Supermicro SUPERSERVER 5018A-MHN4 User manual

SUPER
SUPERSERVER
5018A-MHN4
Revision 1.0
®

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of this
manual, please see our web site at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product
described in this manual at any time and without notice. This product, including software and docu-
mentation, is the property of Supermicro and/or its licensors, and is supplied only under a license.
Any use or reproduction of this product is not allowed, except as expressly permitted by the terms
of said license.
IN NO EVENT WILLSUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO
USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY
HARDWARE, SOFTWARE, OR DATASTORED OR USED WITH THE PRODUCT, INCLUDING THE
COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH
HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall
be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all
claims will not exceed the price paid for the hardware product.
FCC Statement: This equipment has been tested and found to comply with the limits for a Class A
digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial environ-
ment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the manufacturer’s instruction manual, may cause harmful interference
with radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference, in which case you will be required to correct the interference at your own expense.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warn-
ing applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”
WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to the
State of California to cause birth defects and other repro-
ductive harm.
Manual Revision 1.0
Release Date: February 19, 2014
Unless you request and receive written permission from Super Micro Computer, Inc., you may not
copy any part of this document.
Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.
Copyright © 2014 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America

Preface
About This Manual
This manual is written for professional system integrators and PC technicians. It
provides information for the installation and use of the SuperServer 5018A-MHN4.
Installation and maintenance should be performed by experienced technicians only.
The SuperServer 5018A-MHN4 is a 1U rackmount server based on the SC813MTQ-
202CB server chassis and the Super A1SRM-2758F motherboard. Please refer to
our web site for updates on supported processors.
Manual Organization
Chapter 1: Introduction
The first chapter provides a checklist of the main components included with the
server system and describes the main features of the Super A1SRM-2758F moth-
erboard and the SC813MTQ-202CB chassis.
Chapter 2: Server Installation
This chapter describes the steps necessary to install the SuperServer 5018A-MHN4
into a rack and check out the server configuration prior to powering up the system.
If your server was ordered without the processor and memory components, this
chapter will refer you to the appropriate sections of the manual for their installation.
Chapter 3: System Interface
Refer to this chapter for details on the system interface, which includes the functions
and information provided by the control panel on the chassis as well as other LEDs
located throughout the system.
Chapter 4: Standardized Warning Statements
You should thoroughly familiarize yourself with this chapter for a general overview
of safety precautions that should be followed when installing and servicing the
SuperServer 5018A-MHN4.
iii
Preface

SUPERSERVER 5018A-MHN4 User's Manual
iv
Chapter 5: Advanced Motherboard Setup
Chapter 5 provides detailed information on the A1SRM-2758F motherboard, in-
cluding the locations and functions of connectors, headers and jumpers. Refer to
this chapter when adding or removing main memory and when reconfiguring the
motherboard.
Chapter 6: Advanced Chassis Setup
Refer to Chapter 6 for detailed information on the SC813MTQ-202CB chassis.
You should follow the procedures given in this chapter when installing, removing
or reconfiguring Serial ATA or peripheral drives and when replacing system power
supply units and cooling fans.
Chapter 7: BIOS
The BIOS chapter includes an introduction to BIOS and provides detailed informa-
tion on running the CMOS Setup Utility.
Appendix A: BIOS POST Error Codes
Appendix B: System Specifications

v
Preface
Notes

vi
SUPERSERVER 5018A-MHN4 User's Manual
Table of Contents
Chapter 1 Introduction
1-1 Overview .........................................................................................................1-1
1-2 Motherboard Features.....................................................................................1-2
Processors ......................................................................................................1-2
Memory ...........................................................................................................1-2
SATA................................................................................................................1-2
PCI Expansion Slots....................................................................................... 1-2
I/O Ports..........................................................................................................1-2
1-3 Server Chassis Features ................................................................................1-3
System Power................................................................................................. 1-3
SATA Subsystem.............................................................................................1-3
Control Panel .................................................................................................. 1-3
Cooling System............................................................................................... 1-3
1-4 Contacting Supermicro....................................................................................1-5
Chapter 2 Server Installation
2-1 Overview .........................................................................................................2-1
2-2 Unpacking the System....................................................................................2-1
2-3 Preparing for Setup.........................................................................................2-1
Choosing a Setup Location............................................................................. 2-1
2-4 Warnings and Precautions.............................................................................. 2-2
Rack Precautions............................................................................................ 2-2
Server Precautions..........................................................................................2-2
Rack Mounting Considerations....................................................................... 2-3
Ambient Operating Temperature................................................................2-3
Reduced Airflow .........................................................................................2-3
Mechanical Loading ................................................................................... 2-3
Circuit Overloading.....................................................................................2-3
Reliable Ground ......................................................................................... 2-3
2-5 Installing the System into a Rack ...................................................................2-4
Identifying the Sections of the Rack Rails......................................................2-4
Installing the Rear Inner Rails ........................................................................2-4
Installing the Rack Rails .................................................................................2-5
Installing the Server into the Rack.................................................................. 2-6
Installing the Server into a Telco Rack...........................................................2-7

vii
Table of Contents
Chapter 3 System Interface
3-1 Overview .........................................................................................................3-1
3-2 Control Panel Buttons..................................................................................... 3-1
Reset...............................................................................................................3-1
Power..............................................................................................................3-1
3-3 Control Panel LEDs ........................................................................................3-2
Information LED.............................................................................................. 3-2
NIC2................................................................................................................3-2
NIC1................................................................................................................3-3
HDD................................................................................................................. 3-3
Power..............................................................................................................3-3
3-4 SATA Drive Carrier LEDs................................................................................3-3
Chapter 4 Standardized Warning Statements for AC Systems
4-1 About Standardized Warning Statements.......................................................4-1
Warning Definition...........................................................................................4-1
Installation Instructions.................................................................................... 4-4
Circuit Breaker ................................................................................................ 4-5
Power Disconnection Warning........................................................................4-6
Equipment Installation.....................................................................................4-8
Restricted Area................................................................................................ 4-9
Battery Handling............................................................................................ 4-10
Redundant Power Supplies .......................................................................... 4-12
Backplane Voltage ........................................................................................ 4-13
Comply with Local and National Electrical Codes........................................ 4-14
Product Disposal........................................................................................... 4-15
Hot Swap Fan Warning.................................................................................4-16
Power Cable and AC Adapter ...................................................................... 4-18
Chapter 5 Advanced Motherboard Setup
5-1 Handling the Motherboard ..............................................................................5-1
Precautions .....................................................................................................5-1
Unpacking .......................................................................................................5-2
5-2 Motherboard Installation..................................................................................5-2
5-3 Connecting Cables..........................................................................................5-3
Connecting Data Cables.................................................................................5-3
Connecting Power Cables .............................................................................. 5-3
Connecting the Control Panel......................................................................... 5-3
5-4 Rear I/O Ports................................................................................................. 5-4
5-5 Onboard Processor and Heatsink................................................................... 5-5

viii
SUPERSERVER 5018A-MHN4 User's Manual
5-6 Installing Memory Modules.............................................................................5-5
Installing & Removing DIMMs......................................................................... 5-5
Memory Support.........................................................................................5-6
Memory Population Guidelines....................................................................... 5-6
5-7 Adding PCI Cards........................................................................................... 5-7
5-8 Motherboard Details........................................................................................ 5-8
Motherboard Layout........................................................................................ 5-8
A1SRM-2758F Quick Reference Table........................................................... 5-8
5-9 Connector Definitions ...................................................................................5-10
ATX Power Connector..............................................................................5-10
Power Button ........................................................................................... 5-10
Reset Button............................................................................................. 5-10
Power Fail LED........................................................................................ 5-10
Overheat (OH)/Fan Fail/PWR Fail/UID LED.............................................5-11
NIC2 (LAN2) LED......................................................................................5-11
HDD LED...................................................................................................5-11
Power On LED..........................................................................................5-11
NMI Button ............................................................................................... 5-12
Fan Headers............................................................................................. 5-12
Chassis Intrusion......................................................................................5-12
Universal Serial Bus (USB)...................................................................... 5-12
Serial Ports...............................................................................................5-13
Power SMB (I2C) Connector .................................................................... 5-13
Onboard Speaker (SP1)........................................................................... 5-13
Power LED/Speaker................................................................................. 5-13
DOM Power Connector............................................................................ 5-14
TPM/Port 80 Header................................................................................ 5-14
Overheat LED/Fan Fail ............................................................................5-14
LAN3/LAN4 LED Indication Header.........................................................5-14
LAN (Ethernet) Ports................................................................................ 5-15
Unit Identifier Switch/UID LED Indicators ................................................5-15
System Management Bus Header...........................................................5-16
Standby Power......................................................................................... 5-16
Overheat LED Header.............................................................................. 5-16
5-10 Jumper Settings............................................................................................ 5-17
Explanation of Jumpers ................................................................................5-17
CMOS Clear............................................................................................. 5-17
LAN1/LAN2 Enable/Disable.....................................................................5-17
VGA Enable/Disable................................................................................. 5-18

Table of Contents
ix
Watch Dog................................................................................................ 5-18
BMC Enable ............................................................................................5-18
PCI-E Slot SMB Enable........................................................................... 5-18
BIOS Recovery Enable............................................................................ 5-19
USB Wake-Up Enable..............................................................................5-19
5-11 Onboard Indicators........................................................................................5-19
LAN Port LEDs.........................................................................................5-19
IPMI Dedicated LAN LEDs....................................................................... 5-19
Onboard Power LED ............................................................................... 5-20
Overheat/PWR Fail/Fan Fail LED............................................................ 5-20
Unit Identification LED..............................................................................5-20
5-12 SATA Ports....................................................................................................5-21
SATA Ports ............................................................................................... 5-21
5-13 Installing Software.........................................................................................5-22
SuperDoctor® 5 ............................................................................................ 5-23
5-14 Onboard Battery............................................................................................5-24
Chapter 6 Advanced Chassis Setup
6-1 Static-Sensitive Devices..................................................................................6-1
Precautions .....................................................................................................6-1
Unpacking .......................................................................................................6-1
6-2 Control Panel .................................................................................................. 6-2
6-3 System Fans................................................................................................... 6-3
6-4 Drive Bay Installation/Removal....................................................................... 6-3
Removing the Front Bezel..............................................................................6-3
SATA Drive Installation.................................................................................... 6-4
Accessing the Drive Bays...............................................................................6-4
SATA Backplane..............................................................................................6-5
6-5 Power Supply.................................................................................................. 6-7
Power Supply Failure...................................................................................... 6-7
Chapter 7 BIOS
7-1 Introduction...................................................................................................... 7-1
Starting BIOS Setup Utility..............................................................................7-1
How To Change the Configuration Data......................................................... 7-1
How to Start the Setup Utility .........................................................................7-2
7-2 Main Setup...................................................................................................... 7-2
7-3 Advanced Setup Configurations......................................................................7-4
7-4 IPMI Configuration ........................................................................................7-20
7-4 Event Logs....................................................................................................7-22
7-5 Security Settings........................................................................................... 7-24

x
SUPERSERVER 5018A-MHN4 User's Manual
7-6 Boot Settings.................................................................................................7-27
7-7 Save & Exit ................................................................................................... 7-29
Appendix A BIOS Post Error Codes
Appendix B System Specifications

Chapter 1
Introduction
1-1 Overview
The SuperServer 5018A-MHN4 is comprised of two main subsystems: the SC-
813MTQ-202CB 1U chassis and the A1SRM-2758F motherboard. Please refer to
our web site for information on operating systems that have been certified for use
with the SuperServer 5018A-MHN4 (www.supermicro.com).
In addition to the motherboard and chassis, various hardware components have
been included with the system, as listed below:
• One PCI-Express x8 riser card (RSC-RR1U-E8)
• SATA Accessories
One SAS/SATA backplane (BPN-SAS-815TQ)
Four 3.5" hard disk trays (MCP-220-00093-0B)
• One SuperServer 5018A-MHN4 Quick Reference Guide
Note: For your system to work properly, please follow the links below to download
all necessary drivers/utilities and the user’s manual for your server.
• Supermicro product manuals: http://www.supermicro.com/support/manuals/
• Product drivers and utilities: ftp://ftp.supermicro.com
• Product safety info: http://super-dev/about/policies/safety_information.cfm
• If you have any questions, please contact our support team at:
[email protected]
Chapter 1: Introduction
1-1

1-2
SUPERSERVER 5018A-MHN4 User's Manual
1-2 Motherboard Features
At the heart of the SuperServer 5018A-MHN4 lies the A1SRM-2758F, an embed-
ded processor motherboard. The A1SRM Series motherboard supports Intel®
QuickAssist Technology to enhance network routing and Internet security for com-
munications systems.
Below are the main features of the A1SRM-2758F. See Figure 1-1 for a block
diagram of the motherboard.
Processors
TheA1SRM-2758F supports a single Intel® C2000 Tri-Gate 22nm SoC (System-on-
a Chip) Series 8-core processor in an FCBGA1283 package (embedded processor).
Memory
The A1SRM-2758F has four DIMM slots that can support up to 32GB of DDR3-
1600/1333/1066/800 Unbuffered (UDIMM) ECC/Non-ECC memory. DIMMs of the
same size and speed should be used. See Chapter 5 for details.
SATA
A SATA controller is integrated into the chipset to provide a six-port Serial ATA sub-
system (4x SATA 2.0 and 2x SATA 3.0 ports). The SATA drives are hot-swappable
units.
A SATA DOM (Disk on Module) is supported on the motherboard. Insert a DOM
device to a SATA port and connect it to the power connector at JSD1 to use.
PCI Expansion Slots
The motherboard includes one PCI-Express 2.0 x8 and one PCI-Express 2.0 x4
slot. The system supports one PCI-Express 2.0 x8 card with the use of the installed
riser card.
I/O Ports
The I/O ports include a COM port, a VGA port, four USB 2.0 ports, four Gb LAN
(NIC) ports and a dedicated IPMI LAN port.

1-3
Chapter 1: Introduction
1-3 Server Chassis Features
The following is a general outline of the main features of the SC813MTQ-202CB
chassis.
System Power
When configured as a SuperServer 5018A-MHN4, the SC813MTQ-202CB chassis
includes a single 200W power supply.
SATA Subsystem
The SC813MTQ-202CB chassis was designed to support four SATA hard drives,
which are hot-swappable units.
Control Panel
The SC813MTQ-202CB's control panel provides important system monitoring and
control information. LEDs indicate power on, network activity, hard disk drive activ-
ity and system overheat conditions. The control panel also includes a main power
button and a system reset button.
Cooling System
The SC813MTQ-202CB chassis has an innovative cooling design that features two
4-cm high-performance system cooling fans. Each of these fans plug into a chassis
fan header on the motherboard. Fan speed is controlled by IPMI. Note that these
fans are not hot-swappable.

1-4
SUPERSERVER 5018A-MHN4 User's Manual
Figure 1-1. A1SRM-2758F Motherboard:
System Block Diagram
Note: This is a general block diagram. Please see Chapter 5 for details.
PEG [8..15]
LPC
TPM HDR
REAR
AVOTON SOC
VGA
FAN x 3
PEG [0]
AST2400
PCIE x 1
COM1 COM2
RJ45
RTL8211E
GbE LAN
USB 2.0
REAR
REAR
USB 0
USB [2:3]
TX/RX
(debug)
0Ohm
LPC
UART1 UART2
SGMII x 4 88E1543
10BASE-T/100BASE-T/1000BASE-T
LAN1
LAN3 LAN2
LAN4
+
SATA 3.0
SATA 2.0
SATA GEN2
SATA 3.0
SATA GEN3
SATA 2.0 SATA 2.0 SATA 2.0
PEG [4..7]
REAR
USB Hub
PD720114
+
CHA CHA
DIMMB2
DIMMB1
B1B2
DIMMA1
DIMMA2
FLASH 128Mb
SPI
PCIE 2.0 x 8 SLOT
PCIE x 8
PCIE 2.0 x 4 SLOT
PCIE 2.0 x 4 SLOT
PCIE x 4
USB 1
USB 2.0
USB Hub
PD720114
USB 2.0
TYPE-A
USB
HEADER
+
REAR REAR
A1
A2
CHB CHB
USB 2.0
NI
JPCIE1
JPCIE2
(Optional)
JPCIE3
Rangeley

1-5
Chapter 1: Introduction
1-4 Contacting Supermicro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
Web Site: www.supermicro.com
Europe
Address: Super Micro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
[email protected] (Customer Support)
Asia-Pacific
Address: Super Micro Computer, Inc.
4F, No. 232-1, Liancheng Rd
Chung-Ho Dist., New Taipei City 235
Taiwan
Tel: [phone]
Fax: [phone]
Web Site: www.supermicro.com.tw
Technical Support:
Email: [email protected]
Tel: [phone]

1-6
SUPERSERVER 5018A-MHN4 User's Manual
Notes

Chapter 2: Server Installation
2-1
Chapter 2
Server Installation
2-1 Overview
This chapter provides a quick setup checklist to get your SuperServer 5018A-MHN4
up and running. Following the steps in the order given should enable you to have
the system operational within a minimal amount of time. This quick setup assumes
that your system has come to you with the processor and memory preinstalled. If
your system is not already fully integrated with a motherboard, processor, system
memory etc., please turn to the chapter or section noted in each step for details on
installing specific components.
2-2 Unpacking the System
You should inspect the box the server was shipped in and note if it was damaged
in any way. If the server itself shows damage, you should file a damage claim with
the carrier who delivered it.
Decide on a suitable location for the rack unit that will hold the server. It should
be situated in a clean, dust-free area that is well ventilated. Avoid areas where
heat, electrical noise and electromagnetic fields are generated. You will also need
it placed near a grounded power outlet. Read the Rack and Server Precautions in
the next section.
2-3 Preparing for Setup
The box the SuperServer 5018A-MHN4 was shipped in should include two sets of
rail assemblies, six rail mounting brackets and the mounting screws you will need to
install the system into the rack. Follow the steps in the order given to complete the
installation process in a minimal amount of time. Please read this section in its en-
tirety before you begin the installation procedure outlined in the sections that follow.
Choosing a Setup Location
• Leave enough clearance in front of the rack to enable you to open the front door
completely (~25 inches) and approximately 30 inches of clearance in the back
of the rack to allow for sufficient airflow and ease in servicing.This product is for

2-2
SUPERSERVER 5018A-MHN4 User's Manual
installation only in a Restricted Access Location (dedicated equipment rooms,
service closets and the like).
• This product is not suitable for use with visual display work place devices
acccording to §2 of the the German Ordinance for Work with Visual Display
Units.
2-4 Warnings and Precautions
Rack Precautions
• Ensure that the leveling jacks on the bottom of the rack are fully extended to
the floor with the full weight of the rack resting on them.
• In single rack installation, stabilizers should be attached to the rack. In multiple
rack installations, the racks should be coupled together.
• Always make sure the rack is stable before extending a component from the
rack.
• You should extend only one component at a time - extending two or more si-
multaneously may cause the rack to become unstable.
Server Precautions
• Review the electrical and general safety precautions in Chapter 4.
• Determine the placement of each component in the rack before you install the
rails.
• Install the heaviest server components on the bottom of the rack first, and then
work up.
• Use a regulating uninterruptible power supply (UPS) to protect the server from
power surges, voltage spikes and to keep your system operating in case of a
power failure.
• Allow the hot plug SATA drives and power supply modules to cool before touch-
ing them.
• Always keep the rack's front door and all panels and components on the servers
closed when not servicing to maintain proper cooling.

Chapter 2: Server Installation
2-3
Rack Mounting Considerations
Ambient Operating Temperature
If installed in a closed or multi-unit rack assembly, the ambient operating tempera-
ture of the rack environment may be greater than the ambient temperature of the
room. Therefore, consideration should be given to installing the equipment in an
environment compatible with the manufacturer’s maximum rated ambient tempera-
ture (Tmra).
Reduced Airflow
Equipment should be mounted into a rack so that the amount of airflow required
for safe operation is not compromised.
Mechanical Loading
Equipment should be mounted into a rack so that a hazardous condition does not
arise due to uneven mechanical loading.
Circuit Overloading
Consideration should be given to the connection of the equipment to the power
supply circuitry and the effect that any possible overloading of circuits might have
on overcurrent protection and power supply wiring. Appropriate consideration of
equipment nameplate ratings should be used when addressing this concern.
Reliable Ground
A reliable ground must be maintained at all times. To ensure this, the rack itself
should be grounded. Particular attention should be given to power supply connec-
tions other than the direct connections to the branch circuit (i.e. the use of power
strips, etc.).

2-4
SUPERSERVER 5018A-MHN4 User's Manual
2-5 Installing the System into a Rack
This section provides information on installing the SuperServer 5018A-MHN4 into a
rack unit with the rack rails provided. If the server has already been mounted into
a rack, you can skip ahead to Sections 2-5 and 2-6.
There are a variety of rack units on the market, which may mean the assembly
procedure will differ slightly. You should also refer to the installation instructions that
came with the rack unit you are using.
Identifying the Sections of the Rack Rails
You may have received rack rail hardware with the server. (Two front inner rails
should already be attached to the chassis.) This hardware consists of two rear inner
rails that secure to the chassis, one on each side just behind the preinstalled front
inner rails. Note that these two rails are left/right specific.
Installing the Rear Inner Rails
First, locate the right rear inner rail (the rail that will be used on the right side of
the chassis when you face the front of the chassis). Align the two square holes on
the rail against the hooks on the right side of the chassis. Securely attach the rail
to the chassis with M4 flat head screws. Repeat these steps to install the left rear
inner rail to the left side of the chassis (see Figure 2-1). You will also need to attach
the rail brackets when installing into a telco rack.
Locking Tabs: Both chassis rails have a locking tab, which serves two functions.
The first is to lock the server into place when installed and pushed fully into the
rack, which is its normal position. Secondly, these tabs also lock the server in place
when fully extended from the rack. This prevents the server from coming completely
out of the rack when you pull it out for servicing.
