Board Layout
SuperServer 1027R-WC1R/WC1RT Quick Reference Guide
Rear View
CPU Installation
Beep Codes
Front View & Interface
Heatsink Installation
1. Place heatsink on top of installed CPU
2. Line up the four screws to socket
3. Push down heatsink and screw down as shown
(cross pattern)
4. NOTE: Only use 6-8 lb/f of torque; otherwise, hand-tighten
each screw, to avoid damaging the system
MEMORY
Caution
Align CPU to socket;
install CPU straight down
NOTE:
Do not bend pin inside socket
!
Description
No.
1234 5
SXBA1/SXB1B/SXB1C: CPU1/CPU2 PCI-E 3.0 x16 + x16
SXB2: CPU2 PCI-E 3.0 x16
P2-DIMME1 (Blue)/P2-DIMME2 slot
P2-DIMMF1 (Blue)/P2-DIMMF2 slot
CPU2
P2-DIMMH1( Blue)/P2-DIMMH2 slot
P2-DIMMG1 (Blue)/P2-DIMMG2 slot
P1-DIMMA1 (Blue)/P1-DIMMA2 slot
P1-DIMMB1 (Blue)/P1-DIMMB2 slot
CPU1 (it must be installed on it first)
P1-DIMMD1 (Blue)/P1-DIMMD2 slot
P1-DIMMC1 (Blue)/P1-DIMMC2 slot
AOM PCI-E 3.0 x16
I-SATA 3 Ports 0~1 (from Intel PCH)
I-SATA 2 Ports 2~3 (from Intel PCH)
JSD1: SATA DOM Power
JBT1 = CMOS Reset
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
67
SAFETY INFORMATION
IMPORTANT: See installation instructions and safety warning
before connecting system to power supply.
http://www.supermicro.com/about/policies/safety_information.cfm
WARNING:
To reduce risk of electric shock/damage to equipment,
disconnect power from server by disconnecting all power
cords from electrical outlets.
If any CPU socket empty, install protective plastic CPU cap
CAUTION:
Always be sure all power supplies for this system have
the same power output. If mixed power supplies are
installed, the system will not operate.
For more information go to :
http://www.supermicro.com/support
!
!
!
Power LED
Device Activity LED
LAN1 LED & LAN2 LED
Information LED
Power Button
UID Button
USB 2.0 Ports
Hard Drive Signal
Hard Drive Fail
Description
No.
1
2
3
4
5
6
7
8
9
HDD 1
SAS3
HDD 3
SAS3
HDD 5
SAS3
HDD 7
SAS3
HDD 9
SATA3
HDD 0
SAS3
HDD 2
SAS3
HDD 4
SAS3
HDD 6
SAS3
HDD 8
SATA3
Description
No.
8
9
2 14 3
56
7
SNK-P0047PSC (for CPU1)
SNK-P0047PS (for CPU2)
1
73
BIOS Error Beep Codes
Processors and their Corresponding Memory Modules
seludoMMMIDgnidnopserroC#UPC
CPU 1 P1-
DIMMA1
P1-
DIMMA2
P1-
DIMMB1
P1-
DIMMB2
P1-
DIMMC1
P1-
DIMMC2
P1-
DIMMD1
P1-
DIMMD2
CPU2 P2-
DIMME1
P2-
DIMME2
P2-
DIMMF1
P2-
DIMMF2
P2-
DIMMG1
P2-
DIMMG2
P2-
DIMMH1
P2-
DIMMH2
Processor and Memory Module Population for Optimal Performance
Number of
CPUs+DIMMs CPU and Memory Population Configuration Table
1 CPU &
2 DIMMs
CPU1
P1-DIMMA1/P1-DIMMB1
1 CPU &
4 DIMMs
CPU1
P1-DIMMA1/P1-DIMMB1, P1-DIMMC1/P1-DIMMD1
1 CPU &
5~8 DIMMs
CPU1
P1-DIMMA1/P1-DIMMB1, P1-DIMMC1/P1-DIMMD1 + Any memory pairs in P1-
DIMMA2/P1-DIMMB2/P1-DIMMC2/P1-DIMMD2 slots
2 CPUs &
4 DIMMs
CPU1 + CPU2
P1-DIMMA1/P1-DIMMB1, P2-DIMME1/P2-DIMMF1
2 CPUs &
6 DIMMs
CPU1 + CPU2
P1-DIMMA1/P1-DIMMB1/P1-DIMMC1/P1-DIMMD1, P2-DIMME1/P2-DIMMF1
2 CPUs &
8 DIMMs
CPU1 + CPU2
P1-DIMMA1/P1-DIMMB1/P1-DIMMC1/P1-DIMMD1, P2-DIMME1/P2-DIMMF1/P2-
DIMMG1/P2-DIMMH1
2 CPUs &
10~16 DIMMs
CPU1/CPU2
P1-DIMMA1/P1-DIMMB1/P1-DIMMC1/P1-DIMMD1, P2-DIMME1/P2-DIMMF1/P2-
DIMMG1/P2-DIMMH1 + Any memory pairs in P1, P2 DIMM slots
2 CPUs &
16 DIMMs
CPU1/CPU2
P1-DIMMA1/P1-DIMMB1/P1-DIMMC1/P1-DIMMD1, P2-DIMME1/P2-DIMMF1/P2-DIM-
MG1/P2-DIMMH1,P1-DIMMA2/P1-DIMMB2/P1-DIMMC2/P1-DIMMD2, P2-DIMME2/
P2-DIMMF2/P2-DIMMG2/P2-DIMMH2
JIPMB1
JBP-I2C1
JBAT1
JSTBY1
JSD1
I-SATA3 I-SATA2
JPW1
JPW3 JPW2
FANB
FANA
FAN4
FAN3
FAN2
FAN1
BIOS
LED3
LED2
SP1
I-SATA0I-SATA1
JTPM1
JD1
JOH1
JL1
JF1
JBT1
X9DRW-CF31
JPL1
JWD1
JI2C1
JI2C2
JPB1
JPG1
J30
JPME2
JPME1
JPI2C1
IPMI_LAN
USB4/5
AOM PCIE 3.0 X16
SXB1A
SXB2:CPU2 PCI-E 3.0 X16
SXB1B
CPU1/CPU2 PCI-E 3.0 X16+X16
SXB1C
ALWAYS POPULATE DIMMx1 FIRST
P1-DIMMC2
P1-DIMMC1
P1-DIMMD2
P1-DIMMD1
UID
P2-DIMME1
P2-DIMME2
P2-DIMMF1
P2-DIMMF2
LAN2 LAN1
P1-DIMMA2
P1-DIMMB1
P1-DIMMB2
ALWAYS POPULATE DIMMx1 FIRST
P1-DIMMA1
USB2/3 USB0/1
P2-DIMMG2
P2-DIMMH1
P2-DIMMG1
VGA
COM1
DM1
P2-DIMMH2
CLOSE 1st
OPEN 1st
CLOSE 1st
OPEN 1st
ALWAYS POPULATE DIMMx1 FIRST
T-SGPIO1
FP CTRL
PCH
Intel CPU1
CPU2
BMC
LAN
i350 (-CF31)
X540 (-CTF31)
12 11 10 98
13
17
16
14
15
1
2
3
4
5
6
7
8
1 beep
5 short beeps + 1 long beep
5 beeps
Refresh Ready to boot
Memory Error No memory detected in the system
No Con-In or
No Con-Out devices
Con-In: USB or PS/2 keyboard, PCI or Serial
Console Redirection, IPMI KVM or SOL
Con-Out: Video Controller, PCI or Serial Console
Redirection, IPMI SOL
Beep Code/LED Error Message Description
2
8
4
5
6
PCI-E 3.0 x8 Expansion Slot (FH, 6.6”L)
N/A
UID Button (Unit Identifier Button)
LAN1 & LAN2 (1GbE for WC1R. 10GbE for WC1RT)
USB 2.0 Ports
VGA Port
Redundant Power Supply Module
Dedicated LAN for IPMI
Top View of DDR3 Slot
Release Tab Release Tab
Note: Notch should align
with the receptive key
point on the slot.
NotchNotch
Front View
ÌMNL-1534-QRGrÎ
