS
1. STOP! Read the safety information above on this page.
2. Access the lower control compartment.
3. Turn remote wall switch to “OFF.”
4. Verify main line shut-off valve is open.
5. Push in gas control knob slightly and turn clockwise
to “OFF.”
6. Wait five (5) minutes to clear out any gas. If you then smell gas,
STOP! Follow “B”in the safety information above on this page. If you
do not smell gas, go to the next step.
7. Push in gas control knob slightly and turn counterclockwise
to “PILOT.”
8. Push in control knob all the way and hold in. Immediately light the
pilot by triggering the spark ignitor (pushing the button) until pilot
lights. Continue to hold the control knob in for about 1 ¹⁄₂ minutes
after the pilot is lit. Release knob and it will pop back up. Pilot should
remain lit. If it goes out, repeat steps 5 through 8.
•If knob does not pop up when released,
stop and immediately call your service
technician or gas supplier.
•If pilot will not stay lit after several
tries, turn the control knob to “OFF”
and call your service technician or
gas supplier.
9. Turn gas control knob counterclockwise
to “ON.”
10. Close lower control compartment.
•Do not use any phone in your building.
•Immediately call your gas supplier from a neighbor’s phone.
•If your gas supplier cannot be reached, call the fire depart-
ment.
C. Use only your hand to push in or turn the gas control knob.
Never use tools. If the knob will not push in or turn by hand,
do not try to repair it, call a qualified service technician. Force
or attempted repair may result in a fire or an explosion.
D. Do not use this appliance if any part has been under water.
Immediately call a qualified service technician to inspect the
appliance and to replace any part of the control system and
any gas control which has been under water.
Note: Knob cannot be turned from “PILOT”to “OFF”
unless the knob is pushed in slightly. Do not force.
CONTROL KNOB

11
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
INSTRUCTIONS D’ALLUMAGE –VANNE GAZ MILLIVOLT
INSTRUCTIONS D'ALLUMAGE
AVERTISSEMENT : SI VOUS NE SUIVEZ PAS CES INSTRUCTIONS ÀLA LETTRE, IL POURRAIT S’EN SUIVRE UN INCENDIE OU UNE
EXPLOSION CAUSANT DES DOMMAGES MATÉRIELS, DES BLESSURES CORPORELLES OU MÊME DES PERTES DE VIE.
POUR VOTRE SÉCURITÉ, LISEZ CES INSTRUCTIONS AVANT L’ALLUMAGE
A. Cet appareil est muni d’une veilleuse qui doit être allumée avec un
allumeur piézo-électrique. Lorsque vous allumez la veilleuse, suivre
exactement ces instructions.
B. AVANT L’ALLUMAGE: Assurez-vous que vous ne détectez aucune
odeurde gazautour de l’apareil ainsi queprès dusol; certains gaz, étant
plus lourds que l’air, descendent au niveau du sol.
VOICI CE QUE VOUS DEVEZ FAIRE SI VOUS DÉCELEZ UNE ODEUR
DE GAZ:
•Éteignez toute flamme visible.
•Ouvrez les fenêtres.
•N’allumez aucun appareil.
•Ne touchez àaucun commutateur électrique.
•Ne vous servez d’aucun téléphone dans votre édifice.
•Appelezimmédiatementvotrecompagniedegazenutilisantletéléphone
du voisin.
•S’il vous est impossible de contacter votre compagnie de gaz, appelez
le service des incendies.
C. N’utilisez que votre main pour manipuler le bouton de réglage du gaz.
N’utilisez jamais d’outils. Si le bouton refuse de tourner ou de bouger,
n’essayez pas de le réparer. Communiquez immédiatement avec un
technicien de service qualifié. Toute tentative pour le forcer ou le
réparer, risquerait de provoquer un incendie ou une explosion.
D. Ne vous servez pas de cet appareil si l’un de ses éléments a été
immergédans l’eau. Appelez immédiatement un technicien compétent
pour faire inspecter l’appareil et remplacer toute pièce du système de
réglage ou commande du gaz qui a étésous l’eau.
1. Tournez l’interrupteur mural àla position d’arrêt “OFF”. La veilleuse
restera allumée jusqu’au retour du service normal.
2. Pour une fermeture complète, tournez l’interrupteur mural àla
position d’arrêt “OFF”.
3. Ouvrez le compartiment de contrôle du bas.
POUR FERMER LE GAZ QUI ALIMENTE L’APPAREIL
4. Enfoncez légèrement le bouton de réglage du gaz et tournez-le dans
le sens des aiguilles d’une montre jusqu’à la position
d’arrêt “OFF”. Ne forcez pas le bouton.
5. Fermez le compartiment de contrôle du bas.
8. Enfoncez le bouton de réglage jusqu’au fond et gardez-le enfoncé.
Allumez immédiatement la veilleuse en déclenchant l’allume-gaz à
étincelle (en poussant le bouton) jusqu’à ce que la veilleuse
s’enflamme. Continuez de tenir le bouton de réglage enfoncé
pendant environ 90 secondes après l’allumage de la veilleuse.
Relâchez le bouton et il sortira subitement. La veilleuse devrait
rester allumée. Si elle s’éteint, répétez les étapes 5 à8
inclusivement.
•Si le bouton ne sort pas automatiquement après avoir étérelâché,
arrêtez immédiatement et téléphonez àvotre technicien de service
ou àvotre fournisseur de gaz.
•Si la veilleuse refuse de rester
allumée après plusieurs tentatives,
tournez le bouton de réglage jusqu’à
sa position d’arrêt “OFF”et
téléphonez àvotre technicien de
service ou àvotre fournisseur de gaz.
9. Tournez le bouton de réglage du gaz
en sens inverse des aiguilles d’une
montre jusqu’à sa
position de marche “ON”.
10. Fermez le compartiment de contrôle
du bas.
11. Au besoin, rebrancher l’appareil au courant électrique et remettre
l’interrupteur du brûleur principal àla position “ON”ou régler le
thermostat àla température désirée.
12. Si l’appareil ne fonctionne pas, suivre les instructions intitulées
“Pour fermer le gaz qui alimente l’appareil”et appeler un
technicien ou le fournisseur de gaz.
6. Attendez cinq (5) minutes pour l’evacuation du gaz. Si vous décelez
une odeur de gaz, ARRÊTEZ ! Retournez au point “B”des consignes
de sécuritéau verso de cette plaque. Si vous ne remarquez aucune
odeur de gaz, passez àl’étape suivante.
7. Enfoncez légèrement le bouton de réglage du gaz et tournez-le en
sens inverse des aiguilles d’une montre jusqu’à la position de
veilleuse “PILOT”.
1. ARRÊTEZ! Lisez les consignes de sécuritéau verso de cette plaque.
2. Ouvrez le compartiment de contrôle du bas.
3. Tournez l’interrupteur mural àla position d’arrêt “OFF”.
4. Assurez-vous que la soupape d’arrêt de la canalisation principale est
ouverte.
5. Enfoncez légèrement le bouton de réglage du gaz et tournez-le dans
le sens des aiguilles d’une montre jusqu’à la position
d’arrêt “OFF”.
Remarque: Il est impossible de tourner le bouton de
“PILOT”à“OFF”àmoins qu’il ne soit légèrement enfoncé.
Ne le forcez pas.
Le Bouton de Réglage du Gaz

12 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
WARNING:IFYOUDONOTFOLLOWTHESEINSTRUCTIONSEXACTLY,AFIREOREXPLOSION
MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
A. When lighting the appliance, follow these instructions
exactly.
B. BEFORE OPERATING smell all around the appliance area
for gas. Be sure to smell next to the floor because some
gas is heavier than air and will settle on the floor.
WHAT TO DO IF YOU SMELL GAS
•Extinguish any open flame.
•Open windows.
•Do not light any appliance.
•Do not touch any electrical switches.
•Do not use any phone in your building.
FOR YOUR SAFETY READ BEFORE LIGHTING
•Immediately call your gas supplier from a neighbor’s
phone.
•If your gas supplier cannot be reached, call the fire
department.
C. Use only your hand to turn the gas control lever. Never
use tools. If the lever will not turn by hand, do not try to
repair it, call a qualified service technician. Force or
attempted repair may result in a fire or an explosion.
D. Do not use this appliance if any part has been under
water. Immediately call a qualified service technician to
inspect the appliance and to replace any part of the
control system and any gas control which has been
under water.
LIGHTING INSTRUCTIONS —ELECTRONIC
1. For complete shut-down, turn remote wall switch to
“OFF.”
2. Open lower control compartment door.
3. Push in gas control lever slightly and turn to “OFF”. Do
not force.
4. Close the main line shut-off valve.
5. Close lower control compartment door.
TO TURN OFF GAS TO APPLIANCE
LIGHTING INSTRUCTIONS
1. STOP! Read the safety information above on this page.
2. Turn remote wall switch to “OFF.”
3. Open lower control compartment door.
4. Verify main line shut-off valve is open.
5. Push in gas control lever slightly and turn to “OFF”. Do
not force.
6. Wait five (5) minutes to clear out any gas. If you then
smell gas, STOP! Follow “B”in the safety information
above on this page. If you do not smell gas, go to the
next step.
7. Push in gas control lever slightly and turn to “ON”. Do
not force.
8. Turn “ON”all electrical power to appliance (remote wall
switch).
9. Close lower control compartment door.
TO SHUT OFF
1. Turn off all electrical power to the appliance (remote wall
switch).
Note: Lever cannot be turne to "OFF" unless
lever is pushed in slightly. Do not force.
M
C
P
O N
O
F F
ON/OFF SWITCH

13
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
INSTRUCTIONS D’ALLUMAGE —ELECTRONIC
INSTRUCTIONS D’ALLUMAGE
POUR VOTRE SÉCURITÉ, LISEZ CES INSTRUCTIONS AVANT L’ALLUMAGE
A. Lorsquevousallumezl’appareil,suivezexactementcesinstruc-
tions.
B. AVANT L’ALLUMAGE: Assurez-vous que vous ne détectez
aucune odeur de gaz autour de l’apareil ainsi que près du sol;
certains gaz, étant plus lourds que l’air, descendent au niveau
du sol.
VOICI CE QUE VOUS DEVEZ FAIRE SI VOUS DÉCELEZ UNE
ODEUR DE GAZ
•Éteignez toute flamme visible.
•Ouvrez les fenêtres.
•N’allumez aucun appareil.
•Ne touchez àaucun commutateur électrique.
•Ne vous servez d’aucun téléphone dans votre édifice.
AVERTISSEMENT: SI VOUS NE SUIVEZ PAS CES INSTRUCTIONS ÀLA LETTRE, IL POURRAIT S’EN SUIVRE UN INCENDIE OU
UNE EXPLOSION CAUSANT DES DOMMAGES MATÉRIELS, DES BLESSURES CORPORELLES OU MÊME DES PERTES DE VIE.
•Appelezimmédiatementvotre compagnie de gaz en utilisant
le téléphone du voisin.
•S’il vous est impossible de contacter votre compagnie de
gaz, appelez le service des incendies.
C. N’utilisez que votre main pour manipuler l’interrupteur “ON/
OFF”de la valve àgaz. N’utilisez jamais d’outils. Si
l’interrupteur ne bouge pas manuellement, n’essayez pas de le
réparer. Communiquez immèdiatement avec un technicien de
service qualifié. Toute tentative pour forcer l’interrupteur ou le
réparer, risquerait de provoquer un incendie ou une explosion.
D. Ne vous servez pas de cet appareil si l’un de ses éléments a été
immergédans l’eau. Appelez immédiatement un technicien
compétent pour faire inspecter l’appareil et remplacer toute
piècedusystèmederéglageoucommandedugazquiaétésous
l’eau.
1. ARRÊTEZ ! Lisez les consignes de sécuritéau verso de cette
plaque.
2. Tournez l’interrupteur mural àla position d’arrêt “OFF”.
3. Ouvrez la porte du compartiment de contrôle du bas.
4. Assurez-vousquelasoupaped’arrêtdelacanalisationprincipale
est ouverte.
5. Enfoncez légèrement la manette de réglage du gaz et tournez àla
position d’arrêt “OFF”.
6. Attendez cinq (5) minutes pour l’evacuation du gaz. Si vous
décelez une odeur de gaz ARRÊTEZ ! Retournez au point “B”des
consignes de sécuritéau verso de cette plaque. Si vous ne
remarquez aucune odeur de gaz, passez àl’étape suivante.
7. Enfoncezettournezlamanettederéglagedugazjusqu’àlaposition
de marche “ON”. Ne la forcez pas.
8. Ouvrez le courant électrique (“ON”) qui alimente l’appareil
(interrupteur mural).
9. Fermez la porte du compartiment de contrôle du bas.
10. Au besoin, rebrancher l’apareil au courant électrique et
remettre l’interrupteur principal du brûleur àla position “ON”
ou régler le thermostat àla température désirée.
11. Si l’appareil ne se met pas en marche, suivre les instructions
intitulées “Pour fermer le gaz qui alimente l’appareil”et appeler
un technicien ou le fournisseur de gaz.
POUR ÉTEINDRE L’APPAREIL
1. Coupeztoutlecourantélectriquequialimentel’appareil(interrupteur
mural).
POUR FERMER LE GAZ QUI ALIMENTE L’APPAREIL
3. Enfoncez légèrement la manette de réglage du gaz et tournez àla
position d’arrêt “OFF”.
4. Fermez la soupape d’arrêt de la canalisation principale.
5. Fermez la porte du compartiment de contrôle du bas.
1. Pour une fermeture complète, tournez l’interrupteur mural àla
position d’arrêt “OFF”.
2. Ouvrez la porte du compartiment de contrôle du bas.
Remarque: Il est impossible de tourner la manette à“OFF”à
moins qu’il ne soit légèrement enfoncé. Ne le forcez pas.
M
C
P
O N
O
F F
Interrupter
ON/OFF

14 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
TROUBLESHOOTING THE MILLIVOLT GAS CONTROL SYSTEM
Note: Before troubleshooting the gas control system, be sure external gas shut off valve (located at gas supply inlet) is in
the “ON”position.
Important: Valve system troubleshooting should only be accomplished by a qualified service technician.
CORRECTIVE ACTION
SYMPTOM
A. Defective Ignitor
(no spark at electrode)
B. Defective or misaligned
electrode at pilot (spark at
electrode).
C. Gas supply pressure errant.
D. Pilot orifice plugged.
A. Defective pilot generator
(thermopile) or remote wall
switch wiring.
B. Defective automatic valve
operator.
C. Defective limit switch.
A. Wall switch or wires
defective.
B. Pilot generator may not be
generating sufficient
millivoltage.
C. Plugged burner orifice.
A. Pilot flame may be too low or
blowing (high) causing the pilot
safety to drop out.
Check for spark at electrode and pilot; if no spark and electrode wire
is properly connected, replace the ignitor.
Using a match, light pilot. If pilot lights, turn off pilot and trigger the
red button again. If pilot lights an improper gas mixture caused the
bad lighting and a longer purge period is recommended. If pilot will
not light check gap at electrode and pilot - should be ¹⁄₈"
(3 mm) to have a strong spark. If gap measures ¹⁄₈", replace pilot
assembly
(Figure 11 on page 7) .
Check inlet gas pressure. It should be within the limits as marked on
the rating plate.
Clean or replace pilot orifice.
Check pilot flame. It must impinge on pilot generator
(Figure 11 on
page 7) . Clean and/or adjust pilot for maximum flame impingement
on generator.
Be sure wire connections from generator at gas valve terminals are
tight and generator is fully inserted into the pilot bracket.
One of the wall switch wires may be grounded. Remove wall switch
wires from valve terminals. If pilot now stays lit, trace wall switch
wires for a ground. May be grounded to appliance or gas supply.
With pilot operating (lit), check pilot generator with a millivolt meter.
Take reading at generator terminals of gas valve. Should read 325
millivolts minimum while holding valve knob depressed in pilot
position and wall switch “OFF.”Replace faulty generator if reading
is below specified minimum.
Turn knob to “ON,”place wall switch to “ON.”Millivolt meter should
read greater than 100mV. If reading is OK and the burner does not
come on, replace the gas valve.
Reset the limit switch button. If still not working, isolate the limit
switch. Disconnect the wires from the “ON/OFF”switch and the valve
(label wires for reattachment). Test for continuity with a multimeter.
Ifcontinuity isnot indicated, switch is defectiveand mustbe replaced.
Check wall switch and wires for proper connections. Place jumper
wires across terminals at wall switch. If burner comes on, replace
defective wall switch. If OK, place jumper wires across wall switch
wires at gas valve. If burner comes on, wires are defective or
connections are bad.
Re-check Symptom #2.
Check burner orifice for blockage and remove.
Clean/adjust pilot flame for maximum impingement on pilot genera-
tor
(Figure 11 on page 7) .
POSSIBLE CAUSES
1. Spark ignitor will not
light pilot after repeated
triggering of red button.
2. Pilot will not stay lit
after carefully following
lighting instructions.
3. Pilot burning, no gas to
burner, valve knob “ON,”
wall switch “ON.”
4. Frequent pilot outage
problem.

15
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
TROUBLESHOOTING THE ELECTRONIC IGNITION SYSTEM
N ote: Before troubleshooting, be sure that the appliance main line gas shut-off valve, the gas control valve and the wall switch are in
the “ON”position.
Important: “ON/OFF”switch must be “OFF”before performing continuity test. Adjust multimeter to the ohm setting when performing continuity tests.
Important: Valve system troubleshooting should only be accomplished by a qualified service technician.
Confirm 24Vac output from transformer (red and blue leads). If no, then replace
transformer.
Note: Before replacing transformer check wiring for loose connections or broken wires
and repair as needed. Turn off power before replacing transformer.
Disconnect the two black wires from the two red wires attached to the limit switch and
transformer (label wires for correct reattachment). Test “ON/OFF”wall switch for
continuity with a multimeter. If continuity is not indicated, switch is defective and must
be replaced.
Note: Before replacing “ON/OFF”switch be sure to check switch wiring for loose
connections or broken wires and repair as needed.
Resetthelimitswitchbutton. Ifstillnotworking,isolatethelimit switch in the same manner
as the “ON/OFF”switch (label wires for correct reattachment) and test for continuity with
a multimeter. If continuity is not indicated, switch is defective and must be replaced.
If reading is not 24V at “TH”and “TR”terminals on ignition control, replace ignition
control module.
Check for availability of gas at control. Check that manual valve upstream of gas control
and manual valve on gas control are in the full “ON”position. Check for plugged pilot
orifice or plugged pilot tubing. Also check pilot key adjustment at gas control valve.
Confirm 24Vac at gas valve terminals “C”and “P”of the gas valve. If yes, valve is OK. If
no voltage, check the wiring. If wiring tests OK, check ignition control module.
Confirm24Vacat “PV”and “PV/MV”on ignition control module. If no,replacetheignition
control.
Check if pilot line and pilot orifice are plugged. Clean or replace as necessary. Adjust pilot
flame if necessary.
Confirm that the igniter is sparking at the pilot assembly when the “ON/OFF”switch is
activated. If not, undertake the following steps:
With“ON/OFF”switch “OFF,”remove wire at “TR”terminalat the ignition control module.
Disconnect the electrode wire “IGN”at the ignition control. Connect one end of a jumper
wire to the metal blade of a small screwdriver. Attach the other end of the jumper wire to
any metal part of the chassis. Reconnect the “TR”terminal. Position end of metal blade
approximately ¹⁄₈" (3 mm) from the “IGN”terminal. Activate the “ON/OFF”switch.
Sparking should occur between the “IGN”terminal and screwdriver blade. If sparking
does occur, the ignition control module is OK, but either the electrode wire of the igniter
is faulty and the pilot and electrode assembly should be replaced.
Electrode tip needs to be realigned to correct location. ³⁄₃₂" to ¹⁄₈" (2 –3 mm) gap between
electrode tip and pilot hood is desired.
Pilot and electrode igniter must be properly aligned so that the pilot flame impinges the
top ³⁄₄" (19 mm) of the electrode igniter. The electrode igniter must be pushed all the way
into the pilot bracket. Adjust pilot flame if necessary.
Check main burner orifice(s) for stoppage. Clean or replace.
Check for 24 volts at gas operator terminals “M”and “C.”If there is a 24V reading and the
burner does not come on, the valve operator is defective and the gas valve must be
replaced.
Adjust pilot flame and/or check location of electrode igniter.
SYMPTOM CORRECTIVE ACTION
1. No spark and no pilot gas.
2. Spark but no pilot gas
(no solenoid valve click).
3. Spark but no pilot gas
(solenoid valve click).
4. Pilot gas available, but
pilot does not light
(solenoid click).
5. Pilot burning but main
burners will not come on.
Note: Wait at least 90
seconds after pilot lights
before doing the checkout
for possible causes.
6. Burners come “ON”but go
“OFF.”
A. Faulty transformer.
B. “ON/OFF”switch defective.
C. Limit switch defective.
D. Ignitioncontrolmoduledefective.
A. No gas supplied to pilot valve.
B. Faulty gas valve.
C. Ignitioncontrolmoduledefective.
A. Gas supply to pilot restricted.
A. Ignition control or igniter
defective.
B. Sparking, but not at proper
location.
A. Low pilot flame or improper
alignment of electrode igniter in
pilot flame.
B. Burner orifice(s) plugged.
C. Gas valve defective.
A. Low pilot flame or electrode
igniter not correctly positioned.
POSSIBLE CAUSES

16 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
ACCESSORY COMPONENTS
Remote Control System (Standard) H0249 RCL
Standard Remote Control System
(Model RCL)
The Model RCL (Standard) Remote Control
System, features a simplistic on/off control
function for the fireplace. This model includes
a hand-held transmitter, a remote receiver
with wall-mount coverplate and all hardware
required to install the unit. The remote re-
ceiver can be wall or hearth mounted.
The transmitter has ON and OFF functions that
are activated by pressing either button on the
face of the transmitter. When a button on the
transmitter is pressed, a signal light illuminates
briefly to verify that a signal has been sent.
The Model RCL is designed to operate with all
millivolt ignition systems, as well as electronic
ignition systems. It may be installed with use for
either natural or propane gas appliances. The
RCL offers ease of installation and allows you to
execute on-off commands to the fireplace effort-
lessly with one simple motion.
The Model RCL comes complete with detailed
operating instructions.
Forced Air Kit 051331 FAB-1600
with Variable Speed Wall Switch
Forced Air Kit
Ifthe optional forcedair kits,Model FAK-1500or
ModelFAB-1600,aretobeusedontheGHC-5500
Series appliances, refer to the installation in-
structions packed with the fan kit. The GHC-
5500 Series appliances have been pre-wired at
the factory to accept the forced air kit at some
later time. The appliance, must however, be
connected to the main power supply at the time
ofinstallationiftheeitheroftheforced airkitsare
to be installed later. The FAB-1600 kit comes
with a variable speed wall switch.
Horizontal Trim Installation
There are two (2) optional horizontal trim kits,
Models 35HTK-PB, 35HTK-SPB available for
use with the GHC Series appliance. The 35
HTK-SPB kit's trim is solid polished brass, as
opposed to the 35HTK-PB kit's trim which has
a polished brass coating. Refer to the specific
installation instructions packed with each trim
kit for their proper usage and installation.
Horizontal Trim Kit 024477 35HTK-SPB
Horizontal Trim Kit 024474 35HTK-PB
Bi-Fold Doors 12M05 33ABF
12M06 33ABF-BB
Aluminum-Framed Bi-Fold Doors
Your appliance can be fitted with beautiful
aluminum-framed bi-fold doors. Model 33ABF
doors are available for use with these appli-
ances. Doors are easily fitted to the fireplace
opening. Model 33ABF doors come with stan-
dard black finish. Model 33ABF-BB doors have
a beautiful brass finish.
Aluminum-Framed Twin Pane Door
Your appliance can be fitted with beautiful
aluminum-framed twin pane doors. Models
33TBA-BB and 35TBA-BB doors are available
for use with these appliances. Doors are easily
fitted to the fireplace opening. Both models
come with a beautiful bright brass finish.
Glass Enclosure Panels
Your appliance can be fitted with beautiful
glass enclosure panels. Model 33AGEP and
35AGEP doors are available for use with these
appliances. Doors are easily fitted to the fire-
place opening. Model 33AGEP and 35AGEP
doorscome with astandard black finish. Model
33AGEP-BB and 35AGEP-BB doors come with
beautiful bright brass finish.
Twin Pane Door 12M43 35TBA-BB
Twin Pane Door 12M42 33TBA-BB
Glass Enclosure Panels 12M47 33AGEP
12M48 33AGEP-BB
12M49 35AGEP
12M50 35AGEP-BB
To ensure warranty and to prevent a potential
fire hazard, do not use any other doors on
these appliances.
Forced Air Kit 011781 FAK-1500

17
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
GAS CONTROLS—ROBERTSHAW MILLIVOLT
REPLACEMENT PARTS LIST
MILLIVOLT SYSTEM
.oNNOITPIRCSED
0055-CHG enaporPdnalarutaN 0055-DRG enaporPdnalarutaN
.oNtraP.ytQ.oNtraP.ytQ
.1)kcalB(revuoL,raBA71969-BL4--
.2poT,raBA60969-BL1--
.3rewoL/reppU,mirT1717302--
.4lluP/neercS,lenaP37609023760902
.5neercS,doR18311021831102
.6mottoB,yrotcafeR13434011343401
.7)etelpmoC(teSgoL1073M3111073M311
.amottoB,raeR,goL1003M3111003M311
.bmottoB,tnorF,goL1013M3111013M311
.cthgiR,poT,goL1033M3111033M311
.dtfeL,poT,goL1023M3111023M311
.01ylbmessArenruB15244011524401
.11llaW,hctiwSlortnoCFFO/NO27952012795201
.21tnorF,revoC10852011085201
.31noisnetxEeulF,ralloC15803011580301
.41lenaPnialecroP17192011719201
.oNNOITPIRCSED
0055-DRG/CHG larutaN 0055-DRG/CHG enaporP
.oNtraP.ytQ.oNtraP.ytQ
.02)CLRVM0007(saG,evlaV73790011773901
12ozeiP,rotingI10319011031901
.22)etelpmoC(lortnoC,lenaP13334012333401
.32timiL,hctiwS76379017637901
.42).porP(45#/).taN(34#,ecifirO75729016572901
tiKgnitareD,ecifirO11604012160401
.5257-PTelipomrehT99649019964901
.62ylbmessatoliP16739012673901

18 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
REPLACEMENT PARTS —MILLIVOLT
12
13
13
23
11
22
20
24 26
25
14
At Rear of FireBox
14
At Rear of FireBox
10 7c
7d
7a
7b

19
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
GAS CONTROLS—ROBERTSHAW ELECTRONIC
REPLACEMENT PARTS LIST
ELECTRONIC SYSTEM
.oNNOITPIRCSED
0055-CHG enaporPdnalarutaN 0055-DRG enaporPdnalarutaN
.oNtraP.ytQ.oNtraP.ytQ
.1)kcalB(revuoL,raBA71969-BL4--
.2poT,raBA60969-BL1--
.3rewoL/reppU,mirT1717302--
.4lluP/neercS,lenaP37609023760902
.5neercS,doR18311021831102
.6mottoB,yrotcafeR13434011343401
.7)etelpmoC(teSgoL1073M3111073M311
.amottoB,raeR,goL1003M3111003M311
.bmottoB,tnorF,goL1013M3111013M311
.cthgiR,poT,goL1033M3111033M311
.dtfeL,poT,goL1023M3111023M311
.01ylbmessArenruB15244011524401
.11llaW,hctiwSlortnoCFFO/NO27952012795201
.21tnorF,revoC10852011085201
.31noisnetxEeulF,ralloC15803011580301
.41lenaPnialecroP17192011719201
.oNNOITPIRCSED
0055-DRG/CHG larutaN 0055-DRG/CHG enaporP
.oNtraP.ytQ.oNtraP.ytQ
.02)REPI0027(saG,evlaV40289015328901
.12ylbmessatoliP16289012628901
.22)wahstreboR(lortnoCnoitingI30289013028901
.32)llewyenoH(lortnoCnoitingI51740915174091
.42)4102-NART-NIC(-yssAremrofsnarT41404014140401
.52)etelpmoC(lortnoC,lenaP11435012143501
.62timiL,hctiwS76379017637901
.72).porP(45#/).taN(34#,ecifirO75729016572901
tiKgnitareDecifirO11604012160401

20 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
REPLACEMENT PARTS —ELECTRONIC
Printed in U.S.A. © 2001 by Lennox Hearth Products
P/N 725,029M REV. C 07/2004
The manufacturer reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products.
Consult your local distributor for fireplace code information.
1110 West Taft Avenue •Orange, CA 92865
Manufactured by LHP
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
12 13
13
23
11
23
20
27
25
14
At Rear of FireBox
14
At Rear of FireBox
10
7c
7d
7a
7b
26
