Superior MULTI-OPEN SERIES User manual

1
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
HOMEOWNER'S CARE AND
OPERATION INSTRUCTIONS
RETAIN THESE INSTRUCTIONS
FOR FUTURE REFERENCE
FOR YOUR SAFETY: Do not store or use gasoline
or other flammable vapors or liquids in the vicin-
ity of this or any other appliance.
FOR YOUR SAFETY: What to do if you smell gas:
• DO NOT light any appliance.
• DO NOT touch any electrical switches.
• DO NOT use any phone in your building.
• Immediately call your gas supplier from a
neighbor’s phone.
Follow your gas suppliers instructions.
• Ifyourgassuppliercannotbereached,callthe
fire department.
Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
POURVOTRESÉCURITÉ: Nepasentreposer niutiliser
d'essencenid'autrevapeursouliquidesinflammables
dans le voisinage de cet appareil ou de tout autre
appareil.
POUR VOTRE SÉCURITÉ: Que faire si vous sentez une
odeur de gaz:
• Ne pas tenter d'allumer d'appareil.
• Netouchezàaucun interrupteur. Nepasvousservir
des téléphones se trouvant dans le batiment où
vous vous trouvez.
• Evacuez la piéce, le bâtiment ou la zone.
• Appelez immédiatement votre fournisseur de gaz
depuis un voisin. Suivez les instructions du
fournisseur.
• Si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service dos incendies.
L'installationetservicedoitêtreexécutéparunqualifié
installeur, agence de service ou le fournisseur de gaz.
DIRECT VENT
MULTI-OPEN SERIES
VENTED GAS FIREPLACE HEATERS - DIRECT VENT MODELS
P/N 725,001M REV. F 09/2005
WH Report No. J20006712
CDCL (Corner-Left) CDCR (Corner-Right)
MODELS
CDST (See-through) CDPF (Peninsula)
sledoMtlovilliMsledoMcinortcelE
NMC-TSDCNMC-LCDCNEC-TSDCNEC-LCDC
PMC-TSDCPMC-LCDCPEC-TSDCPEC-LCDC
NMC-FPDCNMC-RCDCNEC-FPDCNEC-RCDC
PMC-FPDCPMC-RCDCPEC-FPDCPEC-RCDC
WARNING:IFTHEINFORMATIONINTHISMANUAL
IS NOT FOLLOWED EXACTLY, A FIRE OR EXPLO-
SION MAY RESULT CAUSING PROPERTY DAM-
AGE, PERSONAL INJURY OR LOSS OF LIFE.
AVERTISSEMENT: ASSUREZ-VOUS DE BIEN SUIVRE
LESINSTRUCTIONSDONNÉDANSCETTENOTICEPOUR
RÉDUIRE AU MINIMUM LE RISQUE D'INCENDIE OU
POUR ÉVITER TOUT DOMMAGE MATÉRIEL, TOUTE
BLESSURE OU LA MORT.
A French manual is available upon request. Order Form Number
725,001CF.
Ce manuel d’installation est disponible en francais, simplement en
faire la demande. Numéro de la pièce 725,001CF.

2NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
These appliances are designed to operate on
natural or propane gas only.
OnMillivoltmodelstheinputoftheappliancecan
beadjustedbetween30,000and37,500BTU/HR
when using natural gas or propane gas.
OnElectronicmodelstheinputisfixedat37,500
BTU/HR for both gas types.
CONGRATULATIONS!
In selecting this SUPERIOR Direct-Vent Gas Appliance you have chosen the finest and
mostdependablefireplacetobefoundanywhere. It'sabeautiful,prestigiousalternative
to a wood burning fireplace. Welcome to a Family of tens of thousands of satisfied
SUPERIOR Fireplace Owners.
Please carefully read and follow all of the instructions found in this manual. Please pay
special attention to the safety instructions provided in this manual. The Homeowner's
Care and Operation Instructions included here will assure that you have many years of
dependable and enjoyable service from your SUPERIOR product.
INTRODUCTION
The Fireplace models covered in this manual
are Direct-Vent sealed combustion gas fire-
placeheatersdesignedforresidentialapplica-
tion. Direct-Vent appliances operate with the
combustionchambercompletelyisolatedfrom
the indoor environment. All air for combus-
tion is brought in from the outside and ex-
haust gases are vented through the same
direct vent, vent system.
GENERAL INFORMATION
Note: Installation and repair should be per-
formedbyaqualifiedserviceperson.Theappli-
ance should be inspected annually by a quali-
fied professional service technician. More fre-
quent inspections and cleanings may be re-
quired due to excessive lint from carpeting,
bedding material, etc. It is imperative that the
control compartment, burners and circulating
airpassagewaysoftheappliancebekeptclean.
S'assurer que le brùleur et le compartiment
des commandes sont propres. Voir les in-
structions d'installation et d'utilisation qui
accompagnent l'appareil.
Provideadequateclearancesaroundairopen-
ings and adequate accessibility clearance for
service and proper operation. Never obstruct
the front openings of the appliance.
Duetohightemperaturestheapplianceshould
be located out of traffic and away from furni-
ture and draperies. Locate furniture and win-
dow coverings accordingly.
The millivolt appliances are designed to oper-
ateoneithernaturalorpropanegas.Amillivolt
gas control valve with piezo ignition system
provides safe, efficient operation. If any op-
tional accessories which require electrical
powerare being installed, theelectricalpower
must be provided at the time of appliance
installation.
The electronic appliances are designed to op-
erate on either natural or propane gas. An
electronic intermittent pilot system provides
safe, efficient operation. External electrical
power is required to operate these units.
TheseappliancescomplywithNationalSafety
StandardsandaretestedandlistedbyWarnock
Hersey (Report No. J20006712) to ANSI
Z21.88-2000(inCanada,CSA-2.33-2000),and
CAN/CGA-2.17-M91inbothUSAand Canada,
as vented gas fireplace heaters.
Installation must conform to local codes. In
the absence of local codes, installation must
comply with the current National Fuel Gas
Code,ANSIZ223.1(NFPA54).(InCanada,the
currentCAN/CGAB149installationcode.) Elec-
tricalwiringmust complywithlocalcodes. In
the absence of local codes, installation must
be in accordance with the National Electrical
Code, NFPA 70 - (latest edition). (In Canada,
thecurrentCSAC22.1CanadianElectricCode.)
DO NOT ATTEMPT TO ALTER OR MODIFY
THE CONSTRUCTION OF THE APPLIANCE OR
ITS COMPONENTS. ANY MODIFICATION OR
ALTERATION MAY VOID THE WARRANTY,
CERTIFICATIONAND LISTINGS OFTHISUNIT.
TABLE OF CONTENTS
Introduction..................................... page 2
General Information......................... page 2
Operation/Care of Your Appliance.... page 3
Variable Flame Adjustment .............. page 4
Glass Cleaning................................. page 4
Maintenance .................................... page 4
Front Glass Enclosure Panel,
Removal and Installation ............... page 4
Maintenance Schedule..................... page 5
Burner Adjustments......................... page 6
Flame Appearance and Sooting ....... page 6
Adjustment ...................................... page 6
Log Placement,Decorative Volcanic Stone and
Glowing Embers (Rockwool) ........... page 7
Ceramic Fiber Chunks Placement .... page 7
Millivolt Appliance Checkout............ page 7
Electronic Appliance Checkout......... page 8
Wiring Diagrams.............................. page 8
Warranty.......................................... page 8
Replacement Parts ........................... page 8
Product Reference Information ....... page 8
Accessory Components................... page 9
Lighting Instructions – Millivolt....... page 12
Lighting Instructions – Electronic.... page 14
Troubleshooting Guide – Millivolt ..... page 16
Troubleshooting Guide – Electronic .. page 17
Replacement Parts List..................... page 18
Maximum manifold pressure is 3.5 in. w.c.
(0.87 kPa) for natural gas and 10 in. w.c.
(2.49 kPa) for LP/Propane gas.
* Each model has two burners. Each burner
contains one of these orifices.
Thefollowingtableshowstheunits'orificesize
for the elevations indicated.
ledoM
.oN
*ezisecifirO noitavelE
)sretem(teeF
.taN.porP
TSDC
FPDC
RCDC
LCDC
44#55# 0054-0 )0731-0(
WARNING: THESE FIREPLACES ARE
VENTED HEATERS. DO NOT BURN
WOOD OR OTHER MATERIAL IN THESE
APPLIANCES.
WARNING: IMPROPER INSTALLATION,
ADJUSTMENT, ALTERATION, SERVICE
OR MAINTENANCE CAN CAUSE INJURY
OR PROPERTY DAMAGE. REFER TO
THIS MANUAL. FOR ASSISTANCE OR
ADDITIONAL INFORMATION CONSULT
A QUALIFIED INSTALLER, SERVICE
AGENCY OR THE GAS SUPPLIER.

3
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Do not use these appliances if any part has
beenunderwater.Immediatelycallaqualified,
professional service technician to inspect the
appliance and to replace any parts of the
control system and any gas control which
have been under water.
Ne pas se servir de cet appareil s'il a été plongé
dansl'eau, complètementou en partie. Appeler
untechnicienqualifiépourinspecterl'appareilet
remplacertoutepartiedusystèmedecontrôleet
toutecommandequiontétéplongésdansl'leau.
Test gage connections are provided on the
front of the millivolt gas control valve (identi-
fied OUT for the manifold side and IN for inlet
pressure. A ¹⁄₈" NPT test gage connection is
provided on the electronic gas control valve
adjacent to the outlet to the main burner.
Minimuminletgaspressuretotheseappliances
is5.0 incheswatercolumn(1.24kPa)fornatural
gas and 11 inches water column (2.74 kPa) for
propane for the purpose of input adjustment.
Maximuminletgassupply pressure to theseappli-
ances is 10.5 inches water column (2.61 kPa) for
naturalgasand13.0incheswatercolumn(3.23kPa)
forpropane.
The appliance must be isolated from the gas
supply piping system (by closing its individual
manualshut-offvalve)duringanypressuretest-
ing of the gas supply piping system at test
pressuresequaltoorlessthan¹⁄₂ psig(3.5kPa).
Theapplianceanditsindividualshut-offvalvemust
bedisconnectedfromthegassupplypipingsystem
duringany pressure testing of thatsystem atpres-
suresin excess of¹⁄₂ psig (3.5 kPa).
These appliances must not be connected to a
chimney or flue serving a separate solid fuel
burning appliance.
Any safety guard or screen removed for ser-
vicingthe appliancemust be replaced prior to
operating the appliance.
Carbon Monoxide Poisoning: Early signs of
carbon monoxide poisoning are similar to
thefluwithheadaches,dizziness and/or nau-
sea. If you have these signs, obtain fresh air
immediately. Turn off the gas supply to the
appliance and have it serviced by a qualified
professional, as it may not be operating
correctly.
Operationofmillivoltandelectronicgascon-
trol systems are different. Before lighting
and operating your appliance determine if
you have a millivolt or electronic appliance.
Refer to Figure 1 for access to the gas
control valve. Millivolt appliances will be
fitted with the gas control valve shown in
Figure 2 on page 4 .
Appliances with electronic systems will be
fittedwiththeelectronicvalveshownin
Figure
3 on page 4
.Familiarize yourself with the gas
control valve that your appliance uses.
OPERATION AND CARE OF YOUR
APPLIANCE
Appliance operation may be controlled by the
following means: an optional unit-mounted
ON/OFF control switch (Millivolt appliances
only), an optional wall-mounted ON/OFF con-
trolswitchor an optionalremotecontrol. The
unit-mounted ON/OFF control switch may be
mounted in the bracket below the gas valve
(see Figure 2 on page 4) .
GasControls/ControlCompartmentAccess
Thegascontrolscanbefoundbehindthecontrol
compartmentaccesspanel.Toopenthecontrol
compartment access panel, actuate the spring
loadedmagneticcatchessecuringthepanel,by
gently depressing the outer top corners of the
panel until the catches "pop" the door free,
allowing it to swing out and down to open.
To ease door closure, depress the catches to
place them in their retracted position, then
close the door.
Millivolt appliances are fitted with the gas
control valve shown in
Figure 2 on page 4 .
Onthesesystems,thepiezoignitor,Hi/Loflame
adjustment knob, and pilot and main gas ON/
OFF control knob are located on gas valve.
Figure 1
Control Compartment Access -
Millivolt Control Valve Shown
Millivolt Appliances -
To light millivolt appliances refer to the de-
tailed lighting instructions found on page 12
(English) and page 13 (French). Millivolt ap-
pliance lighting instructions may also be
found on the pull out lighting instruction
labels attached to the gas control valve.
Millivolt appliances may be fitted with an op-
tional ON/OFF rocker switch which is used to
control the main burner operation. The op-
tional ON/OFF rocker switch should be in-
stalledinoneofthetworectangularslotsinthe
piezo igniter mounting bracket below the gas
valve. Once the pilot is lit, the ON/OFF rocker
switchwill controlthe main burner operation.
To operate: Toggle the switch between its ON
and OFF positions.
If your millivolt appliance is equipped with an
optional wall-mounted ON/OFF switch or re-
mote control kit and the pilot is lit, the appli-
ance main burner may be turned on and off
with the wall switch or remote control.
Piezo Ignitor
Gas Valve
Control
Compartment
Access panel
Hinge Pin
WARNING: FAILURE TO COMPLY WITH
THEINSTALLATIONANDOPERATINGIN-
STRUCTIONSPROVIDED INTHISDOCU-
MENT WILL RESULT IN AN IMPROP-
ERLY INSTALLED AND OPERATING AP-
PLIANCE, VOIDING ITS WARRANTY.
ANY CHANGE TO THIS APPLIANCE AND/
OR ITS OPERATING CONTROLS IS DAN-
GEROUS. IMPROPER INSTALLATION
ORUSEOFTHISAPPLIANCE CANCAUSE
SERIOUSINJURYORDEATHFROMFIRE,
BURNS, EXPLOSION OR CARBON MON-
OXIDE POISONING.
WARNING: CHILDREN AND ADULTS
SHOULD BE ALERTED TO THE HAZARDS
OFHIGHSURFACETEMPERATURES.USE
CAUTION AROUND THE APPLIANCE TO
AVOID BURNS OR CLOTHING IGNITION.
YOUNG CHILDREN SHOULD BE CARE-
FULLYSUPERVISED WHEN THEY ARE IN
THE SAME ROOM AS THE APPLIANCE.
WARNING: DO NOT PLACE CLOTHING
OR OTHER FLAMMABLE MATERIALS
ON OR NEAR THIS APPLIANCE.
AVERTISSEMENT: SURVEILLER LES
ENFANTS. GARDER LES VÊTEMENTS,
LESMEUBLES,L'ESSENCEOUAUTRES
LIQUIDES ÀVAPEUR INFLAMMABLES
LOIN DE L'APPAREIL.

4NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Glass Enclosure Panels - Removal and
Installation.
These are direct-vent appliances. They are de-
signedtooperateonlywiththeglassenclosure
panels properly installed. Generally the glass
enclosure panels should not be removed ex-
cept to gain access to the components within
the firebox, and the appliance may only be
operatedwithoutthefrontglassenclosurepanel
in place for very brief periods of time during
initial appliance checkout and adjustment.
During this appliance checkout and adjust-
ment period, a potential safety hazard exists
-EXERCISEEXTREME CAUTION to preventthe
occurrence of any burn injuries from the ex-
posed flames or hot surfaces. Also note, that
whilethefrontglassenclosurepanel(oranyof
the panels) is removed, the flame appearance
will appear to be smaller than normal.
CAUTION: DO NOT TOUCH THE FRONT
ENCLOSURE GLASS WITH YOUR HANDS
WHILE THE FIREPLACE IS IN USE.
Electronic Appliances -
To light electronic appliances refer to the de-
tailed lighting instructions found in both En-
glish and French on
pages 14 and 15 of these
instructionsrespectively.Electronicappliance
lighting instructions may also be found on the
pull out lighting instruction labels attached to
the gas control valve.
Ifyourelectronicapplianceisequippedwithan
optional remote wall switch or remote control
kittheappliancemainburnermaybeturnedon
and off with the wall switch or remote control.
If your electronic appliance is not equipped
with a wall switch or remote control, the main
burner must be turned off and on with the gas
control switch. Toggle the switch from ON to
OFF to operate the main burner.
Figure 3 Honeywell Electronic Gas Valve
Maintenance
The appliance and venting system should be
thoroughly inspected before initial use and at
least annually by a qualified service techni-
cian.However,morefrequentperiodicinspec-
tions and cleanings should be performed by
the homeowner. Homeowner must contact a
qualified service technician at once if any
abnormal condition is observed.
Refer to the maintenance schedule for mainte-
nancetasks,procedures,periodicityandbywhom
theyshouldbeperformed. Alwaysverifyproper
operation of the appliance after servicing.
IMPORTANT: TURN OFF GAS AND ANY
ELECTRICAL POWER BEFORE SERVICING
THE APPLIANCE.
2. When lit for the first time, this appliance will
emitaslightodorfor14hours.Thisisduetothe
“burn-in”ofinternalpaintsandlubricantsusedin
the manufacturing process.
3. Keep lower control compartment clean by
vacuuming or brushing at least twice a year.
Morefrequentcleaningmayberequireddueto
excessivelintfromcarpeting,beddingmateri-
als, etc. It is important that control compart-
ments, burners and circulating air passage-
ways of the appliance be kept clean.
4. Always turn off gas to the pilot (millivolt
appliances) and let the unit cool down before
cleaning. Before re-lighting, refer to the light-
ing instructions in this manual. Lighting in-
structions may also be found on the pull out
lighting instruction labels attached to the
gas control valve.
5. Always keep the appliance area clear and
freefromcombustiblematerials,gasolineand
other flammable liquids.
6. Remember, Millivolt appliances have a con-
tinuous burning pilot flame. Exercise caution
when using products with combustible vapors.
Glass Cleaning
It will be necessary to clean the glass periodi-
cally. Duringstart-upit isnormalfor conden-
sationto form onthe inside ofthe glass. This
can cause lint, dust and other airborne par-
ticles to cling to the glass surface. Also initial
paint curing may deposit a slight film on the
glass. It is therefore recommended that the
glassbecleanedtwoorthreetimeswithanon-
ammoniahouseholdcleanerandwarmwater(a
gas fireplace glass cleaner is recommended).
After that the glass should be cleaned two or
three times during each heating season, de-
pending on the circumstances present.
Figure 2 Millivolt Gas Valve
Variable Flame Height Adjustment
( Millivolt Appliances only)
1. All Millivolt appliances are equipped with a
variablegascontrolvalve.Flameheightforthese
models may be adjusted through a range be-
tween fixed low and high settings while the
applianceisinoperation.Adjusttheflameheight
asdesiredafterlightingtheappliancebyrotating
thevariableadjustmentcontrolknoblocatedon
the front of the valve (refer to Figure 2) .
H
I
L
O
W
TPTH TP TH
P
I
L
O
T
P
I
L
O
T
O
N
it
O
F
F
Variable Flame Height Adjustment
Manifold Pressure Port
Inlet Pressure Port
Main Gas
Control Knob
IN OUT
Optional Burner ON/OFF
Rocker Switch Location Factory-Installed Blower ON/OFF
Rocker Switch Location
Piezo Ignitor
ON/OFF Switch
Electronic
Gas Control
Valve
Inlet
Pressure
Port
Manifold Pressure Port
OFF
IN
PSI
ON
CONTROL
IGNITER
Note: Clean glass after first two weeks of
operation.
WARNING: NEVER OPERATE THE AP-
PLIANCE WITHOUT THE GLASS ENCLO-
SURE PANELS IN PLACE AND SECURE.
DONOTOPERATEAPPLIANCEWITHANY
OFTHEGLASSPANELSCRACKED, BRO-
KEN OR MISSING. REPLACEMENT PAN-
ELS ARE AVAILABLE THROUGH YOUR
LOCAL LENNOX DEALER AND MUST BE
INSTALLED BY A LICENSED OR QUALI-
FIED SERVICE TECHNICIAN.
WARNING: DO NOT USE ABRASIVE
CLEANERS. NEVER CLEAN THE GLASS
WHEN IT IS HOT.

5
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Periodically (After the Burning Season)
Maintenance Task Accomplishing Person Procedure
Cleaning Firebox Interior
Check Flame Patterns and Flame Height
Checking Vent System
Cleaning Glass Enclosure Panels
Homeowner
Homeowner
Homeowner
Homeowner
Carefully remove logs, decorative volcanic stone
and glowing embers. Vacuum out interior of the
firebox.Cleanfireboxwallsandloggrate.Replace
logs, decorative volcanic stone and glowing em-
bersas detailed on
page 7 .
Maintenance Task Accomplishing Person Procedure
Inspecting/Cleaning Burner, Logs
and Controls
Check Flame Patterns and Flame Height
Inspecting/CleaningPilot Burnerand theTwo
Main Burners
Checking Vent System
Appliance Checkout
Qualified Service Technician
Qualified Service Technician
Qualified Service Technician
Qualified Service Technician
Qualified Service Technician
Inspectvalve andensure itis properlyoperat-
ing. Check piping for leaks. Vacuum the con-
trol compartment, fireplace logs and burner
area.
Referto Figure 6 on page 7 and verify thatthe
flame pattern and height displayed by the
appliance conforms to the picture. Flames
must not impinge on the log set.
Referto Figure9 on page7(millivolt)orFigure
10 on page 8 (electronic)
.Removeanysurface
build-uponpilotandburnerassembly.Cleanthe
pilotnozzles, ignitor/flame rod and hood with a
soft brush. Ensure the pilot flame engulfs the
flame sensor as shown.
Inspect the vent system at the top and at the
base(withinthe firebox) forsignsofblockage
orobstruction. Look for anysigns of disloca-
tion of the vent components.
Perform the appropriate appliance checkout
procedure detailed in this manual.
Maintenance Schedule
Annually (Before the onset of the Burning Season)
Clean as necessary following the directions
providedinthismanual. DO NOT TOUCH OR
CLEAN GLASS WHILE IT IS HOT.
Inspect the vent system at the top and at the
base (within the firebox) for signs of block-
age or obstruction. Look for any signs of
dislocation of the vent components.
Refer to Figure 6 on page 7 and verify that
theflamepatternandheightdisplayedbythe
appliance conforms to the picture. Flames
must not impinge on the log set.
THEGLASSDOORSOFTHISAPPLIANCEMUST
ONLYBE REPLACED ASA COMPLETE UNITAS
PROVIDED BY THE MANUFACTURER. DO
NOT ATTEMPT TO REPLACE BROKEN,
CRACKED OR CHIPPED GLASS SEPARATELY.
WARNING: HANDLE THE GLASS WITH EX-
TREME CARE! TEMPERED GLASS IS SUS-
CEPTIBLE TO DAMAGE (SCRATCHES, FOR
EXAMPLE)–HANDLEGLASSDOORS(GLASS
ENCLOSURE PANELS) GENTLY WHILE RE-
INSTALLING THEM.
WARNING: DO NOT ATTEMPT TO SUBSTI-
TUTE THE MATERIALS USED ON THESE
DOORS, OR REPLACE CRACKED OR BRO-
KEN GLASS WITH ANY MATERIALS OTHER
THANTHOSEPROVIDEDBY THE APPLIANCE
MANUFACTURER.

6NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Figure 5
AdjustmentRodPositions(whenviewed
from above):
*Natural Gas - fully clockwise
**Propane - fully counter clockwise
***Settingsshownareforeachburner.
Refer to Figure 4 and remove the front glass
enclosure panel as follows:
1. Remove the top louver assembly or radiant
panel.
2.Openthecontrolcompartmentaccesspanel.
Toopenthecontrolcompartmentaccesspanel,
actuate the spring-loaded magnetic catches
securing the panel, by gently depressing the
outertopcornersofthepaneluntilthecatches
"pop"thedoorfree,allowingittoswingoutand
down to open.
3. Locate the two (2) latches at the top of the
control compartment. To disengage the two
latchesfromthebottomvee-flangeoftheglass
enclosurepanel,reach for thehandleslocated
towards the back of the latches and pull the
handles down toward the front of the unit.
4. Swingthe bottom ofthe door outand raise
itslightlytoliftthetopflangeofthedoorframe
away from the appliance.
To install the front glass enclosure panel,
proceed as follows:
1. Visuallyinspect the gasketon the backside
ofthepanel.Thegasketsurfacemustbeclean,
free of irregularities and seated firmly.
2.Positiontheglassenclosurepanelinfrontof
the firebox opening at a 45 degree angle and
engage the top flange over the lip at the top of
the firebox opening.
3. Swingthe glass enclosurepanel down and
back. Ensure the gasket seats evenly as the
paneldrawsshut. EngagetheVee-flangeatthe
bottomof the panel with thelatches and close
the latches to secure the panel.
4. Reinstallthetoplouverassemblyorradiant
panel.
Burner Adjustments
The following paragraphs address burner ad-
justment concerns and procedures.
Flame Appearance and Sooting
Proper flame appearance is a matter of taste.
Generallymostpeoplepreferthewarmglowof
a yellow to orange flame. Appliances operated
withairshutteropeningsthataretoolargewill
exhibit flames that are blue and transparent.
These weak, blue and transparent flames are
termedanemic.Iftheairshutteropeningistoo
small sooting may develop.Sooting is indi-
cated by black puffs developing at the tips of
very long orange flames. Sooting results in
black deposits forming on the logs, appliance
inside surfaces and on exterior surfaces adja-
cent to the vent termination.
Sootingiscausedbyincompletecombustionin
theflamesandalackofcombustionairentering
the air shutter opening. To achieve a warm
yellowtoorangeflamewithanorangebodythat
does not soot, the shutter opening must be
adjustedbetweenthesetwoextremes. Nosmoke
orsootshouldbepresent.Repositionthelogset
if the flames impinge on any part of it.
If the log set is properly positioned and
sootingconditionsexist, the air shutteropen-
ing on the main burner tube should be ad-
justed. Normally, the more offsets in the vent
system,thegreatertheneedfortheairshutter
to be opened further.
ENSURE THAT ALL GLASS PANELS ARE IN
PLACE AND SEALED DURING ADJUSTMENT.
The adjustment rod and associated adjustable
air shutter is patented technology. Flame ad-
justments can be made quickly and accurately
to taste without the need of disassembling the
applianceandwaitingfor15minutesaftereach
adjustment.
Propane models may exhibit a flame pattern
that may candle or appear stringy. If this is
problematic or persists as the appliance is
continually operated, adjust the air shutter
closedasdescribedinthepreviousparagraphs.
Operatetheapplianceforaperiodoftimeasthe
effect diminishes, ensuring that the appliance
does not develop sooty flames.
Whensatisfiedthattheapplianceoperatesprop-
erly,proceedtofinishtheinstallation.Leavethe
control knob in “ON” position and turn the
remote switch “OFF.” Close the lower control
compartment access panel.
Adjustment
CAUTION: THE ADJUSTMENT ROD AND
NEARBY APPLIANCE SURFACES ARE HOT.
EXERCISECAUTION TOAVOIDINJURYWHILE
ADJUSTING FLAME APPEARANCE.
To adjust the flame, rotate the adjustment
rod (located in the lower control area) coun-
terclockwise to increase or clockwise to re-
duce the air shutter opening. Adjust the air
shutter to the recommended setting as
shown in
Figure 5 .Allow the burner to oper-
ateforatleast15minutes. Observetheflame
continuously. If it appears weak or sooty as
previously described, adjust the air shutter
byrotating theadjustmentroduntiltheflame
appearance is as desired.
Figure 4 CDST Shown
Glass Door Latch
Control Compartment Access Panel and Hinge
Front Glass
Enclosure Panel
Firebox Floor
Bottom Vee-flange
Glass Door Frame
Top Flange
Glass Door Frame
RENRUBNIAM***
GNITTESRETTUHSYROTCAF
sledoM saGlarutaN sehcni )mm(
enaporP saG sehcni )mm(
TSDC FPDC RCDC LCDC
OWT* 8/1)3(STOLS OWT** 61/11)71(STOLS
Air Shutter
Adjusting
Rod
Air Shutter
Adjusting
Arms
Orifice
Increase Shutter
Opening In This
Direction
Decrease Shutter
Opening In This
Direction
Air Shutter
Opening
Burner
Venturi
Tube
Note - Both air shutters open and close
simultaneously when the air shutter
adjusting rod is moved.
Note - Burners are omitted in this view for clarity.
WARNING: AIR SHUTTER ADJUST-
MENT SHOULD ONLY BE PERFORMED
BY A QUALIFIED PROFESSIONAL SER-
VICE TECHNICIAN.

7
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Log Placement
Figure 7
Millivolt Appliance Checkout
Thepilotflameshould besteady,notlifting or
floating. Flame should be blue in color with
traces of orange at the outer edge. The top ³⁄₈"
(10mm) at the pilot generator (thermopile) and
thetop¹⁄₈"min(tip)ofthequickdropoutthermo-
coupleshouldbeengulfedinthepilotflame. The
flame should project 1" (25 mm) beyond the
hood at all three ports. See
Figure 9.
To light the burner, refer to the lighting instruc-
tions on
pages 12 and 13.
Figure 6
Figure 9
Note: If the burners have been removed for
any reason, rear burner must be installed
before front burner. See Figures 7 and 8.
Install the unitized log set:
a- The bottom of the log set is notched to
accommodate the pilot.
b- Place the log set so that the four inner
notchesontheundersideofthelogsetfitover
thefourriserslocatedontheburnerends. See
Figure 6 .This procedure isaccomplishedpri-
marilybyfeel,asthelog set maskstheburner
risers as it is being installed.
c- As a final check for correct log set place-
ment,checkthatthefourouternotchesonthe
underside of the log set fit over the burner
tines as indicated in
Figure 6 .
The log set, the decorative volcanic stone
and the glowing embers (rockwool) are lo-
cated inside the unit. Refer to the following
informationand
Figures 6 and 7 fordetailed
placementinstructionsforthelogs,thedeco-
rative volcanic stone and the glowing em-
bers. Figure 6 also shows a typical flame
pattern for this particular appliance.
Install the decorative volcanic stone and
glowing embers (rockwool):
Spread the decorative volcanic stone onthe
simulatedbrickfloorofthefireboxaroundthe
burners to simulate ashes. Maintain a ¹⁄₂ in.
gapbetweenthebottomofthehorizontalgrate
section and the top of the pile of decorative
volcanicstone. Placeafewdime-sizedpieces
of the glowing ember material on the pan
burner in front of the burned out area on both
sides of the log set. The glowing embers may
touch one another, but should not overlap
each other.
Figure 8
FRONT OF FIREPLACE
REAR BURNER
FRONT BURNER
Outer Log
Notch Location
FIREBOX SUBFLOOR
Outer Log
Notch Location
Outer Log
Notch Location Outer Log
Notch Location
Riser - Inner Log
Notch Location
LOG NOTCH LOCATION RELATIVE TO BURNER
Pilot Assembly
Riser - Inner Log
Notch Location
NOTE: INSTALL REAR BURNER FIRST,
THEN FRONT BURNER.
BURNER POSITIONING
REAR BURNER
FRONT BURNER
PILOT
BURNER
Note: The burners are not identical. Position them so
that the circular burner ports run as shown. Note
especially the vertical run of ports relative to the pilot
burner. Bracket A on the rear burner will interfere
with the pilot burner if an attempt is made to install
the rear burner in the front burner’s position.
BRACKET A BURNER
PORTS
NOTE: INSTALL REAR BURNER FIRST,
THEN FRONT BURNER.
MILLIVOLT
Thermocouple
Hood Ignitor Rod
³⁄₈" Min
(9 mm)
Thermopile
Pilot
Nozzels
WARNING: THIS APPLIANCE IS NOT
DESIGNED TO BURN WOOD. ANY AT-
TEMPT TO DO SO COULD CAUSE IR-
REPARABLE DAMAGE TO YOUR APPLI-
ANCE AND PROVE HAZARDOUS TO
YOUR SAFETY.
WARNING: THE SIZE AND POSITION
OF THE LOG SET WAS ENGINEERED TO
GIVE YOUR APPLIANCE A SAFE, RELI-
ABLE AND ATTRACTIVE FLAME PAT-
TERN. ANY ATTEMPT TO USE A DIF-
FERENT LOG SET IN THE FIREPLACE
WILL VOID THE WARRANTY AND WILL
RESULT IN INCOMPLETE COMBUS-
TION, SOOTING, AND POOR FLAME
QUALITY.
WARNING: LOG SET GETS VERY HOT
AND WILL REMAIN HOT UP TO ONE
HOUR AFTER GAS SUPPLY IS TURNED
OFF. HANDLE ONLY WHEN LOG SET IS
COOL. TURN OFF ALL GAS TO THE
APPLIANCE BEFORE INSTALLING THE
GRATE AND LOG SET.

8NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Electronic Appliance Checkout
To light the burner, refer to the lighting instruc-
tions on
page 14 and 15 . Ensure the ignitor
lightsthepilot.Thepilotflameshouldengulfthe
flame sensor as shown in
Figure 10
Figure 10
With proper care and maintenance, your appli-
ancewillprovidemanyyearsofenjoyment.Ifyou
shouldexperienceany problem, first refertothe
troubleshootingguideinthismanual.Ifproblem
persists, contact your Lennox distributor.
WIRING DIAGRAMS
Wiring diagrams are provided here for refer-
ence purposes only. This information is also
provided on schematics attached directly to
theapplianceonapulloutpanellocatedwithin
the control compartment.
CAUTION: LABEL ALL WIRES PRIOR TO DIS-
CONNECTION WHEN SERVICING CONTROLS.
WIRINGERRORSCANCAUSEIMPROPERAND
DANGEROUS APPLIANCE OPERATION.
WARRANTY
Yourgasapplianceiscoveredbyalimitedtwenty
year warranty. You will find a copy of the war-
ranty accompanying this manual. Please read
the warranty to be familiar with its coverage.
REPLACEMENT PARTS
Acompletepartslistisfoundattheendofthis
manual. Use only parts supplied from the
manufacturer.
Normally, all parts should be ordered through
yourLennoxdistributorordealer.Partswillbe
shipped at prevailing prices at time of order.
When ordering repair parts, always give the
following information:
PRODUCT REFERENCE INFORMATION
Werecommendthat you record thefollowingimportantinformationaboutyourfireplace. Please
contactyourLennoxdealerforanyquestionsorconcerns. ForthenumberofyournearestLennox
dealer, please call 800-731-8101
Your Fireplace's Model Number _______________________________________
Your Fireplace's Serial Number ________________________________________
The Date On Which Your Fireplace Was Installed __________________________
The Type of Gas Your Fireplace Uses ___________________________________
Your Dealer's Name_________________________________________________
If you encounter any problems or have any
questions concerning the installation or appli-
cation of this system, please contact your dis-
tributor, or Lennox directly:
LHP
1110 West Taft Avenue •Orange, CA 92865
1. The model number of the appliance.
2. The serial number of the appliance.
3. The part number.
4. The description of the part.
5. The quantity required.
6. The installation date of the appliance.
Retainthismanual.Fileitwithyourotherdocu-
ments for future reference.
Proper Flame
Adjustment
Hot Surface
Igniter
Flame Rod
Ground
Electrode
3/8 To 1/2 Inch
(9 mm to 13 mm)
1. If any of the original wire as supplied must be replaced,
1. it must be replaced with Type AWM 105°C –18 GA. wire.
2. 120V, 60Hz –Less than 3 amps.
BK
Junction Box
Transf.
120 V.
24 V
Factory Wired Field Wired
BL
Electronic Wiring Diagram (Honeywell)
Showing the Blower Wiring for the Optional
FBK-100 and FBK-200 Kits
R
W
BL
OPT
BLOWER
G
W
*OPTIONAL
ACCESSORY
SWITCH
120
VAC.
BK
W
Gas Valve
B
R
IGNITER
PILOT
ASSEMBLY
Break Off
Tab
BK
G
*Blower speed control switch is provided in FBK200 blower kit.
Outlet Box
Green Ground
Screw
Hot side of Outlet
Schematic Representation Only
**ON/OFF Switch (Integral
with Gas Valve)
**Leave the ON/OFF switch, which is integral
with the gas valve, in the ON position.
OPTIONAL APPLIANCE-MOUNTED ON/OFF SWITCH
OR OPTIONAL WALL SWITCH
OR OPTIONAL THERMOSTAT
OR OPTIONAL REMOTE RECEIVER
Red
pigtail
Black
pigtail
White Wire
to Opposite
Side
G
1. If any of the original wire as supplied must be replaced,
1. it must be replaced with Type AWM 105°C –18 GA. wire.
2. 120V, 60Hz –Less than 3 amps.
BK
Transf.
120 V.
24 V
Factory Wired Field Wired
BL
Electronic Wiring Diagram (Honeywell)
Showing the Blower Wiring for the Optional
FBK-250 Kits
R
WH
BL
OPT
BLOWER
G
W
120
VAC.
BK
W
Gas Valve
B
R
IGNITER
PILOT
ASSEMBLY
BK
G
Outlet Box Green
Ground Screw
Hot side of Outlet
Schematic Representation Only
*ON/OFF Switch (Integral
with Gas Valve)
White Wire
To Opposite
Side
Optional FBK-250
Module
*Leave the ON/OFF switch, which is integral
with the gas valve, in the ON position.
G
OPTIONAL APPLIANCE-MOUNTED ON/OFF SWITCH
OR OPTIONAL WALL SWITCH
OR OPTIONAL THERMOSTAT
OR OPTIONAL REMOTE RECEIVER
Millivolt Wiring Diagram
If any of the original wire as supplied must be replaced,
it must be replaced with Type AWM 105°C, 18 GA. wire.
Thermopile
TH
TP TH
TP
*TWIST WIRES “A”AND “B”TOGETHER TO OPERATE UNIT
SOLELY BY MANIPULATING THE GAS VALVE CONTROL KNOB;
OR CONNECT WIRES TO OPTIONAL UNIT-MOUNTED ON/OFF
SWITCH OR WALL-MOUNTED ON/OFF SWITCH OR
THERMOSTAT TO OPERATE UNIT.
*UNIT-MOUNTED ON/OFF SWITCH (Accessory Option)
OR WALL-MOUNTED ON/OFF SWITCH (Accessory Option)
OR THERMOSTAT (Accessory Option)
OR REMOTE CONTROL RECEIVER (Accessory Option)
AB

9
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Arch Door Kits
Twotypesofarchdoorkitsareavailableforthe
Multi-Open Series. Both types of kits are easy
toinstalland do not require hardware to attach
themtothestandarddoorframe.Thesekitscan
beretrofittedtopreviouslyinstalledMulti-Open
Seriesappliances.Thedecorativearchkitscan
not be used in conjunction with the screen
panel kit.
ACCESSORY COMPONENTS
Door Frame Kits
Two types of decorative door frame kits are
available for use with these appliances - one in
polishedbrassfinish,theother,inbrushedstain-
less steel finish. The DFK is designed to attach
directly to the front face of the appliance at its
extremeedges.TheDFKprovidesapictureframe
finishfortheappliance.Thedoorframekitcanbe
retrofitted onto previously installed appliances.
ON/OFF Wall Switch Kit 85L87 FWSK
ON/OFF Wall Switch Kit
The ON/OFF wall switch kit may be used to
controlthe operation ofthe fireplaceburner as
an alternative to the unit-mounted ON-OFF
switch. Install the ON/OFF wall switch in a
convenient location near the fireplace.
Remote Control System (Standard) H0249 RCL
Standard Remote Control System
(Model RCL)
The Model RCL (Standard) Remote Control
System, features a simplistic on/off control
functionfor thefireplace. This modelincludes
ahand-heldtransmitter,aremotereceiverwith
wall-mount coverplate and all hardware re-
quired to install the unit. The remote receiver
can be wall or hearth mounted.
Thetransmitter has ONand OFF functionsthat
are activated by pressing either button on the
face of the transmitter. When a button on the
transmitterispressed,asignallightilluminates
briefly to verify that a signal has been sent.
The Model RCL is designed to operate with all
millivoltignition systems,as well as electronic
ignition systems. It may be installed with use
for either natural or propane gas appliances.
The RCL offers ease of installation and allows
you to execute on-off commands to the fire-
place effortlessly with one simple motion.
The Model RCL comes complete with detailed
operating instructions.
Flame Modulating Remote Control
Natural Gas H0301 RCL-MN
LP/Propane Gas H0302 RCL-ML
FlameModulatingRemoteControlsweredevel-
opedtoprovideasafe,reliableanduser-friendly
remote control system for appliances equipped
with a Millivolt Gas Valve. A detailed set of
instructions are included with each remote.
stiKemarFrooD
STESFOREBMUNDNA.ONLEDOM/.ONGOLATAC
tinU
ledoM
.oN
hsiniFssarBdehsiloPhsiniFsselniatSdehsurB
ediw.ni42rof
rooDssalG
ediw.ni04rof
rooDssalG
ediw.ni42rof
rooDssalG
ediw.ni04rof
rooDssalG
51L08
B06-EKFD
21L08
B06/6-KFD
02L08
P06-EKFD
71L08
P06/6-KFD
TSDC -2 - 2
FPDC 12 1 2
RCDC
LCDC 11 1 1
YTITNAUQDNA.ONLEDOM/.ONGOLATAC-stiKrooDhcrA
tinU
ledoM
.oN
hsiniFssarBdehsiloPhsiniFsselniatSdehsurB
ediw.ni42rof
rooDssalG
ediw.ni04rof
rooDssalG
ediw.ni42rof
rooDssalG
ediw.ni04rof
rooDssalG
59L08
B06-EKDA
39L08
B06/6-KDA
50L18
P06-EKDA
30L18
P06/6-KDA
TSDC -2 - 2
FPDC 12 1 2
RCDC
LCDC 11 1 1

10 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
ACCESSORY COMPONENTS CONTINUED
Deluxe Remote Control System
(Model RCK-D)
The Model RCL-T (Deluxe) Remote Control
System has all of the features of the standard
system along with an added easy to read LCD
screen which presents access to many en-
hancements, including; battery power level in-
dicator,timer,modeofoperation,thermostatic
display including room temperature in either
metric of English units, flame indicator and
clock. Fully programmable, the Model RCL-T
allows for virtual command over nearly all
operational and temperature variables, using
the hand held remote control transmitter.
TheModelRCL-T(Deluxe)remotecontrolsys-
tem is installed in the same manner as the
standard system, may be operated with elec-
tronicand millivolt systems with eithernatural
or propane gas. The RCL-T comes complete
with detailed operating instructions.
Remote Control System (Deluxe) H0251 RCL-T
Clean Faced Panel Kit
A clean faced panel kit is available to convert the
standard louvered appliances to radiant models
moresuitedforfinishingaroundthefireboxopen-
ing with non-combustible materials such as tile.
Rocker Switch Kit 80L41 FRS
Optional Unit Mounted Rocker Switch
An optional rocker switch kit can be installed
directly on all Millivolt Gas Valve Equipped
Multi-OpenSeriesappliancestoprovideforOn
andOffoperationinlieuofawallswitch.Thiskit
isdesigned to install in thelower control com-
partment out of view and is perfect for use in
high volume areas such as lobbies and model
homes where limited access to the appliance
On/Off switch is desirable. This kit can be
retrofitted to previously installed appliances
and may be temporarily installed in place of
other switch circuitry.
Polished Brass and Brushed Stainless Hood Kits
Attractive hoods are available in two styles to be used on the Multi-Open Series appliances.
Thesehoods aredesigned tobe fittedto the glass viewing sides of the appliance. In addition
to providing an aesthetically pleasing appearance to your appliance installation, the hood
reduces heat effects to decorative mantles and finish materials located above the fireplace
opening.Thehoodkitreplacesthestandardhoodthatcomeswiththeseappliancesandsnaps
into place. These kits can be retrofitted to previously installed appliances.
stiKdooH
STESFOREBMUNDNA.ONLEDOM/.ONGOLATAC
tinU
ledoM
.oN
hsiniFssarBdehsiloPhsiniFsselniatSdehsurB
ediw.ni42rof
rooDssalG
ediw.ni04rof
rooDssalG
ediw.ni42rof
rooDssalG
ediw.ni04rof
rooDssalG
55L08
B06-EKH
35L08
B06/6-KH
36L08
P06-EKH
16L08
P06/6-KH
TSDC -2- 2
FPDC 121 2
RCDC
LCDC 111 1
stiKlenaPdecaFnaelCkcalB
.ONLEDOM/.ONGOLATAC
STESFOREBMUNDNA
tinU
ledoM
.oN
ediw.ni42rof
rooDssalG
ediw.ni04rof
rooDssalG
97L08
06-EKPFC
77L08
06/6-KPFC
TSDC -2
FPDC 12
RCDC
LCDC 11

11
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
ACCESSORY COMPONENTS CONTINUED
Touch-Up Paint Kit (Black) 90L73 FTPK-B
Touch-Up Paint Kit (Tan) 98K67
Touch-Up Paint Kit
Repair of minor scratches and discoloration of
theapplianceblackpaintedcabinetsurfacesmay
be accomplished with the touch-up paint kit.
Forced Air Blower Kits
-Single Speed 80L84 FBK-100
-Variable Speed with wall-mounted switch
80L85 FBK-200
-Variable Speed with unit-mounted switch
80L86 FBK-250
Forced Air Kit
The FBK-100 blower provides for a constant
velocity forced air circulation feature for your
appliance.TheFBK-200assemblywithvariable
speedwallswitchprovidesaforcedaircircula-
tion feature for your appliance. The FBK-250
comes complete with a unit mounted switch
operating system.
Screen Panel Kit
24 inch Wide Glass Door 80L46 SPKE-60
40 inch Wide Glass Door 80L44 SPK-6/60
Screen Panel Kit
An optional screen panel can be installed on the
Multi-Open Series doors. These screen panels
areeasytoinstall.Thesekitscanberetrofittedto
previouslyinstalledappliances.Thescreenpanel
kitscannotbeusedinconjunctionwitheitherof
the arch door kits or door frame kits.
Door Frame Kits (2-Piece, Top and Bottom)
Two types of decorative door frame kits are avail-
able for use with these appliances - one, in pol-
ished brass finish; the other, in brushed stainless
steelfinish.TheDTKisdesigned toattachdirectly
to the front face of the appliance at the glass
enclosure panels top and bottom edges. The DTK
providesatouchofelegancetotheappliance.The
door frame kit can be retrofitted onto previously
installed appliances.
Louvers Kits
Decorative louvers are available for use with
Multi-OpenSeriesfireplaces.Theselouversare
designed to replace the standard black louvers
that are provided with the appliance or to re-
placetheradiantpanelsiftheywereinstalledas
an accessory. The polished brass and brushed
stainless steel louver kits includes eight (8)
louvers. They provide a touch of elegance to
any Multi-Open Series appliance. This kit can
beretrofittedtopreviouslyinstalledappliances.
(FBK-200 Models Only)
)eceip-2(stiKemarFrooD
STESFOREBMUNDNA.ONLEDOM/.ONGOLATAC
tinU
ledoM
.oN
hsiniFssarBdehsiloPhsiniFsselniatSdehsurB
ediw.ni42rof
rooDssalG
ediw.ni04rof
rooDssalG
ediw.ni42rof
rooDssalG
ediw.ni04rof
rooDssalG
49M62
B6-EKTD
98M91
B6-KTD
59M62
SB6-EKTD
09M91
SB6-KTD
TSDC -2 - 2
FPDC 12 1 2
RCDC
LCDC 11 1 1
stiKrevuoL
STESFOREBMUNDNA.ONLEDOM/.ONGOLATAC
tinU
ledoM
.oN
hsiniFssarBdehsiloPhsiniFsselniatSdehsurB
ediw.ni42rof
rooDssalG
ediw.ni04rof
rooDssalG
ediw.ni42rof
rooDssalG
ediw.ni04rof
rooDssalG
17L08
B06-EKL
96L08
B06/6-KL
57L08
SB06-EKL
37L08
SB06/6-KL
TSDC -2 - 2
FPDC 12 1 2
RCDC
LCDC 11 1 1

12 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
LIGHTING INSTRUCTIONS –MILLIVOLT GAS VALVE
FOR YOUR SAFETY READ BEFORE LIGHTING
A. This appliance has a pilot which must be lighted with a piezo
ignitor. When lighting the pilot, follow these instructions
exactly.
B. BEFORE OPERATING smell all around the appliance area for
gas. Be sure to smell next to the floor because some gas is
heavier than air and will settle on the floor.
WHAT TO DO IF YOU SMELL GAS
•Extinguish any open flame.
•Open windows.
•Do not light any appliance.
•Do not touch any electrical switches.
TO TURN OFF GAS TO APPLIANCE
1. Turn remote wall switch “OFF.” The pilot will remain lit for
normal service.
2. For complete shutdown, turn remote wall switch to “OFF.”
3. Access the lower control compartment.
4. Depress gas control knob slightly and turn clockwise
to “OFF.” Do not force.
5. Close lower control compartment.
LIGHTING INSTRUCTIONS
1. STOP! Read the safety information above on this page.
2. Access the lower control compartment.
3. Turn remote wall switch to “OFF.”
4. Verify main line shut-off valve is open.
5. Push in gas control knob slightly and turn clockwise
to “OFF.”
6. Wait five (5) minutes to clear out any gas. If you then smell gas,
STOP! Follow “B” in the safety information above on this page. If you
do not smell gas, go to the next step.
7. Push in gas control knob slightly and turn counterclockwise
to “PILOT.”
8. Push in control knob all the way and hold in. Immediately light the
pilot by triggering the spark ignitor (pushing the button) until pilot
lights. Continue to hold the control knob in for about 1 ¹⁄₂ minutes
after the pilot is lit. Release knob and it will pop back up. Pilot should
remain lit. If it goes out, repeat steps 5 through 8.
•If knob does not pop up when released, stop
and immediately call your service
technician or gas supplier.
•If pilot will not stay lit after several
tries, turn the control knob to “OFF”
and call your service technician or
gas supplier.
9. Turn gas control knob counterclockwise
to “ON.”
10. Close lower control compartment.
•Do not use any phone in your building.
•Immediately call your gas supplier from a neighbor’s phone.
•If your gas supplier cannot be reached, call the fire depart-
ment.
C. Use only your hand to push in or turn the gas control knob.
Never use tools. If the knob will not push in or turn by hand,
do not try to repair it, call a qualified service technician. Force
or attempted repair may result in a fire or an explosion.
D. Do not use this appliance if any part has been under water.
Immediately call a qualified service technician to inspect the
appliance and to replace any part of the control system and
any gas control which has been under water.
Note: Knob cannot be turned from “PILOT” to “OFF”
unless the knob is pushed in slightly. Do not force.
H
I
L
O
W
TPTH TP TH
P
I
L
O
T
P
I
L
O
T
O
N
it
O
F
F
OUT
IN
WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION
MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.

13
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
INSTRUCTIONS D’ALLUMAGE –VANNE GAZ MILLIVOLT
INSTRUCTIONS D'ALLUMAGE
POUR VOTRE SÉCURITÉ, LISEZ CES INSTRUCTIONS AVANT L’ALLUMAGE
A. Cet appareil est muni d’une veilleuse qui doit être allumée avec un
allumeur piézo-électrique. Lorsque vous allumez la veilleuse, suivre
exactement ces instructions.
B. AVANT L’ALLUMAGE: Assurez-vous que vous ne détectez aucune
odeurdegazautourdel’apareilainsiqueprèsdusol;certainsgaz,étant
plus lourds que l’air, descendent au niveau du sol.
VOICI CE QUE VOUS DEVEZ FAIRE SI VOUS DÉCELEZ UNE ODEUR
DE GAZ:
•Éteignez toute flamme visible.
•Ouvrez les fenêtres.
•N’allumez aucun appareil.
•Ne touchez à aucun commutateur électrique.
•Ne vous servez d’aucun téléphone dans votre édifice.
•Appelezimmédiatementvotrecompagniedegazenutilisantletéléphone
du voisin.
•S’ilvousestimpossibledecontactervotrecompagniedegaz,appelez
le service des incendies.
C. N’utilisez que votre main pour manipuler le bouton de réglage du gaz.
N’utilisez jamais d’outils. Si le bouton refuse de tourner ou de bouger,
n’essayez pas de le réparer. Communiquez immédiatement avec un
technicien de service qualifié. Toute tentative pour le forcer ou le
réparer, risquerait de provoquer un incendie ou une explosion.
D. Ne vous servez pas de cet appareil si l’un de ses éléments a été
immergé dans l’eau. Appelez immédiatement un technicien compétent
pour faire inspecter l’appareil et remplacer toute pièce du système de
réglage ou commande du gaz qui a été sous l’eau.
1. Tournez l’interrupteur mural à la position d’arrêt “OFF”. La veilleuse
restera allumée jusqu’au retour du service normal.
2. Pour une fermeture complète, tournez l’interrupteur mural à la
position d’arrêt “OFF”.
3. Ouvrez le compartiment de contrôle du bas.
POUR FERMER LE GAZ QUI ALIMENTE L’APPAREIL
4. Enfoncez légèrement le bouton de réglage du gaz et tournez-le dans
le sens des aiguilles d’une montre jusqu’à la position
d’arrêt “OFF”. Ne forcez pas le bouton.
5. Fermez le compartiment de contrôle du bas.
8. Enfoncez le bouton de réglage jusqu’au fond et gardez-le enfoncé.
Allumez immédiatement la veilleuse en déclenchant l’allume-gaz à
étincelle (en poussant le bouton) jusqu’à ce que la veilleuse
s’enflamme. Continuez de tenir le bouton de réglage enfoncé
pendant environ 90 secondes après l’allumage de la veilleuse.
Relâchez le bouton et il sortira subitement. La veilleuse devrait
rester allumée. Si elle s’éteint, répétez les étapes 5 à 8
inclusivement.
•Si le bouton ne sort pas automatiquement après avoir été relâché,
arrêtez immédiatement et téléphonez
à votre technicien de service ou à
votre fournisseur de gaz.
•Si la veilleuse refuse de rester
allumée après plusieurs tentatives,
tournez le bouton de réglage jusqu’à
sa position d’arrêt “OFF” et
téléphonez à votre technicien de
service ou à votre fournisseur de gaz.
9. Tournez le bouton de réglage du gaz en sens inverse des aiguilles
d’une montre jusqu’à sa position de marche “ON”.
10. Fermez le compartiment de contrôle du bas.
11. Au besoin, rebrancher l’appareil au courant électrique et remettre
l’interrupteur du brûleur principal à la position “ON” ou régler le
thermostat à la température désirée.
12. Si l’appareil ne fonctionne pas, suivre les instructions intitulées
“Pour fermer le gaz qui alimente l’appareil” et appeler un
technicien ou le fournisseur de gaz.
Remarque: Il est impossible de tourner le bouton de “PILOT” à “OFF” à
moins qu’il ne soit légèrement enfoncé. Ne le forcez pas.
6. Attendez cinq (5) minutes pour l’evacuation du gaz. Si vous décelez
une odeur de gaz, ARRÊTEZ ! Retournez au point “B” des consignes
de sécurité au verso de cette plaque. Si vous ne remarquez aucune
odeur de gaz, passez à l’étape suivante.
7. Enfoncez légèrement le bouton de réglage du gaz et tournez-le en
sens inverse des aiguilles d’une montre jusqu’à la position de
veilleuse “PILOT”.
1. ARRÊTEZ! Lisez les consignes de sécurité au verso de cette plaque.
2. Ouvrez le compartiment de contrôle du bas.
3. Tournez l’interrupteur mural à la position d’arrêt “OFF”.
4. Assurez-vous que la soupape d’arrêt de la canalisation principale est
ouverte.
5. Enfoncez légèrement le bouton de réglage du gaz et tournez-le dans
le sens des aiguilles d’une montre jusqu’à la position
d’arrêt “OFF”.
H
I
L
O
W
TPTH TP TH
P
I
L
O
T
P
I
L
O
T
O
N
it
O
F
F
OUT
IN
AVERTISSEMENT : SI VOUS NE SUIVEZ PAS CES INSTRUCTIONS ÀLA LETTRE, IL POURRAIT S’EN SUIVRE UN INCENDIE OU
UNE EXPLOSION CAUSANT DES DOMMAGES MATÉRIELS, DES BLESSURES CORPORELLES OU MÊME DES PERTES DE VIE.

14 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
A. When lighting the appliance, follow these instructions
exactly.
B. BEFORE OPERATING smell all around the appliance area
for gas. Be sure to smell next to the floor because some
gas is heavier than air and will settle on the floor.
WHAT TO DO IF YOU SMELL GAS
•Extinguish any open flame.
•Open windows.
•Do not light any appliance.
•Do not touch any electrical switches.
•Do not use any phone in your building.
FOR YOUR SAFETY READ BEFORE LIGHTING
•Immediately call your gas supplier from a neighbor’s
phone.
•If your gas supplier cannot be reached, call the fire
department.
C. Use only your hand to turn the gas control lever. Never
use tools. If the lever will not turn by hand, do not try to
repair it, call a qualified service technician. Force or
attempted repair may result in a fire or an explosion.
D. Do not use this appliance if any part has been under
water. Immediately call a qualified service technician to
inspect the appliance and to replace any part of the
control system and any gas control which has been
under water.
LIGHTING INSTRUCTIONS —ELECTRONIC
1. For complete shut-down, turn remote wall switch to
“OFF.”
2. Open lower control compartment door.
3. Turn the ON/OFF switch to “OFF”. Do not force.
4. Close the main line shut-off valve.
5. Close lower control compartment door.
TO TURN OFF GAS TO APPLIANCE
LIGHTING INSTRUCTIONS
1. STOP! Read the safety information above on this page.
2. Turn remote wall switch to “OFF.”
3. Open lower control compartment door.
4. Verify main line shut-off valve is open.
5. Turn the ON/OFF switch to “OFF”. Do not force.
6. Wait five (5) minutes to clear out any gas. If you then
smell gas, STOP! Follow “B” in the safety information
above on this page. If you do not smell gas, go to the
next step.
7. Turn the ON/OFF switch to “ON”. Do not force.
8. Turn “ON” all electrical power to appliance (remote wall
or appliance switch).
9. Close lower control compartment door.
TO SHUT OFF
1. Turn off all electrical power to the appliance (remote wall
switch).
ON/OFF Switch
OFF
IN
PSI
ON
CONTROL
IGNITER
Front View
WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION
MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.

15
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
INSTRUCTIONS D’ALLUMAGE —ELECTRONIC
INSTRUCTIONS D’ALLUMAGE
POUR VOTRE SÉCURITÉ, LISEZ CES INSTRUCTIONS AVANT L’ALLUMAGE
A. Lorsquevousallumezl’appareil,suivezexactementcesinstruc-
tions.
B. AVANT L’ALLUMAGE: Assurez-vous que vous ne détectez
aucune odeur de gaz autour de l’apareil ainsi que près du sol;
certains gaz, étant plus lourds que l’air, descendent au niveau
du sol.
VOICI CE QUE VOUS DEVEZ FAIRE SI VOUS DÉCELEZ UNE
ODEUR DE GAZ
•Éteignez toute flamme visible.
•Ouvrez les fenêtres.
•N’allumez aucun appareil.
•Ne touchez à aucun commutateur électrique.
•Ne vous servez d’aucun téléphone dans votre édifice.
•Appelezimmédiatementvotrecompagniedegazenutilisant
le téléphone du voisin.
•S’il vous est impossible de contacter votre compagnie de
gaz, appelez le service des incendies.
C. N’utilisez que votre main pour manipuler l'interrupteur “ON/
OFF” de la valve à gaz. N’utilisez jamais d’outils. Si
l’interrupteur ne bouge pas manuellement, n’essayez pas de le
réparer. Communiquez immèdiatement avec un technicien de
service qualifié. Toute tentative pour forcer l’interrupteur ou le
réparer, risquerait de provoquer un incendie ou une explosion.
D. Nevousservezpas decet appareilsi l’unde seséléments aété
immergé dans l’eau. Appelez immédiatement un technicien
compétent pour faire inspecter l’appareil et remplacer toute
piècedusystèmederéglageoucommandedugazquiaétésous
l’eau.
1. ARRÊTEZ ! Lisez les consignes de sécurité au verso de cette
plaque.
2. Tournez l’interrupteur mural à la position d’arrêt “OFF”.
3. Ouvrez la porte du compartiment de contrôle du bas.
4. Assurez-vousquelasoupaped’arrêtdelacanalisationprincipale
est ouverte.
5. Tournezlamanettederéglagedugazàlapositiond’arrêt“OFF”.
6. Attendez cinq (5) minutes pour l’evacuation du gaz. Si vous
décelezuneodeurdegaz ARRÊTEZ! Retournezaupoint“B”des
consignes de sécurité au verso de cette plaque. Si vous ne
remarquez aucune odeur de gaz, passez à l’étape suivante.
7. Tournezlamanettederéglagedugazjusqu’àlapositiondemarche
“ON”. Ne la forcez pas.
8. Ouvrez le courant électrique (“ON”) qui alimente l’appareil
(interrupteur mural ou l'appareil).
9. Fermez la porte du compartiment de contrôle du bas.
10. Au besoin, rebrancher l’apareil au courant électrique et
remettre l’interrupteur principal du brûleur à la position “ON”
ou régler le thermostat à la température désirée.
11. Si l’appareil ne se met pas en marche, suivre les instructions
intitulées “Pour fermer le gaz qui alimente l’appareil” et appeler
un technicien ou le fournisseur de gaz.
POUR ÉTEINDRE L’APPAREIL
1. Coupez tout le courant électrique qui alimente l’appareil
(interrupteur mural).
POUR FERMER LE GAZ QUI ALIMENTE L’APPAREIL
3. Tournezlamanettederéglagedugazàlapositiond’arrêt“OFF”.
Ne la forcez pas.
4. Fermez la soupape d’arrêt de la canalisation principale.
5. Fermez la porte du compartiment de contrôle du bas.
1. Pourunefermeturecomplète,tournezl’interrupteurmuralàla
position d’arrêt “OFF”.
2. Ouvrez la porte du compartiment de contrôle du bas.
Interrupteur
ON/OFF
OFF
IN
PSI
ON
CONTROL
IGNITER
Vue de face
AVERTISSEMENT: SI VOUS NE SUIVEZ PAS CES INSTRUCTIONS ÀLA LETTRE, IL POURRAIT S’EN SUIVRE UN INCENDIE OU
UNE EXPLOSION CAUSANT DES DOMMAGES MATÉRIELS, DES BLESSURES CORPORELLES OU MÊME DES PERTES DE VIE.

16 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
TROUBLESHOOTING THE MILLIVOLT GAS CONTROL SYSTEM
1. Spark ignitor will not light
pilot after repeated
triggering of ignitor button.
2. Pilot will not stay lit after
carefully following the
lighting instructions.
3. Pilot burning, no gas to
burner, Valve knob “ON,”
Wall Switch “ON.”
4. Frequent pilot/burner outage
problem.
CORRECTIVE ACTIONSYMPTOM
A. Defective ignitor
(no spark at electrode).
B. Defective or misaligned electrode
at pilot (spark at electrode).
C. Gas supply pressure errant.
D. Pilot orifice plugged.
A. Defective pilot generator
(thermocouple).
A. Wall switch or wires defective.
B. Thermopile may not be generating
sufficient millivoltage.
C. Plugged burner orifice.
A. Pilot flame may be too low or
blowing (high) causing the pilot/
valve safety to drop out.
Check for spark at electrode and pilot; if no spark and
electrode wire is properly connected, replace ignitor.
POSSIBLE CAUSES
N ote: Before troubleshooting, make sure that the appliance main line gas shut-off valve and the gas control valve are in the "OPEN"
position and the burner ON/OFF switch is in the “ON” position.
Important: Valve system troubleshooting should only be accomplished by a qualified service technician.
Clean and/or adjust pilot flame for maximum flame impinge-
ment on thermocouple
(Figure 9 on page 7) .
Check burner orifice for stoppage and remove.
Checkthermopilewithmillivoltmeter.Takereadingatthermo-
pile terminals of gas valve. Should read 325 millivolts mini-
mum with optional wall switch “OFF.” Replace faulty thermo-
pile if reading is below specified minimum.
Check wall switch and wires for proper connections. Jumper
wire across terminals at wall switch, if burner comes on,
replacedefectivewallswitch.Ifokay,jumperwiresacrosswall
switch wires at valve, if burner comes on, wires are faulty or
connections are bad.
Check pilot flame, it must impinge on thermocouple
(Figure
9 on page 7)
Clean and/or adjust pilot for maximum flame
impingement on thermocouple. Ensure that the connection
between the valve and thermocouple are tight and secure.
Clean or replace pilot orifice.
Check inlet gas pressure. It should be within the limits as
marked on the rating plate.
Using a match, light pilot. If pilot lights, turn off pilot and
triggertheignitorbuttonagain.Ifpilotlights,animpropergas
mixture caused the bad lighting and a longer purge period is
recommended. If pilot will not light – check gap at electrode
and pilot – should be ¹⁄₈" to have a strong spark. If gap
measures ¹⁄₈", replace pilot
(Figure 9 on page 7) .

17
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
TROUBLESHOOTING THE ELECTRONIC IGNITION SYSTEM
SYMPTOM POSSIBLE CAUSES CORRECTIVE ACTION
See Below.
Disconnect the two black wires from the wire nuts. Test switch(s) for
continuity with a multimeter. If continuity is not indicated, switch(s) is
defective and must be replaced.
Note: Before replacing “OFF/ON” switch, be sure to check wiring for loose
connections or broken wires and repair as needed.
Check main burner orifice(s) for stoppage. Clean or replace.
Check vent system for obstructions.
A. Faulty Valve System.
B. “OFF/ON” or wall switch
defective.
A. Burner orifice plugged.
B. Obstructed vent system.
1. Burner will not light.
2. Burners come “ON” but
go “OFF.”
N ote: Before troubleshooting, make sure that the appliance main line gas shut-off valve and the gas control valve are in the "OPEN"
position and the burner ON/OFF switch is in the “ON” position.
Important: Valve system troubleshooting should only be accomplished by a qualified service technician.
•Turn Off Gas Supply
•Assure Valve Switch Is In ON Position
•Disconnect Control Harness
•Set Thermostat To Call For Heat
•Check For Proper Voltage At Control Harness
(See Insert A). Voltage Should Be 24V
Between Thermostat Or Pressure Switch
And 24V Common And 24V Hot.
•Line Voltage Power
•Low Voltage Transformer
•Limit Controller
•Thermostat
•Wiring
2
CHECK
START
NO
•Plug Control Harness Into Valve. Wait For
Internal Check Delay.
YES
•Igniter Warms Up And Glows Red.
•With Pilot Burner Cable Connected, Measure
Voltage At Valve HSI Element Output. 24V
Nominal. (See Insert B)
NO
•Replace Igniter/Flame Rod Assembly.
YES
•Replace Valve.
NO
•Turn On Gas Supply. •Pilot Burner Lights. •Check That Pilot Gas Is Flowing. Wait To
Assure Plot Gas Tubing Is Purged. Recycle
Call For Heat If Necessary.
NO
YES
NO
YES
YES
1
•Measure Voltage Between 24V Hot And 24V Common
Leads To Valve Control. Must Measure At Least 19.5
VAC With Igniter Powered (See Insert A). To Identify
Proper Lead, This Check Must Be Done With The
Valve Control Connected And Igniter Powered.
•Check Transformer And
Line Volt Supply.
NO
•Replace Pilot Assembly.
YES
•Check That Pilot Flame Makes Good Contact With
Pilot Burner Flame Rod.
•Check For Good Electrical Connection Through The
Pilot Tubing.
•If Both Of The Above Are Good, Replace Igniter/Flame
Rod Assembly.
•Cycle Thermostat Off And Back On.
YES
•Main Valve Opens And Main Burner Lights. NO
YES
•System Is Okay.
YES
•Main Burner Lights. NO
2
1
Igniter Will Cycle Off And Back On Once During
The 90 Second Ignition Trial. All Voltage
Measurements Must Be Taken While The Igniter
Is Powered.
When Measured Voltage At Connections, Use
Care To Assure Terminals Are Not Damaged.
•Replace Valve.
•Replace Valve.
24 Volt Hot
End View Of
Control Harness
Connector
24 Volt
Common
24 Volt
Switched
Check For Damaged Or Missing Terminals
In Connector
Insert A
Igniter Terminals
Insert B
2
1

18 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
REPLACEMENT PARTS LIST
.oNNOITPIRCSED enaporPdnalarutaN
.oNtraP.ytQ.ytQ.ytQ.ytQ
TSDCFPDCLCDCRCDC
a1.ni42-kcalb,dooHZE14919-BLenon111
b1.ni04-kcalb,dooHZC14919-BL2211
a2.ni42-kcalb,lenaPrevuoLreppUE40429-BLenon111
b2.ni04-kcalb,lenaPrevuoLreppUC40429-BL2211
a3.ni42-ylbmessAerusolcnEssalGE43529-BLenon111
b3.ni04-ylbmessAerusolcnEssalGC43529-BL2211
a4.ni42-kcalb,lenaPrevuoLrewoLE50429-BLenon111
b4.ni04-kcalb,lenaPrevuoLrewoLC50429-BL2211
5)dnarB(etalpemaN1039L652211
6teSgoL1026L961111
7srebmEgniwolGfogaB35L881111
8enotScinacloVevitaroceDfogaB24L082222
9lenaPrevuoL,tengaM6234902433
a01 teSrenruBniaM raeRE25459-BL1111
b01tnorFF25459-BL1111
11gnitnuoMyarTrenruB,teksaG1015L911111
21)renrubrep(gnitnuoMebuTirutneV,teksaG1058K341111
a31 /ebuTirutneV rettuhSriA raeR1029L471111
b31tnorF1004L061111
41lenaPerusolcnEssalG,hctaL1012L964644
51dedaoL-gnirpS,hctaL,tengaM1013L962211
61doRtnemtsujdArenruB16559-BL1111
71rotcennoCeniLsaGxelF23L391111

19
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
GAS CONTROLS —HONEYWELL ELECTRONIC
GAS CONTROLS —SIT MILLIVOLT
.oNNOITPIRCSED larutaNenaporP
.oNtraP.ytQ.oNtraP.ytQ
.03TIS-evlaVsaG1070K3411035J881
.13retingIozeiP1068K0111068K011
.23ylbmessAtoliP1071L9611081L961
.33rotareneGtoliP1097J0611097J061
.43elpuocomrehT1075L4711075L471
.53ebuTtoliP1065L4711065L471
.63elbaCdnAedortcelE1085L4711085L471
.73ecifirO1008J0621025L912
REPLACEMENT PARTS LIST
.oNNOITPIRCSED larutaNenaporP
.oNtraP.ytQ.oNtraP.ytQ
.04llewyenoH-evlaVsaG1081L2611091L261
.14ylbmessAtoliP1041L2611051L261
.24remrofsnarT1023J2411023J241
.34)tiK(ylbmessArotingI45L78145L781
.44ecifirO1008J0621025L912
.54ebuTtoliP06659-BL106659-BL1

20 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Printed in U.S.A. © 2002 by Lennox Hearth Products
P/N 725,001M REV. F 09/2005
The manufacturer reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products.
Consult your local distributor for fireplace code information.
LHP
1110 West Taft Avenue •Orange, CA 92865
REPLACEMENT PARTS
Model CDPF Shown - see table on page 18 and 19 for
replacement parts applicable to CDST, CDCR and CDCL
Firebox
Cabinet
1a
2a
3a
4a
8
10a
10b
37
13a
31
30
13b
44
16
12
12
7
17
14
1b
3b
4b
5
2b
11
32
33 34
36
35
40
43
41
45
42
6
15
9
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
