Addendum to MNL#724-- for the X6DA8-G/X6DAE-G & X6DA8-G2/X6DAE-G2 motherboards
Attention!!
ImportantNotice!!
(Read the information listed below before using this product.)
1. For the X6DA8-G/X6DAE-G boards:
Jumpers XJ4F1/XJ4F2 (PLLSEL Select): These jumpers allow the user to select PLLSEL (Memory Speed). Make
sure that the jumper settings are set correctly according to your memory speed before you power on the system.
(*Warning!! If these jumpers are not set correctly according to your memory speed, video display failure may
occur!!!)
DDR
*333 MHz
266MHz
XJ4F1 XJ4F2
Closed Closed
Open Open
PLLSEL Select
Jumper Settings
(XJ4F1/XJ4F2)
(*Default:Closed-333MHz)
KB/
Mouse
DIMM 4A
DIMM 4B
DIMM 3A
DIMM 3B
DIMM 2A
DIMM 2B
DIMM 1A
DIMM 1B
SPKR
GLAN
Enable
Tumwater
(NorthBridge)
(South
Bridge)
IPMI 2.0
BIOS
7902
SCSI
CTRL
IDE #1
IDE #2
Floppy
Fan4
FPUSB 6/7
JD2 SATA0
JPA3
FPC
TRL
JF1
FAN7
PW SMB
CPU1
CPU2
J9
J40
J3
J4
JP8
JD1
J24
XJ4F2
USB 0/
1/2/3
JLAN1
COM2
COM1
Parrallel Port
Fan6 Fan5
J32
4-pin
PWR
Bank 1
Bank 1
Bank 2
Bank 2
Bank 3
Bank 3
Bank 4
Bank 4
ATX PWR
J1B4 JPF
Force
PW
(**JLA
N
)
Line_In/
Line_Out
XJ4F1
(PLL
Select*)
JPC1
Audio
Enable
SI/O
x16 PCI EXP #6
PCI #5-33MHz
PCIX#3-133MHz
PCIX#2-100MHz
J27
BIOSD
ebug
CD1 CD2
PCIX#1-100MHz ZCR
GLAN
CTRL
JPL1
Battery
JWOR SMBus
J22
SATA1
SCSI Ch B
JPA2
SCSI Ch A
JA1
JA2
Fan3
Cha.
Intru
JPA1
SCSI CTRL
Enable
J20
JWD
WD
JK1
Keylock
Fan8
PWR
Fault
(*X6DA8/
E
-
G)
JBT1
Clear
cmos
FAN1
3rd PS
Alarm
OH
LED
PWR
LED
SPKR
ICH
SPKR
J1D1
12V 8-
pinPW
SCSI Ch.A
Term.
SCSICh.B
Term.
JC2
Mic
JC1
x4 PCI EXP #4
JWOL
JL1
JP13
JP14
JOH1
JP15
PW
Fault
(*X6DA8/
E-G2)
JP12
PXH
LAN
USB4/5
JD3
FAN2
WOL
WOR
JP12
PW Fail
2. For the X6DA8-G/X6DAE-G & the X6DA8-G2/X6DAE-G2 models:
J1D1 (12V 8-pin PWR) and J32 (12 V 4-pin PWR): Make sure that both PWR Connectors are used to ensure
adequate power supply to the system and the CPU.
XJ4F1/XJ4F2
(PLLSEL Select):
(*X6DA8-G/
X6DAE-G Only) J1D1 (12V 8-pin
PWR)
(*Note: the default setting is “Closed” for both jumpers to
enable DDR Memory at 333MHz. However, if your memory
speed is 266MHz, please make sure to set both jumpers
to “Open”.)
J32 (12V 4-pin
PWR)
Add-X6DA8-G-MNL#724-6/11/04

Page 2 of 2
Addendum to MNL#724-- for the X6DA8-G/X6DAE-G & X6DA8-G2/X6DAE-G2 motherboards
Add-X6DA8-G-MNL#724-6/11/04
(Caution! We do not recommend that the
CPU or the heatsink be removed. However,
if you do need to un-install the heatsink,
please follow the instructions below to
uninstall the heatsink to prevent damage
done to the CPU or the CPU socket. )
ToUn-installthe Heatsink
1. Unscrew and remove the heatsink
screws from the motherboard in the
sequence as show in the picture on the
right.
2. Hold the heatsink as show in the
picture on the right and gently wriggle the
heatsink to loosen it from the CPU. (Do
not use excessive force when wriggling
the heatsink!!)
3. Once the CPU is loosened from the
heatsink, remove the heatsink from the
CPU socket.
4. Clean the surface of the CPU and the
heatsink to get rid of the old thermal
grease. Reapply the proper amount of
thermal grease on the surface before
you re-install the CPU and the heatsink.
