Supermicro FatTwin F629P3-RTB User manual

USER’S MANUAL
Revision 1.0
FatTwin®
F629P3-RTB
F629P3-RTBN
F629P3-RC0B
F629P3-RC1B

PB
The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes
no responsibility for any inaccuracies that may be contained in this document, and makes no commitment to update
or to keep current the information in this manual, or to notify any person or organization of the updates. Please Note:
For the most up-to-date version of this manual, please see our website at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product described in this manual
at any time and without notice. This product, including software and documentation, is the property of Supermicro and/
or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except
as expressly permitted by the terms of said license.
IN NO EVENT WILL Super Micro Computer, Inc. BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIALDAMAGESARISING FROM THE USE OR INABILITYTO USE THIS PRODUCT
OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER
MICRO COMPUTER, INC. SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED
OR USED WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,
INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa Clara County in the
State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution
of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
FCC Statement: This equipment has been tested and found to comply with the limits for a Class A digital device
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the manufacturer’s instruction manual,
may cause harmful interference with radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case you will be required to correct the interference at your own expense.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warning applies only
to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate Material-special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate”.
WARNING: Handling of lead solder materials used in this product may expose you to lead, a
chemical known to the State of California to cause birth defects and other reproductive harm.
The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment,
nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical

property damage. Accordingly, Supermicro disclaims any and all liability, and should buyer use or sell such products
for use in such ultra-hazardous applications, it does so entirely at its own risk. Furthermore, buyer agrees to fully
indemnify, defend and hold Supermicro harmless for and against any and all claims, demands, actions, litigation, and
proceedings of any kind arising out of or related to such ultra-hazardous use or sale.
Manual Revision 1.0
Release Date: February 27, 2018
Unless you request and receive written permission from Super Micro Computer, Inc., you may not copy any part of this

to herein are trademarks or registered trademarks of their respective companies or mark holders.
Copyright © 2018 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America

3
FatTwin F629P3-RTB/RTBN/RC0B/RC1B User's Manual
Preface
About this Manual
This manual is written for professional system integrators and PC technicians. It provides
information for the installation and use of the FatTwin F629P3-RTB/RTBN/RC0B/RC1B.
Installation and maintenance should be performed by experienced technicians only.

for updates on supported memory, processors and operating systems (http://www.supermicro.
com).
Notes
For your system to work properly, please follow the links below to download all necessary
drivers/utilities and the user’s manual for your server.
• Supermicro product manuals: http://www.supermicro.com/support/manuals/
• Product drivers and utilities: ftp://ftp.supermicro.com
• Product safety info: http://www.supermicro.com/about/policies/safety_information.cfm
If you have any questions, please contact our support team at:
[email protected]
This manual may be periodically updated without notice. Please check the Supermicro website
for possible updates to the manual revision level.
Warnings
Special attention should be given to the following symbols used in this manual.
Warning! Indicates high voltage may be encountered when performing a procedure.
Warning! Indicates important information given to prevent equipment/property damage


4
Preface
Contents
Chapter 1 Introduction
1.1 Overview...............................................................................................................................9
1.2 Unpacking the System .......................................................................................................10
1.3 FatTwin: System Notes ......................................................................................................10
Nodes................................................................................................................................10
System Power ...................................................................................................................10
SAS/SATA/NVMe Backplane/Drives .................................................................................10
1.4 System Features ................................................................................................................11
1.5 Server Chassis Features....................................................................................................12
Control Panel ....................................................................................................................12
Front Features...................................................................................................................13
Rear Features ...................................................................................................................14
1.6 Motherboard Layout ...........................................................................................................15
Quick Reference Table......................................................................................................16
Chapter 2 Server Installation
2.1 Overview.............................................................................................................................18
2.2 Preparing for Setup ............................................................................................................18
Choosing a Setup Location...............................................................................................18
Rack Precautions ..............................................................................................................19
Server Precautions............................................................................................................19
Rack Mounting Considerations .........................................................................................19
Ambient Operating Temperature....................................................................................19
 ............................................................................................................................19
Mechanical Loading.......................................................................................................20
Circuit Overloading ........................................................................................................20
Reliable Ground.............................................................................................................20
2-5 Rack Mounting Instructions................................................................................................21
Identifying the Sections of the Rack Rails........................................................................22
 ............................................................................................................22
Installing the Rails on a Rack ...........................................................................................23
Chassis Installation ...........................................................................................................24

5
FatTwin F629P3-RTB/RTBN/RC0B/RC1B User's Manual
Chapter 3 Maintenance and Component Installation
3.1 Removing Power ................................................................................................................25
3-2 Chassis Components .........................................................................................................26
Removing Nodes from the Chassis ..................................................................................26
Removing the Cover from the Node.................................................................................27
..........................................................................................................28
Overview of the Node....................................................................................................28
F424AS2 Node Layout ..................................................................................................28
Associated Hard Drives.....................................................................................................29
Installing and Removing 3.5" Hard Drives ....................................................................30
Removing the Rear Hard Drive Cage...............................................................................32
Removing and Installing the Backplane............................................................................35
Removing the Backplane...............................................................................................35
Installing the Backplane ....................................................................................................36
Removing the Rear Hard Drive Cage Backplane.............................................................37
Installing the Serverboard ................................................................................................38
Compatible Motherboards .............................................................................................38
Permanent and Optional Standoffs ...............................................................................38
Power Adapter Card Replacement ...................................................................................40
Installing Expansion Cards................................................................................................41
..............................................................................41
Installing the PCI-E Slot Bracket Assembly Into the Node ...........................................42
Installing a SIOM Module..................................................................................................43
Installing Air Shrouds ........................................................................................................44
Removing and Installing System Fans .............................................................................45
Replacing the Power Supplies .........................................................................................47
Power Supply Replacement..............................................................................................47
3.3 Motherboard Components..................................................................................................49
Processor and Heatsink Installation..................................................................................49
The Processor...................................................................................................................49
Overview of the Processor Socket Assembly ...................................................................50
Overview of the Processor Heatsink Module....................................................................51
Preparing the CPU Socket for Installation........................................................................52
Removing the Dust Cover from the CPU Socket .............................................................52

6
Preface
Attaching the Processor to the CPU/Heatsink Carrier......................................................53
Attaching the CPU/Carrier Assembly to the Passive Heatsink to Form the Processor
Heatsink Module (PHM)....................................................................................................54
Installing the Processor Heatsink Module (PHM) ............................................................55
Removing the Processor Heatsink Module (PHM) ...........................................................56
Memory Support and Installation ......................................................................................57
Memory Support ............................................................................................................57
DIMM Population Requirements....................................................................................57
DIMM Installation ..............................................................................................................61
DIMM Removal .................................................................................................................61
Motherboard Battery .........................................................................................................62
Chapter 4 Motherboard Connections
4.1 Power Connections ............................................................................................................63
4.2 Headers and Connectors ...................................................................................................63
4.3 Rear I/O Ports ....................................................................................................................65
Ethernet Ports................................................................................................................66
4.4 Front Control Panel ............................................................................................................67
4.5 Jumpers..............................................................................................................................70
Explanation of Jumpers.................................................................................................70
4.6 LED Indicators....................................................................................................................72
4.7 PCI-E 3.0 Slots...................................................................................................................73
Chapter 5 Software
5.1 OS Installation....................................................................................................................74
Installing the Windows OS for a RAID System ................................................................74
Installing Windows to a Non-RAID System ......................................................................74
5.2 Driver Installation................................................................................................................75
5.3 SuperDoctor®5...................................................................................................................76
5.4 IPMI ....................................................................................................................................77
Chapter 6 BIOS
6.1 Introduction.........................................................................................................................78
Starting the Setup Utility ...................................................................................................78
6.2 Main Menu..........................................................................................................................79
6.3 Advanced Settings Menu ...................................................................................................81
6.4 Trusted Computing ..........................................................................................................110
6.5 Event Logs .......................................................................................................................113

7
6.6 IPMI ..................................................................................................................................115
6.7 Security Settings ..............................................................................................................119
6.8 Boot Settings....................................................................................................................122
6.9 Save & Exit.......................................................................................................................124
Appendix A BIOS Error Codes
Appendix B Standardized Warning Statements for AC Systems
Appendix C System Specications
Appendix D UEFI BIOS Recovery

8
Contacting Supermicro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
Website: www.supermicro.com
Europe
Address: Super Micro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
[email protected] (Customer Support)
Website: www.supermicro.nl
Asia-Pacic
Address: Super Micro Computer, Inc.
3F, No. 150, Jian 1st Rd.
Zhonghe Dist., New Taipei City 235
Taiwan (R.O.C)
Tel: [phone]
Fax: [phone]
Email: [email protected]
Website: www.supermicro.com.tw
FatTwin F629P3-RTB/RTBN/RC0B/RC1B User's Manual

9
Chapter 1: Introduction
Chapter 1
Introduction
1.1 Overview
This chapter provides a brief outline of the functions and features of the
F629P3-RTB/RTBN/RC0B/RC1B. The F629P3-RTB/RTBN/RC0B/RC1B is based on the
X11DPFR-S/SN motherboard and the F424AS2-R1K23BP chassis. This FatTwin system
includes four motherboard tray nodes in the chassis.
In addition to the motherboard and chassis, several important parts that are included with
the system are listed below.
Main Parts List
Description Part Number Quantity
OCuLink v.1.0, 4x PCI-E, 37-cm cables (F629P3-RTBN only) CBL-SAST-0974-1 8
2X mini-SAS HD to 2x SATA, 55-cm, AWG28 cables (F629P3-RTBN only) CBL-SAST-1005-1 4
20 to 20-pin 7.5-cm, 28AWG backplane cables CBL-OTHR-0022L 4
Internal mini-SAS HD to 4 SATA 50-cm, w/50cm SB cables (F629P3-RTB
/F629P3-RTBN only) CBL-SAST-0616 4
Mini-SAS HD to 4x SATA, 55-cm, AWG28 cables (F629P3-RTB only) CBL-SAST-1004-1 4
Internal RA reverse Mini-SAS HD to 2x Mini-SAS HD Y-splitter 15/59-cm,
30AWG cables (F629P3-RC0B/F629P3-RC1B only) CBL-SAST-0691 4
Internal RA reverse Mini-SAS HD to Mini-SAS HD 11-cm, 30AWG, 12Gb/s
cables (F629P3-RC0B/F629P3-RC1B only) CBL-SAST-0706 4
2x 3.5" HDD backplane (F629P3-RTB only) BPN-SAS-F424-A2 4
6x 3.5" HDD backplane (F629P3-RTB /F629P3-RTBN only) BPN-SAS-F424-A6 4
2-Port Hybrid Backplane supports 2x SAS3/SATA3/NVMe Storage Devices
(F629P3-RTBN/F629P3-RC0B/F629P3-RC1B only)
BPN-SAS3-F424-
A2N2A 4
Backplane for 6x 3.5" SAS3/SATA3 HDD/SSD (F629P3-RC0B/F629P3-RC1B
only)
BPN-SAS3-
F424-A6 4
2U passive CPU heat sink with a side air channel, equipped with a narrow
retention mechanism SNK-P0068PSC 4
1.5U proprietary 50-mm tall passive CPU heat sink with a side air channel SNK-P0069PSC 4
Black gen 6.5 hot-swap 3.5 inch HDD trays MCP-220-00094-0B 32
F424AS2 air shroud MCP-310-42408-0B 4
80x80x38-mm, 13.5K RPM, HCP, LMV, and LPC Cooling Fan FAN-0162L4 8
Fat twin F418/F424 static rail set support 28-33.5-inch depth rail MCP-290-41803-0N 1

10
FatTwin F629P3-RTB/RTBN/RC0B/RC1B User's Manual
1.2 Unpacking the System
Inspect the box the SuperServer F629P3-RTB/RTBN/RC0B/RC1B was shipped in and note if

with the carrier who delivered it.
Decide on a suitable location for the rack unit that will hold the server. It should be situated
in a clean, dust-free area that is well ventilated. Avoid areas where heat, electrical noise and

Be sure to read the precautions and considerations noted in Appendix B.
1.3 FatTwin: System Notes

system. With four system boards incorporated into a single chassis acting as four separate
nodes, there are several points you should keep in mind.
Nodes
Each of the four serverboards act as a separate node in the system. As independent nodes,
each may be powered off and on without affecting the others. In addition, each node is a
hot-swappable unit that may be removed from the chassis. The nodes are connected to the
server backplane by means of an adapter card.
Note: A guide pin is located between the upper and lower nodes on the inner chassis wall.
This guide pin also acts as a “stop” when a node is fully installed. If too much force is used
when inserting a node this pin may break off. Take care to slowly slide a node in until you
hear the “click” of the locking tab seating itself.
System Power
Four 1200 Watt power supplies are used to provide the power for all serverboards. Each
serverboard however, can be shut down independently of the others with the power button
on its own control panel.
SAS/SATA/NVMe Backplane/Drives
As a system, the FatTwin F629P3-RTB/RTBN/RC0B/RC1B supports the use of eight (8) SAS/
SATA, or six (6) SAS/SATA drives and two (2) NVMe 3.5" drives in front-mounted hot-swap
drive trays per node, for a total of thirty-two (32) HDD drives in the system. Each of the eight
backplanes works to apply system-based control for power and fan speed functions, yet at
the same time logically connects a set of eight (8) SAS/SATA, or six (6) SAS/SATA drives
and two (2) 3.5" NVMe drives to each backplane/serverboard. Consequently, RAID setup is
limited to an eight-drive scheme (RAID cannot be spread across all drives). See Chapter 6


11
Chapter 1: Introduction
1.4 System Features
The following table provides you with an overview of the main features of the

System Features
Motherboard
X11DPFR-S/SN
Chassis
F424AS2-R1K23BP
CPU
Dual Intel Xeon 81xx/61xx/51xx/41xx/31xx series which offer 2 UPI (UltraPath Interconnect) of up to 10.4GT/s
Note: Both CPUs need to be installed for full access to the PCI-E slots, DIMM slots, and onboard controllers. Refer to the
block diagram on page 16 to determine which slots or devices may be affected.
Socket Type
Socket P
Memory
Integrated memory controller supports up to 1536 GB of ECC Load Reduced DIMM (LRDIMM), Registered
DIMM (RDIMM), and Non-Volatile DIMM (NV-DIMM) DDR4 (288-pin) 2666/2400/2133 Mhz modules in
twelve (12) slots
Chipset
Intel C621 chipset
Expansion Slots
One (1) PCI-Express 3.0 (x16) slot
One (1) PCI-Express 3.0 x16 (x8 + x8) SMCI storage Slot (JSXB2)
One (1) PCI-Express 3.0 x16 SIOM LAN Port
Hard Drives
The amount and type of hard drives in the system depends upon the model number as follows:
F629P3-RTB: eight (8) 3.5" SATA3 drives
F629P3-RTBN: six (6) 3.5" SATA3 and two (2) 2.5" NVME/SATA3 drives
F629P3-RC0B/F629P3-RC1B: eight 3.5" SAS3/SATA3 drives
Power
Four 1200 Watt redundant power supplies
Cooling
Up to two (2) 8-cm cooling fans for each of the system's four serverboard nodes
Form Factor
Proprietary: (LxW): 9.66" x 8.53" (216.66 mm x 499.36 mm)
Dimensions
Chassis dimensions: (WxHxD) 17.63 x 6.96 x 29 in. (448 x 177 x 737 mm)

12
FatTwin F629P3-RTB/RTBN/RC0B/RC1B User's Manual
Control Panel Features
Item Feature Description
1Power Button
The main power button on each of the eight control panels is used to apply
or remove power from the power supply to each of the eight systems in the
chassis. Turning off system power with this button removes the main power,
but keeps standby power supplied to the system. Therefore, you must unplug
system before servicing. The power button has a built-in LED which will turn
green when the power is on.
2NIC 
3Information LED See the table below for full details on the Information LED.
4UID LED
When used with a UID compatible serverboard, the UID indicator is used to
turn on or off the blue light function of the LED. This is built into the front side
of the UID button and at the rear end of each serverboard node, for those
motherboards which support it. Once the blue light is activated, the unit can be
easily located in very large racks and server banks.
Figure 1-1. Control Panel View
1.5 Server Chassis Features
Control Panel
The switches and LEDs located on the control panel are described below. See Chapter 4 for
details on the control panel connections.
1
4
3
2

13
Chapter 1: Introduction
Front Chassis Features
Item Feature Description
1Node Control Panels (4) See the section for Control Panel above for details.
2Drive Bays Each node has six (6) bays in the front for 3.5" HDD/SSD/NVMe drives. The

Figure 1-2. Chassis Front View
Front Features
The F424AS2-R1K23BP is a 4U chassis with four server nodes. See the illustration below
for the features included on the front of the chassis.
Information LED
Status Description
Continuously on and red An overheat condition has occurred. (This may be caused by cable congestion.)
Blinking red (1 Hz) Fan failure: check for an inoperative fan.
Blinking red (0.25 Hz) Power failure: check for an inoperative power supply.
Solid blue Local UID has been activated. Use this function to locate the server in a rack environment.
Blinking blue (300 msec) Remote UID has been activated. Use this function to locate the server from a remote location.
1
2
11
1

14
FatTwin F629P3-RTB/RTBN/RC0B/RC1B User's Manual
Rear Chassis Features
Item Feature Description
1Power Supply Four (4) redundant 1200 Watt power supplies are at rear of the chassis
2Rear I/O Ports Each node has its own rear I/O ports. See Chapter 3 for I/O port descriptions.
3SIOM Module Bay Each node has one rear SIOM module bay available for additional I/O ports.
4Rear Drive Bays Each node has two (2) bays in the rear for 3.5" HDD/SSD/NVMe drives. The

5Expansion Card Slots Each node has one (1) rear expansion card slots available for access.
Figure 1-3. Chassis Rear View
Rear Features
The illustration below shows the features included on the rear of the chassis.
1
4
1
1
1
2
2
2
2
4
4
4
4
4
4
4
33
33
5
5
5
5

15
Chapter 1: Introduction
Figure 1-4. Motherboard Layout
1.6 Motherboard Layout

the table on the following page for descriptions. For detailed descriptions, pinout information

1
+
DESIGNED IN USA
MAC CODE
X11DPFR-S
REV:1.00
BAR CODE
FAN2
S-SATA1
S-SATA0
FAN3FAN1
JS2
JS1
JNVI2C1
JIPMB1
JPWR_HDD3
JPWR_HDD2
