Supermicro X11SSH-CTF User manual

SUPERMICR R
ContaCt InformatIon
• Manuals: http://www.supermicro.com/support/manuals
• Drivers & Utilities: ftp://ftp.supermicro.com/CDR_Images/CDR-X11-UP/
• Safety: http://www.supermicro.com/about/policies/safety_information.cfm
© 2016 Supermicro Computer Inc. All rights reserved. Reproduction of this document whether in part or in whole is strictly prohibited without Supermicro's written consent. All Trademarks are property of their respective entities. All information provided is deemed accurate at the time of printing; however, it is not guaranteed.
PaCkage Contents
X11ssH-Ctf/tf
QuICk referenCe guIde 1.0a
• One (1) Supermicro Motherboard
• Six (6) SATA Cables
• One (1) I/O Shield
• One (1) Quick Reference Guide
• Website: www.supermicro.com
• General Information: [email protected]
• Technical Support: [email protected]
• Phone: [phone], Fax: [phone]
for your system to work ProPerly, Please download aPProPrIate
drIvers/Images/user'smanual from tHe lInks below:
MNL-1783-QRG-10a
DESIGNED IN USA
X11SSH-TF
REV:1.01
BAR CODE
SAS CODE
MEGERAC LICENSE
IPMI CODE
MAC CODE
PRESS FIT
Intel
PCH
LSI3008
(-CTF only)
X550
BT1
JSAS1
JSTBY1
LEDS1
J2
SP1
LE1
LEDBMC
LEDPWR
JBT1
JPSAS1
JOH1
JL1
JPG1 JBR1
JVRM2 JVRM1
JPME2
JVR1
JPS1
JPB1
JI2C1
JI2C2
JWD1
JPTG1
JSD2
JSD1
FAN5
FANA
FAN3
FAN4
FAN1
FAN2
JUIDB1
JIPMB1
JPI2C1
JD1 JPWR2
I-SGPIO2
I-SGPIO1
I-SATA5
I-SATA4 I-SATA3 I-SATA2
I-SATA1 I-SATA0
JF1
JTPM1
JPWR1
I-SATA6I-SATA7
J24
LE3
MH8
JPCK1
DIMMB2
DIMMB1
DIMMA2
DIMMA1
USB8(3.0)
USB4/5
USB9/10(3.0)
USB2/3
CPU Socket LGA1151
PCH SLOT4 PCI-E 3.0 X2(X4)
CPU SLOT6 PCI-E 3.0 X8
VGA
LAN2 LAN1
USB6/7
(3.0)
USB0/1
IPMI_LAN
COM2
COM1
Connectors
DIMM Memory Installation
Connectors and LED Indicators
Back Panel I/O Connectors
Memory Support
Motherboard Layout and Features
Jumpers
CPU Installation
Note: Graphics shown in this quick reference guide are for illustration only. Your components may or may not look exactly the same as drawings shown in this
guide.
Note: Refer to Chapter 1 of the User Manual for detailed information on jumpers, connectors,
and LED indicators.
Note: Refer to Chapter 2 of the User Manual for detailed information on memory support and CPU/
motherboard installation instructions.
Heatsink Installation Front Panel Control (JF1)
CPU Support
LED Indicators
Apply thermal
grease
The X11SSH-CTF/TF motherboard supports up to 64GB of DDR4 ECC UDIMM
memory at a speed of 2133 MHz in four memory slots. Populating these DIMM
slots with a pair of memory modules of the same type and size will result in
interleaved memory, which will improve memory performance.
When installing memory modules, the DIMM slots should be populated in the fol-
lowing order: DIMMB2, DIMMA2, then DIMMB1, DIMMA1. Populate the blue sots
rst. See the motherboard layout on the left for the location of the DIMM slots.
• Always use DDR4 DIMM modules of the same type, size, and speed.
• Mixed DIMM speeds can be installed. However, all DIMMs will run at the
speed of the slowest DIMM.
• The motherboard will support odd-numbered modules (1 or 3 modules in-
stalled). However, for best memory performance, install DIMM modules in
pairs to activate memory interleaving.
Back panel I/O
1. COM Port 6. USB6 (3.0)
2. IPMI LAN 7. LAN1
3. USB1 8. LAN2
4. USB0 9. VGA Port
5. USB7 (3.0)
1
9
1
2
3
4
5
678
Pin 1
Socket Key
CPU Key
Press down
and turn
clockwise
Jumper Description Default Setting
JBR1 BIOS Recovery Pins 1-2 (Normal)
JBT1 CMOS Clear Open (Normal)
JI2C1/JI2C2 SMB to PCI-E Slots Enable/Disable Pins 2-3 (Disabled, Default)
JPB1 BMC Enabled Pins 1-2 (Enabled)
JPCK1 LANCONF Flash Pins 2-3 (Disabled, Default)
JPG1 VGA Enable/Disable Pins 1-2 (Enabled)
JPME2 Manufacturing Mode Pins 1-2 (Normal)
JPS1 SAS 3.0 Enable/Disable (X11SSH-CTF only) Pins 1-2 (Enabled)
JPSAS1 SAS HDD Enable/Disable (X11SSH-CTF only) Pins 1-2 (Enabled, Default)
JPTG1 10Gb LAN Enable/Disable Pins 1-2 (Enabled)
JVRM1 VRM SMB Clock (to BMC or PCH) Pins 1-2 (BMC, Normal)
JVRM2 VRM SMB Data (to BMC or PCH) Pins 1-2 (BMC, Normal)
JWD1 Watch Dog Pins 1-2 (Reset)
Connector Description
BT1 Onboard Battery
COM1/COM2 COM Port/COM Header
FAN1 ~ FAN5, FANA System/CPU Fan Headers (FAN1: CPU Fan)
IPMI_LAN Dedicated IPMI LAN Port
I-SATA0 ~ I-SATA7 Intel PCH SATA 3.0 Ports
I-SGPIO/I-SGPIO2 Serial Link General Purpose I/O Headers
J24 M.2 PCI-E 3.0 X4 Slot
JD1 Power LED/Speaker Header (Pins 1-3: Power LED, Pins 4-7: Speaker)
JF1 Front Control Panel Header
JIPMB1 4-pin BMC External I2C Header (for an IPMI Card)
JL1 Chassis Intrusion Header
JOH1 Overheat LED Header
JPI2C1 Power Supply SMBbus I2C Header
JPWR1 24-pin ATX Power Connector
JPWR2 12V 8-pin Processor Power Connector
JSAS1 Eight SAS 3.0 Ports (X11SSH-CTF only)
JSD1/JSD2 SATA DOM Power Connectors
JSTBY1 Standby Power Header
JTPM1 Trusted Platform Module/Port 80 Connector
JUIDB1 UID Switch
LAN1/LAN2 LAN (RJ45) Ports
SLOT4 PCH PCI-E 3.0 X2 (IN X4) Slot
SLOT6 CPU PCI-E 3.0 X8 Slot
SP1 Internal Speaker/Buzzer
USB0/1 Back panel Universal Serial Bus (USB) 2.0 Port
USB2/3, USB4/5 Front Accessible USB 2.0 Headers
USB6/7 Back panel USB 3.0 Port
USB8 USB Type A Header
USB9/10 Front Accessible USB 3.0 Header
VGA VGA Port
LED Description Status
LEDBMC BMC Heartbeat LED Blinking Green: BMC Normal
LEDPWR Onboard Power LED Solid Green: Power On
LEDS1 SAS Activity LED (X11SSH-CTF only) Blinking Green: SAS Active, Red: SAS Error
LE1 UID LED Solid Blue: Unit Identied
LE3 M.2 LED Blinking Green: Active
The X11SSH-CTF/TF motherboard supports an Intel Xeon E3-1200 v5, 6th
Gen Core i3, Pentium, and Celeron series processors in an LGA1151 type
socket.
Recommended Population (Balanced)
DIMMA1 DIMMB1 DIMMA2 DIMMB2 Total System Memory
2GB 2GB 4GB
2GB 2GB 2GB 2GB 8GB
4GB 4GB 8GB
4GB 4GB 4GB 4GB 16GB
8GB 8GB 16GB
8GB 8GB 8GB 8GB 32GB
16GB 16GB 32GB
16GB 16GB 16GB 16GB 64GB
LE3 SAS Heartbeat LED Blining Green: SAS Normal
Power Button
OH/Fan Fail
NIC1 Active LED
Reset Button
HDD LED
PWR LED
Reset
PWR
3.3V
ID_UID_SW/3.3V Stby
3.3V Stby
Ground
19
X
Ground
X
3.3V Stby
3.3 V
5V Stby
20
1 2
Ground
Power Fail LED
NIC2 Active LED
NMI
